IRIS IRIS604 User manual
IRIS604
Analogue Video Switcher with Quad View
QUICK START GUIDE
Thank you for choosing the IRIS604 Four Channel Quad
Video Switcher from Iris Innovations.
This document is designed to provide a brief overview of
the product, it’s features and installation instructions. Full
instructions, regulatory and safety information can be
downloaded from our website: www.boat-cameras.com
The IRIS604 Quad Switcher is a four input / two output
analogue video switcher in a compact and rugged
enclosure designed for harsh environments.
The switcher is designed to be hidden away out of view
and controlled via the company IRIS540 panel mount
keypad to provide an intuitive and elegant video switching
solution whilst at the same time hiding any unsightly
wires, cables and connections - a feature especially
desirable in high end luxury boating or vehicular
applications.
The IRIS604 features a duplicate output so video can be
switched on upper and lower helm monitors or chart
plotters. Accordingly, two keypad ports are included so
the unit can also be controlled from two positions.
Outputting 75Ωcomposite video 1VP~P, the IRIS604 is
compatible with any multifunctional display, chart plotter or
screen with analogue / CVBS / composite or AVI labelled
video inputs.
Rugged & Compact
With its stylish and compact form factor, heavy duty
plastic moulded case and water resistant locking
connectors, the IRIS604 box can be installed anywhere
on board, even in areas subject to exposure to moisture.
Easy Installation
Four hidden screws are all thats needed to install the
system. Then just plug in your cables, power up, and
you’re good to go! www.boat-cameras.com
ESSENTIAL SAFETY NOTICES:
Product Disposal and Recycling:
Dispose of this product in accordance with the WEEE
Directive. The Waste Electrical and Electronic
Equipment (WEEE) Directive requires the recycling of
waste electronic and electrical equipment. Iris
Innovations supports the WEEE policy and politely
request you observe correct disposal methods. For
further information on how to correctly dispose of this
product please contact Iris Innovations. Please recycle
unwanted packaging and documentation. The
cardboard carton, all paper manuals and documents
and the protective plastic bag in which the camera is
shipped are widely recyclable. Please check with your
local recycling plant for confirmation.
EMC Guidelines:
This camera is designed to be used as a visual aid and
is not part of the vessels navigational system - even if
used in conjunction with other on board equipment or
third party systems - and is compliant with the EMC
directive 2014/30/EC. The original Declaration of
Conformity (DoC) is available from our website The
camera should not be installed on the ships helm or in
close proximity to radio receiver equipment. We
recommend the camera is installed no closer than 1m
from any equipment transmitting or cables carrying
radio signals - particularly VHF radios and associated
equipment. The camera should be powered from a
clean 12VDC supply.
Water Ingress:
Disclaimer This product has been tested and complies
with the requirements of the standard EN60529 to level
IP66, however, water intrusion and subsequent
equipment failure may occur is subject to commercial
high pressure washing or sustained exposure to water
spray. This product is not designed to be completely
submerged. Any damage caused as a result of these
circumstances are not covered by the product
warranty.
Full product safety, warning and compliance
information, including Declaration of conformity is
available from www.boat-cameras.com
What’s in the Box?
The following parts are included with your IRIS604
Quad Switcher
1 x IRIS604 Quad Switcher Box
1 x IRIS540 Switcher Keypad
1 x Fixing Template
1 x Quick Start Guide
1 x CAT5 Cable (For IRIS540 Keypad)
1 x Power Cable (12VDC) - 2 Pin Connector
Installation - Switcher Box
Offer the switcher box into your desired position,
ensuring there is sufficient clearance space to allow
connection and disconnection of the attaching cables.
At either end of the box lid there is a cover flap which
conceals the screw fixing points. Once placed in the
desired position, lift the flaps to reveal the screw shafts,
insert a self tapper screw (supplied) into each of the
four shafts and screw in place.
A fixing template is provided for you to mark off and pre-
drill pilot holes if required.
Installation - IRIS540 Keypad
Remove the lock nut from the back of the connector
and retain.
Offer the keypad up to the desired position, carefully
ensuring there are no cables or obstacles behind the
panel which could become damaged when you drill the
connector hole.
A fixing template is available to download from
www.boat-cameras.com. Use this to determine the
centre point for the hole that must be drilled to
accommodate the keypad connector.
Drill a suitable pilot hole if necessary before opening the
hole out to 30mm using a hole saw.
Installation - Keypad (cont…)
Use a suitable marine grade sealant to apply a bead
around the edge of the back of the keypad. Ensure the
bead of sealant is continuous so as to form a seal
around the entire perimeter of the keypad. It is
recommended that you apply the seal a centimetre or
so in from the edge of the keypad so the silicone does
not extrude past the edge of the keypad bezel when
firmly fixed in place.
Push the keypad down, wiping away and extraneous
sealant that has been pushed out during fitting.
Level~off the keypad so it is flush and level.
Tightly fit the lot nut back onto the cable connector from
the rear - ensuring the keypad remains level as you
tighten. Leave until the sealant has cured in accordance
with the manufacturers instructions and cure times.
Installation - Cable
Finally connect the CAT5 cables supplied to the
connector on the keypad and to the appropriate
Keypad port on the switcher.
The switcher has two ports to allow connection of an
additional keypad if required.
IMPORTANT - Cable Information!
If extending, or installing your own keypad cable you
must use screened CAT5/6 cable and couplers.
IMPORTANT - Connection Warning!
Although the system uses CAT5/6 network cable, this
is not an ethernet device and therefore MUST NOT be
connected to any network equipment so as network
hubs / switches / routers / PoE equipment or
computers. Keep cabling for the switcher separate from
any structured cabling used for an ethernet network.
Video Inputs
The switcher is designed for 75Ω1VP~P analogue
composite video. Video connections are via female
BNC connectors, therefore your video cables must
terminate with the appropriate 75Ωmale BNC plug.
Video Outputs
The switcher is designed for 75Ω1VP~P analogue
composite video and features two output connectors
(sharing the same video output). Video connections are
via female BNC connectors, therefore your video cables
must terminate with the appropriate 75Ωmale BNC
plug.
Power
The switcher must be powered from a clean 12VDC
source. A two pin power cable is supplied with colour
coded tails to connect your power. Red must be
connected to +12VDC and Black must be connected
to DC Ground. ENSURE CORRECT POLARITY IS
OBSERVED TO AVOID POTENTIAL DAMAGE &
INJURY.
Operation
Ensure all connections are made before powering up.
When the system has powered up, you will briefly see a
colour bar pattern flash on the screen as the system
initialises, then the quad view will be displayed.
Switching Camera Inputs / Quad View
To switch individual camera inputs, simply press the
corresponding input number on the IRIS540 keypad.
To switch to quad view (all four cameras displayed in 2x2
layout on the screen together) simply press the QUAD/
MENU button.
Picture in Picture / Split Screen
Use the PinP/SPLIT button to cycle through the various
picture in picture / Split screen displays.
SETUP MENU NAVIGATION
The IRIS604 Quad unit features an on screen set up
menu function. From here you can define regional video
format (PAL / NTSC), set up auto-sequences and dwell
times (per input), change camera titles and a variety of
other features.
To enter the SETUP MENU, press and hold the QUAD/
MENU button for approx 3 seconds.
To navigate around the menu system and make
changes, the numeric (1,2,3,4) keys also have directional
arrows (1 = UP, 2 = DOWN, 3 = LEFT, 4 = RIGHT). Use
1(UP) and 2(DOWN) to select the desired menu item, the
ENTER key to select specific functions and the 3(LEFT)
and 4(RIGHT) buttons to increase and decrease values
or cycle through the options.
Iris Innovations Limited
Unit 240 Ordnance Business Park, Aerodrome Road
Gosport. Hampshire PO13 0FG. United Kingdom
www.boat-cameras.com
Manufactured & Assembled in the United Kingdom
Video Format
1VP~P Composite Video / 75Ω
Regional Formats
PAL / NTSC Switchable
Video Inputs
4
Video Outputs
2 (Same Image x 2)
Keypad Connections
2 x RJ45 Shielded - USE SCREENED CAT5
Network
THIS IS NOT A NETWORK DEVICE
Compatible Keypad
1 x IRIS540 Supplied + Additional IRIS540
(Optional)
Features
Full Image Switch (4 cameras), Quad Image,
7 x Picture in Picture Options, Definable
Auto-Sequence, Image Freeze
Motion Alarm
Special Order - Contact Iris
Material
ABS Plastic
Power
+12VDC / <500mA
Consumption
4W Nominal
Operating Temperature
-30˚C ~ +60˚C
EMC
EN60945 Sections 9 & 10
Environmental
IP66
Dimension/mm
IRIS604: 280mm x 176mm x 60mm
IRIS540 Keypad: 74mm x 74mm x 6mm
Weight/g
0.885Kg
SELECTED SPECIFICATIONS:
Full specifications are listed in the complete product
guide which can be downloaded from our website.
IRIS540 Keypad
MAIN SETUP MENU:!
SYSTEM SETUP MENU:!
DISPLAY SETUP MENU:
AUTO-SEQUENCE MENU:!
CAMERA SETUP MENU:!
Please Note:!
Motion Setup & Event Setup Menus are not supported
in this model.
