ISAFE MOBILE ORBIT 1.0 Operator's manual

ORBIT 1.0
Quick Start Manual
and
Safety Instructions
Schnellstartanleitung
und
Sicherheitshinweise

Template: TEMPMD01REV00
Document No. 1007MD03REV02
Version: 2012-06-28
Reservation: Technical Data is subject to change without no-
tice. Changes, errors and misprints may not be used as a basis
for any claim for damages.
All rights reserved.
i.safe MOBILE GmbH cannot be held responsible for any data
or other loss and direct or indirect damages caused by any
improper use of this headset.
Vorbehalt: Technische Änderungen behalten wir uns vor.
Änderungen, Irrtümer und Druckfehler begründen keinen
Anspruch auf Schadensersatz.
Alle Rechte vorbehalten.
Für Datenverluste oder andere Schäden gleich welcher Art,
die durch den unsachgemäßen Gebrauch des Bluetooth
Headsets entstanden sind, übernimmt die i.safe MOBILE
GmbH keine Haftung.
(c) 2012 i.safe MOBILE GmbH
i.safe MOBILE GmbH
i_PARK TAUBERFRANKEN 14
97922 Lauda-Koenigshofen
Germany
Tel. [phone]
[e-mail]
www.isafe-mobile.com

Note / Hinweis
3
This document contains a quick start guide and the safety
instructions necessary for the safe use of the bluetooth head-
set ORBIT 1.0 in explosive atmospheres. The first part details
the English instructions, the second part the German transla-
tion.
More detailed instructions on the use of the headset can be
found at www.isafe-MOBILE.com or directly at i.safe MOBILE
GmbH.
Dieses Dokument enthält die notwendigen Sicherheitshinwei-
se für die sichere Verwendung des Bluetooth Headsets
ORBIT 1.0 in explosionsfähigen Bereichen. Der erste Teil ent-
hält die englischen Anweisungen, der zweite Teil die deutsche
Übersetzung.
Detailliertere Informationen erhalten sie unter www.isafe-
MOBILE.com oder direkt bei der i.safe MOBILE GmbH.

Contents
4
1Introduction 5
2Ex-Specifications 5
3Faults and Damages 6
4Ex-relevant Safety Regulations 7
5Further Safety Advises 7
6Getting Started 10
6.1 Components 10
6.2 Charging the Battery 11
6.3 Power on/off 11
6.4 Pair and Connect the Headset 12
7Basic Functions 12
7.1 Wearing the Headset 12
7.2 Calls 12
7.3 Clear Settings or Reset 13
8Specifications 13
9Troubleshooting 13
10 Maintenance 14
10.1 Battery and charger information 14
10.2 Care and Maintenance 15

Safety Instructions
5
1Introduction
This document contains information and safety regulations
which are to be observed without fail for safe operation of
the bluetooth headset ORBIT 1.0 under the described condi-
tions. Non-observance of this information and instructions
can have serious consequences and / or may violate regula-
tions.
Please read the manual and these safety instructions before
using the headset. In case of contradicting information, the
text of these safety instructions shall apply.
In case of any doubt, the German version shall apply.
The current EC declaration of conformity, EC and IECEx certifi-
cates of conformity, safety instructions and manual can be
found at www.isafe-mobile.com, or requested from i.safe
MOBILE GmbH.
2Ex-Specifications
The ORBIT 1.0 is a bluetooth headset suitable for use in po-
tentially explosive atmospheres (zones 1, 21, 2 and 22) in
accordance with directives 94/9/EC (ATEX 95) and 99/92/EC
(ATEX 137), as well as the IECEx scheme.
Ex-markings
ATEX II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T135°C Db
EPS 12 ATEX 1 433 X
2004
IECEx: Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db
IECEx EPS 12.0007X

Safety Instructions
6
Temperature range: -20 ... +60°C
Manufactured by: i.safe MOBILE GmbH
i_PARK TAUBERFRANKEN 14
97922 Lauda-Koenigshofen
Germany
3Faults and Damages
If there is any reason to suspect that the safety of the headset
has been compromised, it must be withdrawn from use and
removed from any ex-hazardous areas immediately.
Measures must be taken to prevent any accidental restarting
of the headset.
The safety of the headset may be compromised, if, for exam-
ple:
malfunctions occur.
the housing of the headset shows damage.
the headset has been subjected to excessive loads.
the headset has been stored improperly.
markings or labels on the headset are illegible.
It is recommended that a headset which shows or which is
suspected of faults and damages is returned to the manufac-
turer for inspection.

Safety Instructions
7
4Ex-relevant Safety Regulations
Use of this headset assumes that the operator observes the
conventional safety regulations and has read and understood
manual, safety instructions and certificate.
The following safety regulations must also be complied with:
The housing of the headset must not be opened inside ex-
hazardous areas.
The battery is not changeable by the user.
The headset may only be charged outside the Ex-hazardous
area using the appropriate charger or other equipment ap-
proved by i.safe MOBILE GmbH.
The headset may be charged only at temperatures in be-
tween 0°C ... 40°C.
The headset must not be exposed to abrasive acids or ba-
ses.
The headset must not be taken into zones 0 or 20.
Only accessories approved by i.safe MOBILE GmbH may be
used.
5Further Safety Advises
Charge the headset under indoor conditions only.
Please do not put the headset in high-temperature envi-
ronments (high temperature will lead to heating of the bat-
tery), or else it may result in fire or explosion.
Do not charge the bluetooth headset near any flammable
or explosive substances in order to avoid fire, explosion or
other dangers.
Do not charge the bluetooth headset in environments with
much dust, humidity, or excessively high or low tempera-
tures (the permitted charging temperature range is 0 ...
40°C).
Do not use the headset in areas where regulations or legis-
latives prohibit the use of a mobile phone.

Safety Instructions
8
Do not expose the headset to strong magnetic fields, such
as are emitted from induction ovens or micro-waves.
Do not attempt to open or repair the bluetooth headset.
Improper repair or opening can lead to the destruction of
the headset, fire or explosion. Only authorized personnel
are allowed to repair the headset.
Only use charger and accessories approved by i.safe
MOBILE GmbH.
Power off the headset in hospitals or other places where
the use of mobile phones is prohibited. This Bluetooth
headset may affect proper work of medical equipment,
such as pacemakers, so always keep a distance of at least
15 cm between the bluetooth headset and these devices.
Observe all corresponding laws that are in force in the
respective countries regarding the use of bluetooth head-
sets while operating a vehicle.
Please power off the bluetooth headset and disconnect the
charging cable before cleaning the headset.
Do not use any chemical cleaning agents to clean the blue-
tooth headset or the charger. Use a damp and anti-static
soft cloth for cleaning.
Do not discard old and abandoned lithium batteries into
the trash, send them to designated waste disposal loca-
tions or return them to the manufacturer of the headset.
Warning
The manufacturer will not assume any liability for damages
caused by disregarding any of these advices or by any inap-
propriate use of the headset.

Quick Start
9
Introduction
Dear customer, thank you very much for choosing the
ORBIT 1.0 GSM digital bluetooth headset. This quick start
manual gives you access to the basic functions of the headset.
With the i.safe MOBILE Bluetooth Headset ORBIT 1.0, you can
make and receive calls while on the move .Read this user
guide carefully before using the headset. Also, read the user
guide for the mobile device that you connect to the headset.
This product may contain small parts. Keep them out of the
reach of small children. The surface of this device is nickel-
free.
Bluetooth wireless technology
Bluetooth wireless technology allows you to connect compat-
ible devices without cables. The headset and the other device
do not need to be in line of sight, but they should be within
10 meters (33 feet) of each other. Connections may be sub-
ject to interference from obstructions, such as walls, or other
electronic devices.
The headset is compliant with Bluetooth Specification 2.1 +
EDR supporting the Headset Profiles 1.1 and Hands-Free 1.5.
Check with the manufacturers of other devices to determine
their compatibility with this device.
Please read this Quick start manual before using the phone
and follow the tips and advices in order to be able to use the
mobile phone for your full satisfaction and safety.

Quick Start
10
6Getting Started
6.1 Components
The headset contains the following parts:
(1) Power key
(2) Ear loop
(3) Answer/end key
(4) Speaker
(5) Status indicator light
(6) Charger connector
(7) Microphone
Before using the headset, you have to charge the battery and
pair the headset with a compatible device. Parts of the device
are magnetic. Metallic materials may be attracted to the de-
vice. Do not place credit cards or other magnetic storage me-
dia near the device, because information stored on them may
be erased.

Quick Start
11
6.2 Charging the Battery
Please carefully read chapter 10.1 (Battery and charger in-
formation) before charging the battery.
When you disconnect the power cord of any accessory, grasp
and pull the plug, not the cord.
1. Connect the charger to a wall outlet.
2. Connect the charger cable to the charger connector. The
red indicator light is displayed during charging. Charging the
battery fully may take up to three hours.
3. When the battery is fully charged, the green indicator light
is displayed. Disconnect the charger from the headset, then
from the wall outlet.
If the status light (5) is red, recharge the battery. When the
battery charge is low, the headset beeps every 5 minutes and
the red indicator light flashes.
Warning
The phone may only be charged at ambient temperatures in a
range from 0°C ... 40°C. Please do not use charging equipment
if the temperature exceeds this range. Only use approved
chargers. Use of any other charger may cause danger and will
void the warranty.
6.3 Power on/off
To switch on, press and hold the power key for about 2 se-
conds. The headset beeps, and the blue indicator light is dis-
played. The headset tries to connect to the last connected
device.
To switch off, press and hold the power key for about 2 se-
conds when the headset is on. The headset beeps, and the
blue indicator light is briefly displayed. If the headset is not
connected to a device within about 3 minutes, it switches off
automatically.

Quick Start
12
6.4 Pair and Connect the Headset
1. Ensure that your mobile device is switched on and the
headset is turned off.
2. Press and hold the power key (for about 5 seconds) until
the blue indicator light starts to flash quickly.
3. Within about 3 minutes, activate Bluetooth connectivity on
your device, and set it to search for Bluetooth devices.
4. Select the headset from the list of found devices.
5. If necessary, enter the passcode 0000 to pair and connect
the headset to your device. In some devices, you may need to
make the connection separately after pairing.
When the headset is connected to your device and is ready
for use, the blue indicator light flashes about every 5 seconds.
7Basic Functions
7.1 Wearing the Headset
Place the headset on your ear. The headset is ready to be
used on the left ear. To use the headset on the right ear, ro-
tate the ear loop so that it is to the right of the i.safe MOBILE
logo. Slide the ear loop behind your ear and gently push the
earpiece against your ear. Push or pull the ear loop to set its
length. Point the headset with the microphone (7) towards
your mouth.
7.2 Calls
To make a call, use your mobile device in the normal way
when the headset is connected to it.
To redial the number you last called (if your device sup-
ports this feature with the headset), when no call is in pro-
gress, press the answer/end key twice.
To activate voice dialing (if your device supports this fea-
ture with the headset), when no call is in progress, press
and hold the answer/end key for about 2 seconds. Proceed
as described in the user guide of your device.

Quick Start
13
To answer or end a call, press the answer/end key.
To reject a call, press this key twice.
To switch a call from the headset to a compatible device,
press and hold the answer/end key for about 2 seconds, or
switch off the headset. To switch the call back to the head-
set, press and hold the answer/end key for about 2 se-
conds, or switch on the headset.
7.3 Clear Settings or Reset
To reset the headset if it stops functioning, even though it is
charged, connect the headset to a charger while you press
and hold the power key.
8Specifications
Size: 43x22x10 mm
Weight: ca. 12g including battery
Talking time: up to 4 hours
Stand-by time: up tp 90 hours
Aktive Guard to protect from acoustic shocks
Bluetooth: V2.0 + EDR Class 2
Bluetooth-Profiles: Headset, Handsfree, A2DP
Temperatur range: -20 up to 60 °C
9Troubleshooting
If you cannot connect the headset to your compatible device,
check that the headset is charged, switched on, and paired
with your device.

Quick Start
14
10 Maintenance
Thank you for using the ORBIT 1.0. If there is a problem with
the mobile phone, please contact your vendor or consult the
service center. If your mobile phone is in need of repair, you
can either contact the service center or your vendor.
10.1 Battery and charger information
This device has an internal, non-removable, rechargeable
battery. Do not attempt to remove the battery from the
device as you may damage the device.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. Recharge your bat-
tery only with i.safe MOBILE approved chargers designated
for this device. Use of an unapproved charger may present
a risk of fire, explosion, leakage, or other hazard.
If a battery is being used for the first time or if the battery
has not been used for a prolonged period, it may be neces-
sary to connect the charger, then disconnect and reconnect
it to begin charging the battery. If the battery is completely
discharged, it may take several minutes before the charging
indicator light is displayed.
Unplug the charger from the electrical plug and the device
when not in use. Do not leave a fully charged battery con-
nected to a charger, since overcharging may shorten its
lifetime.
If left unused, a fully charged battery will lose its charge
over time.
Always try to keep the battery between 15°C and 25°C
(59°F and 77°F). Extreme temperatures reduce the capacity
and lifetime of the battery. A device with a hot or cold bat-
tery may not work temporarily. Battery performance is par-
ticularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode.
Batteries may also explode if damaged.
Never use any charger that is damaged.

Quick Start
15
Important
Battery talk and standby times are estimates only and depend
on network conditions, features used, battery age and condi-
tion, temperatures to which battery is exposed, and many
other factors. The amount of time a device is used for calls
will affect its standby time. Likewise, the amount of time that
the device is turned on and in the standby mode will affect its
talk time.
10.2 Care and Maintenance
Your device is a product of superior design and craftsman-
ship and should be treated with care. The following sugges-
tions will help you protect your warranty coverage.
Keep the device dry. Precipitation, humidity, and all types
of liquids or moisture can contain minerals that will cor-
rode electronic circuits. If your device does get wet, allow it
to dry completely.
Do not use or store the device in dusty, dirty areas. Its mov-
ing parts and electronic components can be damaged.
Do not store the device in hot areas. High temperatures
can shorten the life of electronic devices, damage batteries,
and warp or melt certain plastics.
Do not store the device in cold areas. When the device
returns to its normal temperature, moisture can form in-
side the device and damage electronic circuit boards.
Do not attempt to open the device.
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the device.
Do not paint the device. Paint can clog the moving parts
and prevent proper operation.
These suggestions apply equally to your device, charger, or
any accessory. If any device is not working properly, take it
to the nearest authorized service facility for service.

Quick Start
16
Recycling
The crossed-out wheeled-bin symbol on your product, bat-
tery, literature, or packaging reminds you that all electrical
and electronic products, batteries, and accumulators must be
taken to separate collection at the end of their working life.
This requirement applies in the European Union. Do not dis-
pose of these products as unsorted municipal waste.
Always return your used electronic products, batteries, and
packaging materials to dedicated collection points. This way
you help prevent uncontrolled waste disposal and promote
the recycling of materials.
More detailed information is available from the product re-
tailer, local waste authorities, national producer responsibility
organisations, or your local i.safe MOBILE representative.
The content of this document is presented as it currently
exists. The manufacturer does not provide any explicit or tacit
guarantee for the accuracy or completeness of the content of
this document, including, but not restricted to, the tacit guar-
antee of market suitability or fitness for a specific purpose
unless applicable laws or court decisions make liability man-
datory. The manufacturer reserves the right to make changes
to this document or to withdraw it any time without prior
notice.

17

Inhalt
18
1Einführung 19
2Ex-Spezifikationen 19
3Fehler und unzulässige Belastungen 20
4Ex-relevante Sicherheitsvorschriften 21
5Weitere Sicherheitshinweise 21
6Erste Schritte 24
6.1 Komponenten 24
6.2 Laden des Akkus 25
6.3 Ein- und Ausschalten 25
6.4 Koppeln und Verbinden des Headsets 26
7Grundlegende Verwendung 26
7.1 Tragen des Headsets am Ohr 26
7.2 Anrufe 27
7.3 Löschen der Einstellungen oder Zurücksetzen 27
8Spezifikationen 28
9Fehlerbehebung 28
10 Wartungshinweis 28
10.1 Akku- und Ladegerätinformationen 28
10.2 Pflege und Wartung 30

Sicherheitshinweise
19
1Einführung
Dieses Dokument enthält Informationen und Sicherheitsvor-
schriften die für einen sicheren Betrieb des Bluetooth
Headsets ORBIT 1.0 unter den beschriebenen Bedingungen
unbedingt zu berücksichtigen sind.
Nichtbeachtung dieser Informationen und Anweisungen kann
gefährliche Folgen haben oder gegen Vorschriften verstoßen.
Lesen Sie die Bedienungsanleitung und diese Sicherheitshin-
weise bevor Sie das Headset benutzen!
Im Falle widersprüchlicher Informationen gelten die Anwei-
sungen in diesen Sicherheitshinweisen.
Die gültige EG-Konformitätserklärung, EG und IECEx Baumus-
terprüfbescheinigung, Sicherheitshinweise und Bedienungs-
anleitung können unter www.isafe-mobile.com
heruntergeladen oder bei der i.safe MOBILE GmbH angefor-
dert werden.
2Ex-Spezifikationen
Das Bluetooth Headset ORBIT 1.0 ist geeignet für den indust-
riellen Einsatz in explosionsgefährdeten Bereichen (Zonen 1,
21, 2 und 22) nach Richtlinien 94/9/EG (ATEX 95) und
99/92/EG (ATEX 137) und dem IECEx-System.
Ex-Kennzeichnungen
ATEX II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T135°C Db
EPS 12 ATEX 1 433 X
2004
IECEx: Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db
IECEx EPS 12.0007X

Sicherheitshinweise
20
Temperature range: -20 ... +60°C
Manufactured by: i.safe MOBILE GmbH
i_PARK TAUBERFRANKEN 14
97922 Lauda-Koenigshofen
Germany
3Fehler und unzulässige Belastungen
Sobald zu befürchten ist, dass die Sicherheit des Gerätes be-
einträchtigt wurde, muss das Gerät außer Betrieb genommen
und sofort aus explosionsgefährdeten Bereichen entfernt
werden.
Die unbeabsichtigte Wiederinbetriebnahme muss verhindert
werden.
Die Gerätesicherheit kann gefährdet sein, wenn z.B.:
Fehlfunktionen auftreten.
am Gehäuse des Headsets Beschädigungen erkennbar sind.
das Headset übermäßigen Belastungen ausgesetzt wurde.
das Headset unsachgemäß gelagert wurde.
das Headset Transportschäden erlitten hat.
Beschriftungen auf dem Headset nicht mehr lesbar sind.
Wir empfehlen ein Headset, welches Fehler zeigt, oder bei
dem Fehler vermutet werden, zu einer Überprüfung an den
Hersteller zu schicken.
