ISCO 674 Operating instructions

674 Rain Gauge
Installation and Operation Guide
Part #60-3283-011
Copyright © 1992, 2004. All rights reserved, Isco, Inc.
Revision H, March 2004

Foreword
This instruction manual is designed to help you gain a thorough understanding of the
operation of the equipment. Isco recommends that you read this manual completely
before placing the equipment in service.
Although Isco designs reliability into all equipment, there is always the possibility of a
malfunction. This manual may help in diagnosing and repairing the malfunction.
If the problem persists, call or email the Isco Customer Service Department for assis-
tance. Contact information is provided below. Simple difficulties can often be diag-
nosed over the phone. If it is necessary to return the equipment to the factory for
service, please follow the shipping instructions provided by the Customer Service
Department, including the use of the Return Authorization Number specified. Be
sure to include a note describing the malfunction. This will aid in the prompt
repair and return of the equipment.
Isco welcomes suggestions that would improve the information presented in this man-
ual or enhance the operation of the equipment itself.
Isco is continually improving its products and reserves the right to change
product specifications, replacement parts, schematics, and instructions
without notice.
Contact Information
Phone: [phone] (USA, Canada, Mexico)
[phone] (Outside North America)
Repair Service: [phone] (Analytical and Process
Monitoring Instruments)
[phone] (Samplers and Flow Meters)
Fax: [phone]
Email address: [email protected]
Website: www.isco.com
Return equipment to: 4700 Superior Street, Lincoln, NE 68504-1398
Other correspondence: P.O. Box 82531, Lincoln, NE 68501-2531
Revised February 12, 2003

i
674 Rain Gauge
Table of Contents
Operation Instructions
1.1 Description and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.3 Materials and Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.4 Location of the Rain Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.4.1 Suggested Siting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.6 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.7 Electrical Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.8 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.9 Replacement Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
List of Tables
1-1 Technical Specifications for the 674 Rain Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
List of Figures
1-1 Replacement Parts List Illustration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1-2 Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

674 Rain Gauge
Table of Contents
ii

1-1
674 Rain Gauge
Operation Instructions
1.1 Description and
Operation
The Isco 674 Rain Gauge is a precision instrument for accurately
measuring rainfall. The rain gauge is mounted inside a steel cyl-
inder and has an eight-inch opening on top to collect rain. Rain
falls through a screen into a funnel. From the funnel, rain col-
lects in one side of a two-chambered plastic bucket mounted on
jewelled pivots. When rain fills the chamber, the bucket tips,
draining the water and exposing the other chamber to fill. When
that chamber fills, the bucket tips back and the process begins
again.
Each time the bucket tips from one side to the other, a magnet
passes over a reed switch, momentarily closing the normally
open contacts. This contact closure provides a short-duration
output pulse from the rain gauge for each 0.01 inch of rain.
1.2 Applications When connected to a flow meter, the rain gauge enables the flow
meter to print rainfall data on its chart or store rainfall data in
memory. It also lets the flow meter actuate an associated Isco
Automatic Wastewater Sampler.
Typical applications include monitoring of storm water runoff,
inflow and infiltration studies (I&I), and combined sewer
overflow monitoring. You can also use the rain gauge for any
other general purpose rainfall measurement as long as the asso-
ciated equipment is electrically compatible.
1.3 Materials and
Construction
The rain gauge is constructed of steel, stainless steel, aluminum,
and plastic. All metal parts are coated, plated, or painted to
ensure a durable, ruggedly tough instrument capable of resisting
deterioration from exposure to the elements. Screens cover all
openings, preventing clogging by leaves, insects, or other debris.
The powder-coated steel sleeve protects the internal parts. The
jewelled-pivot mounting for the tipping bucket provides long life.
A built-in bubble level makes leveling the rain gauge after instal-
lation easy. A 50-foot cable terminated in an M/S connector
attaches the rain gauge to the flow meter or to other equipment.
CAUTION
The rain gauge is factory-calibrated and adjusted. Do not
attempt to make any adjustments to the jewelled-pivot screws.
You may damage the jewel bearings.

674 Rain Gauge
Operation Instructions
1-2
1.4 Location of the Rain
Gauge
Location affects the accuracy of the rainfall catch because the
prevailing winds may tend to carry the rain away from the
gauge. There are advantages and disadvantages to most sites.
Sites may be either open or protected. Totally open sites affect
the accuracy of the catch if the rain is carried on strong winds,
but are satisfactory if rainstorms are generally calm. With no
nearby vegetation the characteristics of the site will not tend to
change over time, which is an advantage. Where strong winds
are characteristic of storms, protected sites are generally pref-
erable. This is because the effect of the wind on the rainfall catch
is reduced. The presence of small groups of objects or objects of
varying heights around the gauge can also affect accuracy by pro-
ducing eddy currents in the wind which will interfere with the
catch.
1.4.1 Suggested Siting Groups of objects of uniform height (such as trees) in the vicinity
of the gauge are beneficial for an accurate catch by acting as a
windbreak while not interfering with the catch. Mounting the
rain gauge in the clearing of an orchard or a grove of trees would
be a recommendation for a good site.
The height of the surrounding objects should not exceed twice
their distance from the rain gauge. If vegetation serves as a
windbreak, understand that growth will greatly change the con-
ditions of the site with the passage of time. What may originally
have been a good site may not always remain one.
Vegetation grows dramatically over time. Any construction
nearby that takes place after the installation may also make a
site undesirable by altering the wind currents and rainfall pat-
terns around the gauge. Under no circumstances should any
nearby object be allowed to grow above or hang directly over the
gauge.
The rain gauge is solidly built to withstand years of outside use;
however, vandals could ruin it. Always try to install the rain
gauge where it will be protected from vandalism.
Avoid installation in low places where runoff from heavy storms
could flood the gauge or wash it away. The rain gauge would not
be hurt by submersion, but it would be unable to measure.
Do not drop the rain gauge or expose it to shock; that could
damage the jeweled bearings.
1.5 Installation To install the rain gauge, follow the procedure below. Step 7 is
optional, depending on the requirements of your particular
installation.
1. Unpack the rain gauge from the shipping box. Save the box
and packing to return the rain gauge to Isco if that
becomes necessary. Remove the outer tube (white cover
with funnel) from the rain gauge by loosening the two
thumb screws on either side.
2. Locate the bottom (mounting) plate of the rain gauge. This
is circular and made of black metal. Mount this plate
securely to a stable horizontal surface that is relatively

674 Rain Gauge
Operation Instructions
1-3
level. Isco suggests using corrosion-resistant hardware for
mounting. The mounting holes will accommodate hard-
ware as large as ¼ inch in diameter.
3. This is very important: Level the rain gauge by adjusting
the three thumb screws on the base until the bubble in the
bubble level is exactly centered.
4. Carefully remove the rubber band used to secure the tip-
ping bucket assembly. Do not apply pressure to the bucket
or the pivot arm. Do not attempt any adjustments.
5. Reinstall the protective outer tube on the rain gauge.
6. Route the cable from the rain gauge to the flow meter. Coil
any extra wire by the flow meter.
7. If necessary, you can increase the distance between the
flow meter and the rain gauge to 1,000 feet (maximum) by
splicing a two-wire #18 AWG cable (user- supplied)
between the Isco-provided cable and the rain gauge, as
described below.
Disconnect the Isco cable from the terminal block inside
the rain gauge and splice the user-supplied cable to that
end of the Isco cable. If the wiring and the splice will be
exposed to the weather, use wire appropriate for outdoor
use and insulate the splice properly. A weatherproof box
may be necessary. Do not cut the M/S connector from the
Isco cable unless you are connecting the rain gauge to
equipment that does not have a compatible connector. You
will not be able to reconnect it easily.
1.6 Maintenance The Isco Rain Gauge is built of quality materials to withstand
years of exposure to the elements. Normally, no maintenance is
required.
Once a year (or more often if conditions warrant) you may want
to remove the cover and check the gauge to see that it has not
been affected by the buildup of dust, debris, or insect infestation.
The rain gauge is factory-calibrated and needs no further
adjustment. If your installation is temporary and you intend to
move the rain gauge from site to site, use care in transporting
the unit. Again, you could damage the jewelled pivots for the
tipping bucket if you expose the rain gauge to a severe shock - for
example, by dropping it. If you move the rain gauge frequently,
always secure the tipping bucket with a rubber band and use the
original packing box to protect the unit during transport.
Repack the rain gauge as it was originally shipped to you if you
need to return it to Isco.

674 Rain Gauge
Operation Instructions
1-4
1.7 Electrical
Considerations
The electrical output from the Isco Rain Gauge is the rapid
contact closure of a normally open reed switch. The rain gauge is
not itself a powered device. It contains neither batteries nor
transformer and does not connect to the AC line. Electrically, it is
a “dry contact” switch, with power supplied from whatever device
it controls.
When you connect the rain gauge to an Isco Flow Meter, the
current through the switch contacts is very low and there is no
problem with line losses or damage to the switch contacts.
However, if you plan to use the rain gauge for general-purpose
rain measurement with other types of equipment not specified by
Isco, please note the following:
CAUTION
The reed switch is rated for pilot duty only! The sealed contacts
are limited to 10 watts (or 10 VA), 200 VDC maximum. Exceed-
ing these limits may cause welding or rupturing of the reed
switch, ruining it. For safety considerations, Isco recommends
connection only to equipment supplying 30 volts or less, AC or
DC.
Be particularly careful using the rain gauge with equipment sup-
plying DC voltages at higher current loads or equipment pre-
senting an inductive load to the reed switch. Never connect the
rain gauge directly to any equipment where enough current
passes to strike an arc when the contacts switch. You should
always buffer such equipment with a solid-state switch (tran-
sistor, IC, SCR, etc.) or a sensitive relay.

674 Rain Gauge
Operation Instructions
1-5
1.8 Technical
Specifications
The technical specifications for the 674 rain gauge are presented
in Table 1-1.
1.9 Replacement Parts
List
The following pages contain a list of replacement parts for the
Isco 674 rain gauge. The illustration shows the location of the
numbered parts, which are described in the accompanying table.
Replacement parts can be purchased by contacting Isco’s Cus-
tomer Service Department.
Isco, Inc.
Customer Service Department
P.O. Box 82531
Lincoln, NE 68501 USA
Phone: [phone]
[phone]
FAX: [phone]
E-mail: [e-mail]
Table 1-1 Technical Specifications for the 674 Rain Gauge
Type: Tipping bucket
Orifice: 8 inches (20 cm) diameter
Sensitivity: English: 0.01 inches
Metric: 0.1 mm
Accuracy: English: ± 1% at 2 inches/hr; +3, -4% up to 5 inches/hr
Metric: ± 1½% at 5 cm/hr; +3.5, -9% up to 13 cm/hr
Maximum Capacity: English: 22 inches/hr
Metric: 38 cm/hr
Connector Pinout: Pin A - Red, +12V DC from Flow Meter;
Pin D - Black, Output from Rain Gauge
Output Signal: Contact closure, 50 milliseconds minimum duration
Switch Type: Hermetically sealed magnetic reed switch. Normally open.
200V DC, 0.5 A maximum
Height and Diameter: 13 inches (33 cm); 9½ inches (24 cm) at base
Weight: 10 pounds (4.5 kg)
Operating Temperature: 32° to 140° F (0° to 60° C)
Storage Temperature: -40° to 140° F (-40° to 60° C)

674 Rain Gauge
Operation Instructions
1-6
Figure 1-1 Replacement Parts List Illustration

674 Rain Gauge
Operation Instructions
1-7
Figure 1-2 Replacement Parts List

674 Rain Gauge
Operation Instructions
1-8

War ra nt y
In the event of instrument problems, always contact the Isco Service Department, as problems can often be
diagnosed and corrected without requiring an on-site visit. In the U.S.A., contact Isco Service at the numbers
listed below. International customers should contact their local Isco agent or Isco International Customer Service.
Return Authorization
A return authorization number must be issued prior to shipping. Following authorization, Isco
will pay for surface transportation (excluding packing/crating) both ways for 30 days from the
beginning of the warranty period. After 30 days, expense for warranty shipments will be the
responsibility of the customer.
Shipping Address: Isco, Inc. - Attention Repair Service
4700 Superior Street
Lincoln NE 68504 USA
Mailing address: Isco, Inc.
PO Box 82531
Lincoln NE 68501 USA
Phone: Repair service: [phone] (lab instruments)
[phone] (samplers & flow meters)
Sales & General Information [phone] (USA & Canada)
Fax: [phone]
Email: serv[email protected]
Isco One Year Limited Factory Service Warranty *
Isco warrants covered products against
failure due to faulty parts or workmanship for
a period of one year (365 days) from their
shipping date, or from the date of installation
by an authorized Isco Service Engineer, as
may be appropriate.
During the warranty period, repairs,
replacements, and labor shall be provided at
no charge. Isco’s liability is strictly limited to
repair and/or replacement, at Isco’s sole
discretion.
Failure of expendable items (e.g., charts,
ribbon, tubing, glassware, seals and filters),
or from normal wear, accident, misuse,
corrosion, or lack of proper maintenance, is
not covered. Isco assumes no liability for
any consequential damages.
Isco specifically disclaims any warranty of
merchantability or fitness for a particular
purpose.
This warranty applies only to products sold
under the Isco trademark and is made in lieu
of any other warranty, written or expressed.
No items may be returned for warranty
service without a return authorization number
issued from Isco.
This warranty does not apply to the following
products: Process Analyzers, SFX 3560 SFE
Extractor, 6100 VOC Sampler.
The warrantor is Isco, Inc. 4700 Superior,
Lincoln, NE 68504, U.S.A.
August 2002 P/N 60-1002-040
* This warranty applies to USA customers. Customers in other countries should contact their Isco dealer for warranty service.
