IOT-Smart Solutions MPTZ20XIRIP-TA Instruction Manual

Manual operation
V2.12
MPTZ20XIRIP-TA
Network HD IR High Speed PTZ Camera
http://iotsmartsolutions.net

１
I. Notes for Attention
1. Read the manual carefully before installing the product.
2. There are two input ways of power supply: DC12V. Detailed connections refer to the
description files.
3. There are sophisticated optical and electronic components inside the product. Avoid incorrect
operation methods such as heavy pressing or strong vibration during the course of transportation,
store and installation otherwise the product could be damaged.
4. Please do not dismount components inside the product to avoid occurrence of trouble. There is
no part inside the product, which needs repair by customer himself.
5. Observe all electric safety standards in application and adopt special power supply attached the
product. RS-485 control signal and video signal should be kept enough distance with the high
voltage devices and cables during the course of transmission, and take protection measures such
as anti-lightning and surging etc. if necessary.
6. Do not apply the product under the state exceeding limited temperature, humidity or
specifications of power supply.
7. Do not aim the camera at the sun or very bright object, aim or monitor bright and still object for
a long time whether the power supply of the camera is switched on or off.
8. Clean out dirt with special lens tissue if dust is stuck on the lens.
II. Description of Functions
This product is a high-tech monitor and controller which incorporates high definition color camera,
universal variable pan/tilt, infrared lighting, multi-functional decoder, character superimposing,
alarm input/output into a whole, reduces interconnections to a great extent among parts in the
system and rises up the reliability of the system. In addition it has advantages of easy installation
and maintenance, beautiful appearance, lightweight and flexible, simple operation etc.
1. Integrated Multi-Protocol Decoder
a. The built-in decoder integrates 9 kinds of communication protocols in maximum. The baud
rate of communication is adjustable. It has strong universality and is compatible with multiple
common systems only by simple setting on the dip-switch.
b. RS485 serial control: addresses of the pan/tilt 1 – 1023.
2. Integrated Panoramic Pan/Tilt
a. 360ºcontinuously rotation for pan range，manual control speed from 从0.9～60rad/s for
adjusting,Preset speed at 100°/S；Tilt range from-90º～90º，manual speed at 40rad/s，preset
speed at 60°/S.
b. Smooth running at low speed with super lower noise. Images have no fluttering.
c. Panoramic monitor without black spot and the positioning accuracy can reach ±0.1°.
3. High Degree of Intelligence
a. Preset memory has as much as 255positions. Data are kept in memory even power is OFF.
b. Horizontal scan between two positions are supported. Scan speed can be altered and
Please read the manual carefully before using the product.

２
direction of pan can be selected freely. The pan/tilt can make scan larger or smaller than
180° between any two positions with adjustable speed.
c. Self-study function of pattern. The system can simulate the PTZ route of user’s operation
within 40 seconds and data are kept in memory even power is failure.
d. Character superimposing function. It can display the address of the pan/tilt, title of the
preset position etc.
e. Long focus speed-limited function. The pan/tilt can adjust automatically the manual control
speed depending on the focal length of the camera. The larger the magnification times, the
slower the manual control speed thus to ensure searching the target rapidly and accurately.
f. Integrated multiple protocols. A lot of communication protocols are integrated inside the
pan/tilt with selectable baud rates from 2400 bps to 19200 bps.
III、Setup of the Intelligence Full-Dome Pan/Tilt
Before installing the product, first of all confirm the communication protocol and the baud rate of
the main machine in the system, then set the dip-switch SW2 of the pan/tilt to be identical with that
of the system, set the address of the pan/tilt on SW1 and the type of the communication protocol and
the baud rate on SW2.
Dip-Switch of Address Dip-Switch of Protocol
（Figure 1）
2．Power supply panel for the PTZ：
Input voltage is DC10.8-18V, Iin≥4A;
JP1
JP1 1- 2 2- 3
120R ON OFF
ON DI P
1 2 3 4 5 6
ON DI P
1 2 3 4 5 6 7 8 9 10
3
2
1
Code
1 2 3
JP1

３
3．Dip-Switch ofAddress：
Dome
Address
States of Dip-Switch
DIP-1
DIP-2
DIP-3
DIP-4
DIP-5
DIP-6
DIP-7
DIP-8
DIP-9
DIP-10
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
9
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
10
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
11
ON
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
12
OFF
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
13
ON
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
14
OFF
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
15
ON
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
16
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
17
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
18
OFF
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
… …
1023
ON
ON
ON
ON
ON
ON
ON
ON
ON
ON
SW1 is used to set the addresses of the pan/tilt which has the range from 1 to 1023. From DIP-10 to
DIP-1 it corresponds to a binary number with 10 bits in which the highest bit is DIP-10 and the
lowest bit is DIP-1. The state ON for each bit means 1 while the state OFF means 0. The encodes of
some addresses are as follows:
For example：
Speed Dome Address=1
ON
1 2 3 4 5 6 7 8 9 10
Speed Dome Address=2
ON
1 2 3 4 5 6 7 8 9 10
Speed Dome Address=3
ON
1 2 3 4 5 6 7 8 9 10
Speed Dome Address=4
ON
1 2 3 4 5 6 7 8 9 10
Speed Dome Address=18
ON
1 2 3 4 5 6 7 8 9 10
Speed Dome Address=1023
ON
1 2 3 4 5 6 7 8 9 10
a)The address of the dome camera is set according to the binary coding system in which ON means
“1” and OFF means “0”.
b)The coded addresses shown above are only from 1 to 18 and those from 19 to 1023 are and so
forth.
c)Setup of the protocol: the protocol is set up by the first four bits of SW2 and the baud rate is set
up by the later two bits. Please refer to the following table and set the protocol and the baud rate to
be identical with that of the main machine.

４
4．Selection of the Protocol and the Default Baud Rate:
SW2 is used to set the communication protocol and the baud rate used by the pan/tilt. Bits from
DIP-4 to DIP-1 of the SW2 are used to select the protocol and 9 different protocols can be selected
in maximum. The encoded table of the protocol selected by the pan/tilt is as follows:
5．Setup of the Baud Rate of Communication of the Pan/Tilt（later 2 bits of SW2）
Position of Dip-Switch
Baud Rate of Communication 1 2 3 4 5 6
2400 bps OFF OFF
4800 bps ON OFF
9600 bps OFF ON
19200 bps ON ON
6.Description of the Terminals
A．10-Core Input Terminal
6.1 Description of 10-Core Terminal：
1．NET_TX-（Network 2pin）2．NET_RX+(Network 3 pin）
3．NET_TX+（Network 1 pin）4．Video Output(CVBS)
5．GND 6．POWER-
7．POWER+ 8．NET_RX-(Network 6pin）
9
．
RS485+ 10
．
RS485-
Type or Protocol
Selection of Communication
Protocol
Normal Baud
Rate
DIP-1
DIP-2
DIP-3
DIP-4
DIP-5
DIP-6
PELCO-D
ON
ON
OFF
OFF
OFF
OFF
PELCO-P/4800
OFF OFF ON OFF
ON
OFF
PELCO-P/9600
OFF
ON
Longcomity
OFF
ON
ON
OFF
OFF
ON
HUNDA600
ON
ON
ON
OFF
OFF
ON
KALATEL
ON
ON
OFF
ON
ON
OFF
VCL
OFF
OFF
ON
ON
OFF
ON
ALEC
OFF
ON
ON
ON
OFF
ON

５
IV. Installation of the Product
4.1 Drawing of the Sizes of the Product (Unit：mm)
Outline Sizes of the Pan/Tilt
4.2 Installation Style of the Product
A. Installation Style of Plain Base
Drawing of Sizes of the Side Drawing of Sizes of the Bottom
B．Vehicle -Carried
275
2. 5
20
300
350
260
70
180
From up to down：
1 pin to8 pin

６
Sizes of the ShockAbsorber
4.3 Installation Procedures of the Product
1. Remove the bottom plate of the pan/tilt;
2. Set the corresponding information in accordance with the schematic drawing of the
dip-switch of addresses, protocols and baud rates;
3. Install the bottom plate of the pan/tilt and take care of the tightness of waterproof seal ring;
4. If vehicle-carried pan/tilt is used, first of all fix the chock absorber on the bottom of the
pan/tilt then fix the whole pan/tilt;
5. If the plain base is used, fix the pan/tilt onto the fixation hole of the pan/tilt;
6．Connect the output wires of the socket according to relative colors on the schematic drawing
and do not make wrong connections.

７
Attention: the input of power supply couldn’t be selected and should be connected as per
actual applied style.
V、Main Technical Index
Specifications
Power Supply (Option) DC12V Iin≥4A
Power Consumption
50VA
Weight
7Kg
Installation Style
Plain Base Installation
Relative Humidity
10-90%
Operation Temperature
-35
℃
~55
℃
Waterproof Class
IP66
Iris & Zoom
Automatic/Manual
Basic Functions
of Pam/Tilt
Pan range
100
°
/S max
Tilt range
60
°
/S max
Preset Position
255positions in maximum
Patrol Function
Support
Scanning Speed
0.5
～
30
°
/s
Infrared Lamp
Infrared Illuminator
High Brightness LED X 7pcs
Wavelength
850nm
Project Distance
120m
Power Consumption
10W
Control of Infrared Lamp
Auto/Manual control on menu
Service Life of Infrared
Lamp
Over 20000 hours
