IPC2U IB-8 User manual

User’s Manual
IB-8(2014/May/29)

Copyright
This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all
rights reserved.
Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the
manufacturer.
Disclaimer: The manufacturer makes no representations or warranties with respect to the contents hereof and specifically
disclaim any implied warranties of merchantability or fitness for any particular purpose. The manufacturer is not liable for
technical and editorial error for this guide. The manufacturer reserves the right to revise or make changes to this publication
without notice or obligation of the manufacturer to notify any person of such revision or changes.
Software Licenses
The software included with the product and referenced in this document is furnished under a License Agreement. This
Agreement specifies permitted and prohibited uses of this product.
General Guidelines
Read all of the instructions carefully.
Save the instructions for future use.
To ensure follow all warnings and instructions marked in the product documentation and within the computer.
Except as explained elsewhere in this manual, do not attempt to service the computer yourself. Opening or removing
covers might expose you to dangerous voltage points or other risks. Refer all servicing of marked components to qualified
personnel.

Power Cord Requirements
The power cord you received with this computer conforms to local specifications for use in the country where you purchased
it. Power cord use in other countries mayrequire an additional adapter and/or separate power cord. For additional information
on local power requirements, contact an authorized dealer, reseller, or service provider.
About the AC Adapter
The AC adapter will automatically recognize any compatible power supply connected to the computer. The AC adapter can
also be used to recharge the battery, which begins immediately after the AC Adapter cord is connected. A green LED will light
to confirm charging is in progress. The ideal range for safe operation of the computer is from 100 ~ 240V AC.
1. AC Power Cord / 2. AC Adapter / 3. DC (Direct Current) Cord
Warning :
Using the AC adapter to power other devices can damage the adapter or the device. This AC adapter is onlydesigned for
use with the product.
Be sure to only use the AC adapter that comes provided with this product or a compatible option from the manufacturer.
Other adapters may cause damage to the computer and will not be covered under the warranty.
Grasp the adapter plug and not the cord, when unplugging the adapter from an electrical outlet.
If the power cord becomes damaged (exposed or frayed, etc.), replace with a new AC adapter. Using a damaged cord
may cause an electrical shock and may result in fire.
Power off and unplug the AC adapter from the computer before unplugging it from the electrical outlet.

Battery (Lithium-Ion)
NOTE: Refer to following hazard statement within the service and operating documentation or on the adjacent label
to the battery.
1. English
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
INSTALLED. REPLACE ONLY WITH SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD OF USED
BATTERIES IN ACCORDANCE WITH THE MANUFACTURER'S
INSTRUCTIONS.
2. French
IL Y A DANGER D'EXPLOSION S'IL Y A REMPLACEMENT
INCORRECT DE LA BATTERIE. REMPLACER UNIQUEMENT AVEC
UNE BATTERIE DU MÊME TYPE OU D'UN TYPE RECOMMANDÉ
PAR LE CONSTRUCTEUR. METTER AU RÉBUT LES BATTERIES
USAGÉES CONFORMÉMENT AUX INSTRUCTIONS DU
FABRICANT.
3. German
VORSICHT ! Explisionsgefahr bei unsachgemäßen Austausch der
Batterie.
Ersatz nur durch denselben oder einem vom Hersteller empfohlenem
ähnlichen Typ.
Entsorgung gebrauchter Batterien nach Angaben des Herstellers.
4. Swedish
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent typ som rekommenderas
av apparattillverkaren. Kassera använt batteri enligt fabrikantens
instruktion.
5. Danish
Lithiumbatteri- Eksplosionsfare ved fejlagtig håndtering.
Udskiftning måkum ske med batteri af samme fabrikat og type.
Lever det brugte batteri tilbage til leverandoren.
6. Norwegian
Ekspolsjonsafe ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt av
apparatfabriknten.
Brukte batterier kasseres I henhold til fabrikantens instruksjoner.
7. Finnish
Paristo voi räjähtää, jos se on virheellisesti asennettu.
Vaihda paristo ainostaan laitevalmistajan suosittelemaan tyyppiin.
Hävitäkäyteet paristo valmistajan ohjeiden mukaisesti.

FCC Statement
This equipment has been tested and found to comply with the limits fora Class B digital device, pursuantto part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy, and if not installed andused in accordance with the
instructions, may case harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which to receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cord is required to comply with Class B limits in Subpart B of Part 15 of the FCC rules. Do not make any
changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifications should
be made, you could be required to stop operation of the equipment.
FCC Caution:
1. The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions：
（1）This device may not cause harmful interference.
（2）This device must accept any interference received, including interference that may cause undesired operation.
2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
3. FCC RF Radiation Exposure Statement
This device has been tested for compliance with FCC RF Exposure (SAR) limits. The equipment complies with FCC RF
radiation exposure limits set forth for an uncontrolled environment.
4. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user
authority to operate the equipment.
CE Statement
This equipment has been designed to comply with EMC directive 89/336/EEC
And Decision 768/2008/EC
As an amended by 92/31/EEC and the Low Voltage directive 2006/95/EC,
This equipment has been comply with EMC directive 2011/65/EU And Decision 768/2008/EC
Manufacturers will need to test and approve the product to these directives.

Table of Contents
BEFORE USING YOUR COMPUTER ...................................................1
Product Features............................................................................. 2
Installation Guidelines...................................................................... 4
CHAPTER 1..................................................................................6
GETTING STARTED..........................................................................6
Unpacking the Product .................................................................... 7
Packing List ..................................................................................... 7
Power Supply .................................................................................. 8
Using the Battery ....................................................................................8
To install and remove the Battery Pack...................................................9
Installing the Battery/ Remove / Replacing the Battery...........................9
Caring for the Battery……………………………………………………….10
Using the AC adapter...........................................................................10
CHAPTER 2................................................................................ 11
SYSTEM OVERVIEW ...................................................................... 11
Front View of the Computer........................................................... 12
Right Side View of the Computer................................................... 15
Left Side View of the Computer..................................................... 16
Bottom View of the Computer........................................................ 17
Top View of the Computer ............................................................. 18
Rear View of the Computer ........................................................... 19
CHAPTER 3................................................................................21
PROTECTING AND MAINTAINING .....................................................21
Caring for Your Computer.............................................................. 22
Routine Care........................................................................................22
Caring for the Battery...........................................................................22
Caring for the AC Adapter....................................................................23
Caring for the Touch Screen Display ................................................... 23
Configuring DRAM and SIM Card.................................................. 24
Adjusting the Video Resolution...................................................... 25
Changing the Video Resolution of the Computer.................................25
CHAPTER 4................................................................................26
SPECIFICATIONS &SOFTWARE.......................................................26
Specifications and Standard Features .......................................... 27
Software ........................................................................................ 31
Using the Smart Panel to Calibrate the Screen...................................31
Using The Front Panel Hot Key Utility .................................................32
Define the function for Hot Key Utility..................................................36
Using the Bluetooth Utility, BlueSoleilTM............................................... 38
Making a 3.5G Connection and Disconnection.................................... 40
Using the CMOS Camera.................................................................... 41
Using The RFID ...................................................................................42
Using the Minismart card .................................................................... 43
Using the Barcode Scanner.................................................................44

Using the MSR.....................................................................................46
Using the GPS..................................................................................... 47
Using the Fingerrprint Function ...........................................................49
warning…………………………………………………………………… 5 2

B
Be ef fo or re e U Us si in ng g Y Yo ou ur r C Co om mp pu ut te er r
Congratulations on your purchase of the product.
You will soon be in command of the worlds most lightweight,
efficient and secure solution for managing all of your
technology and mission critical data. Scale the computer and
streamline the costs of day-to-day business operations and
multimedia demands. Discover the computer’s unparalleled
in-the-field versatility for efficiently and reliably coordinating a
myriad of tasks without costing a fortune.
Chapter Preview:
Product Features
Installation Guidelines

The Instructions Manual
2
Product Features
The product is a portable multimedia device empowering highly mobile users
with wireless computing capabilities for day-to-day business and wireless
applications. Its light weight and supreme portability combined with
state-of-the-art multimedia capabilities provide exceptional writing,
maneuvering, and on your feet computing. The product’s primary features
include:
Processor and OS (Operating System): INTEL Bay Trail-M Quad
Core N2930 1.86GHZ Processor and Microsoft®Windows
Embedded Standard 7 & 8 & 8.1/ Microsoft®Windows 7 & 8 & 8.1
Professional / Linux OS,a stable platform, providing exceptional
performance for highly mobile users under extreme and variable
conditions.
Multimedia LCD Display: 8 ”-inch TFT 1024X768 (XGA) LCD with Touch
Screen Control Panel (LED back light / Sunlight readable) and Smart Panel
Application enhancing user’s ability to view data outdoors and under
moving conditions.
Complete Connectivity from Anywhere: The computer’s built-in
Bluetooth 3.0®, IEEE 802.11b+g+n WLAN and 3.5G Module offers the
mobile user the maximum opportunities to stay connected from anywhere,
ensuring uninterrupted data sharing and synchronization. Limitless instant
accesses to business critical information.
Integrated Ports and Adaptability: Multiple I/O ports (2 x USB 2.0,
Ethernet,RS-232 Port) provide optimum versatility for any industrial or
Business needs. Its ultra light weight and integrated wireless capability
enable an effective mobile office. Multiple carrying options provide quick
on-the-fly versatility while executing daily tasks comfortably and efficiently.
