IronStrike EPIC33 Operating instructions
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATEUR: Laissez cette notice avec l'appareil.
CONSOMMATEUR: Conservez cette notice pour consul-
tation ultérieure.
- Donotstoreorusegasolineorotherflammablevaporsand
liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
phone in your building.
department.
- Installation and service must be performed by a quali-
WARNING: If the information in these instructions is
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
des téléphones se trouvant dans le bâtiment où vous
trouvez.
depuis un voisin. Suivez les instructions du fournis-
seur.
appelez le service des incindies.
le fournisseur de gaz.
AVERTISSEMENT: Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire
ou la mort.
INSTALLATION AND OPERATION
Ce manuel d’installation est disponible
en francais, s implement en faire
la demande. Numéro de la pièce
900182-00.
MODELS
P/N900110-00 REV.NC 01/2014
Direct-Vent
EPIC™
WARNING
AVERTISSEMENT
UNE SURFACE VITRÉE CHAUDE PEUT
CAUSER DES BRÛLURES.
LAISSER REFROIDIR LA SURFACE
VITRÉE AVANT D'Y TOUCHER.
NE PERMETTEZ JAMAIS À UN ENFANT
DE TOUCHER LA SURFACE VITRÉE.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
EPIC33/40
The Epic™ Gas Stove is factory equipped for 40,000 BTU input and can be con-
verted to 33,000 using a smaller orifice (provided in optional orifice kit P/N H5924).
US
Portland
OTL Report No. 050-S-21b-5
P900110-00
2
CONGRATULATIONS!
When you purchased your new gas stove, you joined the ranks
of thousands of individuals whose answer to their home heat-
ing needs reflects their concern for aesthetics, efficiency and
our environment. We extend our continued support to help you
achieve the maximum benefit and enjoyment available from your
new gas stove.
Thank you for selecting an Innovative Hearth Products LLC (IHP)
gas stove as the answer to your home heating needs.
TABLE OF CONTENTS
Using this Manual ...................................................... 2
Safety and Warning Information ....................................... 3
Homeowner - Attaching Safety In Operation Warnings ........... 5
........................................ 6
Codes and Approvals....................................................... 6
.......................................... 6
Commonwealth Of Massachusetts Requirements ..................... 6
Pre-Installation............................................................7-9
Features ............................................................ 7
Packaging List..................................................... 7
Ratings.............................................................. 7
Preparing Your Epic Stove for Installation .................... 8
Dimensions ........................................................ 8
Clearances to Combustibles..................................... 9
Installation............................................................... 9-13
Trim Installation................................................... 9
Firebox Setup..................................................... 10
Brick Panel Installation ......................................... 11
Log Set and Ember Installation ................................ 12
Vent Installation .......................................................13-17
Venting.............................................................13
Residential and Mobile Home Installations ................. 13
Vent Considerations .............................................13
Vent Parts List ....................................................14
Horizontal Vent Installation.....................................14
Vertical Vent Installation........................................ 15
Flue Restrictors ..................................................16
Horizontal Terminations.........................................17
Vertical Terminations............................................17
Horizontal Vent Termination Locations .......................18
Gas Line Installation ...................................................... 19
Gas Pressure Requirements.................................... 19
LP and Natural Gas Supplies...................................19
Attaching Safety In Operation Warnings............................... 20
Operating Instructions ................................................21-24
Pre-Lighting Checklist........................................... 21
Lighting Instructions............................................. 21
Flame Color and Behavior ...................................... 22
..........................................23
Quiet Operation................................................... 23
Paint Curing....................................................... 23
Optional Wall Thermostat.......................................23
Operating Options................................................ 24
Millivolt Control System ........................................ 24
Maintenance and Servicing .......................................... 25-27
Maintenance Checklist ..........................................25
Millivolt and Systems Checks.................................. 25
Vent Pipe Maintenance..........................................25
Glass Door Cleaning and Maintenance .......................26
Opening and Removing Door................................... 26
Fuel Conversion ..................................................27
Troubleshooting............................................................ 28
Wire Harness Diagram.................................................... 29
Replacement Parts ........................................................ 30
Accessories.............................................................33-34
Stove Labels............................................................ 35-36
Warranty ....................................................................37
Product Reference Information ..........................................38
USING THIS MANUAL
Please read and carefully follow all of the instructions found in this
manual. Please pay special attention to the safety instructions provided
in this manual.
PRODUCT IS SUBJECT TO CHANGE WITHOUT NOTICE
IMPORTANT SAFETY AND WARNING
INFORMATION
WARNING
Youngchildrenshouldbecarefullysupervisedwhen
they are in the same room as the appliance. Tod-
to accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the
young children and other at risk individuals out of
the room and away from hot surfaces.
AVERTISSEMENT
-
contact avec la surface chaude. Il est recommandé
WARNING
-
damage. Refer to this manual. For assistance or
service agency or the gas supplier.
WARNING
Failure to comply with these installation instructions
will result in an improperly installed and operating
appliance and/or its operating controls is dangerous.
WARNING
Clothing or other flammable material should not
be placed on or near the appliance.
AVERTISSEMENT
WARNING
Any safety screen or guard removed for servicing
the appliance must be replaced prior to operating
the appliance.
AVERTISSEMENT
Tout écran ou protecteur retiré pour permettre
WARNING
Improper installation or use of this appliance can
explosion or carbon monoxide poisoning.
WARNING
Children and adults should be alerted to the hazards
of high surface temperature and should stay away to
avoid burns or clothing ignition.
AVERTISSEMENT
des dangers que posent les températures de surface
WARNING
DO NOT ATTEMPT TO ALTER OR MODIFY THE CON-
STRUCTION OF THE APPLIANCE OR ITS COMPO-
NENTS. ANY MODIFICATION OR ALTERATION MAY
OF THIS UNIT.
3
4
FORYOURSAFETYdonotinstalloroperatethisappliancewithout
operation of the appliance deviating from that which is stated
in this manual WILL void the warranty and may be hazardous.
INSTALLATIONANDREPAIRSHOULDONLY BE DONE BY
A QUALIFIED SERVICE TECHNICIAN. DO NOT ATTEMPT
TO SERVICE THE APPLIANCE YOURSELF.
Do not make any make-shift compromises during installation.
-
listings of this unit.
-
niques and construction materials or practices other than those
limited warranty.
This gas appliance must be equipped for the proper fuel type
and altitude at which it will be operated. Any operation outside
the parameters outlined in this manual may result in a hazard-
ous condition and will void the warranty. Please carefully read
appliance is properly equipped.
prior to operating the appliance. Do not operate the appliance
Plated surfaces must be cleaned with glass cleaner and a clean
this will remove the plating!!!
the handle located on the top side of the lower door. Be cautious
lower door as those areas are hot.
-
installé dans un endroit où il y a peu de circulation et loin du
mobilier et des tentures.
Provide adequate clearances around air openings and adequate
accessibility clearance for service and proper operation. Never
obstruct the front openings of the appliance.
These appliances are designed to operate on natural or propane
gas only. The use of other fuels or combination of fuels will
degrade the performance of this system and may be dangerous.
Theseappliances aredesignedassupplementalheaters.There-
when installed in a dwelling.
These appliances must not be connected to a chimney or flue
serving a separate solid fuel burning appliance.
These appliances are vented gas appliances. Do not burn wood
or other material in these appliances.
This appliance is only for use with the type of gas indicated on
rating plate. This appliance is not convertible for use with other
indiqués sur la plaque signalétique. Ne pas l'utiliser avec
Hot while in operation. Do not touch. Severe Burns may result.
having flammable vapors away.
not prohibited by local codes.
permettent.
Ensure clearances are in accordance with local installation
codes and the requirements of the gas supplier.
Dégagement conforme aux codes d'installation locaux et aux
exigences du foumisseunde gaz.
person. The appliance should be inspected before use and at
least annually by a professional service person. More frequent
cleaning may be required due to excessive lint from carpet-
appliance be kept clean.
Do not use these appliances if any part has been under water.
to inspect the appliance and to replace any parts of the control
system and any gas control which have been under water.
-
the installation of this appliance.
Seuleslestroussesde garniture fourniesparlefabricant doivent
INSTALLER: THESE INSTRUCTIONS ARE TO REMAIN WITH THE
HOME OWNER!
5
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
APPOSITION DES MISES EN GARDE RELATIVES
Il est impératif que les étiquettes de sécurité fournies
avec le foyer soient collées à côté des dispositifs
de contrôle du foyer. Une étiquette de sécurité doit
être collée sur la plaque de l’interrupteur contrôlant
l’allumagedufoyer(voir FigureA)ousurlethermostat
mural (voir Figure B)et, le cas échéant, sur le boîtier
de la télécommande (Figure C). Les mises en garde
auraientdûêtrecolléesaumomentdel’installationinitiale
du foyer. Si ce n’est pas le cas, prenez les étiquettes
adhésives multilingues fournies avec ces instructions
et procédez comme suit:
1. Repérez l’interrupteur ou le thermostat mural
qui contrôle le foyer (vérifiez que l’interrupteur
contrôle le fonctionnement du foyer en le faisant
basculerde MarcheàArrêt, etvice-versa). Nettoyez
soigneusement la plaque murale de l’interrupteur
ou le thermostat mural pour éliminer la poussière
et les traces de graisse ou d’huile. Collez l’étiquette
sur la surface de la plaque de l’interrupteur mural
qui contrôle le foyer (Figure A)ou du thermostat
mural (Figure B). Choisissez la langue qui est
principalement parlée dans la résidence du
propriétaire. En cas de doute, collez l’étiquette en
anglais.
2. Si une télécommande est utilisée pour contrôler
le foyer, nettoyez la soigneusement pour éliminer
la poussière et les traces de graisse ou d’huile.
Collez l’étiquette sur le boîtier de la télécommande
(Figure C). Choisissez la langue qui est principale-
ment parlée dans la résidence du propriétaire. En
cas de doute, collez l’étiquette en anglais.
3. Si vous ne trouvez pas les étiquettes, veuillez
appeler IHP ou votre distributeur IHP local pour
recevoirgratuitementdesétiquettessupplémentaires.
Étiquettes de remplacement, n° cat. H8024
IHP
www.IronStrike.us.com
Remarque : Le texte anglais est rouge sur un support
transparent. Le texte français et espagnol est blanc
sur un support noir.
COLOCACIóNDE ADVERTENCIASDESEGURIDAD
EN OPERACIóN
Se requiere que las etiquetas de instrucciones de
seguridad incluidas con la chimenea se coloquen en
el punto de operación y control de la misma. Se debe
colocar una etiqueta de instrucciones de seguridad
en la placa del interruptor de pared desde el cual se
enciende y se apaga la chimenea (ver la Figura A)o
en el termostato de pared (ver la Figura B)y en el
transmisor de control remoto (Figura C)si se usa.
Las advertencias ya deben haberse colocado cuando
se completó la instalación inicial de la chimenea. Si
no están colocadas en estos lugares, encuentre las
etiquetas adhesivas multilingües proporcionadas con
estas instrucciones y prosiga de la siguiente manera:
1. Identifique el interruptor o el termostato de pared
quecontrolalachimenea(verifiquequeelinterruptor
opera la chimenea encendiéndola y apagándola).
Limpiebienlaplacadelinterruptoroeltermostatode
pared para quitar el polvo y aceite. Pegue la etiqueta
enlasuperficiedelaplacadelinterruptorquecontrola
la chimenea (Figura A)o en el termostato de pared
(Figura B).Seleccione el idioma que más se habla
en la casa. Si no sabe cuál es, use la etiqueta en
inglés.
2. Si se usa un control remoto para controlar la
chimenea, encuentre el transmisor y límpielo bien
para quitar el polvo y aceite. Pegue la etiqueta en
la superficie del transmisor (Figura C).Seleccione
el idioma que más se habla en la casa. Si no sabe
cuál es, use la etiqueta en inglés.
3. Si nopuedeencontrar lasetiquetas, sírvasellamar a
IHPo aldistribuidordeIHPmáscercanopararecibir
etiquetasde instruccionesde seguridadadicionales
gratuitas.
Juego de etiquetas de repuesto - Nº de cat. H8024
IHP
www.IronStrike.us.com
Nota: La etiqueta en inglés es transparente con texto
rojo. Las etiquetas en francés y español son negras
con texto blanco.
ATTACHING SAFETY IN OPERATION WARNINGS
It is required that the safety instruction labels fur-
nished with the fireplace be affixed to the operation
andcontrolpointofthefireplace. Asafetyinstruction
label must be affixed to the wall switch plate where
the fireplace is turned on and off (See Figure A)or
wall thermostat (See Figure B)and if used on the
remote control handheld transmitter (Figure C).
The warnings should already have been put in place
when the fireplace initial set-up was completed.
If they are not affixed at these spots, locate the
multi-lingual adhesive labels provided with these
instructions and proceed as follows:
1. Locate the wall switch or wall thermostat that
controlsthefireplace (verifythe switch operates
the fireplace by turning it on and off). Clean the
wall switch plate or wall thermostat thoroughly
to remove any dust and oils. Affix the label to
the surface of the plate of the wall switch that
controls the fireplace (Figure A)or the wall
thermostat (Figure B). Choose the language
primarily spoken in the home. If unknown, affix
the English language label.
2. Ifaremotecontrolisusedtocontrolthefireplace,
locate the transmitter and clean it thoroughly
to remove any dust and oils. Affix the label to
the surface of handheld transmitter (Figure C).
Choose the language primarily spoken in the
home. If unknown, affix the English language
label.
3. If you are unable to locate the labels, please
contactIHP oryour nearestIHP dealertoreceive
additionalsafetyinstructionlabelsfreeofcharge.
Cat. No. H8024 Replacement Label Kit
IHP
www.IronStrike.us.com
NOTE: English is red text on clear label. French
and Spanish are white text on black label.
ATTACHING SAFETY-IN-OPERATION WARNING LABELS
SAFETY LABEL
DIAGRAMS
DIAGRAMAS DE ETIQUETAS
DE SEGURIDAD
DIAGRAMMES DES ÉTIQUETTES
DE SÉCURITÉ
Figure A Figure B Figure C
Illustrations are for example only.
Your accessories may be different.
Les illustrations sont par exemple
uniquement. Vos accessoires
peuvent être différents.
Las ilustraciones son sólo ejemplos.
Tu accesorios pueden ser diferentes.
6
Gas appliances must be tested and certified by a nationally recognized
testing and certification laboratory to ANSI (American National Standard
Institute) gas appliance safety standards.
This stove has been tested and certified by OMNI -Test Laboratories to
ANSI Z21.88 / CSA 2.33 Standard for Vented Gas Fireplace Heater and
CGA 2.17-M91 and UL 307B Gas Burning Heating Appliances for Manu-
factured (Mobile) Homes in both USA and Canada.
• Mustconformwithalllocal,stateandnationalinstallationcodes.In
the absence of local codes, the installation must conform with National
Fuel Gas Code ANSI Z223.1 - latest edition, also known as NFPA 54
(In Canada, the current CAN/CGA B149.1 installation code). Refer to
the National Fuel Gas Code and local zoning and code authorities for
details on installation requirements.
• MobilehomeinstallationsmustconformwiththeMobileHomeCon-
struction and Safety Standard, Title 24 CFR, Part 3280 (in Canada
CAN/CSA Z240 MH), or, when such a standard is not applicable, the
Standard for Mobile Home Installations, ANSI A225.1 - latest edi-
tion.
• Mustbeventeddirectlytotheoutsideinaccordancewiththelatest
edition of the National Fuel Gas Code and must never be attached to
a chimney serving a separate solid fuel burning appliance.
• Hasbeencertiedforusewitheithernaturalgasorpropane.
• Isnotforusewithsolidfuels.
• Isapprovedforsittingroomsand/orbedrooms.
THE EPIC™ STOVE
For altitudes above 2,000 feet (In Canada 4,500 FT/1370 M),the orifice
should be de-rated by 4% for every 1,000 feet to maintain the proper
ratio of gas to air. Improper orifice sizing may result in damage and un-
safe conditions. Changing the orifice should only be done by a qualified
service technician. Contact your IHP dealer for proper orifice sizes. (see
Page 27 for more information).
Since there are always several potential sources of fire in any home, we
recommend installing smoke detectors. If possible, install the smoke
detector in a hallway adjacent to the room (to reduce the possibility of
occasional false activation from the heat produced by the appliance). If
your local code requires a smoke detector be installed within the same
room, you must follow the requirements of your local code. Check with
your local building department for requirements in your area.
ORIFICE SIZE/ALTITUDE ADJUSTMENT
SMOKE DETECTORS
CODES AND APPROVALS
Installation of these appliances are approved for installation in New York
City in the US state of New York (MEA#: 138-07-E).
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS
These appliances are approved for installation in the US state of Mas-
sachusetts if the following additional requirements are met:
• InstallthisapplianceinaccordancewithMassachusettsRulesand
Regulations 248 C.M.R. Sec. 5.08 2(a) through 2(e).
• Installationandrepairmustbedonebyaplumberorgastterlicensed
in the Commonwealth of Massachusetts.
• Theexiblegaslineconnectorusedshallnotexceed36inches(92
centimeters) in length.
• Theindividualmanualshut-offmustbeaT-handletypevalve.
Massachusetts Horizontal Vent Requirements
IntheCommonwealthofMassachusetts,horizontalterminationsinstalled
less than seven (7) feet above the finished grade must comply with the
following additional requirements:
• Ahardwiredcarbonmonoxidedetectorwithanalarmandbattery
back-up must be installed on the floor level where the gas fireplace
is installed. The carbon monoxide detector must comply with NFPA
720, be ANSI/UL 2034 listed and be ISA certified.
• Ametalorplasticidenticationplatemustbepermanentlymountedto
the exterior of the building at a minimum height of eight (8) feet above
grade and be directly in line with the horizontal termination. The sign
must read, in print size no less than one-half (1/2) inch in size, GAS
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS.
It has met all necessary ANSI Standards and is fully certified for installa-
tion in any community. If there are any questions or if you need further
substantiation either write to or call your IHP dealer. If you have further
questions, please contact IHP.
Checkalllocalbuildingandsafetycodesbeforeinstallation.Theinstallation
instructions and appropriate code requirements must be followed exactly
and without compromise. In the absence of local codes the following
standards and codes must be followed.
The Installation must conform with local codes or, in the absence of local
codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54- latest
edition, or the Natural Gas and Propane Installation Code, CAN/CGA
B149.1- latest edition.
The appliance, when installed, must be electrically grounded and wired
in accordance with local codes or, in the absence of local codes, with the
National Electrical Code, ANSI/NFPA 70 - latest edition, or the Canadian
Electrical Code, CSA C22.1 - latest edition.
7
Features
Installation Options
Residential
Vented vertical and horizontal
Manufactured (mobile) home
Natural gas (NG) or propane (LP)
Bedrooms
Optional wall-mounted or remote thermostat
Venting
This appliance can be vented with Secure Vent®direct-vent pipe. Coaxial
pipediametersare6-5/8”outerand4”inner.Thecombustionairforthis
stove is drawn from outside the house through the outer DV (direct-vent)
pipe. Room air is not required for combustion.
When planning your installation, select the correct length of vent pipe
for your particular requirements. Determine the minimum clearance to
combustibles from the rear of the unit to the wall. It is also important
to note the thickness of the wall. Before cutting the vent hole through
the wall make sure that ALL vent and termination clearances (see Page
18) will be met.
Electrical
The standard fan motor requires 120 Volts AC for operation. The stove is
not dependent on the fan or an outside electrical supply to operate.
WARNING-ElectricalGroundingInstructions-This appliance is
-
tion against shock hazard and should be plugged directly into a
properlygroundedthree-prongreceptacle.Do not cutorremove
the grounding prong from this plug.
RATINGS
NATURAL GAS LP GAS NATURAL GAS LP GAS
u
3.5 / 1.7 10.0 / 5.4 3.5 / 1.7 10.0 / 5.4
5.0 11.0 5.0 11.0
w
56.98% 63.58% 63.54% 65.10%
u
uU
v
w
Millivolt Valve
This appliance is operated with a millivolt valve and therefore burns even
during a power outage.
Fuel
This appliance comes from the factory equipped to burn natural gas at a
specified elevation. The appliance can be converted to burn LP gas (liquid
propane) by changing the cassette (valve and pilot assembly) or installing
a conversion kit. Only IHP conversion kits can be used to convert from
NG to LP or LP to NG. Contact your IHP dealer for details.
Pipe:Type - direct-vent
Recommended manufacturer*
Secure Vent®by IHP*
Diameter-6-5/8”x4”forallinstallations
Stove Packaging List
The Epic™ gas stove comes with the following parts:
1 Stove Body with Burner Cassette and 150 CFM Blower
13/8”x9”GasPipe
1 3 pc. Brick Panel Set
1 4 pc. Log Set
1 Bag of Ember Material
1 Bag of Rock Wool
1 Bag of Flue Restrictors, Brick Panel Brackets and Tap-tites
1 Power Cord
1 Installation and Operation Manual
Options
One required: Black Painted, Gold, Brushed Nickel, or Black Nickel Trim
Kit
* Other approved chimney brand is Simpson Dura-Vent DV-GS.
PRE-INSTALLATION
8
Dimensions
The gas line attaches to the gas valve at the lower left corner at the
back of the stove. Test all gas connections for leaks with a gas leak test
solution.
Preparing Your Epic™ Stove For Installation
Read all instructions before beginning your installation. If instructions
have not been read carefully, your installation could void your warranty
and may create a serious fire, health, or other safety hazard.
The IHP warranty will be voided if one of the following occurs:
•Installationofanydamagedstoveorventsystemcomponent.
•Unauthorizedmodicationofthedirect-ventsystem.
•InstallationotherthanasinstructedbyIHPorSimpsonDura-Vent.
•Installationofanystoveorventsystemcomponentnotmanufac-
tured or approved by IHP or Simpson Dura-Vent.
When planning the installation for your Epic gas stove, it’s necessary to
consider the following:
•Wheretheunitistobeinstalled
•Theventsystemcongurationtobeused
•Gassupply(NGorLP)
•Electricalwiring
•Optionalaccessories(doortrimassemblyandwall-mountedor
remote thermostat)
To convert input from 40,000 BTUs to 33,000 BTU’s, remove and replace
thestockburneroricewiththe#36NGoricesuppliedintheoptional
orifice kit P/N H5924. Pipe dope or other approved gas line sealant will
need to be applied before inserting into bulkhead. The foil sticker sup-
plied, stating Epic NG33, will need to be affixed over the model name
Epic NG40 on the serial number label.
23-1/2”
(597mm)
17”
(432mm)
23-1/2”
(597mm)
31-1/4”
(794mm)
Top View
Front View
Figure 1
Figure 2
17”
23-1/2”
23-1/2”
31-1/4”
9
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Clearances to Combustibles
Minimum clearances to combustible materials in inches (millimeters):
Corner Installation
Alcove dimensions
Theminimumwidthbetweenthealcovesidewallsis48”(1219mm).
Theminimumheightofthealcoveis69”(753mm)andthemaximum
depthis48”(1219mm).
Floor Protection
A noncombustible hearth pad is not required. This stove may be installed
on a combustible surface. Also, the floor beneath the stove must be
stable, level, hard and strong enough to support the stove without a
tipping hazard.
48”
Min.
48”
Max.
69”
Min.
24-1/2”
Min.
12-1/2”
Min.
4-1/2”
Min.
4-1/2”
Min.
10-1/2”
Min.
90°
Figure 3
Figure 4
Figure 5 - Alcove Dimensions
Pipe Clearances
All installations using a vertical termination cap must maintain one inch
clearance between the direct-vent pipe and combustibles. For horizontal
runs of pipe, one inch of clearance to combustibles on the sides and
bottom and two inches on the top of the pipe is required. See Page 17
for allowable pipe configurations.
Back Wall
Side Wall
INSTALLATION
Install Door Trim Kit
Install door trim kit per instructions provided in kit (ref. form
#775291M).
Figure 6
Parallel Installation
10
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Log Stands
Secondary Air Holes
Air Deflector
Gas Ports
1
2
3
4
Burner Pan Diagram
Completed Firebox Setup
Firebox Setup
Figure 7
Figure 8
11
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Brick Panel Installation
CAUTION: The brick panels are required for your appliance to
function correctly and safely.
Packaging List: Rear brick panel (A), left brick panel (B), right brick panel
(C), retaining brackets (D) - in flue restrictor bag
1. Remove the brick panels from the box and carefully unwrap them.
The panels are fragile, so handle them with care. Remove the bag
containing the brick retaining brackets (D) and flue restrictors from
the firebox.
4. Using the included screws, install the brick retaining brackets (D) above
the left and right brick panels (B and C).
3. Install the left panel (B) bottom first and stand flush against left wall of
firebox. Repeat for right panel (C) against the right wall of firebox.
2. Install the rear brick panel (A) bottom first and stand it flush against
the rear of the firebox ensuring the pilot cutout is at the bottom directly
above the pilot.
AB C
D
Figure 9
Figure 10
Figure 11
Figure 13
Figure 14
Figure 15
Figure 12
12
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
C
D
Log Set and Ember Installation
If logs are not installed according to the log installation instruc-
occur and result in soot and/or excessive production of carbon
reliableandattractive flamepattern. Anyattempttouseadiffer-
Packaging List: Log set [rear log (A), left rear log (B), left front log (C),
center log (D)], embers (volcanic stone) (E) glowing embers (rockwool )(F)
1. Carefully remove the logs from their packaging and ensure you
have a complete set.
care.
3. Place the rear log (A) onto log stands 1 and 2 (see Burner Pan Dia-
gram, Page 10). The charred surface of the log should face the front.
4. Place the embers (volcanic stone) (E) on the burner pan. Using the
larger embers first, create a small pile on the elevated air deflector
near the center and place
them along the front edge of the burner
(leavingabout1/4”inbetweeneachemberanda2”gapinthecenter).
It will not affect the performance, but smaller embers may
fall into the
front air gap.
Place the rest of the embers throughout the firebox taking
care not to block off any secondary air holes or gas ports (see example
below for proper placement of embers).
5. Place the glowing embers (rockwool) (F) over the gas ports and in
between the ember (volanic stone) along the front of the firebox. The
glowing embers can be placed over gas ports but do not cover the
secondary air holes (see Burner Pan Diagram, Page 10).
6. Placetheleftfrontlog(C) on log stand 3 (see Burner Pan Diagram,
Page 10)and the center log (D) spanning from log stand 4 to the peg
found on the right side of rear log (A). When installed correctly, both
logs should sit firmly in place with the charred side facing forward.
2. Install left rear log (B) onto the front half of log stand 1 (see Burner
Pan Diagram, Page 10). When installed correctly it should sit
firmly in place with the charred surface facing the center of the
firebox.
NOTE: All logs are designed to fit only one way. For the ap-
pliance to function properly, it is essential that the logs be
installed correctly. See below for an example of a correctly
burning Epic™ gas stove.
Figure 17
Figure 20
Figure 16
Figure 18
Figure 19
A
B
CD
E
F
B
A
B
A
C
D
13
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Vent Installation
Venting:
The Epic™ gas stove has been tested and listed as a direct-vent heater
-
mended for use with Secure Vent®pipe*. Use only approved chimney
brands with this appliance.
Important:
• Readallinstructionscarefullybeforestartingtheinstallation.Failure
to follow these instructions may create a fire or other safety hazard
and will void the warranty. Be sure to check for specific clearances
to combustible requirements on Page 9. Do not extend the venting
systemverticallyorhorizontallyin excessofthedistanceprescribed
on Page 17. Consult your local building codes before beginning the
installation.
• Always maintain the proper air spaces between the vent pipe and
. Do not fill air spaces
withinsulation.Besuretocheck theventterminationclearancerequire-
ments from decks, windows, soffits, gas regulators, air supply inlets
and public walkways, as specified in these installation instructions on
Page 18 and local building codes.
• This gas stove and vent system must be vented directly to the out-
side of the building and never be attached to a chimney serving a
separate solid fuel or gas-burning appliance. Each direct-vent gas
appliance must use its own separate vent system. Common vent
systems are prohibited.
• TheEpicgasstoveisrecommendedforusewithSecureVent®pipe*.
The appliances and vent manufacturers warranties will be voided and
serious fire, health, or other safety hazards may result from any of the
following actions:
• Installationofanydamageddirect-ventcomponent.
• Unauthorizedmodicationofthedirect-ventsystem.
• Installationofanyventcomponentpartnotapprovedormanufac-
tured by the approved vent manufacturer.
• InstallationotherthanasinstructedbyIHPandventmanufacturers
instructions.
Residential and Mobile Home Installations:
These are the minimum pieces required. Other parts may be required for
your particular installation.
Minimum Components for Horizontal Installation:
Horizontal Termination Kit which includes:
• 16-5/8”x6”BlackPipe
• 1RiserVentTerminal
• 1WallPenetrationHeatShield(WallThimble)(2pcs)
• 1DecorativeWallTrim(black)
• 1TubeMill-Pac
• Screws
Optional Components:
• 45ºElbow
• VinylSidingShieldforRiserVentTerminal
• VentGuard
• SnorkelTermination(36”)
• SnorkelTermination(14”)
• WallPenetrationHeatShield
Vent Considerations:
Twist-lock procedure: Four indentations on female ends of pipes and
fittings are designed to slide straight onto male ends of adjacent pipes
and fittings by orienting the four pipe indentations so they match and
slide into the four entry slots. Push pipe sections completely together,
then twist-lock one section clockwise approximately one-quarter turn
until the two sections are fully locked. The female locking lugs will not
be visible from the outside on the pipe or fittings. They may be located
by examining the inside of the female ends.
Supports: Horizontal runs of vent must be supported every 3 feet. Wall
straps are available for this purpose.
PipeSealing:IfSimpsonDura-Ventpipeisused,thepipemustbesealed
as follows: seal both the inner and outer pipes with a high temperature
silicone sealant rated for at least 600ºF (commonly know as “RTV”).
Runa1/8”(3mm)beadofsiliconearoundoutsideofmaleendofouter
sleeve.Runa1/8”(3mm)beadofsiliconeabout1/4”(6mm)fromthe
end of the male inner pipe, which is found in the pipe to be attached
above. Twist-lock the pipes or fittings together.
* Other approved chimney brand is Simpson Dura-Vent DV-GS.
Figure 22
Figure 21
Sealant
Female
Locking
Lugs
Male
Locking
Lugs
14
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Vent Parts List
Secure Vent®direct-vent pipe may be used with the Epic™ gas stove.
Please see the lists below to verify the components available from each
direct-vent pipe manufacturer. Snorkel terminations are available for
applications which may require vertical rise on the building exterior.
The components listed below come in a galvanized finish. Most of the
componentsarealsoavailableinapaintedblacknish.Adda“B”tothe
end of the part number when ordering if a black part is desired.
Secure Vent by IHP 6-5/8”x 4” Pipe
Part Number Description
SV4LC 6”PipeLength
SV4L12 12”PipeLength
SV4L24 24”PipeLength
SV4L36 36”PipeLength
SV4L48 48”PipeLength
SV4LA 6”Pipe,Adjustable
SV4LA12 12”Pipe,Adjustable
SV4FA Flashing,1/12to6/12RoofPitch
SV4FB Flashing, 7/12 to 12/12 Roof Pitch
SV4RSM Wall Radiation Shield
SV4E46 45ºElbow
SV4E90 90º Elbow
SV4VS Vinyl Shield Protector
SV4FC Storm Collar
SV4CGV Vertical Termination Cap
SV4BF Firestop
SV4CHC Horizontal Termination Cap
SV4STC36 SnorkelTerminationCap(36”)
SV4STC14 SnorkelTerminationCap(14”)
SV4BM Wall Band
SimpsonDura-VentGS6-5/8”x4”Pipe
Part Number Description
908 6”PipeLength
907 9”PipeLength
906 12”PipeLength
904 24”PipeLength
903 36”PipeLength
902 48”PipeLength
911 11”to14-5/8”Pipe,Adjustable
942 Wall Thimble
940 Rnd Support Box/Wall Thimble Cover
941 Cathedral Ceiling Support Box
943 Flashing,0/12to6/12RoofPitch
943S Flashing, 7/12 to 12/12 Roof Pitch
945 45º Elbow
990 90º Elbow
950 Vinyl Siding Standoff
953 Storm Collar
963 CeilingFirestop
988 Wall Strap
981 SnorkelTermination(36”)
982 SnorkelTermination(14”)
984 Horizontal Termination Cap
985 Horizontal Termination Cap (High Wind)
980 Vertical Termination Cap
991 Vertical Termination Cap (High Wind)
Horizontal Vent Installation
Venting terminals may not be recessed into a wall or siding.
1. Set the unit in the desired location. Check whether or not wall studs
are in the way when the venting system is attached. If wall studs are
in the way, you may want to adjust the location of the unit.
2.Allhorizontallyterminatedventinstallationsmayonlyuse6-5/8”x4”
Secure Vent®pipe*.
3. Assemble the desired combination of pipe and elbow(s) to the appli-
ance adapter with pipe seams facing down. Offsetting the pipe seams
as double seams in one place will cause the outer pipe to take an oval
shape.
4. When this pipe passes through a wall, a wall thimble - Simpson #942
or IHP #SV4RSM - is required. The hole in the wall for the wall thimble
shouldbe9-1/4”x10-1/4”.Ifthewallbeingpenetratedisconstructed
ofnon-combustiblematerial(i.e.masonryblockorconcrete),a7”
diameter hole is acceptable and a wall thimble is not required.
5. Horizontalrunsofventpipe mustbesupportedevery3feet.Wallstraps
- IHP #SV4BM or Simpson #988 - are available for this purpose.
6.Iftheventpassesthroughaceilingoroor,arestop-IHP#SV4BF
orSimpson#963-isrequired.
7. Also note that venting terminals shall not be recessed into a wall or
siding. If installing the termination cap on a wall covered with vinyl
siding, a vinyl siding standoff - IHP #SV4VS or Simpson #950 - or
furring strips must be used to ensure that the termination cap is not
recessed into the siding.
8.Thehorizontalrunofventshouldhavea1/4”(6mm)riseforevery12”
of run toward the termination. Never allow the vent to run downward.
This could cause high temperatures and may present the possibility
of a fire.
9. The location of the horizontal vent termination on an exterior wall must
meet all local and national building codes and must not be blocked
or obstructed. For allowable external vent termination locations see
Page 18.
10.Allowable clearancesfromtheventpipe tocombustiblematerialsmust
be maintained. See Page 9 for these clearances.
11.Do not locate the termination cap where it may be blocked by shrub-
bery or snow.
* Other approved chimney brand is Simpson Dura-Vent DV-GS.
15
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Vertical Vent Installation
Important Notes
1.Allverticallyterminatedventinstallationsuse6-5/8”x4”Secure
Vent®pipe*.
2. Ifthe vent passes through aceilingorfloor,a firestop - Simpson
#963orIHP#SV4BF-isrequired.
3. If the vent passes through the roof, a roof flashing - Simpson
#943 or 943S or IHP #SV4FA or SV4FB - and storm collar
- Simpson #953 or IHP #SV4FC - are required.
4. A 1-inch clearance from the vent pipe to combustible materials
must be maintained.
5. A maximum of either four 45º elbows or two 90º elbows may
be used. See Page 16 for allowable offsets.
6.Themaximumsystemheightis30feet(9.1M)andtheminimum
is 10 feet (3M).
Figure 23
Vertical Termination Cap
Storm Collar
Ceiling Minimum
Framing 10” x 10”
Roof - Maintain
1” Clearance to
Combustibles
Flashing
Ceiling Firestop
Pipe Length
16
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
A B
C D
* Other approved chimney brand is Simpson Dura-Vent DV-GS.
Figure 24
Flue Restrictors
The flue restrictor settings shown in Figures 25 and 26 are for typical
accountothervariablesintheinstallationtoachievepropercombustion.
See Flue Restrictor Guidelines on this page to assist you in making a
This stove requires a balanced flue to ensure proper combustion. As such,
flue restrictors may need to be installed depending on the vent configura-
tion of your stove. The drawings on the next page show all the allowable
pipe configurations for the Epic™ gas stove. To properly install the flue
restrictors, find your pipe configuration in the drawings on the next page
and note which restrictor setting is recommended. The flue restrictors are
shipped in the firebox of your stove. Install the flue restrictors using the
four allen head screws according to the diagram below. Install the flue
restrictor screws in their original holes in the top of the firebox. Restrictor
positions are based on tests run in a laboratory.
After the flue restrictors have been changed to the standard flue restrictor
settings as shown in Figures 25 and 26, the burner flame appearance
should be evaluated to determine if the A, B, C or D flue restrictor standard
settings were the correct adjustment for variables in your installation.
Light the appliance and allow it to burn for 20 minutes on the high setting.
See Flame Color and Behavior on Pages 22 and 23 to determine if you
have a proper burner flame appearance. If the proper flame appearance
cannot be achieved, the flue restrictor may need to be changed to a dif-
ferent position (A,B,C or D). See the following guidelines to determine if
you need to readjust the flue restrictors.
Before proceeding, confirm the manifold and inlet gas pressure is correct,
primary air shutter is properly adjusted, venting system connections are
secure and not blocked and if you are at a high elevation, ensure unit
has been properly derated:
Symptoms - Lack of Combustion Air
flue restrictor to a more open position.
•Flameappearsyellow
•FloatingFlames(lazy,illdened,quiet,mayroll)
•Sooting
•Pilotbecomesyellowandapplianceshutsdown
Symptoms - Excessive Combustion Air
flue restrictor to a more closed position.
•LowFlame
•Pilotpullsandapplianceshutsdown
•Pilotameghosts
17
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Vertical Terminations
The diagram below shows all allowable combinations of straight vertical
and offset to vertical vent configurations with vertical terminations. The
termination must fall within the shaded areas on the diagram. Use the
restrictor positions indicated. Offsets may consist of two 90° elbows
OR four 45° elbows. The minimum termination height is 10 feet and the
maximum is 30 feet.
NOTE: Horizontal pipe requires 1/4” rise for every 12” of run. Offsets
must remain within max and min lines. Vertical height is measured
from the bottom of stove.
Horizontal Terminations
The shaded areas in the diagram below show all allowable combinations
of vent configurations with horizontal terminations. Horizontal sections
ofpiperequire1/4”ofriseforevery12”ofrun.Asecond90°or45°
elbow (in addition to the first 90° elbow at the top of the vertical length
of pipe) is allowed as long as the overall length of the horizontal run of
pipe does not exceed those shown below. Use the restrictor positions
indicated. Note that if the termination cap falls in the unshaded area, then
no restrictor is installed in the stove.
Figure 25 Figure 26
2
4
6
8
10
12
14
16
18
20
2
4
6
8
10
12
14
16
18
20
22
24
26
28
MIN. 24" VERT. PIPE SECT.
WITH 9" HORIZONTAL SECT.
8' MAX
30' MAX
30
19' 7" MAX VERT. WITH
8' HORIZONTAL
VERTICAL HEIGHT (FT)
2468
2468
VERTICAL HEIGHT (FT)
HORIZONTAL DISTANCE (FT) HORIZONTAL DISTANCE (FT)
6' MAX
VERTICAL PIPE
REQUIRED BELOW
TERMINATION
2
4
6
8
10
12
14
16
18
20
2
4
6
8
10
12
14
16
18
20
22
24
26
28
MIN. 24" VERT. PIPE SECT.
WITH 9" HORIZONTAL SECT.
8' MAX
30' MAX
30
19' 7" MAX VERT. WITH
8' HORIZONTAL
VERTICAL HEIGHT (FT)
2468
2468
VERTICAL HEIGHT (FT)
HORIZONTAL DISTANCE (FT)
HORIZONTAL DISTANCE (FT)
6' MAX
A B C D
RESTRICTOR POSITIONS
18
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Exterior Horizontal Vent Termination Clearance Requirements
V
V V
V
V
F
C
B
B
A
B
H
M
I
X V
D
V
A A
A
V
L
B
J
X E
V
A
G
*18”
18”
B
C
C
C
K
X
* See Item D in the Text Below.
Center Line
of Termination
Exterior Wall
Horizontal
Termination
Inside Corner
DETAIL D
Minimum Clearances Canadian Installation * US Installation **
A = Clearance above grade, veranda, porch, deck
or balcony.
12 inches (30 cm) * 12 inches (30 cm) **
B = Clearance to window or door that may be
opened.
6in.(15.2cm)forappliances<10,000BTU/hr(3kW),
12in.(30cm)forappliances>10,000BTU/hr(3kW)and<
100,000BTU/hr(30kW),36inches(91cm)forappliances
> 100,000 BTU/hr (30kW)*
6in.(15.2cm)forappliances<10,000BTU/hr(3kW),
9in.(23cm)forappliances>10,000BTU/hr(3kW)and<
50,000 BTU/hr (15kW), 12 inches (30 cm) for appliances
> 50,000 BTU/hr (15kW)*
C = Clearance to permanently closed window 12 inches (305 mm) recommended to prevent window
condensation
9 inches (229 mm) recommended to prevent window
condensation
D = Vertical clearance to ventilated soffit located
abovetheterminal withinahorizontal distance of18
in. (458 mm) from the center line of the terminal
18 inches (458 mm) 18 inches (458 mm)
E = Clearance to unventilated soffit 12 inches (30 cm) 12 inches (30 cm)
F = Clearance to outside corner 5 inches (12.7 cm) 5 inches (12.7 cm)
G = Clearance to inside corner 6in.(15cm) 6in.(15cm)
H = Clearance to each inside of center line extended
above meter / regulator assembly
3 feet (91 cm) within a height of 15 feet above the meter /
regulator assembly *
3 feet (91 cm) within a height of 15 feet above the meter
/ regulator assembly **
I = Clearance to service regulator vent outlet 3 feet (91 cm) * 3 feet (91 cm) **
J = Clearance to non-mechanical air supply inlet
to building or the combustion air inlet to any other
appliance
6in.(15.2cm)forappliances<10,000BTU/hr(3kW),12
in.(30cm)forappliances>10,000BTU/hr(3kW)and<
100,000BTU/hr(30kW),36inches(91cm)forappliances
> 100,000 BTU/hr (30kW)*
6in.(15.2cm)forappliances<10,000BTU/hr(3kW),9
in.(23cm)forappliances>10,000BTU/hr(3kW)and<
50,000 BTU/hr (15kW), 12 inches (30 cm) for appliances
> 50,000 BTU/hr (15kW)*
K = Clearance to mechanical air supply inlet 6feet(1.8meters)* 3 feet (91 cm) above, if within 10 feet (3 m) horizon-
tally**
L = Clearance above paved sidewalk or paved
driveway located on public property
7 feet (2.13 m) ‡ 7 feet (2.13 m) ‡
M = Clearance under veranda, porch, deck or
balcony
12 in. (30 cm) * ‡ 12 in. (30 cm) ** ‡
* In accordance with the current CAN/CGA B149.1 National Gas and B149.2 Propane Installation Code - Latest Editions.
** In accordance with the current ANSI Z223.1 / NFPA 54 National Fuel Codes - Latest Edition.
‡ A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings.
*‡ Only permitted if veranda, porch, deck or balcony is fully open on a minimum 2 sides beneath the floor.
Inside
Corner Detail
Operable
Window
Fixed
Closed
Window
= 9" in U.S.
= 12" in Canada
3 ft.
3 ft.
= Air Supply Inlet = Vent Terminal = Area where Terminal is NOT permitted
Figure 27
19
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Gas Line Installation
This stove must be connected to the gas line in accordance with local
codes and/or the National Fuel Gas Code, ANSI Z223.1 (In Canada, the
current CAN/CGA B149.1 installation code). Remove the four screws
holding the back of the pedestal in place. Slide rear cover back far enough
to gain access to the inside of the pedestal. Remove plastic plug from
the3/8”x9”pipe.Connectgaslinetothe3/8”x9”pipe.Afterconnect-
ing the gas line, all joints in the line and connections at the valve should
be checked for leaks before final positioning of the unit. Conduct a gas
leakage test of the appliance piping and control system downstream of
the shutoff valve in the supply line to the appliance.
Gas Pressure Requirements
A MAJOR CAUSE OF OPERATING PROBLEMS WITH GAS
APPLIANCES IS IMPROPER GAS PRESSURE!
The most important item to check during the initial installation
gas pressure! This appliance will not function properly unless
the required gas pressure is supplied. See the table on this
page for gas pressure requirements.
Two pressure taps are provided on the appliance’s valve to check gas
pressures. To access the taps, remove the four socket head screws from
the valve control panel. The taps are located below the On/Off/Pilot knob
(see Figure 29 on Page 22). The left tap is the inlet (supply) pressure
side. To check inlet pressure (with the appliance burning) insert a small
flat-bladedscrewdriverintothe tap and turn ahalf-turncounterclockwise.
Cover the tap with the line from the manometer and check the pressure.
Close the tap gently but securely after completing the check. The manifold
(outlet) tap is to the right of the inlet tap. To check manifold pressure (with
the appliance burning at the high burn setting) insert a small flat-bladed
screwdriver into the tap and turn a half-turn counterclockwise. Cover
the tap with the line from the manometer and check the pressure. Again
close the tap gently but securely after completing the check. Check the
taps for gas leaks with a gas leak test solution (retighten if necessary).
If the pressure is not sufficient, make sure the gas supply line is large
enough, the supply regulator is properly adjusted and the total gas load
for the residence does not exceed the amount supplied.
Propane tanks are at pressures that will cause damage to valve com-
ponents. Verify that the tanks have step down regulators to reduce the
pressure to safe levels.
LP and Natural Gas Supplies:
Your Epic™ gas stove is equipped from the factory for use with natural
gas only as specified on the Safety / Listing label attached to the appli-
ance. This appliance can only be operated using propane gas (LP) if a
certified fuel conversion kit provided by IHP is installed by a qualified
service technician.
Also check the orifice size on the label on the igniter bracket. It must be
the correct size for the fuel and altitude.
Do not run propane tank dry. Running the tank dry may cause a
hazardous condition due to pressure drop in empty tank.
Solid fuel is NOT to be used with this unit.
Fuel
Type
Inlet Pressure Manifold Pressure
Desired Minimum Maximum On Hi
Fire
On Lo
Fire
Natural
Gas
7" WC 5" WC 10.5" WC 3.5" WC 1.7" WC
LP Gas 11" WC 11" WC 13" WC 10" WC 6.0” WC
Check all connections
for leaks using a gas
leak test solution.
Figure 28
The appliance must be isolated from the gas supply piping system
by closing its equipment shutoff valve during any pressure testing of
the gas supply piping system at test pressures equal to or less than
1/2 psig (3.5 kPa).
The appliance and its appliance main gas valve must be disconnected
from the gas supply piping system during any pressure testing of that
system at test pressures in excess of 1/2 psig (3.5 kPa).
Check all connections for leaks
using a gas leak solution
20
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
INSTALLER INSTRUCTIONS - ATTACH SAFETY-IN-OPERATION WARNING LABELS
Page 5. It is the installers responsibility to ensure these warnings are properly
Other manuals for EPIC33
1
This manual suits for next models
1
Table of contents
Other IronStrike Stove manuals
Popular Stove manuals by other brands
Olsberg
Olsberg ALID 23/496 instructions
Hearth & Home
Hearth & Home Quadra-Fire CASTILE-MBK-C owner's manual
Ashley
Ashley AW2020E manual
Charlton & Jenrick
Charlton & Jenrick Paragon Edge owner's manual
Texsport
Texsport 14204 operating manual
England's Stove Works
England's Stove Works 25-PDVC Installation & operation manual
Extraflame
Extraflame Marilena Plus AD user manual
Dimplex
Dimplex Opti-myst Cassington CSN20 installation instructions
Woolly Mammoth
Woolly Mammoth 5 mk2 user manual
WANDERS
WANDERS DANTA 500 Installation, servicing and user instructions
Hearth and Home Technologies
Hearth and Home Technologies Quadra-Fire 27I-ACC owner's manual
HearthStone
HearthStone Harvest owner's manual
KVS
KVS 8111 Operation & maintenance manual
Breckwell
Breckwell Classic Cast P4000 owner's manual
United States Stove
United States Stove GW7400 manual
Vermont Castings
Vermont Castings The Intrepid II 1990 Installation & operating manual
HASE
HASE Delhi 124 operating instructions
Wolf Steel
Wolf Steel Bayfield GDS25NA-1 Installation and operation manual
