IPEX PH422REPi User manual

Doc No: PH422REPi-UM-001
USER’S MANUAL
IPEX
(IP Electronix)
15 August 2013
PH422REPi
RS-422 (4-Wired RS-485) Repeater & Amplifier

www.ipelectronix.com
IPEX (IP Electronix) PH422REPi
: User’s Manual
Page 2 of 8 Doc No. : PH422REPi-UM-001
15 August 2013

www.ipelectronix.com
IPEX (IP Electronix) PH422REPi
: User’s Manual
Page 3 of 8 Doc No. : PH422REPi-UM-001
15 August 2013
Contents
1INTRODUCTION .......................................................................................................................................4
2SPECIFICATIONS ......................................................................................................................................4
3PACKAGE CHECKLIST ............................................................................................................................... 5
4TOP PANEL ..............................................................................................................................................5
5POWER SUPPLY .......................................................................................................................................5
6RS-422 CONNECTING METHODS ..............................................................................................................6
7GUARANTEE ............................................................................................................................................8
8TECHNICAL SUPPORT...............................................................................................................................8

www.ipelectronix.com
IPEX (IP Electronix) PH422REPi
: User’s Manual
Page 4 of 8 Doc No. : PH422REPi-UM-001
15 August 2013
1Introduction
IPEX PH422REPi™ is a RS-422 Repeater and Amplifier. If it is needed to have RS-422 network with more than
1200m length or to have more than 32 nodes, using a PH422REPi™ helps you to increase the network length up
to 2400m and also to have up to 64 devices connected to it. PH422REPi™ is compatible with RS-422 standard
devices differential TX+, TX-, RX+ and RX- signals and is fully Plug & Play. It works with a wide range of +10V up
to +30V DC power supply with low (about 45mA) consumption. PH422REPi™ is designed for industrial usage
and is useful for Industrial Automation, Telecommunications, SCADA Systems, and DCS Systems …
Protection against Surge, ESD and EMI is considered in its design and also has 3kV isolation between RS-422
sides. PH422REPi™ is Full-Duplex converter and supports Point-to-Point and Multidrop RS-422 network
topologies.
2Specifications
RS-422 Bidirectional Repeater and Amplifier
Fully Plug & Play
RS-422 Signal: TX+, TX-, RX+, RX- and GND
Baud Rate Type: Auto Switching Baud Rate
Serial Transmission Speed Up to 230.4 kbps
Maximum Communication Distance: 2400m (8000 feet) – 1200m for each side
Loading: Supported up to 64 Nodes – 32 Nodes for each side
Isolation Protection: 3kV Instantaneous, 500V DC continuous
Power (Green) LED Indicator
Transmit (Blue) and Receive (Yellow) LED Indicator
Power Supply Input Voltage: +10VDC to +30VDC
1 Year Guarantee and 5 Years Support
Operating Temperature: -10°C to +70°C (+14°F to +158°F)

www.ipelectronix.com
IPEX (IP Electronix) PH422REPi
: User’s Manual
Page 5 of 8 Doc No. : PH422REPi-UM-001
15 August 2013
3Package Checklist
Before installing the PH422REPi, verify that the package contains the following items:
1) PH422REPi
2) Installation CD-ROM
3) #2 Phonix 7Pin Green terminals
NOTE: Notify your sales representative if any of the above items is missing or damaged.
4Top Panel
Green LED: It is turned ON, when the power supply connects to +VS and GND correctly.
Yellow LED: It is blinking if there is a data stream from right to left side of the repeater.
Blue LED: It is blinking if there is a data stream from left to right side of the repeater.
5Power Supply
Connect a DC voltage in range of +10V to +30V, between +VS and GND terminals. If the power supply connects
correctly, the Green LED should be ON.
NOTE: It is not required to connect GND signal from one side to GND signal of other side.

www.ipelectronix.com
IPEX (IP Electronix) PH422REPi
: User’s Manual
Page 6 of 8 Doc No. : PH422REPi-UM-001
15 August 2013
6RS-422 Connecting methods
6.1 0BRS-422: Point to Point (Without Repeater)
6.1 0BRS-422: Point to Point (With a Repeater)

www.ipelectronix.com
IPEX (IP Electronix) PH422REPi
: User’s Manual
Page 7 of 8 Doc No. : PH422REPi-UM-001
15 August 2013
6.2 RS-422: Multi Drop Network (Without Repeater)
6.3 RS-422: Multi Drop Network (With a Repeater)

www.ipelectronix.com
IPEX (IP Electronix) PH422REPi
: User’s Manual
Page 8 of 8 Doc No. : PH422REPi-UM-001
15 August 2013
7Guarantee
All products manufactured by IPEXare under warranty regarding defective materials for a period of one year
from the date of delivery to the original purchaser.
8Technical Support
If you have any technical question or need any technical support, please contact us using this Email address:
[e-mail].
