Introduction
Thanks for buying the IRIS065 Miniature IP Dome Camera from
Iris Innovations.
The IRIS065 is part of our best selling IRIS06x range of dome
cameras, made successful due to its stylish, miniature design
and quality reliable performance.
If youʼre looking for a great all round camera with superb
resolution, day/night operation and neat, unobtrusive styling, all
in a tiny, robust housing, the IRIS065 Compact Fixed Dome is
the camera for you.
Based around Irisʼs best selling IRIS060 camera, the new
IRIS065 measures only 6cm (2.36″) in diameter by 5.8cm
(2.28″) high. Itʼs stylish, rounded body is cast from aluminium
which is then anodised and powder coated in a marine white
finish for environmental protection.
The camera module itself is a new multi format low-light camera
which uses the latest 1/2.8” ultra wide 1080P sensor and DSP
Processor.
The IRIS065 is available in PAL or NTSC video systems and
outputs multiple video formats for maximum compatibility and
the highest resolution. Video output format: Composite Video
(CVBS),
Overview of Key Features
Hereʼs a brief list of some of the IRIS065ʼs key features:
•1280(H) x 960(V)
•1000TVL Resolution
•High Performance LEDʼs - 10 Meter Range
•Mechanical IR Cutout filter for True Day / Night Operation
•Low Power 12VDC Operation <100mA
•IP66 Ingress Protection
•Small, Compact Housing
•Suitable for Multiple Applications, such as on-board security,
sports fishing, engine room monitoring and vehicle
monitoring.
•Wide Operating Temperature Range
•Compatible with Chart Plotters that have composite video
inputs.
Contents of Package
Please unpack your IRIS065 and check to make sure the follow-
ing items are included. If there are any items missing please
contact your Iris dealer:
•1 x IRIS065 Marine Mini Dome Camera
•1 x Fixing Pack
•1 x Instruction Manual
•1 x Connector kit
v1.0/04-07-18
Iris Innovations Unit 15 Fareham Innovation Center, Meteor Way, Lee on Solent. Hampshire PO13 9FU T [phone] www.boat-cameras.com

Camera Overview
The diagram below details the various parts of your
camera:
Warning!
Camera Installation Sequence
The diagram below shows the sequence in which the
camera parts are fit into place during installation...
Warning!
It is strongly advised that the camera is powered up
and connected to a monitor / computer to check the
desired field of view prior to fixing the camera in
place.
Iris do not accept any liability if the camera is
installed and does not cover desired field of view.
1. Fit Base
2. Slide camera cable through base
3. Set desired camera field of view
4. Slide Cowling over inner dome onto base
5. Tighten Grub Screws
!5
Inner Dome
Lens
Photo-Diode
(Light Sensor)
Infra Red LEDs
Cowling
Lock Screw
(in 2 positions)
Base
FULLY LOOSEN PRIOR TO
ADJUSTING INNER DOME POSITION
(BOTH SIDES OF CAMERA)
TO AVOID DAMAGE TO THE CAMERAS PAINTWORK
WHICH COULD RESULT IN EROSION TO THE
HOUSING, ENSURE THE GRUB SCREWS ARE FULLY
LOOSENED BEFORE MAKING ANY POSITIONAL
ADJUSTMENTS TO THE INNER DOME.
FAILURE TO DO SO WILL INVALIDATE ANY
WARRANTY CLAIM IF THE PAINTWORK IS
SCRATCHED OR DAMAGED.

Installation
WARNING!
Only trained electrical installers or competent persons
should install this product. Incorrect installation could lead
to personal injury or death and/or damage to property.
Ensure the electrical regulations specific to your region are
observed, and observed wiring colour conventions.
Ensure the cameras power supply is connected via a
suitably rated fuse or circuit breaker.
Switch off the power supply you are working on whilst
installing the camera, until the product is correctly installed.
Step 1:
Offer base into desired mounting position and mark off
screw hole positions and cable entry position through the
mounting surface.
TIP!
Power up camera and check to ensure you have the
desired field of view prior to drilling any holes and mounting
the camera in place.
Step 2:
Fit the camera base into position. Drill pilot holes
appropriate for the fixings you are using, and then screw
base into place, observing caution not to splinter or
damage the surface if fitting onto a GRP surface.
Step 3:
Present your cables to the camera through the cable entry
hole you’ve just drilled. Connect up the video connector
(BNC plug). Ensure your power cable is either switched off
or disconnected from the supply then connect the power
cable to the camera. It is recommended that a waterproof
amalgamating tape or other suitable waterproof tape is
used to protect the connections from moisture ingress.
Step 3:
Slide the ‘slack’ cable from the camera back through the
hole in your panel, ensuring connectors are still in tact and
sit the inner dome onto the protective foam / rubber ring
on the base.
Step 4:
Place the cowling over the inner dome and move into
position. The cowling will fit over the inner dome and push
up to the base. Once in position, carefully tighten the grub
screws until they lightly hold the inner dome in position.
Now power up the camera and check you have achieved
the desired field of view. If any adjustments are required,
loosen the grub screws to make the necessary
adjustments, lightly tighten and then check again. Repeat
until you have the desired field of view. Once you are
happy with the cameras position, tighten the grub screws.
Step 5:
Connector the video cable into the composite input of your
chartplotter. Note - The type of connector may vary
depending on your plotter. A BNC Through-Piece
connector and a BNC-RCA adapter are included with your
camera.
Step 6:
Finally connect to a suitably rated, protected 12VDC
supply and test.
