IRT DAI-3206 User manual

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 1 of 12 3206-DAI ib Rev6.doc
IRT Eurocard
Type DAI-3206
Digital Audio Inserter for 270Mb s SDI
Designed and manufactured in Australia
IRT can be found on the Internet at:
http: www.irtelectronics.com
I R T Electronics Pty Ltd A.B.N. 35 000 832 575
26 Hotham Parade, ARTARMON N.S.W. 2064 AUSTRALIA
National: Phone: [phone] Fax: [phone]
International: [phone] [phone]
Email: [e-mail]
Web: www.irtelectronics.com
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 2 of 12 3206-DAI ib Rev6.doc
IRT Eurocard
Type DAI-3206
Digital Audio Inserter for 270Mb s SDI
Revision History
Revision Date By Change Description Applicable to:
1 20/03/2001 AL Original Issue. S/N: ≥ 0110001
2 03/12/2001 SH Cleanup and update of spec sheet before release. S/N: ≥ 0110001
3 16/02/2004 AL Update with balanced/unbalanced common rear
assembly.
S/N: ≥ 0307001
4 22/07/2004 AL Corrections to configuration adjustments – RV1 to
RV4 and SW2, and addition of “MODE” descriptions.
S/N: ≥ 0307001
5 12/01/2011 AL Configuration LK1 link position stipulated to be in OUT
position only.
S/N: ≥ 0307001
6 03/05/2011 AL Equalisation specification corrected to > 250m. S/N: ≥ 0307001
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 3 of 12 3206-DAI ib Rev6.doc
IRT Eurocard
Type DAI-3206
Digital Audio Inserter for 270Mb s SDI
Instruction Book
Table of Contents
Section Page
Revision History 2
Operational Safety 3
General Description 4
Technical Specifications 5
Technical Description 6
Configuration 7
Description of DAI-3206 Modes 8
Installation 9
Front and rear layouts 11
Maintenance & Storage 12
Warranty & Service 12
Equipment return 12
This instruction book applies to units later than S/N 0307001.
Operational Safety:
WARNING
Operation of electronic equipment involves the use of voltages and currents that
may be dangerous to human life. Note that under certain conditions dangerous
potentials may exist in some circuits when power controls are in the OFF position.
Maintenance personnel should observe all safety regulations.
Do not make any adjustments inside equipment with power ON unless proper
precautions are observed. All internal adjustments should only be made by suitably
qualified personnel. All operational adjustments are available externally without
the need for removing covers or use of extender cards.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 4 of 12 3206-DAI ib Rev6.doc
IRT Eurocard
Type DAI-3206
Digital Audio Inserter for 270Mb s SDI
General Description
The DAI-3206 is intended as a high performance audio embedder for 270 Mbit SDI video signals.
A typical SDI signal may contain up to eight audio pairs arranged in four groups although only one group is
normally required for program distribution.
2 AES signals, 4 analogue audio signals, or a combination of 1 AES and 2 analogue audio signals may be inserted
into an existing SDI video stream.
Each DAI-3206 is capable of inserting one audio group (2 AES signals – 4 channels). Group position selection is
made by the front panel local control.
Regenerated SDI outputs are provided to allow connection of more modules if additional channels are required.
The DAI-3206 supports AES/EBU synchronous / asynchronous audio at 48 kHz, 20-bit audio data packets.
An audio presence indicator is provided for each input. Depending on the mode selected, if one AES audio pair is
missing then those particular channels are set to zero. If both AES pairs are missing then no packets are inserted.
The DAI-3206 complements the DAX-3206 audio extractor.
Front panel LED’s indicate a loss of SDI input and the presence of AES1 and AES2 signals. An external relay alarm is
also provided on the rear assembly.
The DAI-3206 is fabricated in IRT's standard Eurocard format and may be housed in a variety of IRT Eurocard
frames alongside other standard modules.
Standard features:
•Standard 75 Ω
ΩΩ
Ω 270 Mbit s video input.
•Inserts audio - either 2 AES signals containing 2 channels each, 4 analogue channels or a combination of
AES and analogue pairs.
•Selectable re-sampled or non re-sampled modes.
•Supports SMPTE 272M-A Synchronous 48 kHz Insertion (re-sampled mode).
•Supports SMPTE 272M-AD Asynchronous 48 kHz Insertion (non re-sampled mode).
•20 bit audio supported.
•Z, C, U data preserved (non re-sampled mode).
•Select between AES & Analogue audio inputs.
•Automatic EDH correction and or insertion.
•Ability to replace existing embedded audio.
•Automatic selection between 525 & 625 line formats.
•Indicators external alarms for loss of carrier & audio.
•Automatic input equaliser to >250 m.
•Two 270 Mbit s SDI outputs for loop through to additional units.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 5 of 12 3206-DAI ib Rev6.doc
Technical Specifications
IRT Eurocard module
Type DAI-3206
SDI input:
Number 1 (BNC).
Impedance 75Ω terminated.
Equalisation Automatic for cables lengths > 250 m (Belden 8281).
Format 270 Mbit/s video with or without embedded audio serial data to SMPTE
259M-A/D.
SDI outputs:
Number 2 (BNC).
Type 75Ω sourced.
Format Regenerated and re-clocked.
AES EBU inputs:
Number 2 x 48 kHz synchronous/ asynchronous, 20-bit audio data packets.
Impedance 75 Ω unbalanced, solder link selectable
110 Ω balanced, standard
Analogue Audio inputs:
Number 4 (Left 1/Right 1, Left 2/Right 2)
Type Balanced Phoenix plug in terminal blocks.
Input level +24 dBu at Full Scale
Impedance 10 kΩ
Alarm output: N/C Relay contacts
Other:
Power requirements 28 Vac CT (14-0-14) or ± 16 Vdc.
Power consumption <7 VA.
Temperature range 0 - 50° C ambient.
Mechanical Suitable for mounting in IRT 19" rack chassis with input output and power
connections on the rear panel.
Finish: Front panel Grey background, black lettering & red IRT logo.
Rear assembly Detachable silk-screened PCB with direct mount connectors to Eurocard and
external signals.
Dimensions 30 mm x 3 U x 220 mm IRT Eurocard.
Accessories supplied with module Rear connector assembly including matching connectors for audio and
alarms.
Related Modules DAX-3206 digital and analogue audio extractor.
Due to our policy of continuing development, these specifications are subject to change without notice.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 6 of 12 3206-DAI ib Rev6.doc
Technical Description
Audio Packet Distribution
Groups are embedded in non-switching lines with each group residing in a fixed number of bytes from the End of
Active Video (EAV) flag. Each group contains either 3 or 4 AES words in length. Preserving this distribution
simplifies insertion or removal of audio groups. Other manufacturers support this method.
In the non-resampled mode, each of the two channels within the AES group must be the same data rate. If both
channels are present, input one is deemed master and the packet distribution is performed according to its input
rate.
Input 1 corresponds to channels 1 & 2 of the audio group while Input 2 corresponds to channels 3 & 4. Note that in
the non-resampled mode, Input 2 may experience clicks or pops and C channel errors if asynchronous to Input 1.
If Input 1 is not present then Input 2 becomes master. If neither is present then no audio packets are embedded.
If both a combination of one AES and one analogue audio pair are used, then the AES input becomes master if
present, else the analogue sampling rate is locked to the SDI clock rate. This is true for the non-resampled mode.
In the resampled mode, both AES and Audio are locked to video.
If both analogue audio pairs are used, the analogue sampling rate is locked to the SDI clock rate.
Group 1 Immediately after EAV.
Group 2 64 bytes after EAV.
Group 3 128 bytes after EAV.
Group 4 192 bytes after EAV.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 7 of 12 3206-DAI ib Rev6.doc
}
Configuration
Adjustments:
RV1 Left 2 analogue audio input level adjustment
RV2 Right 2 analogue audio input level adjustment
RV3 Left 1 analogue audio input level adjustment
RV4 Right 1 analogue audio input level adjustment
Links:
Link Normal Function
LK 1 IN: Not Used (Leave OUT).
OUT: Remove existing embedded data (Default position).
LK 9 (when LK 1 out) IN: Erase selected embedded data.
OUT: Erase all embedded data.
* LK 11 IN: Don’t insert control packet.
OUT: Insert control packet.
Switches:
Sw 1 Front panel: Group selection 1 – 4.
Sw 2 Mode (Position)
0 Insert AES 1 & AES 2
1 Insert AES 1 & AUDIO 2 - (Analogue Audio 2 locked to AES1, if present, else locked to video).
2 Insert AUDIO 1 & AES 2 - (Analogue Audio 1 locked to AES2, if present, else locked to video).
3 Insert AUDIO 1 & AUDIO 2 - (Analogue Audio 1 & 2 locked to video).
4 Insert resampled AES1 & resampled AES2
5 Insert resampled AES1 & Analogue 2
6 Insert AUDIO 1 & resampled AES2
7 Insert AUDIO 1 & AUDIO 2
All other switches are unused.
* NOTE:
LK 11:
LK 11 is used to control the insertion of Audio Control Packets. Audio Control Packets are used to tell the decoder
the format of the embedded audio, parameters such as synchronous or asynchronous, sampling rate 32 kHz,
44.1 kHz, 48 kHz etc. are defined.
Each group must have a control packet except in the case of 48 kHz synchronous operation when the Audio
Control Packet is defined as OPTIONAL. In the absence of an Audio Control Packet, 48 kHz synchronous operation is
assumed.
Locked to video,
Synchronous.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 8 of 12 3206-DAI ib Rev6.doc
Description of DAI-3206 Modes:
Overview:
The DAI-3206 supports several insertion modes to provide flexibility in the studio environment. These modes
determine the input (AES or Analogue audio) and sampling reference. The DAI-3206 was originally designed to
support the new compressed digital audio formats such as Dolby-E, which must pass unchanged from origin to
destination. This required that the DAI-3206 supported asynchronous 48K plus associated control packet. This
control packet is only optional for synchronous 48kHz mode.
It was also decided that the channel pairs might be either both AES, Analogue or a combination of the two. In the
combined AES/analogue case, the analogue audio is locked to the AES if present of locked to video if the AES is
lost.
AES audio can be resampled to become synchronous with the video, however, a small but measurable degradation
of performance occurs, which in almost all cases is insignificant. Additionally, the channel data is destroyed and
subsequently partially rebuilt. However, performing this resampling allows the audio data to become 48K
synchronous and more flexible when used with other studio equipment.
MODE 0 (Asynchronous AES1 & AES2)
This mode is used when perfect AES transfer is required. This is most useful for Dolby-E type applications,
otherwise MODE 4 is recommended. In this mode the data is asynchronously distributed which is not compatible
with synchronous decoders unless the AES is already synchronized to video at the AES encoder. Additionally, some
AES decoders employ a minimal sample buffer implementation; this is done for several reasons, primarily in tape
recorders, which try to minimize coding delay. This delay accumulates over multiple play modify and record
operations which may finally result in annoying lip sync.
MODE 1&2 (Asynchronous AES & Analogue Audio)
This mode is used when perfect AES transfer is required. The analogue audio is sampled using the AES input as a
reference. If the AES is missing, then the analogue audio is synchronous to the video. However, this distribution is
even and no attempt to compensate (pre-load the receiver buffer) for the absence of audio packets during in the
vertical interval is performed. Most receivers such as the DAX-3206 contain a buffer structure that easily handles
this distribution. You may be aware of the audio packet distribution differences between the SMPTE & SONY
formats. The DAX-3206 was designed with a buffer capable of tolerating either distribution.
MODE 3 (Synchronous Analogue Audio)
This mode is probably the most confusing and it is not recommended in favour of MODE 7. This was the original
distribution mode of the DAI-3206. In this mode the audio is synchronous to the video, however, no attempt to
compensate (pre-load the receiver buffer) for the absence of audio packets during in the vertical interval is
performed. The DAX-3206 was designed with a buffer capable of tolerating many sample distributions.
MODE 4 (Resampled AES1 & AES2)
With the advent of high performance digital audio receivers many synchronization issues can be eliminated. The
advantage is that the audio is now synchronized to the video with little loss of performance. The disadvantage is
the channel data is lost and is therefore rebuilt. This is not an issue in practice and is mentioned for completeness.
To fully complement minimal buffer management practices in some studio video recorders, the packet distribution
has been completely changed from previously described distributions. A fixed packet distribution is generated that
is identical to SDI test signal generators known to be acceptable to studio VCRs. This distribution compensates for
the absence of audio packets in the vertical switching region.
MODE 5&6 (Asynchronous AES & Analogue Audio)
This mode treats the AES as in MODE 4, with the analogue audio following the sample fixed distribution.
MODE 7 (Synchronous Analogue Audio)
This is the recommended analogue input mode that uses the same fixed distribution as described in MODE 4.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 9 of 12 3206-DAI ib Rev6.doc
Installation
Pre-installation:
Handling:
This equipment may contain or be connected to static sensitive devices and proper static free handling precautions
should be observed.
Where individual circuit cards are stored, they should be placed in antistatic bags. Proper antistatic procedures
should be followed when inserting or removing cards from these bags.
Power:
AC mains supply: Ensure that operating voltage of unit and local supply voltage match and that correct rating
fuse is installed for local supply.
DC supply: Ensure that the correct polarity is observed and that DC supply voltage is maintained within
the operating range specified.
Earthing:
The earth path is dependent on the type of frame selected. In every case particular care should be taken to ensure
that the frame is connected to earth for safety reasons. See frame manual for details.
Signal earth: For safety reasons a connection is made between signal earth and chassis earth. No attempt should
be made to break this connection.
Installation in frame or chassis:
See details in separate manual for selected frame type.
Connections:
Controls
•Group select (1,2,3 or 4) – Front panel switch SW1
•Channel pair select (1&2 or 3&4) – Internal rotary switch SW2
Indicators and alarms
The alarm output on the rear of the DAI-3206 indicates a loss of 270 Mb/s data or power failure. The alarm state is
indicated by a contact closure, which is available on J3A of the rear assembly.
J2 alarm connectors on rear panel:
Pin 4 Relay COM
Pin 3 Relay N/C
Pin 2 Not Used
Pin 1 Ground
LED’s on the front panel indicate:
Loss of carrier
Presence of Audio 1
Presence of Audio 2
DC power
1
3
2
4
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 10 of 12 3206-DAI ib Rev6.doc
SDI Video:
Input:
The SDI input is a single BNC connector terminated in 75 Ohms.
The input equaliser compensates automatically for losses of up to 250 metres of high quality 75 Ohm coaxial cable.
Performance tests are made using Belden 8281 cable as a reference. Actual results and bit error rates will depend
on the quality of the cable and the noise environment as well as the quality of the originating equipment.
Outputs:
Two SDI outputs are provided. These are equalised and reclocked outputs and so will exhibit a small time delay
with respect to the input. This may need to be taken into account if they are to be used for other than monitoring
purposes.
These outputs are matched 75 Ohm impedance and should only be used with 75 Ohm coaxial cable. They must be
75 Ohm terminated at the destination in order to obtain correct levels and performance.
AES Audio:
AES audio inputs are provided in either balanced (standard) or unbalanced (solder link selectable on rear assembly)
formats. The AES signals are encoded as stereo and therefore does not require separate connections for ‘Left’ and
‘Right’ channels. 2 input AES signals may be inserted into the one group.
Analogue channels are mapped Left1, Right1, Left2, Right2 to channels 1,2,3,4 using consumer mode.
The unbalanced BNC input connectors, on the 75 Ohm rear connector unit, should only be used with 75 Ohm
coaxial cable and must be 75 Ohm terminated at the source in order to obtain correct levels and performance.
The balanced inputs, on the 110 Ohm rear connector unit, should be used with high quality twisted pair shielded
cable and terminated in a balanced configuration of 110 Ohms at the source. This format is not polarity (phase)
conscious, but +ve and -ve marks are provided beside the output connector for consistency in wiring. However, it is
important that the cable lengths and losses of the pair be the same. In particular, patch bays can introduce these
problems, resulting in distorted eye patterns and thus, high bit error rates.
This format is not generally suited to long cable runs. For these applications the unbalanced 75 Ohm input should
be used.
AES Digital Input Configuration:
There are four pairs of pads on the reverse side of the rear assembly marked  . To convert a rear assembly from
110Ω balanced to 75Ω unbalanced connect each pair of pads together.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 11 of 12 3206-DAI ib Rev6.doc
Front & rear panel connector diagrams
The following front panel and rear assembly drawings are not to scale and are intended to show connection order
and approximate layout only.
AES GROUP
DC
AUDIO 2
AUDIO 1
CARRIER
D A I - 3 2 0 6
N140
1
2
3
4
OFF
1
AES 1 IN
-
+
Gnd
-
+
Gnd
AES 2 IN
ALARMS
SDI OUT 2
SDI IN
SDI OUT 1
RIGHT 1
-
+
Gnd
-
+
Gnd
LEFT 1
LEFT 2
-
+
Gnd
-
+
Gnd
RIGHT 2
AES 1 IN
AES 2 IN
RA1
RA2
RA4
A
RA3
J1A
RA5
LA1
J2A
CA4
CA3
CA2
CA1
CA5
CA6
CA8
CA7
Underside of rear assembly with
areas marked with a ■ indicating
where to connect together to
convert to a 75 Ohm unbalanced
AES input.
IRT Communications
www.irtcommunications.com

DAI-3206 Instruction Book Revision 6
www.irtelectronics.com Page 12 of 12 3206-DAI ib Rev6.doc
Maintenance & Storage
Maintenance:
No regular maintenance is required.
Care however should be taken to ensure that all connectors are kept clean and free from contamination of any
kind. This is especially important in fibre optic equipment where cleanliness of optical connections is critical to
performance.
Storage:
If the equipment is not to be used for an extended period, it is recommended the whole unit be placed in a sealed
plastic bag to prevent dust contamination. In areas of high humidity a suitably sized bag of silica gel should be
included to deter corrosion.
Where individual circuit cards are stored, they should be placed in antistatic bags. Proper antistatic procedures
should be followed when inserting or removing cards from these bags.
Warranty & Service
Equipment is covered by a limited warranty period of three years from date of first delivery unless contrary
conditions apply under a particular contract of supply. For situations when “No Fault Found” for repairs, a
minimum charge of 1 hour’s labour, at IRT’s current labour charge rate, will apply, whether the equipment is
within the warranty period or not.
Equipment warranty is limited to faults attributable to defects in original design or manufacture. Warranty on
components shall be extended by IRT only to the extent obtainable from the component supplier.
Equipment return:
Before arranging service, ensure that the fault is in the unit to be serviced and not in associated equipment. If
possible, confirm this by substitution.
Before returning equipment contact should be made with IRT or your local agent to determine whether the
equipment can be serviced in the field or should be returned for repair.
The equipment should be properly packed for return observing antistatic procedures.
The following information should accompany the unit to be returned:
1. A fault report should be included indicating the nature of the fault
2. The operating conditions under which the fault initially occurred.
3. Any additional information, which may be of assistance in fault location and remedy.
4. A contact name and telephone and fax numbers.
5. Details of payment method for items not covered by warranty.
6. Full return address.
7. For situations when “No Fault Found” for repairs, a minimum charge of 1 hour’s labour will apply,
whether the equipment is within the warranty period or not. Contact IRT for current hourly rate.
Please note that all freight charges are the responsibility of the customer.
The equipment should be returned to the agent who originally supplied the equipment or, where this is not
possible, to IRT direct as follows.
Equipment Service
IRT Electronics Pty Ltd
26 Hotham Parade
ARTARMON
N.S.W. 2064
AUSTRALIA
Phone: [phone] Fax: [phone]
Email: [email protected]
IRT Communications
www.irtcommunications.com
