ioCorp ProEdge Z201 User manual

z201 ProEdge™ DVI Dual-Display Zero Client
Tera2321 PCoIP™ Portal Processor
QUICK START GUIDE

Quick Start Guide
Copyright and Trademark Notices
Copyright 2012 I-O Corporation
ALL RIGHTS RESERVED
Information in this ocument is subject to change without notice an oes not represent a commitment on the
part of the manufacturer. No part of this gui e may be repro uce or transmitte in any form or means an for
any purpose, without the express written permission of the manufacturer.
I-O® is a registere tra emark an Pro|E ge™ is a tra emark of I-O Corporation.
PCoIP™ is a registere tra emark of Tera ici Corporation.
VMWare® is a registere Tra emark of VMWare Corporation.
All other tra emarks an registere tra emarks are property of their respective owners.
Every effort has been ma e to make this gui e as complete an accurate as possible, but no warranty of fitness
is implie .
The authors an the publisher shall have neither responsibility nor liability to any person or entity with respect to
loss or amages arising from the use of information containe in this gui e.
October 2012
I-O Corporation
1485 S Heritage Crest Way
Unit 1-A
Bluffdale, UT 84065
phone: [phone]
fax: [phone]
http://www.iocorp.com

Table of Contents
Copyright and Trademark Notices....................................... 3
Table of Contents..................................................................4
Introduction.......................................................................... 5
Resolution Options............................................................... 5
ackage Contents................................................................. 5
Status Indicators and orts……........................................... 6
Button Operation................................................................. 7
Installation Steps……………………….............................. 7
Establishing a CoI Connection.........................................8
Teradici CoI Management Console..................................8
Diagram for 2560x1600 Resolution Monitors..................... 9
Manufacturer's Warranty Statement..................................... 10
Customer On-Site Exchange & Repair olicy......................11
4

Introduction
About I-O Corporation
I-O Corporation’s z201 ProEdge™ DVI Dual-Display Zero Client delivers crystal clear communication
to VMWare VDI Desktops. Since 1977, I-O Corporation has developed display-oriented solutions and now
offers the next generation zero client solution based on Teradici’s Tera2321 PCoIP™ Portal Processor.
Consistent with our policy of continuous development, the product you received may have features in
addition to those described in this guide. lease visit us at www.iocorp.com for current information.
Resolution Options
•1-2 DVI Monitors up to 1920x1200
•1 DVI + 1 VGA monitor up to 1920x1200
•1 DVI monitor up to 2560x1600 (Requires Cable Adapter for dual-link DVI)
Package Contents
•Z201 CoI Zero Client based on Teradici’s TERA2321 ortal rocessor
•ower Supply
•Cable adapter for dual-link DVI
•Quick Start Guide
5

Status Indicators and Ports
1
2 3
4
5
6
7
8
9 10
11 12
1. Session LED. Soli Green=PCoIP Session Active.
2. Power Button LED.
•Soli Green = Unit Powere On.
•Soli Yellow = Client Stan by = Wake-on-LAN or Wake-on-USB Enable
•Flashing Yellow = Setting up for Wake-on-USB or Client Powering Down
3. Rear USB Ports
4. Ethernet Network Connection
5. DVI-D
6. DVI-I
7. Front USB Ports
8. Speaker-Out
9. Hea phones-Out
10.Kensington Lock
11. Microphone Port
12.12 VCD Power
6

Button Operation
•Press to Turn On (when off or in WoL/WoUSB suspen mo e)
•Press an hol to Turn Off
•When in-session
oWhen connecte to a virtual esktop – Press to Disconnect.
oWhen connecte to a PCoIP host car – Press to show zero client
control panel with options to isconnect, or power off the workstation.
Installation Steps
1. Connect USB keyboar an mouse.
2. Connect one en of the Ethernet cable to the zero client an the other en
to a switch/router. The switch or router shoul be on the same network as
the host car or virtual esktop server. For more a vance network
environments, visit the Tera ici support site at techsupport.tera ici.com
3. Connect monitor cables to the zero client.
4. Connect speakers an /or hea phones (optional).
5. Connect power supply to the zero client an a power source.
6. Press front panel button to power on the zero client.
7

Establishing a PCoIP Connection
Your zero client is pre-configure to connect irectly to a PCoIP host car , but can
be configure to use a thir party connection broker such as Vmware View to
connect to virtual esktops.
Direct connect to Host Car
1. Power on host PC with PCoIP host car .
2. Power on the zero client an the connecte isplays.
3. Ensure the zero client is on the same network as the host car .
4. Wait until the “Connect” ialog appears on screen.
5. Select “Connect” an you will see a message “Discovering hosts,
please wait…”
6. A list of available hosts is isplaye .
7. Select the host car you wish to connect to an click “OK”.
8. The isplay will show the host PC screen an the zero client’s Session
LED on the front panel will turn green in icating a successful PCoIP
connection.
Connect to Vmware View brokere VDI esktop an /or PCoIP Host Car
See PCoIP Zero Client & Host A ministrator Gui e for etaile setup instructions.
This Gui e can be ownloa e from I-O Corp’s FTP Site at:
ftp://ftp.iocorp.com/Thin_Clients/Z201/
Teradici PCoIP Management Console
Zero Clients that are base on Tera ici’s PCoIP Portal Processors can be manage
via Tera ici’s PCoIP Management Console. A copy of the Management Console
an instructions for its installation can be foun at http://www.tera ici.com/ .
A copy can also be ownloa e from I-O Corp’s FTP Site at:
ftp://ftp.iocorp.com/Utilities/PCoIP%20Management%20Console/
8

Diagram for 560x1600 Resolution Monitors
The ProE ge z201 DVI Dual-Display Zero Client supports a single monitor
resolution up to 2560x1600. In or er to achieve this, utilize the cable a apter
provi e an connect as isplaye below.
9

Manufacturer’s Warranty & Repair Policy
anufacturer's Five-Year Limited Warranty
(United States)
The following warranty applies only to products purchased and operated within the United States.
I-O Corporation (I-O) warrants this product against defects in material and workmanship for a period of one year commencing
from date of purchase by the original customer, when operated and maintained in accordance with I-O's published
specifications. I-O's liability shall be limited, at its option and expense, to refund to buyer the actual amount paid by buyer or to
repair or replace any defective or nonconforming product or part thereof, F.O.B. I-O's authorized repair depot. Buyer may obtain
a replacement product by meeting the terms of the I-O Customer On-Site Exchange Repair olicy in effect at the time of the
request.
THE EX RESS WARRANTY SET FORTH ABOVE IS IN LIEU OF ALL OTHER EX RESS OR IM LIED WARRANTIES.
OTHERWISE, THE RODUCTS ARE SOLD AS IS WITHOUT FURTHER OBLIGATION OR LIABILITY ON THE ART
OF I-O. I-O EX RESSLY EXCLUDES ANY IM LIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
ARTICULAR UR OSE.
EXCE T AS EX RESSLY SET FORTH HEREIN, IN NO EVENT SHALL I-O BE LIABLE FOR ANY CLAIMS OR
DAMAGE ARISING DIRECTLY OR INDIRECTLY FROM THE FURNISHING OR FAILURE TO FURNISH RODUCTS,
S ARE OR RE LACEMENT ARTS, INFORMATION OR SERVICES HEREUNDER. UNDER NO CIRCUMSTANCES
SHALL I-O BE LIABLE IN ANY WAY FOR INDIRECT, S ECIAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT
NOT LIMITED TO LOST BUSINESS OR ROFITS, WHETHER OR NOT FORESEEABLE AND WHETHER OR NOT
BASED ON BREACH OF WARRANTY, CONTRACT, OR NEGLIGENCE.
I-O shall not be liable for non-performance or delays hereunder due to causes beyond its control. These shall include, but not be
limited to, acts of God, wars, strikes, fires, flood, storm, earthquake, shortages of labor or materials, labor disputes,
transportation embargoes, acts of any government or agency thereof.
MODIFICATIONS OR RECONFIGURATION OF THE HARDWARE BY ANYONE OTHER THAN I-O OR I-O’S
AUTHORIZED RE AIR FACILITY WILL VOID THIS HARDWARE WARRANTY.
10

Customer On-Site Exchange Repair Policy
Terms, Conditions, and Limitations
For products covered by the I-O Corporation (I-O) Manufacturer's Limited Warranty (United States), I-O's Customer On-Site Exchange (COE)
Repair olicy provides customers with a replacement unit for a defective product, subject to the following terms and conditions
Call Customer Support
If a product fails, call I-O Customer Support for assistance at [phone].
Verify Product Failure
I-O will verify the product serial number, warranty coverage and product failure.
You are responsible for assisting in verifying the product failure.
When I-O Customer Support verifies a product failure they will issue a Return Merchandise Authorization (RMA) number for the failed
product.
Replacement Units
Replacement units are shipped from I-O's stock of refurbished units, subject to availability.
Replacement units carry the same warranty as remaining on the original product.
I-O's COE Repair olicy applies only to warranted product failures. Buyer guarantees payment for non-warranted product repairs or
replacement.
Buyer will pay reasonable labor and handling charges for each product returned for repair which is found to have no defect.
Return Your Failed Unit
When you return the failed product it must be shipped freight prepaid. Always note the RMA number on the outside of the package.
Install the Replacement Unit
You are responsible for installing the replacement unit.
After receiving the replacement unit please call I-O Customer Support if any assistance is required.
I-O reserves the right to change the terms and conditions of this policy without notice.
11
