iSimple ISFM21 User manual
Table
of
Contents
1.
Introduction
2.
ISFM21
Components
3.
Installation
Options
4.
Frequency Selection and
App
Operation
5.
Bluetooth
pairing and
connecting
6.
Troubleshooting
7.
Warranty
Information
Pages
2
2
2
3
3
3
4
1.
Introduction
Thank you for choosing the iSimple ISFM
21
as youraudio inputsolution.The ISFM21 (Tranzlt
BLU) is designed to provide the connecting link between your Android powered device with
Bluetooth, and your vehicle. This interface provides a Bluetooth connection point for your
android phone,
or
tablet, and delivers streaming audio directly into your radio.
2. ISFM21 Components
• Radio input module
·Application (Free download from android market)
3.
Installation Options (Choose A or B)
The ISFM21 interrupts the incoming antenna signal when
in
use, to deliver the cleanest
audio possible from your device.
To
regain standard FM operation without interruption,
simply pause the android device, and approximately 8 seconds later the full
FM
band will be
accessible. There is also a power on/off/auto option
in
the Tranzlt BLU app.
If
manual power
on/off control
of
the ISFM21 is desired, disconnect the "loop plug
",
and plug the "optional
toggle switch" into the power harness,
in
its place. This will allow the userto turn the ISFM21
on or off at any time.
A. Connecting to any FM equipped radio
1)Red Wire. Connect to switched accessory power (not constant)
2) Black Wire. Connect to ground.
3) Antenna input. Connect antenna lead from the vehicle.
4)
Antenna output. Connect antenna lead into back
of
radio.
Note:Antenna adaptors may be needed for select vehicles!
The ISFM21 is compatible with amplified antenna systems, and adaptors.
Android phone
or
tablet
(not included)
<<(
DD
~=
=ll
lr
Opt
io
n
al
toggle
swi
tch
B. Connecting to a radio equipped with an
RCA
auxiliary audio input
2
1) Red Wire. Connect to switched accessory power (not constant)
2) Black Wire. Connect to ground.
3) RCA connections. Use these connectors when the radio is equipped with an
RCA audio input. Connect a short pair
of
stereo RCA cables to this outpu
t,
and
into the radio's aux input.
The antenna connectors are not used
in
this configuration.
~===-
A
n
te
nn
a
In•
r. Antenna Out' round
Android phone
or
tablet
(not included)
r((
t
dac
({~
o~
({(
DD
O
iri
loopp
lug I c
~
1r
Op
ti
onal toggle
sw
i
tch
------..r
-:::=
t
oauxolia~aud
i
o
Inputon back ol
radoo
4. Frequency Selection and
App Operation
Selecting the ISFM21 Frequency
The factory-set operating frequency
is
88.3
FM.
If
an
alternate frequency is desired, the
frequency may
be
easily adjusted using the selector switch on the side
of
the module (see
illustration
).
For full frequency tuning control, visit the Android Market to download the free
app for Tranzlt BLU. Side
of
ISFM21
app
controlled 1106
.318
8.3 187.9
5.
Bluetooth Pairing and Connecting
To
pair your Android device with the ISFM21(this is only required the first time you use
the Tranzlt BLU, after being paired, itwill automatically reconnect with the android device
when returning to the vehicle)
A.
Turn the vehicle on.
B.
Open your device's Bluetooth settings menu, and search for new
Bluetooth adaptors.
C.
Select the device called "TranzltBLU
".
Choose "Connect"
Note: Ifpairing is not successful within the first 2 minutes afterturning the vehicle on, cycle
ignition off, then begin again
at
step A
6. Troubleshooting
Symptom
Cause Remedy
NoAudio from the Android 1)The radio
is
not set to the Tune to the default frequency: 88.3FM
source correct station
2) Device is notpaired Please reference section 5
fordevice pairing.
Noise
I static on
regular
FM
ISFM21 is active. Pause the andorid device, and wait 8
stat
i
ons
seconds.
Access the ISFM21 App, and select the
OFF option.
Audio
is
distorted The input from the android turn down the volume on the android
source is too loud. source until distortion is
no
longer
heard.
Can not find Tranzlt BLU The Tranzlt BLU is no longer in Turn the vehicle off, then back on again,
when searching bluetooth pairing mode (lasts 2 minutes try to pairwithin the first 2 minutes of
devices after key on) key on.
Message
appears
on
The device did notproperly Press "Connect" aagin.
If
pairing
adnroid
device
If
a establish a bluetooth connection continues to fail. cycignition off, back on
message
appears
on
your
and try pairing again.
device sating "Pairing The ISFM21 gain is set too low Adjust the gain setting on the back side
unsuccessful"
Make
sure
of
the ISFM21
"Tra
nzlt
BLU
"
is
turned
on, in
range
,
and
is
ready
to pair.
3
7.
Warranty
lnfonnation
One Year Limited Warranty
The quality controls used
in
the manufacture
of
this product will ensure your satisfaction.
This warranty applies only to the original purchaser
of
this product from an authorized
iSimple® dealer. This warranty covers any supplied or manufactured parts
of
this product that,
upon inspection by iSimple® authorized personnel, is found to have failed
in
normal use due
to defects
in
material orworkmanship. This warranty does not apply to installation expenses.
Attempting to service or modify this unit, operating this unit under conditions other than the
recommended voltage will render this
WARRANTY VOID.
Unless otherwise prescribed by law, iSimple® shall not be liable for any personal injury, prop-
erty damage and or any incidental or consequential damages
of
any kind (including water
damage) resulting from malfunctions, defects, misuse, improper installation or alteration
of
this product. All parts
of
this iSimple® product are guaranteed for a period
of
1year as follows:
Within the first 12 months from date
of
purchase, subject to the conditions above, iSimple®
will repair or replace the product at ourdiscretion, if it is defective
in
material orworkmanship
· providing it is returned to an Authorized iSimple®' dealer, with PROOF OF PURCHASE from
an authorized iSimple® dealer.
Warning:
This equipment may be reset by unintentional electrostatic discharge during operation.
Exposure to direct sunlight
or
extreme heat may cause damage or malfunction.
FCC Class B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15
of
FCC rules. These limits are designed to provide reasonable
protection against harmful interference
in
a residential installation. This equipment gener-
ates, uses, and can radiate radio frequency energy and, if not installed and used
in
accor-
dance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will
not
occur
in
a particular installation. If
this equipment does cause harmful interference to radio ortelevision reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more
of
the following measures:
1.
Re-orientate or relocate the receiving antenna.
2.
Increase the separation between the equipment and receiver.
3.
Connect the equipment into an outlet on a circuit different from that
of
which the receiver
is connected.
4.
Consult the dealer or an experienced radio I television technical for help.
Notice: The changes or modifications not expressly approved by the party responsible com-
pliance could void the user authority to operate the equipment.
4
For best performance, have
it~~
professionally installed.
A
division
of
AAMP
of
America
rM
13190 56th
Court
Clearwater,
Florida
33760
Ph. 866-788-4237
support@iSimpleSolutions
.
com
©
2011
AAMP
of
Florida
, Inc.
www.iSimpleSolutions.com
TranzltBLU Android APP User
Manual
r---~--------------~
ON: Turns
FM
radio interface
ON
and keeps
it
ON
while
APP
is
running
or
OFF
is
selected
1--------
OFF:
Turns
FM
radio interface
OFF
AUTO:
Automaticallyturns
FM
radio
interface ON/OFF according
to
Bluetooth
(A2DP)
activity
(Note: Select
ON
before
selecting
AUTO)
r-------------------
1
FM
broadcast frequency:
- - -
-I
This
is
the
FM
frequencyTranzltBLU
is
: broadcasting
to
your
FM
radio on.
Be
sure
1
to
tune
yourradio
to
this same frequency.
L-------------------
r-------------------
-1
FM
broadcast frequency slide
I adjustment:
- - I : Slide left
or
right
to
select best performing
I 1
FM
frequency
I
L-------------------
-
-,
1
-r
FM
broadcastfrequency
b~tt;n
-
- -
1 I adjustment:
: :
Use
these
to
select best performing
1 1
FM
frequency
I
L-
r---·
_....,_..,.
__
L - MENU Button (on phone):
Allows selection
of
FM
radio region;
North America, Japan
or
Europe
L-------------------
IMPORTANT NOTE: While listening
to
certain sources
of
music such
as
Pandora
that
have extended pauses between songs
it
is
possible
that
the radio interface
of
the
TranzltBLU will disengage. When this occurs your
FM
radio will play through again
momentarily. Once thenextsong begins, theTranzltBLU will reengage and playthrough.
The
TranzltBLU behaves this way due
to
the
Bluetooth
A2DP
signaling.
If
this
functionality
is
not
desired, you
can
choose
not
to
use the
AUTO
setting and instead
select
ON
in the TranzltBLU App
as
outlined above. This will provide a
less
disruptive
listening experience.
