inveo NANO User manual

User manual
Nano RFID
Nano RFID PoE
Soft >= 0.37
User manual: Nano RFID / Nano RFID PoE Page 1 of 24
[ 01]

Dear Customer!
Thank you very much for choosing our product. efore its use, please read these
instructions carefully. Here you find the most appropriate ways of dealing with this
device, the basic principles of safety and maintenance. Please, also keep the user manual
so that you can read it during later use.
Attention!
The manufacturer is not liable for an damage caused b improper use of
the device which differ from its intended purpose, or improper handling, as well
as a fault of driver resulting from improper use.
User manual: Nano RFID / Nano RFID PoE Page 2 of 24
[ 01]

Contents:
1 PRELIMINARY INFORMATION...................................................................................................................4
2 APPLICATION OF THE DEVICE..................................................................................................................5
3 WARRANTY AND LIABILITY OF THE MANUFACTURER...................................................................5
4 SAFETY GUIDELINES.....................................................................................................................................6
4.1 S TORAGE , WORK AND TRANSPORT CONDITIONS .........................................................................................................6
4.2 I NSTALLATION AND USE OF THE DEVICE ..................................................................................................................6
4.3 D ECOMMISSIONING OF THE DEVICE .........................................................................................................................6
5 CONSTRUCTION OF THE DEVICE..............................................................................................................7
5.1 N ANO RFID P O E..............................................................................................................................................7
5.2 N ANO RFID.....................................................................................................................................................9
6 CONFIGURATION OF THE DEVICE.........................................................................................................11
6.1 C HANGING THE DEVICE S IP ADDRESS BY D ISCOVERER APPLICATION .........................................................................11
6.2 C HANGING THE PC S SUBNET ADDRESS ................................................................................................................12
6.3 C OMMUNICATIONS PROTOCOLS AND ADMINISTRATION ..............................................................................................14
7 THE DEVICE FUNCTIONS...........................................................................................................................15
7.1 C OMMUNICATION WITH THE READER ....................................................................................................................15
7.2 I NBUILT WWW SITE ............................................................................................................................................15
7.3 I NTEGRATION WITH USER S SOFTWARE ...................................................................................................................16
7.4 V IEWING THE READER STATUS BY HTTP GE T...................................................................................................17
7.5 C ONTROL BY HTTP GET PROTOCOL .................................................................................................................18
7.6 C ONTROLLING BY HTTP PROTOCOL IN CLIENT MODE .............................................................................................19
7.7 M ODBUS TCP.................................................................................................................................................21
7.8 SNMP...........................................................................................................................................................22
8 COMMUNICATION WITH THE DEVICE FROM E TERNAL NETWORK.......................................23
9 DHCP..................................................................................................................................................................23
10 RETURN TO THE FACTORY SETTINGS DEFAULT............................................................................23
11 FIRMWARE UPDATE..................................................................................................................................24
User manual: Nano RFID / Nano RFID PoE Page 3 of 24
[ 01]

1 Preliminar information
Before starting work with the device, read The User manual and follow the
instructions contained therein!
Description of visual symbols used in this user manual:
This symbol is responsible for reviewing the appropriate place in the
user instructions, warnings and important information. Failure to
follow warnings could cause injury or damage to the device
Important information and guidelines
Following this guidelines makes the use of the device easier
Attention: The screenshots in this manual can be dissimilar from actual images at
the time of the device purchase. Due to continuous development of the devices
software, some of the functions may differ from these in the manual. The
manufacturer claims no responsibility for any undesirable effects (misunderstanding)
caused by changes of the software.
User manual: Nano RFID / Nano RFID PoE Page 4 of 24
[ 01]

2 Application of the device
The Nano RFID device is used to read RFID Unique tags. The device is prepared for
an integration with other systems by way of of Modbus TCP, HTTP client / server, SNMP
protocols.
3 Warrant and liabilit of the manufacturer
The manufacturer provides a 2-year warranty on the device. The manufacturer also
provides post-warranty service for 10 years from the date of the introducing the device
on the market. The warranty covers all defects in material and workmanship.
The manufacturer undertakes to comply with the contract of guarantee, if the following
conditions are met:
all repairs, alterations, extensions and device calibrations are performed by the
manufacturer or authorized service,
supply network installation meets applicable standards in this regard,
the device is operated in accordance with the recommendations outlined in this
manual,
the device is used as intended.
The manufacturer assumes no responsibility for consequences resulting from improper
installation, improper use of the device, not following this manual and the repairs of the
device by individuals without permission.
This device doesn’t contain serviceable parts.
User manual: Nano RFID / Nano RFID PoE Page 5 of 24
[ 01]

4 Safet guidelines
The device has been designed and built using modern electronic components, according
to the latest trends in the global electronics. In particular, much emphasis was placed on
ensuring optimum safety and reliability of control. The device has a housing with a high-
quality plastic.
4.1 Storage, work and transport conditions
The controller device has to be stored in enclosed rooms which are free of caustic vapors
and substances and also meet the requirements:
•surrounding temperature from -40°C to +85°C,
•humidity from 5 to 95%,
•atmospheric pressure from 700 to 1060hPa
The device working conditions:
•surrounding temperature from -10°C to +60°C,
•relative humidity from 5% to 95%,
•atmospheric pressure from 700 to 1060hPa.
Recommended transport conditions:
•surrounding temperature from -40°C to +85°C,
•humidity from 5 to 95%,
•atmospheric pressure from 700 to 1060hPa.
4.2 Installation and use of the device
The device should be used following the guidelines shown in next part of the
user manual.
4.3 Decommissioning of the device
When it becomes necessary to recycle the device (for instance, to decommission the
device from service), please contact the manufacturer or its representative, who are
obliged to respond, appropriately, i.e. collecting the device from the user. You can also
ask the companies involved in recycling of electrical or computer equipment. Under no
circumstances should you place the device along with other waste material.
User manual: Nano RFID / Nano RFID PoE Page 6 of 24
[ 01]

5 Construction of the device
5.1 ano RFID PoE
Technical data:
Power supply:
PoE: 33-57V POE IEEE 802.3af,
DC: 12-24VDC (screw terminals 3,5mm),
Power consumption: max 1,5W.
Transponders:
Tag readout standards: UNIQUE ; 125kHz,
Tag reading distance: up to 8cm.
Inputs:
Number of inputs: 1,
Input type: opto-isolator, dry contact (NO) ,
Maximum input voltage: 24V.
Outputs:
Number of outputs: 1,
Output type: relay NO,
Maximum relays current load: 1A @ 30VDC.
LAN:
Ethernet 1x10Mbps, RJ45
Dimensions:
All dimension values are in millimeters.
User manual: Nano RFID / Nano RFID PoE Page 7 of 24
[ 01]

General view
Indicators and connectors:
The device is equipped with LED two diodes:
•POWER LED - the device power supply status,
•TAG LED - optical indications for read out tags.
The Nano RFID PoE is equipped with screw terminal connectors.
•POWER - power connector. Power supply 10-24VDC or PoE 802.3af,
•INPUT1 – dry contact NO input. The input status is available via the MOD US
TCP or HTTP Get protocol,
•RELAY OUT1 – relay NO output. Switching on/off relay and reading its status are
available via the Modbus TCP or HTTP Get protocol,
User manual: Nano RFID / Nano RFID PoE Page 8 of 24
[ 01]

•LAN – LAN connection socket,
•RESET – reset button. Its necessary for enable DHCP and restore factory
settings.
5.2 ano RFID
Technical data:
Power supply:
Passive PoE: 12-24VDC,
Power consumption: max 1,5W.
Transponders:
Tag readout standards: UNIQUE ; 125kHz,
Tag reading distance: up to 8cm.
LAN:
Ethernet 1x10Mbps, RJ45
Dimensions:
All dimension values are in millimeters.
User manual: Nano RFID / Nano RFID PoE Page 9 of 24
[ 01]

General view
Indicators and connectors:
The device is equipped with LED two diodes:
•POWER LED - the device power supply status,
•TAG LED - optical indications for read out tags.
•LAN – LAN connection socket,
•RESET – reset button. Its necessary for enable DH P and restore factory
settings.
User manual: Nano RFID / Nano RFID PoE Page 10 of 24
[ 01]

6 Configuration of the device
The device when used for first time needs to be configured.
There are two methods to do so. The network configuration can be easily changed by
Inveo “Discoverer” (http://inveo.com.pl/discoverer/) software:
6.1 Changing the device's IP address by Discoverer application.
When the “Discoverer” is opened and the relevant device is found, choose Interface list
box and click on Change IP button.
If Remote Config is disabled (enabled by default), it is necessary to configure the device
by changing the computer's subnet (chapter 6.2).
To enable the remote configuration it is necessary to enter tabs Administration
and check mark Enable Remote Network Config
Save the setup by selecting Save Config button.
User manual: Nano RFID / Nano RFID PoE Page 11 of 24
[ 01]

6.2 Changing the PC's subnet address
After the device is connected to a network, a subnet address of a PC which is connected
the same network has to be changed.
To do so, go to the PC's MS Windows network configuration: Start->Control panel
->Network and Sharing Center->Network and Internet->Network Connections,
then choose the related controller and right click on „Properties”.
After selecting this option configuration window will show up:
Next choose "Internet Protocol (TCP/IP)", double click on it and enter following settings:
Illustrative TCP/IP protocol settings
After saving changes by clicking OK, open a web browser and enter in the address line:
192.168.111.15. Next change the following: ("Default user name / password"
to admin/admin00))
User manual: Nano RFID / Nano RFID PoE Page 12 of 24
[ 01]
Changing network settings in MS WINDOWS

Next select option „NETWORK”
To set up the network settings of the device, use the following fields:
MAC Address – read only,
Host ame – NET IOS name,
Enable DHCP – checking this box force use of the address assigned by the DHCP server,
IP Address – the IP address of the device (at this address, the device will be visible on
the network),
Gateway – network gateway,
Subnet Mask – IP subnet mask,
Primary D S, Secondary D S – DNS servers addresses,
HTTP Srv IP: – server IP (mode: „Control only by HTTP Client”),
HTTP Srv Port: – the server's listening port,
HTTP Resource: - resource file for the reader's reference e.g. /somefile.php.
Save the setting by clicking Save Config button.
User manual: Nano RFID / Nano RFID PoE Page 13 of 24
[ 01]

6.3 Communications protocols and administration
The Administration settings allow for changing access password and to enable/disable
particular services in the device.
Admin Password change
To change an administrator password, in Current Password value field write a current
password. Next in appropriate value field ew Password write your new password and
confirm it at Re-type Password value field. The password can be blanked by leaving
new password value field empty.
Services configuration
The device allows to choose suitable services. To do that, a value of corresponding
service has to be check marked and then activated by Save button.
Enable MODBUS TCP Protocol – enables access using MOD US TCP protocol,
Enable SNMP - enables access using SNMP protocol,
Control onl b HTTP GET – the reader's HTTP Server work's mode is selected
Control onl b HTTP Client – the reader's HTTP Client work's mode is selected
Enable Remote Network Config – remote network configuration is selected (for
Discoverer application)
Enable TFTP Bootloader – enables a bootloader mode.
Attention:
TFTP Bootloader and Remote Network Config ought to be disabled during normal
work operation. It should be enabled for a firmware update only.
User manual: Nano RFID / Nano RFID PoE Page 14 of 24
[ 01]

7 The device functions
7.1 Communication with the reader
User can choose from the following options to access the code readout from a RFID tag:
•through built-in web server, using a standard web browser (preferred
browsers are MOZILLA FIREFOX, OPERA, CHROME),
•HTTP server mode,
•HTTP client mode,
•MOD US TCP,
•SNMP.
7.2 Inbuilt www site
The reader status can be found again at Home tab in the reader's menu (default –
192.168.111.15) .
- SV: 0.35 – software version
- Last ID: 04001BB7BC – last tag readout in HEX format,
- Number Of Read ID: 1 – number of read IDs since the reader's reset.
Uwaga:
If readout at a last ID shows 04001 7 C (LOCK!) it indicates blocking of further tags
reading until releaseId (HTTP GET) command is sent or in case of Modbus, value “0” has
to be sent to 1004 Single Coil address.
User manual: Nano RFID / Nano RFID PoE Page 15 of 24
[ 01]

7.3 Integration with user's software
The Nano RFID reader may be used with a customer's own software, in server mode (by
choosing Administration → Control onl b HTTP GET) or in client mode (by choosing
Administration → Control onl b HTTP Client).
Server work mode (HTTP Server):
In this mode external host (client) connects to the reader and controls it by HTTP
protocol GET method. The client has to read status.xml periodically and after suitable
XML tags are decoded, (individual tags are explained in the chapter 7.4) it may send
back data and commands. The resource file status.xml let a user read all required
information, which can be entered to a database (e.g. the reader's mac address, inputs
outputs status, card ID). After the data processing the client is able to send back data
which is required for interaction with a user of the reader. The client can send
information to the reader which may control the accept/reject sounds, the LED diodes
blinking, a lock's bolt release, as well as displaying text on the reader display. In this
mode, every time a tag is read the reader blocks reading ability until the client triggers
releaseId=1 function.
Client work mode (HTTP Client):
In this mode the reader may be compared to an Internet browser. The client's page (The
reader's) sends a request to server and waits for answer. The server - the page which
shares data - waits for requests, then processes them and sends a response back.
The reader connects with the server automatically and sends a tag's readout to the
server resource by HTTP GET. In response the server may send a XML file with
commands which specify type and status of the reader's indicator system, e.g. the LED
diodes status, the sounds indicators and the like.
In this mode an advantage is that, immediately after the card readout the reader
automatically sends request to the server or the controlling application.
This mode allows easy integration with PHP, Node JS, MySQL and the like servers.
User manual: Nano RFID / Nano RFID PoE Page 16 of 24
[ 01]

7.4 Viewing the reader status by HTTP GE T
The RFID IND-U2/U4 and RFID IND-M2/M4 readers can be controlled by HTTP protocol.
To view the reader's current status user may refer to the resource file by entering in an
Internet browser address line e.g. - http://192.168.111.15/s tatus.xml
It shows the resource file with basic information in XML format:
<status>
<netbios>NANO RFID</netbios>
<mac>00:00:00:00:00:00</mac>
<id>8500c2b4a8</id>
<newId>0</newId>
<cnt>1</cnt>
<resetFlag>1</resetFlag>
<enable>1</enable>
<httpClientStatus>0</httpClientStatus>
<out>0</out>
<in>1</in>
</status>
Section Description
<netbios>NANO RFID</netbios>
The reader s name
<mac>00:00:00:00:00:00</mac>
The reader s MAC address
<id>8500c2b4a8</id>
The last RFID tag s readout in hexadecimal
system
<newId>0</newId>
In the Control only by HTTP GET mode,
only
1- a new RFID tag has been read
0- a new RFID tag hasn't been read
<cnt>1</cnt>
Number of RFID tags readouts since the
reader s reset
<enable>1</enable>
1- radio module has been switched on
0 -radio module has been switched off
< esetFlag>1</ esetFlag>
1- reset took place
<httpClientStatus>0</httpClientStatus>
Current status of TCP connection in
Control only by HTTP Client mode
1- the server has been connected – open
socket
2- data from the server has been received
3- connection has ended
100- lost connection with server
<out>0</out>*
Current status of relay output.
<in>1</in>*
Current status of input.
* Nano RFID PoE only
User manual: Nano RFID / Nano RFID PoE Page 17 of 24
[ 01]

7.5 Control by HTTP GET protocol
Controlling the reader in Control onl b HTTP Client mode mode involves sending
proper command by HTTP protocol:
http://192.168.111.15/status.xml?
No Command Name Description
1 enable Enable RFID Switches on RFID reader's antenna
http://192.168.111.15/status.xml?en able =1
Switches off RFID reader's antenna
http://192.168.111.15/status.xml?enable =0
2 resetFlag Reset Flag When the reader is switched on or reset, the flag
is set to 1
Reset Flag deletion
http://192.168.111.15/status.xml?resetFlag=0
3 releaseId Release ID Deletes read flag and awaits for RFID tag to draw
near
http://192.168.111.15/status.xml?release I d=1
4 led Led control Switches on the LED diode indicator
led=TimeOn,TimeOff,Cnt
TimeOn*0,1 second, TimeOff*0,1 second
http://192.168.111.15/status.xml?led =5,3,4
Switches on the LED for 0,5 second, switches off
for 0,3 second and repeats sequence 4 times
5 buzz* uzzer control Załączenie sygnalizatora dźwiękowego
buzz=TimeOn,TimeOff,Cnt
TimeOn*0,1 second, TimeOff*0,1 second
http://192.168.111.15/status.xml?buzz=5,3,4
Switches on the buzzer for 0,5 second, switches
off for 0,3 second and repeats sequence 4 times
Controls the sound tone indicator
Generates the sound tone REJECT
http://192.168.111.15/status.xml?buzz=r
Generates the sound tone ACCEPT
http://192.168.111.15/status.xml?buzz=a
6 out* Output Control Controls relay output
out=1 – switch on relay
out=0 – switch off relay
http://192.168.111.15/status.xml?out=1
* Nano RFID PoE only
User manual: Nano RFID / Nano RFID PoE Page 18 of 24
[ 01]

7.6 Controlling by HTTP protocol in client mode
To control the reader by HTTP protocol in client mode the option Control onl b HTTP
Client in Administration tab needs to be selected.
When the Control onl b HTTP Client option is selected, an address for a data
transfer has to be configured. For this the table in →Network HTTP Client
Configuration tab is used.
Lp Nazwa Opis
1 HTTP Srv Add The server's IP address the reader will use to send data
2 HTTP Srv Port The server's listening port
3 HTTP Resource Resource file for the reader's reference e.g. /somefile.php
The reader, after a valid RFID tag readout sends data to the server relevant resource file
in the format: mac=123456789012&id=1314151617 e.g.
http://192.168.111.99 /rfid.php?mac=123456789012&id=1314151617
User manual: Nano RFID / Nano RFID PoE Page 19 of 24
[ 01]

W odpowiedzi serwer może nic nie odsyłać lub odesłać zasób XML z tagami:
No Command Name Description
1<led> Switches on the LED diode indicator
led=TimeOn,TimeOff,Cnt
TimeOn*0,1 second, TimeOff*0,1 second= 5,3,4
Switches on the LED for 0,5 second, switches off for
0,3 second and repeats sequence 4 times
2<buzz> Załączenie sygnalizatora dźwiękowego
buzz=TimeOn,TimeOff,Cnt
TimeOn*0,1 second, TimeOff*0,1 second= 5,3,4
Switches on the buzzer for 0,5 second, switches off
for 0,3 second and repeats sequence 4 times
Controls the sound tone indicator
a- Generates the sound tone ACCEPT*
r- Generates the sound tone REJECT*
* Nano RFID PoE only
The XML file may consist of e.g. fields (in the following example the code brings out
activation of the sound indicator and switch on LED).:
<buzz>10,0,0</buzz>
<led>10,0,0</led>
The XML file syntax is not checked. It is searched for data inside known tags only.
An example of code for php server:
<?php
if( $_GET["id"] ) // module send id and MAC - $_GET["mac"]
{ // some function to add id to SQL DB o sth like that
$use _allowed = 1; // it could be etu ned f om DB
if($use _allowed==1)
{
echo "<buzz>10,0,0</buzz>";
echo "<led>10,0,0</led>";
}
else {
echo "<buzz>5,5,4</buzz>"; // diffe ent signal
echo "<led>5,5,4</led>";
}
}
?>
User manual: Nano RFID / Nano RFID PoE Page 20 of 24
[ 01]
