IRIS IC-SB1U Series User manual

CONTENT PAGE
Safety Precautions........................3
Parts ..................................6
Assembly ...............................7
Wall Mount Installation.....................8
Usage Instructions
How to Use.............................10
Cleaning and Maintenance.................12
Other
Troubleshooting .........................15
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . .16
Warranty ..............................17
by IRIS USA, Inc.
Series IC-SB1U
Thank you for your purchase. Please read this instruction manual carefully to ensure proper
use. Read all safety precautions prior to use. Please store this instruction manual in a safe
place for future reference.
READ AND SAVE THESE INSTRUCTIONS
Lightweight Vacuum Cleaner

SAFETY PRECAUTIONS
Disassembly prohibited.
• Do not disassemble, repair, or modify. Doing so can cause fire, electric shock, or injury.
• Repair by persons other than trained repair technicians can be dangerous.
Product use.
• For household use only. Do not use for commercial use. Do not use product for anything other than its
intended use. Doing so could cause the product to malfunction or cause fire.
• Do not use the product outdoors.
• Before use, make sure that the filter is installed correctly. Use only manufacture recommended filter.
• Please do not splash or immerse the vacuum in water.
• Do not use near water or in spaces with high humidity levels, such as bathrooms.
• Please do not clean large amounts of litter/debris in one pass to avoid blocking the intake port and
decreasing suction.
• Do not use to clean liquid or damp materials as this may cause a short circuit, electrical shock or breakage.
• Pick up the device by the handle to avoid risk of dropping and property damage.
• Do not run the vacuum for extended periods of time.
• Do not drag the device as this may damage the floor.
• Do not drop, break, hit against other objects or put pressure on the vacuum.
Cleaning and replacement parts.
• Please change any replaceable parts per manual directions.
• Please clean dust off the device regularly to avoid buildup resulting in poor insulation.
• To avoid electrical shock or accidentally starting the unit, please unplug before changing replaceable pieces.
• Please clean the contents out of the dust cup, and avoid collected dust splattering.
• Do not use without the dust cup and/or filters in place.
• Clean using a fully wrung cloth. See Cleaning and Maintenance for further instructions.
• Bag holder is not replaceable. Please contact IRIS USA, Inc. Customer Service Department when damaged or
lost.
• Only use manufacture recommended dust bag. Using another dust bag may cause damage to the product.
Also attach dust bag correctly.
• Do not use a torn dust bag. This may cause dust to scatter, which can contaminate the surrounding air and
cause health issues if inhaled.
• Do not remove dust bag or wind the power cord while operating vacuum cleaner.
• Please properly assemble the dust bag set and place it into the device to avoid injury or product damage.
• Do not use when extension pipe is broken. This may cause damage or injury. Please contact IRIS USA, Inc.
Customer Service Department.
• Do not use if the intake port is blocked.
• To avoid deformation or damage of the product and to reduce the risk of fire, do not block intake port.
Use power plugs and power cords correctly.
• Please use only in a 120V AC outlet. Do not charge in a DC outlet or with an electric generator as this may
cause fire or electrical shock.
• To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other).
This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any
way.
• Please remove the plug from the outlet and remove dust or dirt regularly to avoid electrical shock or injury.
• Please be sure that the plug is tightly inserted into the power base to avoid electrical shock, short circuits or
fire.
• Please do not insert or pull plug with wet hands to avoid electric shock, burn, or injury.
• Do not damage, modify, bend forcibly, pull, twist, pinch, or put heavy objects on the power cord. This may
cause damage to the cord, fire or electrical shock.
• Do not bundle and use the power cord. This may cause overheating the cord or fire. Be sure to extend the
power cord.
• Do not use outlet or extension cords if they exceed power ratings.
• When removing the power plug from the socket, please ensure that the machine has stopped running. Not
doing so may cause damage to the plug blades or socket, or may cause a fire.
Abnormalities and malfunctions can cause smoke, re, or electric shock.
Stop use immediately, cut power, and unplug from the electric socket when abnormalities or malfunctions occur.
Examples of Abnormalities
• Abnormal sounds or odors.
• Power plug or power cord become abnormally hot.
• Loss of power, etc. when power cord is moved.
• The product periodically stops during operation.
• Tingling sensation from electric current felt when the product is touched.
• Stop use and contact IRIS USA, Inc. customer service at 1-800-320-4747.
Safety precautions continue on page 3.
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE)
When using an electrical appliance, basic precautions should always be followed. Please read the manual before use and
carefully follow all safety precautions to avoid injury or property damage and to reduce the risk of fire or electrical shock. Save
the instructions in a safe place for later use.
Graphic Symbol Indications: Indicates content that could lead to death or injury if handled incorrectly.
CAUTION PROHIBITED INSTRUCTIONS THAT MUST BE FOLLOWED
WARNING - To reduce the risk of re, electric shock, or injury:
a. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
b. Do not allow to be used as a toy. Close attention is necessary when used by or near children.
c. Use only as described in this manual. Use only manufacturer's recommended attachments.
d. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service center.
e. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners.
Do not run appliance over cord. Keep cord away from heated surfaces.
f. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
g. Do not handle plug or appliance with wet hands.
h. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything
that may reduce air flow.
i. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
j. Turn off all controls before unplugging.
k. Use extra care when cleaning on stairs.
l. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be
present.
m. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
n. Do not use without dust bag and/or filters in place.
o. Do not use outdoors or on wet surfaces.
SAVE THESE INSTRUCTIONS
1 2

Power cord
Cord holder
Handle
Power cord
Power plug
Sponge filter (inside)
Extension pipe
Cover button
Cord hook (bottom)
Dust cover
Cord hook (top)
Magnet
Bag holder
Dust bag
Dust intake port
Brush
Main body
Exhaust port
WALL ATTACHMENT PARTS
Collection head
DUST BAG SET
*1 disposable dust bag
is already attached
when shipped.
*1 disposable dust bag is already
attached when shipped.
REPLACEMENT DUST BAG
Wall mount
Screws (2)
Adhesive sheet
*Use these when hanging the vacuum on the wall.
Dust bag: 25 bags
PARTS
To avoid risk if injury or property damage, please do not place the vacuum where it could fall.
CAUTION
SAFETY PRECAUTIONS
Avoid re hazards.
• Please keep away from heat as this may damage the vacuum and can result in a short circuit or fire.
• Using the vacuum with a buildup of dust may result in overheating, product damage, breakage or fire.
• Do not use or store the product in areas of high heat with temperatures reaching 104°F/40°C (near heaters,
etc.) in case the vacuum becomes damaged, resulting in short circuits or fire.
• Do not spray or apply insecticide, hair spray, lubricant and etc.
• Do not vacuum oil, gasoline, paint thinner, copy toner, or any other flammable things.
• Do not vacuum carpet cleaning soap, foam, or liquid.
• Do not vacuum oil smoke or steam.
• Do not use near flammable substances (kerosene, gasoline, paint thinner, etc.), objects that have flames
(cigarettes, incense, etc.) or combustible materials. Can cause fires.
Usage Cautions
Use only on cloth products such as mattresses, futons, pillows, carpet, sofa, etc.
Do not use to clean the following:
• Liquid, wet litter/debris, powder, broken glass, and sharp or pin type objects
• Do not use on floors, walls, or unupholstered furniture. Do not pull on the main body and avoid hitting walls
or furniture.
This appliance is provided with double insulation. Use only identical replacement parts. See instructions for
Servicing of Double-Insulated Appliances.
SERVICING OF DOUBLE-INSULATED APPLIANCES
• In a double-insulated appliance, two systems of insulation are provided instead of grounding. No grounding
means is provided on a double-insulated appliance, nor should a means for grounding be added to the
appliance. Servicing a double-insulated appliance requires extreme care and knowledge of the system, and
should be done only by qualified service personnel. Replacement parts for a double-insulated appliance must
be identical to the parts they replace.
43

When assembling or storing, lay the vacuum sideways to avoid it falling over. When completely assembled, vacuum can be
stored upright using the wall mount.
ASSEMBLY
Main body
Extension pipe
Collection head
Collection head
Main body
Brush
COMPLETE ASSEMBLY HAND-HELD:
COLLECTION HEAD
HAND-HELD:
BRUSH ONLY TO DISASSEMBLE
Line up the triangles (Δ)
on the collection head and
extension pipe and press
together firmly.
Line up the triangles (Δ)
on the extension pipe
and main body and press
together firmly.
Collection head can be
attached directly to the
main body without using
the extension pipe.
Main body can be used on
its own by pulling down the
brush head.
Please pay attention to
surroundings and use
caution when removing
the collection head and
extension pipe in order to
avoid hitting anything.
The cord hook on the back of the main body has a built-in magnet, allowing you to store the unit by placing it against the iron
plate of the wall mount. Unit can also be stored by leaning it against the wall.
MATERIALS Polypropylene, polyethylene, soft rubber.
LOCATIONS
On wallpaper, textured wall, dry wall, easily
peeled paint, walls treated with fluorine or
silicone, etc.
Uneven surfaces
Areas of high heat and humidity
Areas that moisture can easily permeate
Outdoors
Wall seams and the surrounding areas
WALL MOUNT INSTALLATION
Using the Adhesive Sheet
1 If using the adhesive sheet, wipe off dust, oil, and moisture from the
surface the adhesive sheet will be placed on. Please do not use
chemical cleaning products to wipe the wall.
2 Peel the paper off the back of the wall mount and press it firmly into
place. See Mounting Height directions for ideal placement.
*It will take approximately 24 hours for the glue on the adhesive sheet
to set. Do not mount the vacuum until the adhesive glue is fully set.
Does not stick well in low temperatures. Installation should be done in areas with a temperature of
50°F/10°C or higher.
May damage or change color of certain surfaces, such as paint or varnished plywood.
Adhesive may not stick well to certain surfaces, such as wallpaper. In this case, use screws to
attach wall mount to the wall.
Original adhesive sheet cannot be reused if moving the wall mount. Please use a spare adhesive
sheet or double sided tape found in retail stores to reattach.
CAUTION
How to Remove Adhesive Sheet
1 If screws were used to install the wall mount, remove them.
2 Slide a thread in the gap between the mount and the wall. Move
the thread left and right, then pull off the wall mount. There will still be
adhesive residue.
3 Place a damp cloth or paper towel over the residue. Please hold in
place for about 10 seconds.
4 Please remove the damp cloth and lightly wipe away the remaining
residue with a dry cloth.
Wall mount parts
Adhesive sheet
on the back
Mounting Height
Screw
hole
height
38-38.5in / 96-97.5cm
5 6

Using Screws
When the adhesive sheet cannot be used, do not peel off the paper backing on
the wall mount. Instead, screw the wall mount into the wall as shown.
Screw hole
How to Store the Vacuum
Place the body vertically against the wall so the top is at the wall mount.
Do not place on anything other than the wall mount. Vacuum may fall.
Be sure to store vertically. Vacuum may fall down if stored at an angle.
CAUTION
The vacuum body can be attached to the
wall mount with the magnet.
Please place the vacuum as
close as possible to the wall
and stand upright.
Main body
Wall mount
Cord hook (top)
Magnet
HOW TO USEWALL MOUNT INSTALLATION
1 Insert the power plug.
2 Turn the vacuum on.
Turn the power to ON to start the vacuum.
3 Turn the vacuum off.
Turn the power to OFF to stop the vacuum.
4 Unplug the vacuum.
Unplug the power plug from the outlet.
Before disconnecting the power plug, be sure the power is set to OFF.
When unplugging the vacuum, do not pull on the power cord. Always unplug holding the power
plug.
Do not leave the vacuum plugged in when finished. Be sure to unplug the power plug from the
outlet.
CAUTION
Be sure the power is set to OFF
before inserting the power plug into
the outlet.
CAUTION
ON/OFF Switch
ON/OFF Switch
ON/OFF Switch
7 8

1 Wrap the power cord around the cord hooks on the back of the
main body.
Make sure the top cord hook faces up, as shown on the right.
2 Insert the power cord into the cord holder. The part of the cord
placed in the cord holder should be near the power plug.
If wound too loosely or too tightly, the cord will not fit correctly into the
cord holder. Please rewind the power cord so that it fits properly.
When using the vacuum, change the direction of top of the cord hook
as shown in the figure below. This will make it easier to remove the
power cord.
CLEANING AND MAINTENANCEHOW TO USE
How to Store
When the product is not in use for an extended period of time, cover the
unit with a plastic bag, etc., and then store it in a dry location away from
direct sunlight.
After use, please store the power cord using the cord hooks.
Cord holder
Power plug
Cord hook
(top)
Power cord
Cord hook
(bottom)
Cord hook
(top)
Power cord
Main body
Remove
Please do not splash water on the vacuum as this could cause damage or electric shock.
Use a diluted neutral cleaning agent.
Use of strong cleaning agents such as amylacetic ester, alcohol, oil, etc. can cause fading,
deformation, or breakdown.
Unplug the power plug from the electric socket before cleaning.
WARNING
Main Body and Extension Pipe
Fully wring out a rag and use it wipe down the body.
Please wipe thoroughly after using a neutral detergent.
Collection Head
Clean hair, string and other small objects from back of the
collection head (marked with a circle in the image) using
tweezers.
Remove dust clogged in the pipe with a stick.
Soak the cloth in water with diluted neutral cleaning
agent, and fully wring out the cloth and use it to wipe
down the surface.
After rinsing the bag holder and dust
cover, place these in a well-ventilated
area or shade until fully dry.
WARNING
Bag Holder, Dust Cover
Rinse the bag holder and dust cover with running water.
Rinse
Protection Mode
If you continue to use product without emptying the dust cup and cleaning the filter, protection mode will activate to prevent
overheating of the motor. The operation light blinks even if the power is turned on. The vacuum motor will temporarily shut
down.
Solution:
1. Turn off the vacuum. Unplug from the outlet.
2. Replace dust bag and clean the sponge filter.
3. Place in a cool location.
After about an hour, protection mode will be unlocked and product can be used again.
Problems that could not be resolved. Please contact the dealer of purchase or IRIS USA, Inc. customer service.
910

After rinsing the sponge filter, place it in a well-ventilated area or shade until fully dry.
After cleaning, please make sure to attach the sponge filter before use to avoid damage to the
motor.
WARNING
CLEANING AND MAINTENANCE
1. Remove the dust cover.
Push in the right and left cover buttons to remove the dust
cover.
2. Remove dust bag set.
Dust may fall. Remove the dust bag set over a trash can.
Dust bag set
Dust cover
Cover button
3. Dispose of the dust bag.
Pinch the corners of the disposable dust bag, remove it from
the bag holder, and throw it away.
Please do not throw away the dust bag holder.
Bag holder
Disposable dust bag
4. Reassemble the dust bag set.
Insert the bottom of the dust bag holder into the disposable
dust bag. Be sure the bag slides all the way into the clips.
Be sure the bag is set so that it does not come off.
Disposable dust bags must
be used or the motor may
malfunction.
Do not force the clip open as this
could damage or break it.
CAUTION
Clips
Disposable
dust bag
Bag holderDisposable dust bag
Bag holder
Be sure the bag slides all
the way into the clip.
Dust bag set
6. Attach dust cover.
Please press the cover into place until the left and right
buttons snap into place. Listen for a “clicking” sound.
5. Reassemble dust bag set in the dust bag chamber.
Insert the dust bag set firmly back into the main body in the
reverse order from how it was removed.
Make sure the disposable dust
bag is in the upright position for
use. Other orientations may allow
dust to leak out.
CAUTION
Dust bag set
Replacing Dust Bag
Please empty the dust bag frequently. Using the disposable
dust bag while full can cause the suction to decrease and
noise to increase.
Sponge Filter
1 Refer to Cleaning and Maintenance (P13) steps 1-2 and remove dust bag
cover and dust bag set.
2 Pull out the sponge filter in the back of the dust bag set chamber.
3 Wash the sponge filter and dry well.
4 Attach the sponge filter. Insert the sponge filter in the back of the dust bag
set chamber.
5 Refer to Cleaning and Maintenance (P13) steps 5-6 and attach the dust
bag set and dust cover.
WARNING: Unplug the power plug from the electric socket before emptying the dust bag Replacement Disposable Dust Bag, (25 PC)
Please purchase replacement parts from IRIS USA, Inc.
Model number: FDPAG-1414
11 12

STATUS POSSIBLE CAUSE REMEDY
Not running
Plug is not inserted into the outlet
correctly. Reinsert the plug and turn on.
“Protection mode” has been activated
to prevent overheating
Follow the Protection Mode (P9)
instructions carefully.
Low suction
Dust bag is full. Replace dust bag. (P11)
Collection head or extension pipe is
clogged. Check inside and remove clogged dust.
Sponge filter is clogged. Clean sponge filter. (P12)
Dust cover is not closed correctly. Reinstall dust cover.
Loud noise
Dust bag is full. Replace dust bag. (P11)
Collection head or extension pipe is
clogged. Check inside and remove clogged dust.
Sponge filter is clogged. Clean sponge filter. (P12)
Main body and handle are
warm while running Running motor causes them to heat up. This is not abnormal.
TROUBLESHOOTING SPECIFICATIONS
Before making repairs, please read the following content carefully to fix common problems.
Problems that could not be resolved.
Please contact the dealer of purchase or IRIS USA, Inc. Customer Service.
Warning: Do not disassemble, repair or modify the product yourself. Any other servicing should be performed by any
authorized service representative.
MODEL SPECIFICATIONS
RATED VOLTAGE 120V~
RATED CURRENT 3.8A
RATED FREQUENCY 60Hz
PRODUCT SIZE
(NOT INCLUDING THE POWER CORD)
MAIN BODY
3.3 x 17.6 x 6.1 in
83 x 448 x 154 mm
WITH ATTACHMENTS
9.1 x 6.5 x 39.2 in
230 x 165 x 996 mm
PRODUCT WEIGHT
MAIN BODY About 2.4 / 1.1kg
WITH ATTACHMENTS About 3.1 / 1.4kg
WORKING TEMPERATURE RANGE 32°F/0°C ~ 104°F/40°C
DUST BAG CAPACITY 10.1 oz / 0.3 L
POWER CORD LENGTH About 13.1 ft / 4 m
ITEMS INCLUDE (INCLUDED IN UNIT) Vacuum, extension pipe, collection head (1 unit), wall mount with
adhesive sheet, dust bag (25 bags), screw (2 units)
*Specifications are subject to change without prior notice.
13 14

Attn: Customer Service (Returns Department)
IRIS USA, Inc.
13423 West Cactus Road
Surprise, AZ 85379
©2019 IRIS USA, Inc. All rights reserved.
THE MANUFACTURER WARRANTS
Your IRIS USA, Inc. products are to be free from defects in material and workmanship under normal non-commercial,
household use, when operated and cared for in accordance with the Manufacturer’s written instructions provided.
THE 1-YEAR WARRANTY (“WARRANTY”) DOES NOT COVER
Any damage caused by accident, misuse, or abuse, including without limitation, damage caused by use in a humid
area, improper cleaning, neglect, alteration, fire, theft, non-recommended temperature use and does not apply to minor
imperfections, scratches, stains, discoloration, surface markings as a result of shipping or other damage to external or internal
surfaces which does not impair the utility and/or functionality of the product.
TO OBTAIN SERVICE
If service should be necessary, you should contact IRIS USA, Inc. Customer Service (“Customer Service”) at 1-800-320-4747.
You may then return the properly packaged product(s), (using adequate packing and shipping material to prevent damage in
transit), with postage prepaid along with name, address, telephone number, model number, and proof of date of purchase (a
copy of the receipt) and a detailed description of the claimed defect. This warranty shall not cover any damage incurred to the
products during transit to Customer Service. You shall have the obligation and responsibility to: pay for all services and parts
not covered by the warranty.
MANUFACTURER’S OBLIGATION
The Warranty may not be altered, expanded, extended, revised or varied except by written instrument executed by the
Manufacturer.
THE MANUFACTURER’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THE
DEFECTIVE PRODUCT(S) AT THE MANUFACTURER’S SOLE AND EXCLUSIVE OPTION. THE MANUFACTURER WILL REPLACE
ANY ITEM FOUND TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP WITH THE MOST COMPARABLE CURRENT ITEM. IRIS
USA, INC. DOES NOT ACCEPT SPECIAL REQUESTS, NOR DO WE HAVE THE ABILITY TO UPGRADE IN EXCHANGE FOR MONEY.
THE MANUFACTURER SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, WHETHER
DIRECT OR INDIRECT. THE WARRANTIES SET FORTH HEREIN ARE EXCLUSIVE AND NO OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE OR USE ARE MADE WITH RESPECT TO THE PRODUCTS.
Some states do not allow the exclusion of limitation of incidental or consequential damages, so the above limitation exclusions
may not apply. This Warranty gives specific legal rights, and there may also be other rights which vary from state to state.
DISCONTINUED ITEM RETURNED
If the item returned is discontinued and is no longer available, IRIS USA, Inc. will automatically replace your item with the most
comparable item currently manufactured.
MANUFACTURER 1-YEAR WARRANTY
15 16

CONTENIDO PÁGINA
Precauciones de seguridad ................19
Piezas ................................22
Ensamblaje ............................23
Instalación del soporte de pared ............24
Instrucciones de uso
Cómo utilizar ...........................26
Limpieza y mantenimiento .................28
Otros
Solución de problemas....................31
Especificaciones ........................32
Garantía ...............................33
de IRIS USA, Inc.
Series IC-SB1U
Gracias por su compra. Lea este manual de instrucciones para garantizar un uso adecuado.
Lea todas las precauciones de seguridad antes de usar. Guarde este manual de instrucciones
en un lugar seguro para consultas futuras.
LEA Y GUARDE ESTAS INSTRUCCIONES.
Aspiradora ligera
17 18
