IQCCTV HD 960H User manual

User Manual
Version 1
Adjustable Viewing
Angle (23 to 92°)
IR
Night Vision
30m
Weatherproof
Rated
IP66
HD
Resolution
HD 960H
HD 960H Dome Camera
with 30m IR Night Vision

1. Product Overview ......................................... 4
1.1. Product Features ......................... 4
2. Product Contents ........................................ 5
3. Installation .................................................. 6
4. Installation Diagram .................................... 8
5. Specifications .............................................. 10
Contents

3
Warning
Caution: To prevent electric
shock and fire hazards, please
don’t use a power supply not
listed oin the manual.
Warning: To reduce the risk of
electric shock, non-professional
personnel should not remove the
cover.
This symbol alerts the user to operate and maintain the
product according to the manual.
This symbol alerts the user to be careful as the product may
lead to serious shock hazard.
Caution: Any changes or modifications in construction of the
product that are not approved by our company, may affect the
functionality of the camera.
Install and use the camera in an environment that does not
exceed -20°C ~ +55°C and maintain good ventilation.
Do not use the camera in a high pressure or highly corrosive
environment.
This may cause the camera to malfunction or damage the camera.
Do not install the camera in a place where lighting conditions are
not stable.
Drastic illumination changes could cause the camera to malfunction.
Precautions

4
1. Product Overview
Adjustable Viewing
Angle (23 to 92°)
IR
Night Vision
30m
Weatherproof
- IP65 Rated
HD
Resolution
Plug and Play Cable Managed
Design
High Resolution 960H
30m IR Night Vision
Automatic Gain Control
23-92° Adjustable Angle
Durable Metal Casing
Compact and Discreet
Cable Managed Design
Easy Installation - Plug and Play
Internal/External
IP66 Rated
Thank you for purchasing the IQC960VV Internal/External Dome
Camera from IQCCTV.
The camera features a high quality adjustable wide-angle lens (23-92°)
to capture more, clear images. The mini dome is ideal for indoor or
outdoor use (IP65 Rated) and has up to 30 Metres IR Night Vision.
The IQC range of 960H cameras from IQCCTV are designed to offer
crystal clear images and amazing value for money, this is achieved by
removing high-end features not needed in everyday applications.
1.1 Product Features

5
2. Product Contents
Before installing this product, please ensure that it contains the
following;
Contents
1x IQC960VV
Dome Camera
1x User Manual
User Manual
Version 1
Adjustable Viewing
Angle (23 to 92°)
IR
Night Vision
30m
Weatherproof
Rated
IP65
HD
Resolution
HD 960H
HD 960H Mini Dome Camera
with 30m IR Night Vision
1x Installation Pack

12v DC Input
Power Cable
BNC
Video Cable
1. Unscrew the base of the camera
by holding the bottom and
moving the ring anti-clockwise.
2. Use the camera base as a template
and mark out the holes in the
wall/ceiling where you wish to install
the camera.
3.Get the correct drill bit for the type
of wall you are drilling, then drill
the holes in the wall and insert the
wall plugs into the holes.
4. Take the base and feed through
the camera wires. (You can drill a
hole through the centre of the base
and feed the wires through the
wall/ceiling. But for this example we
have just fed through the base for
the cableto be external).
6
3. Installation
5.Screw the camera base into the
wall or ceiling.

6.Screw the bracket and camera
back onto the base by turning the
ring clockwise. Please don’t
tighten completely if you wish
to change the camera angle.
7
7. Adjust the camera angle to
the desired view. It would be
advised to use a test monitor
when choosing the angle, to
get the perfect angle for
your application.
8. You can adjust the focus and
zoom on the camera using the
tool provided. To adjust, simply turn
the screw marked ‘focus’ or ‘zoom’
to adjust the view. Insert the tool
into the slots on the face of the
camera.

DVR
TV/Monitor
Power Supply
For Camera
MAINS
POWER
BNC
Video lead
BNC Input
Power
Jack
PLUG & PLAY
CABLE
HDMI
4
5 6
8
9
Power Supply for camera(s)
(Do not use DVR PSU)
Power Lead
Use a power splitter lead to
power more than one
camera.
Plug & Play
Cable
Connect DVR to VGA Monitor
Connect DVR to
TV/Monitor
VGA output also available to
connect to a monitor. * VGA
Cable not included
Connect the HDMI
output from the DVR to
your TV/Monitor HDMI
input. *Monitor not
included.
10
Router
Network
Cable
BNC
Video lead
8
* * *
* *
*
* Not Included
Camera
Power Lead
Power
Jack
4. Installation Diagram
*
*
*

9
To Connect Cable to Camera(s)
To Connect Power to the Camera(s)
Connect the power lead coming from the camera to the power jack on
the Plug & Play cable
Connect the BNC connector from the camera to the BNC on the Plug
& Play cable
Connect the power socket on the cable to the Power Supply – See
additional information for connecting more than 1 camera
To Connect Cable to the DVR
Connect the BNC connector to the required channel input on the DVR
To Connect Cable to Router
Connect the Network Cable to the DVR then to a Router
Network Access *Router not included
for
1
2
3
5 6
810
78
To Connect Cable to TV/Monitor
Connect the HDMI Lead to the HDMI output on the DVR then to the
HDMI Input on your TV/Monitor *TV/Monitor not included
8
9
Your system is now ready to use
4

10
5. Specications
Image Sensor High Resolution CMOS Image Sensor
Resolution 800 TVL
Lens Size 2.8 - 12mm
DSP Functions
Automatic Electronic Iris
Automatic Electronic Shutter
Automatic Gain Control
Minimum Illumination 3 Lux (IR Off), 0 Lux (IR On)
Night Vision 20-30m IR Night Vision
Power Supply 12v DC ±10%
Weatherproof IP65 Rated
Automatic White Balance
Backlight Compensation
Dimensions (WxHxD) 120x95x120mm

11
Notes

TECHNICAL SUPPORT
For technical support, please contact your local distributor.
Alternatively, call 0871 222 1430
