iSimple TranzIt BLU ISFM23 User manual

ISFM23
TranzItTM BLU
I
S
FM2
3
TM
WIRELESS BLUETOOTH AUDIO
TO ANY CAR RADIO
MAKE THE CONNECTION
iSimple®
A Division of AAMP of America™
13190 56th Court Clearwater, FL 33760
Ph. 866-788-4237
[email protected]
©2012 AAMP of Florida, Inc.
www.isimplesolutions.com
Smartphones and
Bluetooth™media devices
98.3
98.2 98.4
98
.
3
7LYMLJ[MVY
(5+960+
Rev.072312

Table of Contents
Pages
1. Introduction 2
2. ISFM23 Components 2
3. Installation Options 2
4. Frequency Selection and
App Operation 3
5. Bluetooth pairing and connecting 3
6. Troubleshooting 3
7. Warranty Information 4

2
1. Introduction
Thank you for choosing the iSimple ISFM23 as your audio input solution. The ISFM23 (TranzIt
BLU) is designed to provide the connecting link between your Android device, iPod, iPhone or
iPad, and your vehicle. This interface provides a Bluetooth connection point for your Android
device, iPod, iPhone or iPad, and delivers streaming audio directly into your radio.
2. ISFM23 Components
5DGLRLQSXWPRGXOH
$SSOLFDWLRQ)UHHGRZQORDGIURP*RRJOH3OD\RUWKHDSSVWRUH
3. Installation Options (Choose A or B)
The ISFM23 interrupts the incoming antenna signal when in use, to deliver the cleanest
audio possible from your device. To regain standard FM operation without interruption,
simply pause the Android device, iPod, iPhone or iPad, and approximately 8 seconds later
the full FM band will be accessible. There is also a power on/off/auto option in the TranzIt
BLU app. If manual power on/off control of the ISFM23 is desired, disconnect the “loop plug”,
and plug the “optional toggle switch” into the power harness, in its place. This will allow the
user to turn the ISFM23 on or off at any time.
A. Connecting to any FM equipped radio
1) Red Wire. Connect to switched accessory power (not constant)
2) Black Wire. Connect to ground.
3) Antenna input. Connect antenna lead from the vehicle.
4) Antenna output. Connect antenna lead into back of radio.
Note: Antenna adaptors may be needed for select vehicles!
7KH,6)0LVFRPSDWLEOHZLWKDPSOL¿HGDQWHQQDV\VWHPVDQGDGDSWRUV
B. Connecting to a radio equipped with an RCA auxiliary audio input
1) Red Wire. Connect to switched accessory power (not constant)
2) Black Wire. Connect to ground.
3) RCA connections. Use these connectors when the radio is equipped with an
 5&$DXGLRLQSXW&RQQHFWDVKRUWSDLURIVWHUHR5&$FDEOHVWRWKLVRXWSXWDQG
into the radio’s aux input.
 7KHDQWHQQDFRQQHFWRUVDUHQRWXVHGLQWKLVFRQ¿JXUDWLRQ
switched accessory
ground
Antenna In*
Antenna Out*
ISFM23
a
ccess
ccess
ces
ces
ces
ory
switc
switc
wit
wit
wit
hed
Loop plug
Optional toggle switch
Smartphone or
Bluetooth device
(not included)
98.3
98.2 98.4
98
.
3
to auxiliary audio
input on back of radio
switched accessory
ground
Antenna In*
Antenna Out*
ISFM23
a
ccess
ces
ces
or
y
switc
wit
hed
Loop plug
Optional toggle switch
Smartphone or
Bluetooth device
(not included)
98.3
98.2 98.4
98
.
3

3
4. Frequency Selection and
App Operation
Selecting the ISFM23 Frequency
The factory-set operating frequency is 88.3 FM. If an alternate frequency is desired, the
frequency may be easily adjusted using the selector switch on the side of the module
(see illustration). For full frequency tuning control, visit the app store to download the free app for
TranzIt BLU.
5. Bluetooth Pairing and Connecting
To pair your Android device, iPod, iPhone or iPad with the ISFM23 (this is only required the
¿UVWWLPH\RXXVHWKH7UDQ],W%/8DIWHUEHLQJSDLUHGLWZLOODXWRPDWLFDOO\UHFRQQHFWZLWK
your
Android device, iPod, iPhone or iPad when returning to the vehicle)
A. Turn the vehicle on.
B. Open your device’s Bluetooth settings menu, and search for new
Bluetooth adaptors.
C. Select the device called “TranzItBLU”. Choose “Connect”
1RWH,ISDLULQJLVQRWVXFFHVVIXOZLWKLQWKH¿UVWPLQXWHVDIWHUWXUQLQJWKHYHKLFOHRQF\FOH
ignition off, then begin again at step A
app | 106.3 | 88.3 | 87.9
Side of
ISFM23
controlled
6. Troubleshooting
Symptom Cause Remedy
No Audio from the Android
Device, iPod, iPhone or iPad
1) The radio is not set to the correct
station
Tune to the default frequency: 88.3FM
2) Device is not paired Please reference section 5
for device pairing.
Cannot access regular
FM stations
ISFM23 is active. Pause the Android Device, iPod, iPhone or
iPad, and wait 8 seconds.
Access the ISFM23 App, and select the
OFF option.
Audio is distorted The input from the android source
is too loud.
turn down the volume on the Android
Device, iPod, iPhone or iPad until distortion
is no longer heard.
&DQQRW¿QG7UDQ],W%/8ZKHQ
searching bluetooth devices
The TranzIt BLU is no longer in
pairing mode (lasts 2 minutes after
key on)
Turn the vehicle off, then back on again, try
WRSDLUZLWKLQWKH¿UVWPLQXWHVRINH\RQ
Message appears on iPod,
iPhone or iPad stating “Pairing
unsuccessful Make sure TranzIt
BLU is turned on, in range, and
is ready to pair”.
The device did not properly
establish a bluetooth connection
Press "Connect" again. If pairing continues
to fail, cycle ignition off, back on and try
pairing again.

4
7. Warranty Information
One Year Limited Warranty
The quality controls used in the manufacture of this product will ensure your satisfaction.
This warranty applies only to the original purchaser of this product from an authorized
iSimple®dealer. This warranty covers any supplied or manufactured parts of this product that,
upon inspection by iSimple®authorized personnel, is found to have failed in normal use due
to defects in material or workmanship. This warranty does not apply to installation expenses.
Attempting to service or modify this unit, operating this unit under conditions other than the
recommended voltage will render this
:$55$17<92,'
Unless otherwise prescribed by law, iSimple®shall not be liable for any personal injury, prop-
erty damage and or any incidental or consequential damages of any kind (including water
damage) resulting from malfunctions, defects, misuse, improper installation or alteration of
this product. All parts of this iSimple®product are guaranteed for a period of 1 year as follows:
:LWKLQWKH¿UVWPRQWKVIURPGDWHRISXUFKDVHVXEMHFWWRWKHFRQGLWLRQVDERYHL6LPSOH®
will repair or replace the product at our discretion, if it is defective in material or workmanship
providing it is returned to an Authorized iSimple®¶GHDOHUZLWK3522)2)385&+$6(IURP
an authorized iSimple®dealer.
Warning:
This equipment may be reset by unintentional electrostatic discharge during operation.
([SRVXUHWRGLUHFWVXQOLJKWRUH[WUHPHKHDWPD\FDXVHGDPDJHRUPDOIXQFWLRQ
)&&&ODVV%5DGLR)UHTXHQF\,QWHUIHUHQFH6WDWHPHQW
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment gener-
ates, uses, and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio communications.
+RZHYHUWKHUHLVQRJXDUDQWHHWKDWLQWHUIHUHQFHZLOOQRWRFFXULQDSDUWLFXODULQVWDOODWLRQ,I
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
5HRULHQWDWHRUUHORFDWHWKHUHFHLYLQJDQWHQQD
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that of which the receiver
is connected.
4. Consult the dealer or an experienced radio / television technical for help.
1RWLFH7KHFKDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\UHVSRQVLEOHFRP-
pliance could void the user authority to operate the equipment.

For best performance, have it
professionally installed.
