ISON IS-DF102 Series User manual

1
IS-DF102 Series
Quick Installation Guide
FCC Marking
This Equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance w ith the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct
the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received; including interference that may c ause undesired operation.
CE MARKING
This equipment complies with the requirements relating to
electromagnetic compatibility, EN 55022 class A for ITE, the essential
protection requirement of Council Directive 2004/108/EC on the
approximation of the laws of the Member States relating to
electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may
be possible that information in this document is not up-to-date. Please
check with your local distributors for the latest information. No part of
this document can be copied or reproduced in any form without written
consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective
companies.
Copyright © 2013, All Rights Reserved.

2
Key Features
True Mini, rugged design enclosure 59x36x49mm (LxWxD)
Supports 18V-36VAC/12V-60VDC
Supports Link Fault Pass through (LFP) function
Supports switch model and converter mode.
Surge protection diodes on power input.
ESD protection diodes on RJ-45 port
Provides Far End Fault function on FX port.
Provides increased Noise Immunity
Extended environmental specification -40°C to 75°C
Introduction
This true mini, rugged Industrial media converter is designed for where critical but
space-limited outdoor CAM enclosure. It can be powered by wide range of VAC , VDC
or external DC power adapter . With its multi-purpose design, it can also be used for Din-
Rail or wall-mounted. It is an ideal unit for IP surveillance, traffic monitoring and Security
application in critical environment. It can tolerate -40°C to 75°C in harsh environment to
perform a reliable network.
Housing Dimension

3
Power connection
This unit provides 3 pin terminal block. And it can be operated using either VAC or VDC power
source. The VDC power range is from 12VDC to 60VDC, and the VAC power range is from 18VAC
to 36VAC. Always Make sure your input voltage is within this supported voltage
range.
WARNING –any exceeded input voltage will not make this unit function and
may damage this unit.
To make power connection –Follow the printed polarity for V+, V-, Ground. Connect positive wire
to V+ , connect negative wire to V-, also connect neutral wire to ground.
Connecting procedure
STEP 1 –
Pull out 3 pin terminal block.
STEP 2 –
connect wire to V+, V-, and Ground
STEP 3 –
Connect SFP fiber connector or SC fiber wire to fiber port.
STEP 4 –plug back 3 pin terminal block to its place.
WARNING -- Always pull out terminal block to connect power wire. DONOT force SFP fiber into
Din Rail Bracket x 1
Wall mount bracket x 2
3 pin Terminal Block x1
Installation package
This unit can be installed by din-rail mounted or wall-mounted. Din-rail brackets and wall-
mounted bracket are included.

4
Dip switch function
Amber
ON –100M speed is detected.
OFF –10M speed is detected
P1--Power
ON -- Power is detected
LK/Act-- Fiber port
Link/Active
ON --fiber is detected.
Flashing -- data is transmitting / receiving
Green –
ON—TX link is detected
Flashing –TX data is
transmitting / receiving
DIP 1
ON
Converter mode
OFF
Switch mode (default)
DIP 2
ON
LFP function enabled
OFF
LFP function disabled (default)
ON
OFF
2 1
LED indicator
This unit is equipped with dip switches, located on the front panel marked as SW1. Adjusting the dip
switches will change the default function of this unit. This unit has set to manufacturer default as:
switch mode and LFP function off.
The table shown as you may change the dip switch setting to your desired environment.
SW1

5
IEEE Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3u 100Base-FX Fast Ethernet
IEEE802.3x Flow Control and Back Pressure
Data Processing
Store and Forward
Flow Control:
IEEE 802.3x Flow Control and Back Pressure
Architecture
Full wire speed conversion,
Transparent conversion to 802.1Q VLAN tagged packets.
MAC address Table Size
1K
Packet Buffer Size
1Mbits
Network Connector :
RJ-45 10/100M BaseT(X)
Auto negotiation, Auto MDI/MDI-X function,
Full/Half duplex
Fiber ports: 100BaseFX SC, ST, SC SM 30km, SFP 100BaseX
LED indicators
P1, Speed, LK/Act
Speed (TP port)
LK/Act(TP and Fiber port)
DIP Switch
Link Fault Pass Through (LFP)
Converter Mode, Switch Mode
Power protection
Surge protection diodes on power input
Connector protection
ESD protection diodes on TX port
Reserve polarity protection
Present
Overload current protection
Present
Power Input
18V-36VAC,
12V-60VDC,
Conformance to UL Standards
Use Isolated power supply to conform with UL 508 standard
Power Consumption
1.44Watts
Removable Terminal Block
3 pin contact terminal block for power input
Operating Temperature
-40℃~75℃
Operating Humidity
5% to 95% (Non-condensing)
Storage Temperature
-40℃~85℃
Housing Design
IP40 Design, high graded Aluminum
Case Dimension (W X D X H)
59x36x49mm (LxWxD)
Installation
DIN Rail mounted,
Panel Mounted,
EMC/EMS
CE, FCC
Specification:

6
EMI
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
Safety
EN60950-1
Environmental
RoHS, REACH
