Intratone 07-0105-EN Quick start guide

Wiring diagram – 07-0105-EN (EEN-PARK1-A)
Page 1 / 2 EN-V234-0011-AA
W IRING D IAGRAM – HF RECEIVER 07-0105-EN ( EEN - PARK 1- A )
Power supply
12-24V AC/ DC
100 mA
+
-
2
1
AER.
With aerial
868 MHz
Core
Braid
Opening delay:
1 second
.
Stand-alone receiver with built-in aerial
No anti-passback.
No more than 10 INTRATONE remote controls :
Pushbutton
LEDs
HF aerial optional
Relay:
Never connect the relay’s CT
terminals directly to power supply.
This relay provides a dry contact
designed to be connected to a
pushbutton input on the device.
Dry contact to
Device

Wiring diagram – 07-0105-EN (EEN-PARK1-A)
Page 2 / 2 EN-V234-0011-AA
A DDITIONAL INFORMATION
LEDSPUSHBUTTON (PB)
Operation Meaning
Normal 1 flash every 2 sec.
Detecting Solid light for 10 sec.
HF Detection 3 quick flashes.
Opening Lit for 1 second
Mode Explanations
Detecting Press PB once
The LED lights up:
Enter detection mode.
Pass over with remote controls
HF Detection:
Detecting remote controls.
Press PB once
The LED does not stay lit:
Exit detection mode.
Reset Press and hold PB for 3 sec.
LED flashes quickly:
For 10 sec, awaiting reset
confirmation.
Press PB once
Reset confirmation:
All remote controls are deleted
from receiver.
