1 User and safety instructions
Thank you for purchasing this high quality product from inVENTer!
This section provides an overview of the basic safety precautions for safe and proper operation of
your control unit.
1.1 User information
Safety and warning instructions
The safety and warning instructions in these installation instructions have a uniform structure and
are marked with a symbol on the left side of the instruction. A signal word in front of the text also
indicates the hazard level. If several hazard levels exist, the highest level safety instruction is
always used.
The safety and warning instructions contain the following information:
SIGNAL WORD: Type and origin of the danger. Possible consequences of the danger!
Measures to avoid the danger.
The signal word indicates the severity of the potential danger unless the preventive measures are
taken:
DANGER means: Imminent danger of serious injury or death.
WARNING means: Possible danger of serious injury or death.
CAUTION means: Direct danger of minor/signicant injury.
NOTICE Means: Direct or possible risk of property damage due to an adverse event/state.
If you see these signs, ensure you observe the described measures to prevent possible hazards
and/or damage.
Other symbols used in this documentation
In addition to the safety instructions, the following symbols are used:
This symbol indicates practical and useful tips for handling your ventilation system.
Before each step, any additional tools and materials required for the activity are listed.
The graphics in Section 6: Installation show the interior wall.
► Action required: This prompts the user to perform a specic action.
Check the results: This requires you to check the results of the action you have performed.
Action focus: To be taken into account in the corresponding assembly step.
1.2 Safety instructions
The installation instructions are part of your sMove control and must be available at all times (see
www.inventer.de/downloads). When handing the system to a third party, the information regarding
access to the installation instructions must be handed over also.
Before performing any work on the equipment/system, read the installation instructions carefully
and observe all notices that refer to the installation process in this section.
Also note the safety instructions that precede the described handling instructions. Non-obser-
vance of safety instructions could result in injury and/or property damage.
Intended use
The sMove control unit (also referred to in the further text as "controller" or "sMove controller")
must only be used to control decentralised iV ventilation devices with heat recovery (iV-Smart+,
iV14-Zero, iV-Light, iV-Compact [Xenion fan in each case], iV14-MaxAir, iV-O󰀩ce product series
[Xenion EFP fan in each case] and the iV-Twin+ product series [Mini-Xenion fan]) from inVENTer
GmbH.
Specically, the following must be used:
• The sMove controller for controlling the inVENTer ventilation devices with heat recovery integra-
ted into the system.
• The sensor technology paired with the controller (HYG18 humidistat, HYG12 humidistat,
CS1 CO2 sensor or pressure monitor) for the delivery of temperature, humidity and CO2 values
to the sMove controller, which in turn uses these values to control the inVENTer ventilation
devices with heat recovery.
Requirements for intended use
• Always observe the relevant standards, regulations and guidelines when installing the equip-
ment / system. In particular also applicable building regulations, re safety regulations and
accident prevention regulations of the employers' liability insurance association.
• Use the devices integrated into the ventilation system only in accordance with the applications
that are described in this documentation and only in conjunction with the components that are
recommended, approved and named by inVENTer GmbH in this documentation.
Changes or modications to the devices are not permitted.
• Before starting work, you should have a project plan showing the number of ventilation devices,
the location of the ventilation devices, the ventilation principle (cross ventilation, single room
ventilation, extract ventilation) and the associated controllers. The exact positioning of the
individual devices and control units must be checked at the installation site and, if necessary,
adapted to the local conditions with the involvement of the responsible planner or user.
• Your ventilation system is exclusively designed for use in ambient temperatures between -20
and 50°C.
• Trouble-free and safe operation of the equipment/system depends upon proper transportation,
proper storage and installation as well as careful operation and maintenance.
• These installation instructions are only valid in conjunction with the installation and operating
instructions of the corresponding ventilation device with heat recovery and supplement these.
All legal notices that are listed in the respective installation instructions also apply without
restriction to this document.
!
i

6 7
USER AND SAFETY INSTRUCTIONS SYSTEM OVERVIEW: SMOVE CONTROLLER
67
sMove controller | Installation instructions sMove controller | Installation instructions
• DANGER:
The unit may only be installed by a qualied electrician.
- When laying the power cable, observe the requirements of protection class II.
- Connect all devices of a ventilation system to the same circuit breaker.
- Route and connect cables only while in a voltage-free state!
- The mains supply must correspond to the specications on the type plate.
- Before working on electrical installations, disconnect all a󰀨ected units from the power supply.
- Check before making any drill holes whether there are wires in the drilling area.
• WARNING: For joint operation of a ventilation device with replaces, safety measures must be
taken to prevent a negative pressure from developing in the building. The responsible chimney
sweep and/or building planner decides which measures need to be carried out.
• NOTICE: Ensure adequate contact between the wires when connecting the sMove controller.
• NOTICE: Laying cables whose sheathing is not resistant to plastering under plaster leads to
short circuits and cable re! Lay cables without a plaster-resistant cable sheath in the conduit.
• NOTICE: The use of too small a cable cross-section leads to too great a voltage drop and/or
contact is not guaranteed!
Use wire ferrules with collars to connect braided wires.
• NOTICE: The unit has scratch-sensitive plastic surfaces. Do not touch the components with
oily and/or dirty hands. Avoid contact with sharp or pointed objects, e.g. rings.
• When using several ventilation devices controlled by several controllers, you must ensure that
the ventilation devices are synchronised with each other.
Any kind of use other than the intended use will exclude all liability claims.
Improper use
The sMove controller is intended exclusively for the control of the ventilation devices specied in
the section on intended use. Any other use is strictly prohibited.
Qualied personnel
The equipment/system may only be set up, operated and cleaned in conjunction with this docu-
mentation and the documentation for the controllers.
Installation, electrical connection and commissioning of the equipment/system may only be
performed by qualied personnel. Qualied personnel within the meaning of the safety notices
in this documentation are persons who are authorised to install, put it into operation and identify
equipment, systems and circuits in accordance with established safety procedures.
Conformity
The ventilation device complies with the technical safety requirements and standards of electrical
appliances for domestic use. It conforms to current European Union and United Kingdom
directives. The full text of the EU declaration of conformity is available at the following Internet
address: https://www.inventer.de/downloads/.
2 System overview: sMove controller
The sMove controller is an electronic control unit for controlling inVENTer®ventilation devices with
heat recovery. It is available in the variants s4 or s8, each in two versions (standard or at).
Each sMove controller can control the following maximum number of ventilation devices:
Ventilation units from the product series Count sMove 4 Count sMove 8
with Xenion fan 4 8
with Xenion EFP/Mini-Xenion fan 2 4
It features a visually discreet, timeless and at design as well as easy installation. The controller
is operated by touching the capacitive button and the slide control on the control panel. Integrated
indicator lights mean that the control panel acts simultaneously as a visual feedback / display for
the user.
The sMove controller can be used either as a base control unit or with additional sensors
connected.
When used as a base control unit, there is a choice of operating modes for the ventilation device
and the air ow can be set steplessly or at 4 predened levels.
An external interface allows the scope of functions to be expanded:
• Demand-based ventilation via sensor technology (humidistat, CO2 sensor, VOC sensor1)
[NO]), or
• Integration of a safety device (e.g. pressure monitor, [NC]) with simultaneous operation of the
ventilation devices with replaces.
• Integration of the sMove controller into an existing building management system via an ana-
logue input
Components
• Mounting plate
• Operating unit
• Switching power supply unit2)
• Mounting box (optional)
Versions
The sMove controller is available in standard and at versions.
In both versions, the external interface can be congured either as an external switching contact
or as an analogue input.
Flat version: The controller switches o󰀨 the ventilation device for 1 hour when in "O󰀨" mode.
The ventilation device then continues to operate using the previously saved operating mode and
ventilation level. The use of the Flat version is recommended in areas where it is desirable not to
turn o󰀨 the ventilation system in order to protect against moisture build-up.
Standard version: The sMove controller switches the ventilation device o󰀨 completely when in
"O󰀨" mode. For the ventilation device to work again, a ventilation level must be selected.
1) VOC = volatile organic compounds 2) optionally as a ush-mounted or DIN rail switching power supply unit

8 9
SYSTEM OVERVIEW: SMOVE CONTROLLER SYSTEM OVERVIEW: SMOVE CONTROLLER
89
sMove controller | Installation instructions sMove controller | Installation instructions
2.1 Construction
The sMove controller consists of a mounting plate for installation on the interior wall and a control
unit. The control unit contains the controller electronics and the control panel (acrylic glass cover).
A switching power supply unit (ush-mounted or control cabinet mounting) for power supply is also
included in the scope of delivery of the sMove controller.
The control panel on the surface of the control unit serves as the operating and display surface.
Figure 1: Front view of sMove controller
2.2 Function
The sMove controller is a control unit for decentralised ventilation devices with heat recovery from
inVENTer GmbH. Where these are connected, the information determined at the controller via the
sensor technology is incorporated into the control of the ventilation device.
sMove controller without connected external interface
If no sensor is connected and the controller is not integrated into the home control system, the
operating mode and the intensity of the air volume ow can be set on the sMove controller.
The heat recovery and ventilation modes can easily be set by repeatedly touching the Mode
button. The operating modes Pause (optionally 1h, 2h, 4h or 8h) and OFF are switched on or o󰀨
by repeatedly pressing the Pause/O󰀨 button.
The ventilation device can also be switched o󰀨 completely by holding down the Pause/O󰀨 button
(standard version only). The boost function can be selected by holding down the top fan symbol
on the slider.
There are four preset ventilation levels (fan symbols on the slider) for the ventilation devices which
dene the rotational speed of the fans and therefore the units' air ow. These are xed and cannot
be changed:
• Level 1 – 25 %
• Level 2 – 35 %
• Level 3 – 50 %
• LED10 - 70 %
• Level 4 – 100 %
The air volume ow can also be changed continuously by means of the slider.
sMove controller with connected external interface
The external interface is a bi-functional port on the back of the operating unit. It enables
A: the connection of a sensor with potential-free switching contact (NO/ NC contact), or
B: Use as an analogue input for the integration of the ventilation system into an
existing building management system.
A: Interface congured as external switching contact (sensor system)
If sensors are connected to the sMove controller, the range of the controller's functions increases
and this also allows demand-based ventilation alongside manual ventilation, or the integration of a
safety device.
All functions of the controller without connected sensors are available (manual control).
The sensor used must have a potential-free relay contact as its output.
The function settings of the interface are adjusted via the jumper on the back of the operating unit.
Sensor Switch Limit value exceeded Limit value not reached
CO2sensor Make
contact
(NO)
Switch all ventilation devices
connected to the controller to
ventilation mode, ventilation
level 3 (50 %).
Switch all ventilation devices
connected to the controller
to the originally set operating
mode and ventilation level.
VOC sensor
Humidistat
Pressure sen-
sor (4 Pa)
Break
contact
(NC)
Switch all ventilation devices
connected to the controller to
OFF mode.
• Connection of an external normally open contact, (NO):
If the pre-dened limit (cannot be changed on the controller) is exceeded, the sensor relays this
to the controller. This then switches all connected ventilation devices to ventilation mode with a
pre-dened air ow of 50%.
The function remains active until the corresponding parameter falls below the pre-set limit again.
Then all ventilation devices connected to the controller switch to the originally set operating mode
and ventilation level.
• Connection of a safety device, (NC):
The external interface is used to integrate safety devices, e.g. a 4 Pa pressure sensor, into the
ventilation system while simultaneously operating the ventilation system with replaces.
If this interface is used in conjunction with an external pressure sensor (4 Pa pressure sensor),
the air pressure indoors is continuously monitored. As soon as this exceeds the safety-relevant
limit, the sensor transmits this to the controller. This then switches all connected ventilation
devices o󰀨. The function remains active until the air pressure drops below the safety-relevant limit
again. Then all ventilation devices connected to the controller switch to the originally set operating
mode and ventilation level.
1 a Flush-mounted switching PSU or
b Top-hat rail switching PSU
2 Mounting plate
3 Operating panel
4 Control panel (Acrylic glass-cover)
a Operating mode button
b Pause/O󰀨 button
c Slider
c

10 11
ELECTRICAL CONNECTION ELECTRICAL CONNECTION
10 11
sMove controller | Installation instructions sMove controller | Installation instructions
3 Electrical connection
DANGER
Exposed electrical components.
Electric shock and injury due to live components (230V, 50Hz)!
• Before working on electrical installations, disconnect all a󰀨ected equipment from the power
supply.
• Observe the requirements for protection class II when laying the power supply cable.
Do not lay live cables.
• Lay the mains connecting cables and signal cables separately.
• Guide the system components of the ventilation system to the same automatic safety device.
Installation and connection must only be performed by qualied and trained personnel.
NOTICE
Insu󰀩cient cable cross-section.
Excessive voltage drop and/or contact cannot be guaranteed!
Only use the following cable cross-sections:
• Power cable: 1.5 mm²
• Fan BUS: min. 0.75 mm² – max. 33 m length with star-shaped
connection of the fans
• Operating voltage cable: 0.75 – 1.0 mm²
The terminals on the back of the control unit are nger-operated, spring-loaded terminals. The
terminals have a connection capacity of 0.1 to 1.0 mm². They are suitable for solid and braided
wires.
The use of wire ferrules is not necessary. If wire ferrules are used, they must increase the
cross-section. Their material thickness is not included.
3.1 Terminal assignments
Connector Terminal Meaning Colour
Switching power supply unit
Power cable/
Input cable for switching power supply
unit
AC/L Phase Brown
AC/N Neutral conductor Blue
Controller operating voltage
Output cable for switching power supply
unit
+ 24 V Controller operating voltage Red
GND (┴) Black
Rear view of sMove controller operating unit
Connecting ter-
minal, 5-pole,
spring-loaded
terminal
Controller operating
voltage
GND (┴) Controller operating voltage Black
+ 24 V Red
Fan BUS
connection
DIR1 (III) Direction signal 1 White
VOUT+
(IV)
Fan operating voltage Green
DIR2 (V) Direction signal 2 Brown
Connecting ter-
minal, 2-pole
spring-loaded
terminal
External interface
(optional)
SC1 Switching contact 1, ana-
logue (+)
–
SC2 Switching contact 2, ana-
logue (-)
–
Jumpers,
each 2-pin
(Jumper)
NO
plugged
2
on circuit: Normal operation
not plugged on circuit: Ventilation, level 3
NC plugged on circuit: OFF
not plugged on circuit: Normal operation
– 1 Only for service settings
sMove controller with connected external interface
B: Interface congured as analogue input (building control system)
If the interface is used as an analogue input, the ventilation device can be integrated into an
existing building management system. To do so, a predened DC voltage level is set in the home
automation control unit, depending on the desired function.
Depending on the control voltage, the ventilation and heat recovery modes are available in venti-
lation stages 1 - 4, as well as switching o󰀨 the connected ventilation devices.
(for control voltages, see section 3.3: Electrical connections – jumpers).
Connection terminal 8-Pin
2-Pin plug for jumper
(function anment external interface)
Connection terminal, 2-pole
(external interface
– potential free switching contact, or
– analogue control line 0 ... 10 V DC)
1
2
3
4
5
1
2
1
2
1
2
1
2
3
i

12 13
ELECTRICAL CONNECTION ELECTRICAL CONNECTION
12 13
sMove controller | Installation instructions sMove controller | Installation instructions
If the sMove s8 is connected in conjunction with a ush-mounted switched-mode power supply,
we recommend distributing the cables between the controller and the fan in a separate mounting
box.
3.2 Cabling
Figure 2: Connection example for sMove controller
Components
A Rear sMove control unit
Connection terminal, 5-pole
(fan BUS)
Jumper, 2 x 2-pin
Jumper service settings
Connection terminal, 2-pole
(external interface)
B Fans
C Connection terminals, 5-pole
(fan BUS distribution)
D Sensor technology (optional)
E Switching power supply unit
Maximum cable lengths
Cable Cross-section/cable type and cabling
Maximum
length
(controller ...
last connected
unit)
Operating voltage 2x 1.0 mm;
24 V DC
between switching power supply unit
and operating unit
100 m
Fan BUS LiYY3x0.75;
6 ... 16 V DC
between sMove control unit and fans
Ventilation units with Xenion reversible fan
Star-shaped connection 33 m
Connection in series (2 units) 25 m
Connection in series (4 units) 15 m
sMove s8
only
Connection in series (8 units) 10 m
Ventilation units with Xenion-EFP / Mini-Xenion reversible fans
Star-shaped connection 25 m
Connection in series (2 units) 15 m
sMove s8
only
Connection in series (4 units) 10 m
i
3
3
3
3
3
3
3
3
3
+ 24 V DC
GND (┴)
DIR1 (III)
VOUT+ (IV)
DIR2 (V)
SC1
SC2
+ 24 V DC
GND (┴)
V IV III
V
IV
III
VIV III
VIV
III
VIV III
VIV
III
VIV
III VIV III
VOUT+
(IV)
DIR1
(III)
DIR2
(V)
L
NAC
DC A
B
C
D
E

Schaltschrank-Schaltnetzteil Unterputz-Schaltnetzteil
s4 / s8, 1 Montagedose,
min. 66 mm tief
s4 / s8: 1 Doppelkammer-Montagedose
14 15
ELECTRICAL CONNECTION PREPARING FOR INSTALLATION
14 15
sMove controller | Installation instructions sMove controller | Installation instructions
4.1 Principle sketches: Connection options for ventilation devices
Switching power supply unit
Terminal blocks
Potential-free opener
Ventilation unit
4 Preparing for installation
• Read the "Installation" and "Electrical connection" sections carefully before installation to avoid
installation errors. The installation and connection of the entire ventilation system must be
carried out by qualied and trained personnel.
• Before and during installation, note the safety regulations in order to avoid electrical accidents.
• Check the delivery for completeness and transport damage upon receipt using the delivery
note. Report missing items immediately.
• Only install all ventilation system devices intended for indoors
- on nished and at interior walls.
- in rooms which are free from aggressive or corrosive gases and extreme dust exposure.
• The sMove controller is installed on the interior wall via a mounting box.
Recommended installation height: 1.50 m oor to lintel height (reachability for operation)
�68 mm
s4/s8: 1x, depth 66 mm s4/s8: 1x, double box
s4 (Alternative): 1x, box, depth min. 90 mm
3.3 Jumpers
Jumper 2 is used to assign the function of the external interface when a potential-free switching
contact is connected (safety device: opener / other sensors: closer) as well as in the case of inte-
gration into a house control system.
The position of the jumper may only be changed in a de-energised state.
Function assignment depending on the switching contact
NO (closer NC (opener) Sensor
Position of jumper 2 Function with switch actuation / switching
attached Normal operation OFF (chimney func-
tion)
NO contact:
Safety device
(4 Pa)
not
attached
Ventilation
Ventilation level 3 Normal operation
Closer:
Humidistat
CO2
VOC
Interface as analogue input
i
2
2
2
2
The 2-pin connector for jumper 2 is located on the rear of the operating unit.
Jumper 2 is not plugged in at the factory and is located in the accessory bag of the controller. It
must be plugged in if required. Jumper 1 is used for service settings and must be left in the deliv-
ery state for the controller to function correctly.
If, in the case of an sMove controller being replaced, for example, a pressure sensor (safety
device) with normally open contact is connected, it must be congured as normally closed contact
(switch with changeover contact) or, if this is not possible, it must be replaced with a (pressure)
sensor with normally closed contact.
It is not possible to connect a potential-free switch and an analogue input simultaneously. A
connected analogue input always has priority over a potential-free switching contact. If a safety
device is integrated, it has priority over other connected sensors.
If jumper 2 is not plugged in and the sMove controller is connected to a home control system, the
following DC voltages must be set:
Function Control voltage [V DC]
Ventilation level 3 0.00 ≤ U ≤ 0.25
Ventilation level 4 0.75 ≤ U ≤ 1.25
Ventilation level 2 1.75 ≤ U ≤ 2.25
Ventilation level 1 2.75 ≤ U ≤ 3.25
OFF 3.75 ≤ U ≤ 4.25
Heat recovery ventilation level 1 4.75 ≤ U ≤ 5.25
Heat recovery ventilation level 2 5.75 ≤ U ≤ 6.25
Heat recovery ventilation level 3 6.75 ≤ U ≤ 7.25
Heat recovery ventilation level 4 7.75 ≤ U ≤ 8.25
2x � 82 mm
xyz
xyz
�82 mm�68 mm
xyz

16 17
PREPARING FOR INSTALLATION INSTALLATION
16 17
sMove controller | Installation instructions sMove controller | Installation instructions
4.2 Installation dimensions
Designation Width [mm] Height
[mm]
Depth
[mm]
Ø [mm]
Mounting boxes
Wall opening for ush-mounted box
60x66
‒ ‒ 66 82
Wall opening for ush-mounted plaster-
board box 68x61
‒ ‒ 61 68
Wall opening for ush-mounted box
60x90
(masonry box 66 mm incl.
plaster compensation ring 24 mm)
≥ 95 82
Wall opening for ush-mounted du-
al-chamber box
‒ ‒ 68 2x 82
Wall opening for exible ush-mounted
plasterboard box
‒ ‒ 61 68
Switching power supply unit
s4 control cabinet switching power
supply unit
25 (1.5 HP) 93 56 –
s8 control cabinet switching power
supply unit
76.5 (4.5 HP)
Flush-mounted switching power supply
unit
33 54
Table 1: Installation accessories and installation dimensions
5 Installation
DANGER
Exposed electrical components.
Electric shock and injury due to live components (230V, 50Hz)!
• Installation and connection must only be performed by qualied and trained personnel.
5.1 Routing wires and attaching the mounting box
Requirements:
• The milled holes for the mounting box(es) on the interior wall are created.
►Route the wires needed to connect the controller to the installation site:
• Power cable between control cabinet and installation site:
Flush-mounted switching power supply unit: AC 230 V, 50 Hz
Control cabinet switching power supply unit: DC 24 V
• Fan BUS, 3-wire, route between ventilation device wall opening and controller installation
site.
• Optional when sensor connected:
Power cable to the installation site of the external sensor
Signal cable, 2-wire, between the controller installation site and installation site of the exter-
nal sensor
►Lay the cables at the mounting location of the controller and at the mounting location of the
junction box in the respective mounting box.
►Install the mounting box on the interior wall.
24 V DC
230 V AC max. 8 x 16 V DC

The ush-mounted switching power supply unit is
placed in the lower area of the double-chamber
mounting box.
18 19
INSTALLATION INSTALLATION
18 19
sMove controller | Installation instructions sMove controller | Installation instructions
►Place the power supply unit in the lower cavity area
of the mounting box.
The switching power supply unit output
wires extend into the interior.
The ush-mounted switching PSU is connected.
5.3 Distributing fan cables
We recommend the star-shaped connection of fans to the sMove controller.
The distribution of wires to the fan in this case takes place within the prepared mounting box using
5-pole connection terminals. Alternatively, the fans can be connected in sequence. In this case,
no distribution takes place. The fan BUS is attached directly to the terminal on the operating unit.
Note the connection capacity of the screw terminal of no more than 1.5 mm2.
Stripping tool, crimping tool, fan BUS connecting cable, 3-wire, terminal blocks (5-pole
(3x), included scope of supply)
Requirements:
• The switching power supply unit is attached.
►Connect the fan BUS cables to a terminal block,
5-pole, as follows:
The wire ends
• of the same colour
• ventilation devices operated in pairs
attach together with one pole of a terminal block
A maximum of 4 poles are occupied with 1 wire
each.
►Attach the wire ends of the additional connecting
cable, 3-wire, to the terminal block of the corre-
sponding colour (1).
►Place the connected terminal blocks in the mount-
ing box (2).
The connecting cable extends out of the mounting
box.
5.2 Connecting the switching power supply unit
Flush-mounted switching power supply unit: Terminal blocks, 2-pole
Requirements:
• The cables are routed to the installation site.
• The mounting box is attached.
Control cabinet switching power supply unit
►Secure the switching power supply unit to the con-
trol cabinet's DIN rail.
sMove s4: It requires 1.5 HP of space.
sMove s8: It requires 4.5 HP of space.
►Connect the switching power supply unit:
• Attach the phase conductor to terminal L
• Attach the neutral conductor to terminal N
• Attach the (red) wire to the (+) terminal.
• Attach the (blue) wire to the (–) terminal.
The control cabinet switching power supply unit is
connected.
Flush-mounted switching power supply unit
►Connect the power supply unit input wires (blue/
brown) using the terminal blocks:
• Connect the phase conductor (brown) to wire L.
• Connect the neutral conductor (blue) to wire N.
The fan cables are distributed.
24 V DC
230 V AC
1 2
3 4
L N
+ –
230 V AC
24 V DC
2
1
!


20 21
INSTALLATION INSTALLATION
20 21
sMove controller | Installation instructions sMove controller | Installation instructions
5.4 Installing the operating unit
The control unit is mounted on the prepared controller mounting box. The fan cables are in the
box and are already distributed in it. Depending on the installation scenario, the switching power
supply is located in the control cabinet or in the lower area of the mounting box.
To connect an optional sensor, e.g. CO2sensor or to a home automation system, follow the
instructions in grey italics.
Stripping tool; crimping pliers; screwdriver
Requirements:
• The switching power supply unit is attached.
• The fan wires are distributed.
►Pull the lever on the lower right side of the operat-
ing unit backwards (1).
►Slide the base plate downwards as far as the stop
(2).
The operating unit is unlocked.
►Remove the base plate from the operating
unit (3).
The base plate has been removed from the
operating unit.
►Screw the operating unit base plate to the box
using xing screws.
The arrow above the lettering TOP is
pointing upwards.
!
NOTICE: If the terminals are connected
incorrectly, the sMove controller or connected
components will not work!
• Ensure the correct terminal assignment
when connecting the cables.
►Attach the cables to the back of the operating unit:
• Operating voltage cable, 2-core, in the two
upper poles of the 5-pole connection terminal:
- Red wire (+) to the rst connecting pole
- Black wire (┴) to the second connecting pole;
• Fan BUS, 3-wire, in the three lower poles of the
connection terminal;
- DIR1 (III) in the third connection pole
- VOUT+(IV) in the fourth connection pole
- DIR2 (V) in the fth (lower) connection pole;
• Optional: Sensor cable, 2-wire, to the 2-pole
connection terminal.
Termi-
nal
Meaning Colour
+ 24 V Supply voltage
24 V DC Red
┴GND Black
DIR1 Direction signal 1 White
VOUT+ Fan operating voltage Green
DIR2 Direction signal 2 Brown
SC1 (+) External interface
(optional sensor)
SC2 (–)
1
2
3
1
2
3
+ 24 V
–
DIR1
VOUT+
DIR2
SC1
SC2

22 23
INSTALLATION TECHNICAL DATA
22 23
sMove controller | Installation instructions sMove controller | Installation instructions
You have installed the sMove controller.
NOTICE: If the jumper on the circuit board
is set incorrectly, the controller will not have
the desired function!
• Note the position of the jumper.
►Plug in jumper 2 (above, in the accessory bag) so
that the desired function is activated (see Electrical
connection - jumpers).
Interface Jumper 2 Function dur-
ing switching
Pressure sensor
(opener)1)
closed
(plugged in) OFF
Other sensors
(closer)
open
(not plugged in)
Ventilation
level 3
Analogue open
(not plugged in)
Integration into
building control
system
1) For retrotting, observe the information on the pressure sensor,
page 14 - Jumper position.
►Turn the operating unit around.
The cables are directed towards the mounting
box.
►Mount the operating unit behind the guides on the
base plate.
The ventilation slots are directed upwards
and downwards.
The positions of the receptacle for the
control unit lock and the lever on the base
plate match.
►Slide the operating unit downwards as far as the
stop.
The operating unit should snap audibly into
place.
6 Technical data
Feature Value
Protection class (DIN EN 61140) /
Type of protection (DIN EN 60529) IP20 / II
Switching power supply unit input voltage /
mains voltage [V AC] [Hz] 220 ... 240 / 50 ... 60
Switching power supply unit output voltage /
Controller operating voltage [V DC] 24
Power consumption in standby [W] 2.5
Max. power consumption [W] 18
Output voltage fan BUS [V DC] 6 ... 16
External switching contact (optional)
Safety device Potential-free break contact
Other sensor technology Potential-free make contact
Operating temperature [°C] 5 ... 50
Electrical protection area
(in accordance with VDE 0100) Outside protection areas 0 ... 2
Conformity
7 Scope of supply
Standard components
All standard components are also available as spare parts. Contact your local distributor to order
accessories for your controller.
Component Item number
sMove s4 controller
- Standard or Flat, each incl. switching power supply unit 1001-2006
sMove s8 controller
- Standard or Flat, each incl. switching power supply unit 1001-2007
!
!

24 25
ACCESSORIES AND SPARE PARTS TROUBLESHOOTING
24 25
sMove controller | Installation instructions sMove controller | Installation instructions
8 Accessories and spare parts
Contact your local distributor to order accessories for your ventilation system.
Component Item number
Operating unit
sMove operating unit 3002-0396
Sensor technology (optional)
CO2sensor CS1 1004-0145
HYG12 humidistat 1002-0015
HYG18 humidistat 1002-0044
Switching power supply units
Switching power supply unit Nt17-s4 (for DIN rail installation) 3002-0274
Switching power supply unit Nt17-s8 (for DIN rail installation) 3002-0275
Flush-mounted PSU NT18-s4 3002-0318
Flush-mounted power supply unit NT17-Mz/s8 3002-0267
Installation accessories
Hollow wall box 68x61 (s4/s8 with switching power supply
unit) 1003-0084
Hollow wall box 60x66 (s4/s8 with switching power supply
unit) 3002-0244
Flexible hollow wall box (s4/s8 with ush-mounted power
supply unit) 1003-0150
Dual-chamber ush-mounted box box incl. dividing wall (s4/
s8 with ush-mounted power supply unit) 1003-0149
Flush-mounted box 60x90 incl. compensating ring
(s4 with ush-mounted power supply unit) 1003-0104
Round cable LiYY-O 3x0.75 (33m) 1004-0020
9 Troubleshooting
Fault Possible cause Remedy
Incorrect function with
connected interface
Upper jumper incorrectly/
not attached
Check the upper jumper on
the back of the operating unit
control:
• attached: OFF for opener
(pressure sensor)
• not plugged in: Ventilation
operating mode, level 3
with closer (humidistat, CO2
sensor)
Fans not working
Pressure sensor connected
as closer (e.g. exchange
operating unit)
Conversion of the pressure
sensor as a normally closed
contact (changeover contact)
or, if necessary, replacement
with a pressure sensor with a
normally closed contact.
Controller not working
Operating unit is incorrectly/
not connected Check wiring.
No electrical contact.
Check cables. Ensure cables
are stripped su󰀩ciently (ap-
prox. 8.5 mm).
Indicator lights do not light up Faulty controller. Replace controller.
There is no power. Check power supply.
Slide control defective Replace controller
If you cannot eliminate the fault, please contact our technical customer service. Information as to
how, can be found in section 11: Service

26 27
GUARANTEE AND WARRANTY GUARANTEE AND WARRANTY
26 27
sMove controller | Installation instructions sMove controller | Installation instructions
NOTES
10 Guarantee and warranty
Guarantee:
The guarantee refers to the defect-free condition of the product at the time of purchase and
covers all defects that were present at the time of purchase. Failure to observe the intended use
will invalidate all guarantee claims.
Outside Germany, the national guarantee provisions of the country in which the system is sold
apply. Please contact the distributor for your country.
Warranty:
inVENTer GmbH provides a ve-year warranty for electronic components. This covers premature
product wear.
Guarantee and warranty claims:
Further information about the guarantee is available at www.inventer.de/garantie.
In the case of a guarantee or warranty claim, contact your local distributor or factory representa-
tive.
In all cases, please return the complete unit to the manufacturer.
The warranty is an additional o󰀨ering by the manufacturer and in no way a󰀨ects the appli-
cable law.
11 Service
Complaint:
Check the delivery for completeness and transport damage upon receipt using the delivery note.
Report missing items immediately, and at the latest within 14 days to your supplier, distributor or
factory representative.
Accessories and spare parts:
To order components for your ventilation device, contact your dealer or factory representative.
Technical customer service:
For technical support contact our service sta󰀨:
[phone]
[e-mail]

Item number: 5021-0029
Version: 1.0 – 10/2022
Subject to modications.
We accept no liability for printing errors.
inVENTer GmbH
Ortsstraße 4a
07751 Löberschütz
Germany
www.inventer.eu
