Intuis HRC70 tri V User manual

Made in
France
Installation and User manual
HRC70 tri V
High temperature, modulating
Heat Pump
HRC70 40kW tri V
Ref. 151475
HRC70 60kW tri V
Ref. 151485
HRC70 80kW tri V
Ref. 151495
Manual ref. : 1898893
Edition n°: 23.49
The information contained in this document is non-contractual. We reserves the right to modify the technical specifications or characterisitcs of any of their appliances without prior notice.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
2

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 3
TABLE OF CONTENTS
1  PLEASE READ IMMEDIATELY ....................... 4
1.1 - Important information.......................................................................4
1.2 - Safety advice and instructions........................................................4
1.3 - Symbols used........................................................................................5
1.4 - Abbreviations and acronyms...........................................................5
1.5 - Rating plate............................................................................................6
1.6 - Delivery terms and conditions........................................................7
1.7 - Storage and transport........................................................................7
1.7.1 - General information ................................................................................................7
1.7.2 - Transporting with a forklift truck ........................................................................ 8
2  INTRODUCTION............................................. 9
2.1 - Standard conguration .....................................................................9
2.2 - Operation................................................................................................9
3  INSTALLATION.............................................. 10
3.1 - Installing the Heat Pump ................................................................10
3.1.1 - General.......................................................................................................................10
3.1.2 - Placement..................................................................................................................11
3.1.2.1 - Anti-vibration support - Rubber foot..............................................12
3.1.2.1.1 - Rubber foot for HRC70 40kW tri V..................................12
3.1.2.1.2 - Rubber foot for HRC70 80kW tri V..................................13
3.1.2.2 - Anti-vibration support - Spring ........................................................14
3.1.2.2.1 - Rubber foot for HRC70 40kW tri V..................................14
3.1.2.2.2 - Rubber foot for HRC70 80kW tri V..................................15
3.1.3 - Noise levels...............................................................................................................16
3.1.4 - Condensates drainage..........................................................................................17
3.2 - Hydraulic installation........................................................................17
3.2.1 - Hydraulic connections on the installation ....................................................17
3.2.2 - Sizing of the Heat Pump circuit.........................................................................17
3.2.3 - Pressure-relief valves.............................................................................................17
3.2.4 - Heat Pump water inlet lter (supplied) ..........................................................18
3.2.5 - Back-ow prevention device..............................................................................18
3.2.6 - Purging the heating circuit(s)..............................................................................18
3.2.7 - Insulating the piping.............................................................................................18
3.2.8 - Expansion vessel.....................................................................................................18
3.2.9 - Frost protection and water treatment ......................................................................18
3.3 - Electrical control connections.......................................................19
3.4 - Connecting to the power supply.................................................19
3.4.1 - Proximity switch......................................................................................................20
3.4.2 - Recommendations for connecting the system to the power supply..20
3.4.3 - Connecting the heat Pump to the power supply.......................................20
3.4.4. - HRC70 Heat pump: 400V three-phase connection........................................ 24
3.4.5 - Electrical protection of the compressors.......................................................25
3.5 - Aeraulics and ducted heat pumps...............................................25
4  MAINTENANCE AND TROUBLESHOOTING26
4.1 - General information .........................................................................26
4.2 - Maintenance on the hydraulic circuit.........................................26
4.3 - Maintenance on the heat pump ..................................................26
4.4 - Maintenance of the electrical components .............................26
4.5 - Decommissioning and disposal ...................................................26
4.6 - Compressor start-up faults.............................................................27
5  LIST OF SPARE PARTS .................................. 28
5.1 - HRC70 heat pump................................................................................28
5.2 - Electrical boxes...................................................................................30
6  WARRANTY ................................................... 31
6.1 - Limitations of warranty....................................................................31
6.1.1 - General information ..............................................................................................31
6.1.2 - Cases (not limited to) for exclusion from warranty ....................................31
6.1.2.1 - Water from the heating circuit ..........................................................31
6.1.2.2 - Handling....................................................................................................31
6.1.2.3 - Placement.................................................................................................31
6.1.2.4 - Electrical connections ..........................................................................31
6.1.2.5 - Hydraulic connections .........................................................................31
6.1.2.6 - Accessories...............................................................................................31
6.1.2.7 - Maintenance............................................................................................31
APPENDICES...................................................... 32
A1 - Dimensions...........................................................................................32
A1.1 - HRC70 40kW tri V heat pump dimensions.......................................................32
A1.2 - HRC70 80kW tri V heat pump dimensions.......................................................32
A1.3 - Appliance connections ........................................................................................33
A2 - Technical specications....................................................................33
A2.1 - General characteristics..........................................................................................33
A2.2 - Performances...........................................................................................................34
A3 - EU declaration .....................................................................................34
A4 - Frost protection ..................................................................................34
A5 - Treatment of the water in the heating circuit..........................35
A5.1 - Preparation of the hydraulic circuit (rinsing).........................................................................35
A5.2 - Filling water..............................................................................................................35
A5.3 - Treatment of the heating circuit........................................................................35
A5.4 - Protection from freezing ......................................................................................35
A6 - Sizing the expansion vessel............................................................36
A7 - HRC70 40kW tri V heat pump internal wiring diagram ..........37
A8 - HRC70 80kW tri V heat pump internal wiring diagram ..........38
A9 - Product information sheet..............................................................39
A9.1 - HRC70 40 kW tri V product information sheet................................................39
A9.2 - HRC70 80 kW tri V product information sheet................................................40
A10 - Electricity provider information form.......................................41
A10.1 - Standard form, HRC70 40kW tri V heat pump..............................................41
A10.2 - Standard form, HRC70 80kW tri V unducted heat pump .........................42
A10.3 - Standard form, HRC70 80kW tri V ducted heat pump...............................43

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
4
1.1 - Important information
1 - PLEASE READ
IMMEDIATELY
These installation and operating instructions
form part of the appliances which they refer to.
In order for the warranty to be valid, they must
be read before using the appliance.
This manual must be safeguarded and passed
on to successive users for future reference.
It will be considered as evidence in case of
litigation.
•It is the responsibility of the installer
and of the client to ensure that the
appliance is compatible with the power grid
before connecting the HRC70 Heat Pump (see
the electricity provider information form in the
Appendix)
•The power grid impedance value must be less
than the Heat Pump impedance Zmax value (see §
«Connecting the HRC70 Heat Pump to the power
supply»).
•If the electrical installation standards are not
respected there could be irreversible damages
to the HRC70 Heat Pump which are not covered
by the manufacturer’s warranty.
RECOMMENDATIONS FOR
ELECTRICAL INSTALLATION
•Clean and ush the hydraulic heating
circuit before connecting the appliances
(Heat Pump and Pilot).
•The appliance only works when lled with
water. Never switch the appliance on if it is not
properly lled with water and purged of air.
•The lter valve ensures the protection of
the Heat Pump. An annual inspection of the
condition of the lter must be carried out.
•It is recommended to carry out periodic
inspections for sludge and limescale and to
clean when necessary. The appliance must
always be switched o before any cleaning is
undertaken.
•Always switch o the appliance before working
on any of theWWwelectrical components.
Caution: The fan may continue turning through
inertia even when the appliance is switched o.
Wait for the fan to stop before working on the
appliance.
•Never get water on the control components or
electrical parts. Always switch o the appliance
before cleaning.
RECOMMENDATIONS FOR
HYDRAULIC INSTALLATION
1.2 - Safety advice and instructions
• The Heat Pump must only be installed outside.
•This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or by persons
lacking experience or knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• Installation of the Heat Pump indoors is strictly
prohibited.
•The HeatPumpoperates usingan airtemperature
range of -20°C to 40°C. When the temperature
falls below -20°C, the installation no longer heats
using the Heat Pump, but using the back-up.
• It is FORBIDDEN :
- to operate the Heat Pump using air intake
containing solvents or explosive materials.
- to use air intake containing grease, dust, or
aerosol particles.
- to connect vented exhaust hoods to the
appliance.
• Use of the appliances are FORBIDDEN if the
installation is not lled with water.
• All work must be carried out by a qualified
professional with the appliance switched o.
• This appliance must be installed in accordance
with national electrical installation regulations.
Check that the appliance is equipped with
a properly sized and properly connected
grounding cable.
The high temperature Heat Pump absorbs the
calories present in exterior air, and transforms
them into useful energy which is then transferred
to the heating water for your home. We cannot
be held responsible for any other usage of the
appliance.
The safety advice and instructions present in this
document must be strictly respected.
Before making any connections to the installation,
make sure the appliances are compatible with the
installation.
Before switching on the appliance, check that the
network voltage to be applied to the appliance
is the same as the one on the rating plate of the
appliance.
Before undertaking any maintenance work,
handling, or in the case of the appliance not
functioning or malfunctioning, always disconnect
the appliance from the power supply and seek
advice from a technician or specialist.
We cannot be held liable for damages caused
by not following the instructions provided, nor
any problems or errors caused from improper
handling, improper installation, or misuse.
The installation and operating instructions are
subject to change without prior notice.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 5
DHW.......Domestic Hot Water
DCW .......Domestic Cold Water
T°..............Température
HP............Heat Pump
1.4 - Abbreviations and acronyms
This CE approved unit is in compliance with
the following standards:
- Low voltage 2006/95/CEE (standard EN
60.335.1).
- Electromagnetic compatibility 2004/108/CEE
(standard EN 55014.1 / EN 55014.2).
• Any work on the refrigerant circuit must be
carried out by a qualied professional with a
category 1 certicate of aptitude. The release
of refrigerant fluid into the atmosphere is
prohibited, the refrigerant fluid must be
recovered before any work is undertaken on the
refrigerant circuit.
The HRC70 Heat Pump uses R290 refrigerant uid.
Given the ammable nature of the uid, any
work on the refrigerant circuit must be done with
appropriate materials and by conforming to all
regulations in eect. In case of handling of uid
(recovery, evacuation or relling), the appliance
must be switched o. Do not smoke or light any
ame (e.g. lighter, blowtorch) when handling
refrigerant uid. if work must be carried out on
the refrigerant circuit using a ame (blowtorch)
the refrigerant circuit must rst be evacuated and
replaced with a nitrogen atmosphere.
• The appliance should be cleaned carefully so as
not to damage its electronics from the outside.
The use of a high pressure cleaner is PROHIBITED.
Identies important warnings and recommendations.
1.3 - Symbols used
Contains controlled substances, do not dispose of in
the garbage. In case of disposal, please respect the
regulations for the recovery of electrical and electronic
equipment.
Type and refrigerant charge.
PS High: Max high service pressure
PS Low: Max low service pressure
Heating capacity :
nom: nominal
max: maximal
Max current protection (A)
Caution : contains a ammable refrigerant uid.
Please make sure to respect the installation and
handling precautions.
Consult the installation manual before all work on the
product: handling, installation, use and maintenance.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
6
1.5 - Rating plate
Ser.n° : 151475-232600000
Hermétiquement scellé / Hermetically sealed
Made In France
HRC 40 tri V
70
Réf :
151475
AUER
Rue de la République
80210 Feuquières en Vimeu
Pompe à chaleur
1898774
430 kg
0082
R290 (groupe 1) : 3,200kg
PS High : 3,1MPa (31 bar)
PS Low : 1,7MPa (17 bar)
Ts min : -20°C
Ts max : +40°C
400V tri ~ 50Hz
Imax : 27A - Pmax : 16kW
Pnom* : 20,25kW
COP* : 4,64 (A7W35)
IPX4
P : 0,3MPa
(3 bar)
*Selon EN14511 / According to EN14511
PED cat. II
Manufacturer’s identity
Appliance identity
Serial number of the appliance
Appliance type
Certication agency
intuis reference of the appliance
Rating plate reference
Appliance weight
CE marking
Appliance electric data
PED’s category
According to 2014/68/UE Notied oragnisme
identifying
Protection rating
Reference of
the appliance
Year of
manufacture
2023
Week of
manufacture
Appliance
number in the
series
151475 - 23 26 00000
Serial number of the appliance
Maximum hydraulic system
pressure
P : 0,3MPa
(3 bar)
Pnom* : 20,25kW
COP* : 4,64 (A7W35)
Nomimal performances
According to EN 14511
Description
:
Refrigerant type/quantity
R290
(
groupe 1
)
: 3,200kg
PS High : 3,1MPa (31 bar)
PS Low : 1,7MPa (17 bar)
Ts min : -20°C
Ts max : +40°C
H
LOutside temperature limits
operating
Maximal pressure of the refrigerant
circuit
Note :
The rating plate shown above in the manual, corresponds to that of a HRC70 40kW tri V. Do not use this information for the HRC70 60 and 80kW
tri V. Please refer directly to the appliance’s rating plate.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 7
1.6 - Delivery terms and conditions
In general, the material is transported at the recipient’s own risk.
It is important to verify that all of the elements have been received and that no damage has been sustained during transport upon receipt of
the appliance and before beginning the installation procedures.
1.7 - Storage and transport
Admissible storage and transport temperatures of the appliance
are between -20°C and +60°C.
1.7.1 - General information
The appliances must be stored and transported packaged and
on their wooden pallets, in a vertical position, and completely
empty of water.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
8
1.7.2 - Transporting with a forklift truck
The forklift truck can only be transported through the opening on the
transport pallet (on the compressor side). It is important to maintain
a low lifting and moving speed, as the heat pump can easily lose its
balance due to the length of the product.
The heat pump can also be lifted using the four hooking holes located
at each corner of the heat pump.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 9
2.1 - Standard conguration
2 - INTRODUCTION
The ensemble is composed of an exterior unit (Mono-block high temperature Heat Pump to be installed outdoors exclusively) and of an
interior unit (Pilot, to be installed indoors exclusively) connected together through a hydraulic connection and a communication bus.
The air to water Heat Pump, draws calories from the exterior air and transfers them to the heating water circuit with high energy eciency.
The Pilot ensures the regulation and hydraulic distribution of the installation.
A circulator is built into the heat pump. It supplies water ow from the heat pump to the pilot.
The cylinder built into the pilot provides hydraulic decoupling between the heat pump and the heating circuit(s).
The Pilot is delivered pre-congured for the heating of a radiator circuit controlled by a room temperature thermostat from the Heat Pump alone.
In the case of connection to a back-up boiler, it is used to load the decoupling tank directly.
Nota :
The heat pump is designed to operate in heating mode. Operation in cooling mode is possible subject to compatibility with the pilot and the
heat emitters.
2.2 - Operation
The Heat Pump is a closed and pressurised system in which the
refrigerant serves as the medium for transferring energy.
A safety pressure switch is used on the refrigeration circuit, it is
located on the high pressure part of the circuit at the output of the
compressors. It is a dry contact that when the pressure becomes
too high (>31 bar) opens. Once opened, it cuts the power to the
compressors, independently of the electronics and thus protects
all circuit components.
The evaporator () is a cooling exchanger which draws calories
from the air.
The humidity in the air condenses on contact with the cold surface,
and forms condensation (evacuation in ()).
The condenser (), a plated ehat exchanger which is hydraulically
linked to the heating installation (), via the Pilot, enables to heat
the water in the heating circuit, and in turn enables the heating of
the building.
1112 22
3
4
5
6
7
8
Mid-season
only compressor (1)
is used,
the fan(6) operates at
speed 1.
In cold weather
only compressor (2)
is used,
the fan (6) operates at
speed 2.
In extreme cold
both compressors (1) and (2)
are used at the same time,
the fan (6) operates at
speed 3.
1 : Compressor 1
2 : Compressor 2
3 : Expansion valve
4 : Evaporator
5 : Condenser
6 : Fan
7 : Outlet / inlet towards heating
installation
8 : Condensates drainage

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
10
3 - INSTALLATION
3.1 - Installing the Heat Pump
The Heat Pump must always be transported in a vertical position,
including during installation.
Because of its heavy weight, it must be handled and transported
using suitable means.
Donothandletheunitbythehydraulicconnectionsorthevariouscovers.
Installation must be carried out by a qualied installer, taking all
necessary precautions to avoid any risk of accidents or of material
damage.
3.1.1 - General
The Heat Pump must be installed on a hard
and stable base, which is suciently raised
from ground level to avoid risks of damage in case
of ooding or snow.
Always make sure the heat exchanger ns are
protected when handling the appliance.
The Heat Pump must be handled with caution and without being
subjected to impacts, especially when placing on the ground.
•The Heat Pump is designed to be installed
OUTSIDE exclusively.
• Any installation in an ENCLOSED and
UNVENTILATED space is PROHIBITED, unless
there is ventilation which ensure at least 80% of the
nominal ow rate of the Heat Pump.
• DO NOT RESTRICT air intake or ventilation
exhaust. NO OBJECT should impede the ow of air
over the heat exchanger, or the renewal of air. The
Heat Pump should be placed OUT OF THE WAY OF
PREVAILING WINDS.
• DO NOT INSTALL the Heat Pump NEAR SOURCES
OF EXCESSIVE HEAT, COMBUSTIBLE MATERIALS,
OR NEAR VENTILATION POINTS of adjacent
buildings.
• DO NOT INSTALL the Heat Pump NEAR A
KITCHEN OR WORKSHOP exhaust ducts; this
can result in a mixture of oil and air settling onto
the heat exchanger ns which could hamper its
performance.
• DO NOT INSTALL the Heat Pump in an area with
FLAMMABLE GAS, ACIDIC SUBSTANCES, OR
ALKALINES which could cause irreversible damage
to the copper-aluminium heat exchanger.
• AVOID INSTALLING the Heat Pump in a location
subject to NOISE REVERBERATION such as near
windows or near the corners of buildings.
• As the condensates draining trough slopes
downward, the Heat Pump must be installed on a
LEVEL BASE.
• The HEAT PUMP must be EASILY ACCESSIBLE
so as to facilitate access for inspections and
maintenance.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 11
3.1.2 - Placement
The heat pump is designed to be installed exclusively outdoors, leaving a clear space around the appliance in an area free from excessive dust.
Under no circumstances should it be placed in a closed room without ventilation ensuring at least 80% of the heat pump’s ventilation output.
It is designed to operate in the rain, but can also be installed under a well-ventilated shelter (with a large opening to ensure air ow to the fan
intake and discharge).
In regards to the fan, the free space from any obstacles must be at least 1m.
Minimum distances to respect for proper installation of the HRC70
40kW heat pump: (mm) :
300*
150*
300*
The dimensions shown are the minimum distances recommended
for working on the product.
Dimensions marked with an asterisk «*» are the minimum
dimensions required for the system to operate correctly.
Minimum distances to respect for proper installation of the HRC70
60kW and HRC70 80kW heat pump: (mm) :

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
12
3.1.2.1 - Anti-vibration support - Rubber foot
Mounting on rubber foot kit :
The stringers are lengthwise (rubber foot kit length 600mm) - Ref. 754603.
3.1.2.1.1 - Rubber foot for HRC70 40kW tri V
)L[DWLRQ%LJIRRWORQJXHXU
)L[DWLRQ%LJIRRWORQJXHXU)L[DWLRQ%LJIRRWORQJXHXU
)L[DWLRQ%LJIRRWORQJXHXU

Rubber foot attachment
length 600mm
1140
Rubber foot attachment
length 600mm

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 13
Mounting on rubber foot kit :
3.1.2.1.2 - Rubber foot for HRC70 80kW tri V
)L[DWLRQVUXEEHUIRRW
)L[DWLRQVUXEEHUIRRW

The stringers are lengthwise (1000mm rubber foot kit) - Ref. 754604.
Rubber foot xings
Rubber foot xings

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
14
3.1.2.2 - Anti-vibration support - Spring
Mounting on spring kit - Ref. 754605 :
)L[DWLRQUHVVRUW
)L[DWLRQUHVVRUW
)L[DWLRQUHVVRUW
)L[DWLRQUHVVRUW


1140
1505
Spring xing
Spring xing
Spring xing
Spring xing
3.1.2.2.1 - Rubber foot for HRC70 40kW tri V
The kit includes four springs:
- 2 x EMCSFr30 : to be placed on the compressor side (see illustration below, in red);
- 2 x EMCSFr13 : to be placed on the fan side (see illustration below, in green).
The two reinforcements (see illustration below, dotted red ) supplied with the instructions must be tted
before the two springs on the compressor side are xed.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 15
Mounting on spring kit - Ref. 754606 :
3.1.2.2.2 - Rubber foot for HRC70 80kW tri V
The kit includes six indentical springs : EMCSFr22 (see illustration below, in fuchsia).
The two reinforcements (see illustration below, dotted red ) supplied with the instructions must be tted
before the two springs on the compressor side are xed.
)L[DWLRQVUHVVRUWV


Spring xing

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
16
3.1.3 - Noise levels
The Heat Pump is equipped with a large diameter fan so as to allow for an appropriate air ow rate. This ow rate can rise up to 12000m3/h for
the HRC70 40kW heat pump and the double that for the HRC70 80kW heat pump. The fan speed is adjustable to limit the noise level.
Depending on the installation conditions, the noise levels may be dierent, in particular if the walls closest to the Heat Pump cause a reverberation
and amplication of noise.
The diagrams below show dierent installation examples for dierent placements.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 17
3.2.1 - Hydraulic connections on the installation
In order to ensure that uids can circulate properly, it is advisable to
check that the sizing of piping in the circuit is appropriate between
the Heat Pump and the Pilot.
The HRC70 40/60/80kW Heat Pump is intended for with a large variety
of heating installations due to its power level.
The circulator(s) included in the heat pump provide the ow rate
required to transmit power to the pilot.
The connection between the heat pump and the pilot must be
sized to ensure the correct ow rate between these two elements.
3.2 - Hydraulic installation
It is MANDATORY to read the additional
document concerning the quality of
water used for lling the installation.This
document is included with this manual as well as
in the packet with the warranty information.
This document also contains information which is
PERTINENT to the WARRANTY of the material.
3.2.3 - Pressure-relief valves
The Heat Pump and the Pilot are both equipped with pressure-
relief valves.
The pressure-relief valve on the Heat Pump sets the maximum
acceptable pressure in the installation (3 bar when hot). The
maximum service pressure on the Heat Pump must, consequently
be lower than 3 bar.
Example : If the Heat Pump is positioned 5m below the Pilot, the
pressure reading on the Pilot would be 0.5 bars less than the
real pressure of the water in the Heat Pump. In this case, the
maximum service pressure for the Pilot would be 2,5 bar.
Therefore it would be advisable to ll the heating circuit at
an intermediary pressure (between 2 and 2.5 bar).
In case of operating with a back-up boiler, these pressure-relief
valves MUST be installed in addition to the ones which the boiler
is already equipped with (set at 3 bar).
The connections and the evacuation conduits for the pressure-relief
valves must be made from materials which are resistant to high
temperatures and corrosion.
3.2.2 - Sizing of the Heat Pump circuit
A sucient ow rate must be ensured so that the temperature
dierence between the ow and return of the heat pump does not
exceed 8°C during operation (carry out a test measurement when the
HRC70 heat pump is in heating mode and the operating mode is set):
The hydraulic cross-section of the connection between the heat
pump and the decoupling cylinder must be sucient. For this, refer
to the pilot part supplied with the heat pump.
Heat pump model 40kW 60kW 80kW
Minimum nominal ow rate 4700 L/h 7700 L/h 11000 L/h
Maximum pressure 3 bar 3 bar 3 bar
«Hydraulic sizing» in the installation manual
Nota :
Condensate must not run o into passageways (risk of freezing).
3.1.4 - Condensates drainage
The condensate drain for the HRC70 40kW-60kW-80kW is located
under the heat pump. A G1’’F connection is located in the centre of
the condensate tray. Condensate can drain freely or be connected
to a draining surface. In the latter case, ensure that the drain is kept
frost-free (optional defrosting cord - Ref. 751004).

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
18
3.2.5 - Back-ow prevention device
French law (articles 16.7 and 16.8 of the ‘‘Règlement Sanitaire
Départemental’’) stipulates that a type CA back-ow prevention
device must be installed. This device must be at dierent, non-
regulated pressure zones, in accordance with the NF EN 14367
standard. This is also an obligatory requirement in other countries,
which makes it important to verify the current laws and standards in
eect in the country of installation and ensure that your installation
is in compliance with them. The back-ow prevention device is
designed to prevent incoming heating water from entering the
drinking water circuit. It must be connected to the mains drainage
system.
3.2.6 - Purging the heating circuit(s)
All necessary measures must be taken to ensure that the installation
can be continuously degassed. Automatic air purging valves should
be placed at each high point of the installation, and manual air
purging valves should be installed on each radiator.
3.2.8 - Expansion vessel
An expansion vessel needs to be installed onto the heating circuit.
See Appendix A6 for information on proper sizing of the expansion
vessel.
3.2.9 - Frost protection and water treatment
See the recommendation in Annexes A4 and A5.
3.2.4 - Heat Pump water inlet lter (supplied)
A 500μm sieve lter (or two for HRC70 60 and 80kW tri V) is installed
in the heat pump.
• Do not change the connection direction.
• Observe the direction of ow of the lter (arrow).
• Clean the lter at least once a year (do not use tools that
could damage the sieve).
Before installing the heat pump, the system
must be de-silted and ushed.
Clean the lter several times when starting
up the heat pump circulators (take care to
stop the heat pump circulator when cleaning).
3.2.7 - Insulating the piping
Insulations must conform to the DTU 65.20 and the DTU 67.1
standard, or the current regulations in eect in the country of
installation.
All visible piping and accessories (circulator pump, expansion vessel,
valves, etc...) must be either insulated or placed in insulated sleeves.
Remember to insulate the distribution manifolds and the inlet and
outlet ow pipes to the underoor heating circuit.
Remember to insulate the piping which connects the Heat Pump
to the Pilot.

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL - 19
The rules and regulations in the country of installation MUST be respected (standard C15-100).
•The electrical lines for general power supply to the circuits must be made in compliance with your country’s
current rules and regulations (standard C15-100).
• Standard C15-100 determines the cable section to be used based on acceptable currents.
• Standard C15-100 determines the cable section to be used based on the following elements :
- Nature of the conductor :
. type of insulation, number of strands, etc...
- Installation mode :
. inuence of conductor and cable groups
. ambient temperature
. tightly or non-tightly installed
. length of cables, etc...
3.4 - Connecting to the power supply
Ensure that the power supply is sucient to supply both the Heat Pump and the electrical back-up if necessary, taking into account any other
domestic usage of electricity.
Connection to the power supply for each appliance must be done by a qualied professional with the mains power switched o.
3.3 - Electrical control connections
The Heat Pump is pre-equipped with a non-polarised, 2-core sheathed cable (communication bus). This 10m cable is supplied with, and
already connected to, the Heat Pump. It must be connected to the Pilot.
If the connection needed is longer than 10m replace this cable with a 20m cable which is available to order (Ref.753102).
If the connection needed is longer than 20m replace this cable with a 50m cable which is available to order (Ref.754103).
• Cut the bus link to the right length : LOOPS ARE FORBIDDEN.
A : Marron / Brown
GND : Noir / Black
B : Blanc / White
For heat pumps supplied with a ZéPAC pilot, a 50 metre bus cable is supplied with the pilot.
It is MANDATORY to connect the
shielding of the connection cable
on the terminal block «GND».

- INSTALLER HRC70 40KW60KW80KW TRI V HEAT PUMPS MANUAL -
20
3.4.3 - Connecting the heat Pump to the power
supply
•It is the responsibility of the installer and of the
clientto ensurethat theappliance iscompatible
with the power grid before connecting the
HRC70 Heat Pump (see the electricity provider
information form in the Appendix)
•If the electrical installation standards are not
respected there could be irreversible damages
to the HRC70 Heat Pump which are not covered
by the manufacturer’s warranty.
ELECTRICAL INSTALLATION
RECOMMENDATIONS
3.4.1 - Proximity switch
The HRC70 40/60/80kW heat pump is fitted with a proximity
switch. The heat pump is supplied with electricity by connecting
the four conductors to the switch (three phases + neutral).
The stripping length (or crimped end length) for this connection
is 12mm. Use a 6.5mm slotted screwdriver or Pozidriv 2. Each
conductor should be tightened to 4.5N.m. Once the conductors have
been connected, be sure to replace the terminal covers supplied.
• During transport, the electrical connections
may be subject to accidental loosening.
• To eliminate any risk of abnormal heating, it is
necessary to ensure the placement of the faston
type electrical connections are secure and tighten
the screw connections.
See § «Spare parts - electrical boxes»
Each appliance is delivered from the factory completely pre-wired.
However, it is necessary to connect the following elements to the
relevant terminals:
• The electrical supply of the power circuit for each appliance
separately : the Heat Pump.
• The 2-core sheathed (+ ground) connecting cable (10m length
supplied) between the Heat Pump and the Pilot.
Under no circumstances will the manufacturer be held liable for any
problems which may arise due to improper installation, choice of
power supply cable, or measures used for installation.
Note :
The wires must be stripped to the following lengths :
- for the 2,5mm² control terminals: between 10 and 12mm;
- for the mains power terminal between 18 and 20mm.
Terminal strips
Their terminal strips are spring-loaded «Cage Clamps».
For handling, use the following :
- for 2,5mm² control terminals power
terminals(tetra),usea 3,5x0,5mm at-head
screwdriver.
- for 10mm² mains power terminals
(single-phase), use a 5,5 x 0,8mm at-
head screwdriver.
1 : Insert the screwdriver into the ap just above or
below the identication number.
2 : Insert the wire into the «CAGE CLAMP» when
the ap is open.
3 : Remove the screwdriver.
pp
p
3.4.2 - Recommendations for connecting the
system to the power supply
Check :
• The power consumption
• Number and thickness of the power supply
cables
• Fuse or circuit breaker ratings
The power supply must come from an electrical protection and
sectioning device which complies with all current rules and
regulation in eect in the country of use.
This CE-approved unit complies with all the essential requirements
of the following directives:
- Low voltage n°2006/95/CE
- Electromagnetic compatibility n° 2004/108/CE
Ensure that the installation is equipped with a properly sized and
connected grounding cable.
Ensure that the voltage and frequency of the general power supply
ts requirements.
The acceptable variation in voltage is:
230 V +/- 10% 50Hz for single-phase models
400 V +/- 10% 50Hz for three-phase models
See Appendix A2 for components adapted to the heat
pump.
Ground
Neutral
400V three-phase
power supply
Tightening torque 4.5N.m
Ground
5G6mm² power cable
See § «Recommendations for power
connection».
fuse or thermal-magnetic
circuit breaker
