ISON IS-DG102-F Operator's manual

1
FCC MARKING
This Equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received; including interference
that may cause undesired operation.
CE MARKING
This equipment complies with the requirements relating to electromagnetic
compatibility, EN 55022 class A for ITE, the essential protection requirement of
Council Directive 2004/108/EC on the approximation of the laws of the Member
States relating to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may be
possible that information in this document is not up-to-date. Please check with
your local distributors for the latest information. No part of this document can be
copied or reproduced in any form without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective
companies.
Copyright © 2013, All Rights Reserved.
IS-DG102-F
Quick Installation Guide

2
Key Features
Rugged design aluminum enclosure 103.5x32x81.5mm (LxWxD)
Supports 18V-36VAC/12V-60VDC
Supports Link Fault Pass through (LFP) fu nction
Supports switch model and converter mode.
Support SFP fiber speed 100M or 1000M dual mode
Surge protection diodes on power input.
ESD protection diodes on RJ-45 port
Provides Far End Fault function on FX port.
Provides increased Noise Immunity
Environmental specification -40°C to 75°C
This mini, rugged Industrial Gigabit media converter is designed for Security, Transportation and Telco
application to expand your network distances. It can be powered by wide range of VAC , VDC or external
DC power adapter . With its multi-purpose design, it can also be used for Din-Rail or wall-mounted. It is an
ideal unit for IP surveillance, traffic monitoring and Security application in critical environment. It can
tolerate -40°C to 75°C in harsh environment to perform a reliable network.

3
Power connection
This unit provides 4 pin terminal block. It can be operated using either VAC or VDC power source. The VDC
power range is from 12VDC to 56VDC, and the VAC power range is from 18VAC to 36VAC. Always Make
sure your input voltage is within this supported voltage range.
WARNING –any exceeded input voltage will not make this unit function and may damage this unit.
To make power connection –Follow the printed polarity for V+, V-, Ground. Connect positive wire to V+ ,
connect negative wire to V-, also connect neutral wire to ground.
Connecting procedure
STEP 1 –
Take out 4 pin terminal block located in the included mounting kit package.
STEP 2 –
connect power wire to 4 pin terminal block. V1+, V1- or redundant power wire to V2 + V2-. and Ground
STEP 3 –
Plug into terminal block socket shown above. Polarity needs to match the V+ and V-
WARNING -- Always SHUTS OFF power source to connect power wire.
+ V1 - + V2 -
Din Rail Bracket x 1
Wall mount bracket x 2
4 pin Terminal Block x1
Installation package
This unit can be installed by din-rail mounted or wall-mounted. Din-rail brackets and wall-mounted bracket
are included.

4
Dip switch function
Power – PW 1
Fiber port Link/Active
ON --fiber is detected.
Flashing -- data is transmitting /
receiving
Green –
ON—1000M link is detected
Flashing – TX data is
transmitting / receiving
LED indicator
This unit is equipped with 4 pin dip-switch located on the front panel. Adjusting the dip-switch setting will
change the default function of this unit. All the dip-switch settings are set to manufacturer default as OFF
Table shown below is the features of these dip-switch function. You may change the dip-switch setting to your
desired environment.
Default OFF to enable 1000M SFP
speed
Default OFF to enable SFP Auto-
negotiation mode
Default OFF to enable Switch
Mode.
Default OFF to disable LFP
function
Power – PW 2
Amber –
ON—100M link is detected
Flashing – TX data is
transmitting / receiving

5
Specification:
IEEE Standard
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3z 1000Base-X Gigabit Ethernet
Data Processing
Store and Forward
Flow Control
IEEE 802.3x Flow Control and Back Pressure
Architecture
Full wire speed conversion
Auto negotiation
Full/Half duplex
Auto MDI/MDI-X function
Supports LFP (Link Fault Pass Through) function
Supports 9K bytes jumbo frame
Packet Buffer Size
1M
Jumbo Frame
9KB
Network Connector
Twisted Pair:
10/100/1000 Base-T(X) RJ-45 Distance 100 Meter
Optical Fiber: SFP pluggable fiber, 100M or 1000M by adjustable dip
switch
LED Indicators
Power:
P1(Power 1) - Green
P2(Power 2) - Green
Twisted Pair:
1000M/Link/Act - Green
100M Link/Act - Yellow
Optical Fiber: Link/Act - Green
DIP Switch Function
Set LFP (Link Fault Pass Through) : Enable / Disable
Set Switch mode / Pass Through mode.
Set SFP speed 100M or 1000M
Set Enable or Disable SFP Auto-Negotiation
Power Protection
Surge protection diodes on power input
Reverse polarity protection on power input
Overload current protection
Power Input
Redundant Power 1 and Power 2
18V-36VAC or 12V-56VDC

6
Power Consumption
Max Power: 3 Watts
Removable Terminal Block
4 pin contact terminal block for power input
Wire range : 0.34mm^2 to 2.5mm^2
Solid wire (AWG) : 12-24/14-22
Stranded wire(AWG) : 12-24/14-22
Wire Strip length : 7-8mm
Torque : 5lb-In/0.5Nm/0.56Nm
Operating Temperature
-40℃~75℃
Operating Humidity
5% to 95% (Non-condensing)
Storage Temperature
-40℃~85℃
Housing Design
IP40 Design, high graded Aluminum
Case Dimension (LxWxD)
103.5mmx32mmx81.5mm (LxWxD)
Installation
DIN Rail mounted
Panel Mounted
Certifications:
EN55022/24
ITE equipment
EN50155
Railways Applications Electronic Equipment used on Rolling Stock
EN55011
Industrial, Scientific and Medical (ISM) equipment
EN50121-3-2
Railway Applications –Electromagnetic Compatibility –Part 3-2 Rolling
Stock - Apparatus
EN50121-4
Railway Applications –Electromagnetic Compatibility –Part4 Emissions
and Immunity of the Signaling and Telecommunications Apparatus
Safety
IEC EN60950-1
EMC/EMS
CE, FCC
EMI
FCC Part 15 Subpart B Class A,
CE EN 55022 Class A
EN 50155 / EN 60068-2-6
Vibration
EN 50155 / EN 60068-2-27
Shock
EN 50155 / EN 60068-2-32
Free Fall
Traffic Control
NEMA TS2 compliant

7
Housing Dimension
