ISCO Signature Operating instructions

Installation and Operation Guide
Manual #69-4333-004 of Assembly #60-4334-005
Copyright © 2012. All rights reserved, Teledyne Isco
Revision J, October 2017

Foreword
This instruction manual is designed to help you gain a thorough understanding of the operation of
the equipment. Teledyne Isco recommends that you read this manual completely before placing the
equipment in service.
Although Teledyne Isco designs reliability into all equipment, there is always the possibility of a
malfunction. This manual may help in diagnosing and repairing the malfunction.
If a problem persists, call or e-mail Teledyne Isco technical support for assistance. Simple
difficulties can often be diagnosed over the phone. For faster service, please have your serial
number ready.
If it is necessary to return the equipment to the factory for service, please follow the shipping
instructions provided by technical support, including the use of the Return Material
Authorization (RMA) specified. Be sure to include a note describing the malfunction. This will
aid in the prompt repair and return of the equipment.
Teledyne Isco welcomes suggestions that would improve the information presented in this manual
or enhance the operation of the equipment itself.
Teledyne Isco is continually improving its products and reserves the right to change product
specifications, replacement parts, schematics, and instructions without notice.
Contact Information
Customer Service
Phone: [phone] (USA, Canada, Mexico)
[phone] (Outside North America)
Fax: [phone]
Email: [email protected]
Technical Support
Phone: Toll Free [phone] (Syringe Pumps and Liquid Chromatography)
Email: [email protected]
Return equipment to: 4700 Superior Street, Lincoln, NE 68504-1398
Other Correspondence
Mail to: P.O. Box 82531, Lincoln, NE 68501-2531
Email: [email protected]

5
Signature® Flow Meter
Table of Contents
Section 1 Introduction
1.1 Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.2 Data Integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.3 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.4 Compatible Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.5 Identifying Signature Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1.6 Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.6.1 Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1.6.2 Display and LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
1.6.3 Backlight and Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
1.6.4 Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
1.7 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Section 2 Setup and Programming
2.1 User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.1 Keypad Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.1.2 Connecting to the Signature with Flowlink . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.2 The Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3 Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3.1 Adjust Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3.2 Adjust Velocity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3.3 Purge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3.4 Histograph . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3.5 Real-Time Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.3.6 Report View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.4 Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.4.1 Off-Screen Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.4.2 Character Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
2.4.3 Pull Down Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2.5 Program Steps
(Menu Trees) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2.6 Hardware Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
2.6.1 Smart Sensor Setup (TIENet) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
2.6.2 SDI-12 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.6.3 Modbus Input Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
2.6.4 Modbus Output Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2.6.5 Modem Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2.7 Configure Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
2.7.1 Site Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
2.7.2 Measurement Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
2.7.3 Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2.7.4 Equation/Trigger Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2.7.5 Data Storage/Push Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
2.7.6 Sampler Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
2.7.7 Inputs/Outputs/Alarms
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-27
2.7.8 Reset Totalizers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30

Signature® Flow Meter
Table of Contents
6
2.7.9 Reports/History Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
2.8 Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
2.8.1 Language Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
2.8.2 Set New Passcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
2.8.3 Update Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
2.8.4 Sensor Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
2.8.5 Display Signature Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
2.8.6 Display License Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
2.8.7 Gather Fault Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
2.8.8 Restore to Factory Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
2.8.9 Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
2.9 USB Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
2.9.1 Retrieve Text Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
2.9.2 Retrieve Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
2.9.3 Update Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
2.9.4 Save Current Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.9.5 Load Existing Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.9.6 Save Signature Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.9.7 Gather Fault Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.9.8 None of the above . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.10 Signature Data in Flowlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.10.1 Event Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
2.11 Verifying Exported Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
Section 3 Standard Installation
3.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 Connecting External Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.3 Case Bottom Cable Entries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3.3.1 Cable Fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3.3.2 Connecting TIENet Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.4 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
3.4.1 Hard Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
3.4.2 Line Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
3.4.3 Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
3.5 Mounting the Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3.6 Outdoor Recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3.7 The Bubble Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.1 Standard Bubble Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.2 Comparing Vinyl and PTFE Bubble Lines . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.3 Bubble Line Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
3.7.4 Attaching the PTFE Bubble Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.7.5 Attaching the Vinyl Bubble Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.7.6 Installing the Bubble Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.7.7 High-Velocity Flow Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
3.7.8 Stilling Wells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
3.7.9 Flume Bubble Line Fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
3.7.10 Bubble Line Extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
3.7.11 Open Channel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
3.8 Setting the Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
3.9 TIENet Sensor Installation in a Hazardous Location. . . . . . . . . . . . . . . . . . . . . . 3-19
Section 4 Portable Installation
4.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Portable Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2.1 Adjust Signature to Upward Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.3 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Signature® Flow Meter
Table of Contents
7
4.3.1 Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.3.2 Outdoor Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.3.3 Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4.4 Battery Life Expectancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.4.1 Major Standard Equipment Settings Effecting Battery Life . . . . . . . . . . . 4-6
4.4.2 Major Optional Equipment Settings Effecting battery Life . . . . . . . . . . . . 4-7
4.4.3 Additional Considerations for Battery Life . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4.4.4 Calculating Average Current Draw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4.4.5 Battery Life Calculations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
4.4.6 Low Battery Cut Off and Battery Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
4.5 Connect to External Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.5.1 Connecting Devices to the TIENet Receptacle . . . . . . . . . . . . . . . . . . . . . . 4-12
Section 5 Equipment Options
5.1 AC Power Cord Kit /AC Wiring (Applies to Permanent Installation Only). . . . . . 5-2
5.2 Battery Backup (Applies to Permanent Installation Only) . . . . . . . . . . . . . . . . . . 5-4
5.3 Power Loss Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
5.4 Mechanical Totalizer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
5.5 External Desiccator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
5.6 TIENet®Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
5.6.1 Ultrasonic Level Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
5.6.2 Bubbler Level Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5.6.3 Laser Doppler Velocity Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5.6.4 Continuous Wave Doppler Velocity Sensor . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5.6.5 Sampler Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
5.6.6 pH and Temperature Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
5.6.7 TIENet Expansion Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
5.6.8 Contact Output Card
(TIENet 304) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
5.6.9 Analog Input Card
(TIENet 307) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
5.6.10 Analog Output Card (TIENet 308) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
5.7 Isco Flowlink Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
5.8 Ethernet Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
5.8.1 Ethernet Modem Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
5.8.2 Network Firewall Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-32
5.9 Cellular Modems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
5.9.1 CDMA Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
5.9.2 GSM Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-34
5.9.3 Installing the Cellular Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-34
5.9.4 Cellular Modem Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-37
Section 6 Maintenance and Servicing
6.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6.2 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6.3 Firmware Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6.4 Accessing the Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6.5 Desiccant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6.5.1 Internal Desiccator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6.5.2 External Desiccator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6.6 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6.6.1 Signature Flow Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6.6.2 TIENet 300 Connector Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
6.6.3 TIENet 301 pH/Temp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
6.6.4 TEINet 304 Contact Output Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
6.6.5 TIENet 307 Analog Input Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13

Signature® Flow Meter
Table of Contents
8
6.6.6 TIENet 306 Sampler Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
6.6.7 TIENet 308 Analog Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
6.6.8 TIENet 310 USLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
6.6.9 TIENet 330 Bubbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
6.7 330 Bubbler Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
6.7.1 Preparation: Non-Bubbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
6.7.2 Preparation: Existing Bubbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
6.7.3 Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21
6.8 Front Cover Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24
6.9 System Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24
6.10 Service and Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-25
Appendix A Replacement Parts
A.1 How to Order. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.2 Signature Flow Meter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
A.3 330 Bubbler. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-14
Appendix B Options and Accessories
B.1 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.2 Signature Flow Meter Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.3 Power Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2
B.4 TIENet Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.4.1 Internal to Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.4.2 Sensor and Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.4.3 301 pH/Temperature Device with Signature Connection Ending in Untermi-
nated Leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.4.4 301 pH/Temperature Device with Signature Connection Ending in TIENet
Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.4.5 306 Sampler Interface Cable with Signature Connection Ending in Untermi-
nated Leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
B.4.6 306 Sampler Interface Cable with Signature Connection Ending in TIENet
Plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
B.4.7 310 Ultrasonic Level Sensor with Signature Connection Ending in Untermi-
nated Leads. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
B.4.8 310 Ultrasonic Level Sensor with Signature Connection Ending in TIENet
Plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
B.5 330 Bubble Options and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-4
B.5.1 350 Area Velocity Sensor with Signature Connection Ending in Unterminated
Leads. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-5
B.5.2 350 Area Velocity Sensor with Signature Connection Ending in TIENet Plug.
B-5
B.5.3 360 LaserFlow Velocity Sensor with Signature connection ending in untermi-
nated leads. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-5
B.5.4 360 LaserFlow Velocity Sensor with Signature Connection Ending in TIENet
Plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6
B.6 Modems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6
B.7 Manuals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6
B.8 Sensor Mounting Rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6
B.8.1 Spring Rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-6
B.8.2 Scissor Rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-7
Appendix C Modbus Output Protocol
C.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.2 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
C.3 Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2

Signature® Flow Meter
Table of Contents
9
C.4 Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
C.5 Signature ASCII or RTU Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
C.6 Register Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
C.6.1 Modbus Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Appendix D Material Safety Data Sheets
List of Figures
1-1 Signature Flow Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1-2 Multiple options can be used in any combination . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1-3 Front and exterior component identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
1-4 Home screen and basic keypad functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
1-5 Specification drawing: Signature Flow Meter with stand in side facing position 1-10
1-6 Specification drawing: Signature Flow Meter with stand in upward facing position
1-11
1-7 Specification drawing: Signature Bubbler Flow Meter, 1 of 2 . . . . . . . . . . . . . . . 1-12
1-8 Specification drawing: Signature Bubbler Flow Meter, 2 of 2 . . . . . . . . . . . . . . . 1-13
2-1 Flowlink Connect screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2-2 Site Info tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2-3 Devices tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
2-4 Program tab: Accessing the browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
2-5 Home screen (normal operating mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2-6 Character grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
2-7 Menu Tree: Top menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
2-8 Menu Tree: Hardware Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
2-9 Measurement parameters for each TIENet device . . . . . . . . . . . . . . . . . . . . . . . . 2-13
2-10 Modbus Input Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
2-11 Editing Modbus device parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
2-12 Modbus Output Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
2-13 Menu Tree: Configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
2-14 Menu Tree: Flow rate input setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
2-15 Menu Tree: Volume Input Setup (total flow) . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
2-16 Menu for Rainfall Input Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
2-17 Menu for Load Calculation Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
2-18 Example of defining conditions & building equations. . . . . . . . . . . . . . . . . . . . . 2-26
2-19 Local alarm setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
2-20 SMS and Server alarm setup (modem required) . . . . . . . . . . . . . . . . . . . . . . . . 2-29
2-21 Menu Tree: Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
2-22 Menu Tree: USB Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
2-23 Event Viewer in Flowlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-35
2-24 Report file verifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
3-1 Open door and front panel to access interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3-2 Connector case, connectors, and fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3-3 Connector Case cable entries for power and external devices . . . . . . . . . . . . . . . . 3-4
3-4 Strain relief 3/4NPT Cord-grip fitting for TIENet devices . . . . . . . . . . . . . . . . . . 3-5
3-5 Cord-grip fittings installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3-6 Diameter-seal plugs for unused ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
3-7 TIENet Device terminal strips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3-8 Installing TIENet cable with a cord-grip fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
3-9 TIENet Device terminal connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
3-10 Attach wired terminal strip to connector case socket . . . . . . . . . . . . . . . . . . . . . 3-9
3-11 Insert the cable reference tubing into the case board reference port . . . . . . . . . 3-9
3-12 Position and secure the cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
3-13 Location of power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
3-14 Signature Flow Meter mounted on wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Signature® Flow Meter
Table of Contents
10
3-15 Weather shield - recommended for outdoor installations
(Drawing & Photo courtesy of TRACOM, Inc.) . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
3-16 Positioning the Bubble Line in the Flow Stream . . . . . . . . . . . . . . . . . . . . . . . . 3-16
3-17 Installing the Stainless Steel Bubble Line Extension . . . . . . . . . . . . . . . . . . . . 3-18
3-18 Level adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
3-19 Hazardous Location Installation Control Drawing-ATEX . . . . . . . . . . . . . . . . . 3-20
4-1 Signature on portable stand side facing (left) and upward facing (right) . . . . . . . 4-1
4-2 Pull out the handle latch pins on each side of the stand . . . . . . . . . . . . . . . . . . . . 4-2
4-3 One of the eight screws loosened. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-4 Signature tilted up in preparation of removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4-5 Signature in upward facing position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4-6 Notch in stand for the power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
4-7 946 lead-acid battery installed under the Signature Portable . . . . . . . . . . . . . . . 4-5
4-8 Battery hold down and thumb screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
4-9 Example of defining conditions and building equations . . . . . . . . . . . . . . . . . . . . 4-6
4-10 Measuring flow meter current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4-11 Connector case, connectors, and fuses for Signature Portable Flow Meter . . . 4-12
4-12 How to connect a TIENet receptacle to the Signature Portable . . . . . . . . . . . . 4-13
4-13 Removing the plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
4-14 Connecting a rain gauge to the Signature receptacle (L) and then to the Signature
connector board (R) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
5-1 AC Line cord with a cord-grip fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5-2 Power supply mounting screw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5-3 Power supply removal/replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5-4 Power supply terminal strip: AC Input and DC Output . . . . . . . . . . . . . . . . . . . . 5-3
5-5 Battery backup kit contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
5-6 Attach extension cable to the connector case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5-7 Installing the battery backup mounting plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
5-8 Backup battery, installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
5-9 Disconnect and remove bubbler module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
5-10 Remove totalizer window cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
5-11 Optional non-resettable totalizer installation . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
5-12 External desiccator, installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
5-13 Remove red caps before installing external desiccant cartridge . . . . . . . . . . . . 5-13
5-14 Removing the external desiccant cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
5-15 Tubing configuration for optimal drying power (Exterior desiccator required) 5-15
5-16 TIENet Expansion Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
5-17 304 contact output card front and back view . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
5-18 View of two cards installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
5-19 304 contact output device configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
5-20 304 contact output setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
5-21 307 analog input channel identification and terminal connections . . . . . . . . . 5-22
5-22 Direction of switch in active and passive modes . . . . . . . . . . . . . . . . . . . . . . . . 5-23
5-23 307 analog input device configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
5-24 307 analog input setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
5-25 308 analog output channel identification and terminal connections . . . . . . . . 5-26
5-26 308 analog output device configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
5-27 308 analog output setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
5-28 Reference port kit (full length not shown) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-29
5-29 Reference port kit: Remove filter and barb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-29
5-30 Reference port kit: Install filter and barb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-30
5-31 Reference port kit: Installed on flow meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-30
5-32 Ethernet modem kit contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-32
5-33 Ethernet modem installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
5-34 Ethernet modem setup: Communication settings (default settings shown) . . . 5-34
5-35 Locating the NODE ID (MAC address) on the ethernet modem . . . . . . . . . . . . 5-35
5-36 Magnetic-mount cellular antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-36
5-37 CDMA Cellular modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-36
5-38 GSM Cellular modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-37

Signature® Flow Meter
Table of Contents
11
5-39 FCC ID label on modem and location of label on the bottom of Signature case 5-37
5-40 Cellular modem kit contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-38
5-41 Cellular modem installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-39
5-42 Cellular modem setup: Communication settings . . . . . . . . . . . . . . . . . . . . . . . . 5-40
6-1 Locating firmware updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6-2 USB Micro adaptor cable (flash drive not included) . . . . . . . . . . . . . . . . . . . . . . . 6-3
6-3 Open door and front panel to access interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6-4 Removing the internal desiccant bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6-5 External desiccator, installed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6-6 Desiccant indicating saturation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6-7 Removing the external desiccant cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6-8 Opening the desiccant cartridge chambers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6-9 Plumbing diagram of bubbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
6-10 Remove non-bubbler shield . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-19
6-11 Remove bubbler module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
6-12 330 Bubbler assembly installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21
6-13 Remove extra tubing and fitting (if applicable) . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
6-14 Routing and connections of 330 bubbler tubing . . . . . . . . . . . . . . . . . . . . . . . . . 6-23
6-15 Front cover (door) replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24
C-1 Configuration example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
List of Tables
1-1 Signature Flow Meter Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
1-2 TIENet 330 Bubbler Module Technical Specifications . . . . . . . . . . . . . . . . . . . . . . 1-9
2-1 Modbus Setup Worksheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
4-1 Battery Life Expectancy
(default measurement rate of 15 minutes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4-2 Battery Life Expectancy
( measurement rate of 5 minutes, all other parameters use default) . . . . . . . . . . 4-8
4-3 Default Method for Portable Signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
4-4 Additional Average Current Draw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
5-1 Direction of arrows and mode types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-23
6-1 Recommended Maintenance (Accessible Locations) . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-2 Recommended Maintenance (Difficult-to-Access Locations) . . . . . . . . . . . . . . . . . 6-1
6-3 Troubleshooting: Signature Flow Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6-4 Troubleshooting: TIENet 300 Connector Case . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
6-5 Troubleshooting: TIENet 301 pH/Temperature Device . . . . . . . . . . . . . . . . . . . . 6-11
6-6 Troubleshooting: TIENet 304 Contact Output Card . . . . . . . . . . . . . . . . . . . . . . 6-12
6-7 Troubleshooting: TIENet 307 Analog Input Card . . . . . . . . . . . . . . . . . . . . . . . . 6-13
6-8 Troubleshooting: TIENet 306 Sampler Interface . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
6-9 Troubleshooting: TIENet 308 4-20mA Analog Output . . . . . . . . . . . . . . . . . . . . . 6-14
6-10 Troubleshooting: TIENet 310 Ultrasonic Level Sensor . . . . . . . . . . . . . . . . . . . 6-15
6-11 Troubleshooting: TIENet 330 Bubbler Module . . . . . . . . . . . . . . . . . . . . . . . . . . 6-18
C-1 Modbus Output Registers for Signature Flow Meter . . . . . . . . . . . . . . . . . . . . . . C-4

Signature® Flow Meter
Table of Contents
12

Signature® Flow Meter
Safety
v
Signature® Flow M eter
Safet y
General Warnings Before installing, operating, or maintaining this equipment, it is
imperative that all hazards and preventive measures are fully
understood. While specific hazards may vary according to
location and application, take heed of the following general
warnings:
WARNING
Avoid hazardous practices! If you use this instrument in
any way not specified in this manual, the protection
provided by the instrument may be impaired.
AVERTISSEMENT
Éviter les usages périlleux! Si vous utilisez cet instrument
d’une manière autre que celles qui sont specifiées dans ce
manuel, la protection fournie de l’instrument peut être
affaiblie; cela augmentera votre risque de blessure.
Hazard Severity Levels This manual applies Hazard Severity Levels to the safety alerts,
These three levels are described in the sample alerts below.
CAUTION
Cautions identify a potential hazard, which if not avoided, may
result in minor or moderate injury. This category can also warn
you of unsafe practices, or conditions that may cause property
damage.
WARNING
Warnings identify a potentially hazardous condition, which
if not avoided, could result in death or serious injury.
DANGER
DANGER – limited to the most extreme situations
to identify an imminent hazard, which if not
avoided, will result in death or serious injury.

Signature® Flow Meter
Safety
vi
Hazard Symbols The equipment and this manual use symbols used to warn of
hazards. The symbols are explained below.
Hazard Symbols
Warnings and Cautions
The exclamation point within the triangle is a warning sign alerting you of
important instructions in the instrument’s technical reference manual.
The lightning flash and arrowhead within the triangle is a warning sign alert-
ing you of “dangerous voltage” inside the product.
Symboles de sécurité
Ce symbole signale l’existence d’instructions importantes relatives au
produit dans ce manuel.
Ce symbole signale la présence d’un danger d’électocution.
Warnungen und Vorsichtshinweise
Das Ausrufezeichen in Dreieck ist ein Warnzeichen, das Sie darauf
aufmerksam macht, daß wichtige Anleitungen zu diesem Handbuch
gehören.
Der gepfeilte Blitz im Dreieck ist ein Warnzeichen, das Sei vor “gefährlichen
Spannungen” im Inneren des Produkts warnt.
Advertencias y Precauciones
Esta señal le advierte sobre la importancia de las instrucciones del manual
que acompañan a este producto.
Esta señal alerta sobre la presencia de alto voltaje en el interior del
producto.

1-1
Signature® Flow Meter
Section 1 Introduction
The Signature Flow Meter is designed for open channel flow
monitoring applications using any combination of flow and
parameter measurement technologies and sampling, depending
on what is required at the monitoring site.
The bubble line is anchored in the flow stream at the appropriate
measuring point in the weir, flume, or other open channel flow
situation. Air slowly bubbles out of the line into the flow stream.
The pressure in the bubble line is proportional to the liquid level
in the flow stream, and the flow meter measures this pressure,
sensing the liquid level.The Signature has built-in standard
level-to-flow conversions that cover the majority of open channel
flow measurement situations. Flow measurement is usually a
calculation based on a known relationship between liquid level
and flow rate. Additionally, the Signature can calculate flow
using standard open channel level-to-flow and area-velocity con-
versions, as well as equations, or data points, depending upon the
measurement device(s) attached to the meter and the program
specified by the user.
Note
Recent enhancements have been made to the Signature Flow
Meter. Many of these features are standard for all new Signa-
ture units which are identifiable by the serial label mounted on
the bottom of the unit (PN 60-4304-065).
Figure 1-1 Signature Flow Meter

Signature® Flow Meter
Section 1 Introduction
1-2
1.1 Quick Start
Numerical:
•Entervalues•Typecharacters
Arrows:
•Navigateup,down,left,right
Soft Keys:
•Currentdisplayedfunction
•=Returntolastmenu
•=Confirm&advancetonext
step
Home:
•ReturntoHomeScreenfromanywhere
Enter:
•Openlist•Confirmselection•Activate
field
•=Pulldownlistavailable
•=Charactergridavailable
Delete / Exit:
•Clearlastentry•Exitlist•Closewindow
Decimal:
•Navigateuponescreenatatime
Plus-Minus:
•Navigatedownonescreenatatime
•Adjustscreencontrast,whenusedwith
theupordownarrowkeys.
,,. . .
,. . .
Back
Next
Configure Options
Site: Clock, Name, Display, Units
Measurement Setup:
Level, Velocity, Flow, Volume
Adjust: Level, pH, Velocity
Equation / Trigger
Data Storage Rate / Data Push
Sampler Interface Setup
Outputs: Alarm, Analog
Reset Totalizers
Reports / History
Administration
Language
Set New Passcode
Update Firmware
Sensor Diagnostics
System Information
License Information
Gather Fault Data
Restore Defaults
Hardware Setup
TIENet Devices
SDI-12 Setup
Modbus In
Modbus Out
Modem

Signature® Flow Meter
Section 1 Introduction
1-3
1.2 Data Integrity What makes the Signature Flow Meter unique is its ability to
verify data integrity. This is accomplished by logging four special
event data types that cannot be altered, and are designed to alert
the user to any trends or anomalies, and to assess compliance.
This data can be downloaded from the flow meter and observed
in tabular or graphical format alongside regular site data, using
Flowlink software (see Section 2.10 Signature Data in Flowlink).
The data can also be downloaded onto a flash drive via the
micro-USB assembly on the front panel of the flow meter, then
imported into a spreadsheet or other viewing application (refer to
Section 2.9 USB Options for more information).
The four event data types are:
Program Report – Tracks changes to the Signature Flow Meter
configuration
Summary Report – Documents summaries of data measure-
ments (e.g., Min/Max/Avg)
Diagnostic Report – Tracks results from diagnostic tests
History Report – Tracks user and meter events (e.g., level
adjustments, data push, etc.)
1.3 Security The Signature Flow Meter can be secured shut with a padlock
with the hasp on the right side of the housing (refer to
Figure 1-3). The program settings and recorded data can be pro-
tected by a user-selected passcode (refer to Section 2.8.2 Set New
Passcode.
1.4 Compatible
Equipment
The Signature Flow Meter can interface with a variety of mea-
surement devices and other system components, depending on
site requirements.
Measurement devices for flow and water quality can be con-
nected to the same Signature Flow Meter and run simultane-
ously with TIENet®connectivity (up to nine TIENet devices).
The flow meter can also communicate with an optional Teledyne
Isco wastewater sampler and rain gauges.
For descriptions of interfacing and parameter sensing TIENet
devices, refer to Section 5 Equipment Options. Each external
TIENet device comes with its own user manual.
The Signature is capable of receiving data from devices using
Modbus ASCII or Modbus RTU protocol.
A variety of application-specific accessories are available from
Teledyne Isco. Refer to Appendix B Options and Accessories for a
complete list with ordering information.
A basic Signature system has one or more TIENet devices for
flow and/or parameter measurement connected to the Signature
Flow Meter (up to nine TIENet devices at once). Other configura-
tions may include an enclosure and additional internal or
external devices, including analog output cards, analog input
cards, contact output cards, a modem, up to two SDI-12 inputs,
and Modbus devices.

Signature® Flow Meter
Section 1 Introduction
1-4
When connected remotely via modem, the web interface of the
Signature Flow Meter provides remote control and data access.
Figure 1-2 Multiple options can be used in any combination

Signature® Flow Meter
Section 1 Introduction
1-5
1.5 Identifying Signature
Components
The following are key components of the Signature Flow Meter:
Figure 1-3 Front and exterior component identification
Padlock
Hasp
Desiccant
Holder
(Used with TIENet 330
Bubbler, TIENet 350
AV Sensors, and 360
Laser Flow)
USB
Connector
Signature Connection
ports for power,
TIENet devices,
antenna, bubble line
hose barb
to bubbler air
supply
to reference
port
Injection molded UV protected
sturdy enclosure
USB Cable
Signature Portable Connection
ports for power and TIENet devices

Signature® Flow Meter
Section 1 Introduction
1-6
1.6 Controls and
Indicators
Before programming and operating the Signature Flow Meter,
become familiar with the keypad and standard screens.
1.6.1 Keypad Keys are identified in Figure 1-4; keypad functions are detailed
in Section 2.1.1.
Figure 1-4 Home screen and basic keypad functions
Below the display are three software configured function keys
(softkeys) that are used to make selections and navigate through
menus. Their specific functions are dependent upon what oper-
ation you are performing, and will appear in the display window.
Flow Meter
™
SHORTCUTS MENU HELP
12345678 gal
Flow: 8.55 cfs
Level B: 2.00 ft
pH: 7.00 pH
[ Status: 10/01/2011 15:20 ]
To t a l F l o w
Site Name Here
Non-resettable
totalizer (optional)
User-programmed name
of measurement site
Main data type (Default = Total Flow)
Additional
data types
Status
line
Softkeys (3)
Softkey
functions
Scroll
bar
Arrow keys (4) for screen navigation
Home
(Run screen)
Enter
(Return key)
Delete
(Undo)
Numerical keys (12)
Red/Green
LED
indicator
Micro-USB
indicator
