Introduction to EZYiD
®
Who Should Read this User Instruction Manual?
Precautions of Use
Nomenclature
EZYiD Reader Operation
5.1 - Charging the Reader
5.2 - Powering the Reader
5.3 - Pairing the Reader to Your Device
5.4 - Status Notifications: Sounds & LED Lights
5.5 - How to Hold the EZYiD Reader
5.6 - Reading the EZYiD Retrofit System
EZYiD Retrofit Application
Cleaning, Storage & Maintenance
System Conformity
Technical Specifications
Lifespan & Warranty
Global Service & Support
Disposal of Reader
Feedback
Legal Notices

4 5
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
Radio Frequency Identication (RFID), is a method of communicating
information from one point to another point by use of electromagnetic
waves (radio waves). RFID Technology has unique characteristics,
making it benecial for use in industrial systems.
The EZYiD Reader is a specially designed Ultra High Frequency
(UHF) device, designed for use in conjunction with EZYiD RFID Tags,
Cable Ties, Stickers and Universal Moulded Tags and also with EZYiD
embedded hardware products. The Reader is designed to transfer
unique serial number information from the tag to a computer, tablet or
mobile phone device of the user’s choice.
The EZYiD Reader User Instruction Manual provides users with
information about the features of the Reader, how to install, congure,
operate and maintain it, together with troubleshooting information.
Before working with the EZYiD Reader, users should familiarise
themselves with this manual and that of the device that they wish to
use the Reader in conjunction with.
It is the responsibility of the seller to provide this instruction manual
and it is the responsibility of the user to read and understand these
instructions prior to use. If the Reader is used in a manner contrary to
the specication of the manufacturer (as dened in this manual), the
performance of the equipment may be impaired.
1Introduction to EZYiD®
2Who Should Read this User Instruction Manual?
Attentively read all the precautions of use and the operating
instructions before use.
NOTE: The Reader device has not been designed for use in processes
or machineries for the monitoring and the safety of human life or for
medical treatments.
3 Precautions of Use

6 7
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
The Reader
1.
2.
3.
4.
5.
6.
Antenna
Central Button
LED (Blue)
EZYiD® Logo
Body of Reader
LED (Orange)
7.
8.
9.
10.
11.
Product Information Label
Serial Number
Charging Port
Identication Numbers
Product Regulatory Information (Not to Scale)
EZYiD®Retrottable System
EZYiD Cable Tie
EZYiD Sticker
EZYiD Universal Moulded Tag
EZYiD Tag
4 Nomenclature

8 9
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
5EZYiD®Reader Operation
5.1 Charging the Reader
Insert the Micro USB into the portal on the back of the EZYiD Reader
Insert the USB into the computer, tablet or other USB charging portal
Flashing Blue Light (when charger cable unplugged) = Battery Low
Flashing Blue Light (when charger cable is connected to device and to
power source) = Reader is charging
Solid Blue Light (when charger is connected to device and to power
source) = Reader is fully charged
NOTE:
• The Reader remains fully operational and can be used to read Tags,
while the device is re-charging
• As with all battery powered, re-chargeable devices, the device
should be disconnected from the power supply
• The EZYiD Reader is tted with a non-replaceable battery. This
battery is capable of approximately 10,000 reads per charge.

10 11
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
5.2 Powering the Reader
OffOn
1 Second
2 Seconds
1. Hold down the central diamond shaped button for one (1) second
2. An orange LED will appear on the right side
3. The LED will move to the left and appear in blue. Two (2) beeps will
sound. The blue LED will remain on if the Reader has been turned on
successfully
4. To turn the device off, hold down the central diamond shaped
button. The blue light will ick to orange

12 13
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
5.3 Pairing the Reader to Your Device
The EZYiD Reader is a “Plug ‘n’ Play” device. It is not necessary to
download any software onto your computer, tablet or mobile phone, in
order for the EZYiD Reader to function.
Simply, turn on your EZYiD Reader, and follow the Bluetooth pairing
instructions for your computer, tablet or mobile phone to pair the
Reader to your personal device.
Your Reader can only be paired to one computer, tablet or
mobile phone at a time in order for it to function correctly.
If you wish to pair the Reader to a different personal
device, ensure you have unpaired it from the original computer, tablet
or mobile phone. To unpair the Reader from your computer/device,
please refer to the operating instructions of your computer/device.
Note: The serial number of the Reader (shown as ‘sn’, on the label on
the reverse side of the Reader), can be used to identify the Reader on
your computer, tablet or mobile phone.

14 15
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
Status Notications: Sounds & LED Lights
Status Notications When Reading: Sounds & LED Lights
Status Indicator State Indicates
One (1) sound Device is on
One (1) flash orange LED Device is readable & reader can identify & read the tag
Reader is not paired to device
Data is not being sent & stored to device
No Sound Device is on
Two (2) LED, orange & blue Device attempting to locate a readable tag & has not yet found such tag
Device will search for readable tag for three (3) seconds before resetting
Three (3) short sounds Device is on
One (1) flash orange LED Tag is readable & reader can identify & read the tag
Reader is paired to device
Information from tag is being sent to & stored onto device
Flashing blue LED Reader battery is low
One beep with one ash of orange light:
[Successful Read, Unsuccessful Data Transfer]
After a single press of the central button, the device is on, the tag
is readable and the reader is able to read the tag, but your Reader
is not paired to a computer, tablet or mobile device. Therefore,
data information is not being sent/stored on any device. [See
section 5.3: Pairing the Reader to your Software]
No beep and both the blue and orange lights are on:
[Unsuccessful Read]
After a single press of the central button, the Reader device is on
and it is currently trying to search for a readable tag but has not
yet found a functioning tag to read. The Reader will attempt to
nd a readable tag for three (3) seconds. If a readable tag is not
found, the orange light will go off, the blue will remain on and the
user will need to attempt again to read a tag.
Three (3) short beeps with one ash of orange light:
[Successful Read & Successful Data Transfer]
After a single press of the central button, the device is on, the
tag is readable, the Reader is able to successfully read the tag,
your Reader is paired to your computer, tablet or mobile device
and the information from the tag is being sent to and stored onto
that device.

16 17
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
5.5 How to Hold the EZYiD®Reader
The EZYiD Reader should be held comfortably in one hand, ensuring
that the antenna is not covered. Care should be taken not to press,
hold or damage the antenna, as this may result in your Reader
malfunctioning.

18 19
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
5.6 Reading the EZYiD® Retrottable System
To scan, hold the Reader 2-3mm
away from the tag
Press the central button. The
Reader will search for a readable
tag for 3 seconds
Repeat the process if a tag is not
located. Different LED and sounds
will notify you of the outcome
Hold the antenna closely (2-3mm) over the Tag, Sticker, Cable Tie or
Universal Moulded Tag which needs to be read
Press down on the central button. The Reader will search for a readable
tag for three (3) seconds
If a readable tag is not located, the Reader will reset and will need
to be pressed again in order to read a tag. Different LED and sounds
will notify you of the outcome of the read. (See Section 5.4: Status
Notications: LED Lights & Sounds).

20 21
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
6EZYiD® Retrottable Application
Tags
6mm
~2mm
Tags:
Tags are low prole, with a depth of ~2mm and diameter of 6mm.
Tags can be applied to assets using a commonly available Contact
Adhesive or Two-part Epoxy Resin (not supplied). It is the responsibility
of the user to ensure that the adhesive used is suitable for use on the
intended asset.

22 23
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
Cable Ties
Cable Tie:
Cable Ties are tted with an EZYiD Tag, near the buckle-end of the tie,
thus allowing the Cable Ties to be tted in the usual manner with any
excess length of the Cable Tie trimmed.
6EZYiD® Retrottable Application

24 25
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
25mm
25mm
Stickers
Stickers:
Stickers are 25mm x 25mm (1”x1”), with a low prole of <1mm and
contain a special at RFID tag.
Stickers are supplied with a self-adhesive backing and can be applied
to a range of non-metal assets.
6EZYiD® Retrottable Application

26 27
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
Universal Moulded Tags
Universal Moulded Tags:
Universal Moulded Tags are 19mm x 10mm x 5mm (3/4” x 25/64” x
13/64”) and can be tted to assets by using a cable tie, nail, screw,
pop-rivet, or glue. The Universal Moulded Tags can be attached to
any asset.
6EZYiD® Retrottable Application

28 29
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
6Considerations
Considerations when choosing tag type and tting locations:
All Tags, Cable Ties, Stickers and Universal Moulded Tags should be
applied to an area of the asset where they will not interfere with the
function of the asset. Care should also be taken to position the tag
away from the high-wear areas of the asset, in order to best defend
the tags from abrasion/wear, which may cause the tag to become
detached.
All Tags, Cable Ties, Stickers and Universal Moulded Tags are passive
(passive components are electronic components that do not require a
source of energy to perform their intended functions).

30 31
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
The EZYiD Reader should be cleaned using a dampened cloth. A mild,
diluted detergent may be added to the water in which the cloth is
dampened, but do NOT directly apply detergents on to the product.
Do NOT immerse the device in water/liquid.
The EZYiD Reader should be handled with care and when not in use,
should be stored in the protective case (as supplied with the device)
and the case placed in a cool, dry place, which is free from water, heat,
chemicals and other environmental conditions that could possibly
cause damage to the Reader. Damage to the Reader could result in a
lack of integrity in operating functions.
CAUTION: The EZYiD Reader case provided with product is designed
to provide some protection to the Reader, but care should still be
taken when transporting the Reader in this case. The case is not
watertight, nor airtight and is not designed to withstand extreme
weights or pressures. It is the responsibility of the user and
owner of the reader to care for it in an appropriate manner as to avoid
any damage that could result in malfunctioning of the Reader.
The EZYiD Reader is a non-maintenance device and there are no
serviceable parts.
7 Cleaning, Storage & Maintenance

32 33
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
8: System Conformity:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer.
RoHS Conformity
BlueBerry has been realized using materials and constructive processes
conforming to the limits imposed by the directive 2003/108/CE (RoHS)
concerning the use of dangerous substances in electronic products.
9: Technical Specications:
EZYiD UHF Reader:
Operating System Compatibility: iOS, Android, RIM, Windows Mobile/
Phone, Windows, macOS, Linux
USB interface – Bluetooth 2.1 + EDR
4mm Antenna is suitable for EZYiD Tags, Cable Ties, Stickers, Universal
Moulded Tags and embedded tags.
Frequency Options: Europe (ETSI), North America (FCC) or Australia
(AMCA)
Features: Simple 1 function key for read activation, multitone beeper,
2 colour LED for device operation signalling
Reading distance: 2-3mm
Operating Temperature: -20°C to 70°C (-4°F to 158°F)
Battery Information:
Li-Poly Battery 3.7Vdc 300mAh, USB 5Vdc re-chargeable (cable
supplied). Battery life up to 10,000 readings, per full charge. Can be
used and re-charged simultaneously.
Dimensions: Width 44mm (1 11/16”) x Length 95mm (3 11/16”) x
Thickness 18mm (3/4”). Webbing width 30mm (1”)
Weight: 30g (1oz)
Retrot Range:
Tags: 6mmØ x 2mm deep (15/64 x 5/64”)
Cable Ties: 200mm x 5mm (7 7/8” x 13/64”)
Stickers: 25mm x 25mm (1 x 1”)
Universal Moulded Tags: 19mm x 10mm x 5mm (3/4” x 25/64” x
13/64”)
NOTE: Stickers are NOT suitable for use on metal items

34 35
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
All Tags, Cable Ties, Stickers and Universal Moulded Tags are passive
(passive components are electronic components that do not require a
source of energy to perform their intended functions).
10: Lifespan & Warranty:
CSP Distribution Pty. Ltd. guarantees that EZYiD products will be free
from material defects caused by workmanship or production. This
guarantee extends to and no more than twelve (12) months from the
date of purchase.
Our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
The warranty that covers this product does not extend to damage or
malfunctions caused by improper installation, use, storage or improper
modications or repairs on the product.
To claim warranty, the purchaser must notify CSP Distribution Pty.
Ltd. of the material defect immediately after its discovery, or within
a timeframe that would be deemed as reasonable. After notication
has been made, the purchaser must not use or attempt to use
the defective product until CSP Distribution Pty. Ltd. has had the
opportunity to assess the product’s defects and respond appropriately
to the complaint. Any use of the product after notication may result
in the claim becoming void.
For warranty support please contact [email protected]
11: Global Service & Support
Web Support:
Basic reader FAQ can be found at www.ezyid.com. Alternatively, use
our online contact portal to speak to customer support regarding any
other queries you may have regarding your EZYiD Reader.
Telephone Support:
For Australian or International support, call [phone] (calls are
charged at standard rate)
Alternatively, please contact your nearest EZYiD reseller.
12: Disposal
Each country has specic legislation in place, relating to the responsible
disposal of lithium batteries. When disposing of your EZYiD Reader,
please consult your local authority for compliance advice.
13: Feedback
Your feedback is crucial to the continual improvement of our
documentation and products. To provide feedback about this manual
or the EZYiD Reader and/or Tags, please contact:
CSP Distribution Pty. Ltd.
Customer Service
[email protected]
14: Legal Notices
CSP Distribution Pty. Ltd. declines every responsibility in relation to
possible damages, losses of income or any other damage resulting
from the use of this product. The content of this manual cannot
be brought anywhere without the permission of the producer. The
technical specics of the product and the information brought

36 37
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
in the manual are subject to change without notice; for the latest
information, visit www.ezyid.com
It is the responsibility of the user to read and understand these
instructions prior to use. If the Reader is used in a manner contrary
to the specication of the manufacturer (as dened in this manual),
the protection of the equipment may be impaired. In no event will
CSP Distribution Pty. Ltd. be responsible or liable for indirect or
consequential damages resulting from the use or application of this
Reader.

38 39
EZYiD® Retro-t System - Issue A - August 2019 EZYiD® Retro-t System - Issue A - August 2019
Notes Notes
