ISSC BM63SPKA1MGA User manual

BM63SPKA1MGA
5F, No.5, Industry E. Rd. VII, Hsinchu Science Park, Hsinchu city 30077, Taiwan, R.O.C Version:1.2
Phone: [phone]/2014
Fax: [phone]
BM63SPKA1MGA
Bluetooth 3.0 Digital Audio Output Module

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 2 - 10/15/2014
Product Description
The ISSC BM63SPKA1MGA is a highly integrated Bluetooth 3.0 digital audio
output module, designed for high data rate, short-range wireless
communication in the 2.4 GHz ISM band. With the built-in ISSC Bluetooth
stack, profiles and digital audio interface, the ISSC BM63SPKA1MGA can
combine the external DSP and codec to provide high performance Bluetooth
audio.
Features
Main Chip: ISSC IS2063GM(Flash version)
Bluetooth 3.0 compliant
Max. +4dBm Class 2 output power
Receiver Sensitivity: GFSK typical -89dBm, π/4 PSK typical -90dBm,
8DPSK typical -83dBm
Piconet and Scatter net support
CVSD, A-law, -law, mSBC CODEC algorithms for voice applications
Support SONY new feature
SBC/AAC decode for Bluetooth audio streaming
Microphone input and audio line-in support
Built-in four language voice prompt (Chinese/English/Spanish/French)
Support PCM and I2S digital audio interface
Built-in 350mAH Li-ion battery charger
HSP 1.2, HFP 1.6,A2DP 1.2, AVRCP 1.5,SPP 1.0 profiles supported
Support USB 1.1 DFU and BC1.2/Apple charger detection
USB BC1.2 charger detection for DCP/CDP/SDP
Apple Charger: 2.5W, 5W, 10W, 12.5W
3.3V operating voltage
Built-in program ROM and 64Kb EEPROM
51 pins for SMT module Size: 15mmx32mm
Built-in PCB Antenna
RoHS compliant

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 3 - 10/15/2014
Module Pin Out Diagram
BM63SPKA1MGA
P02 43
P31 42
P33 41
P36 40
DP 39
ADAP_IN
24
DM 38
VDD_IO
23
EAN 37
P03 36
P05 47
P00 35
LED3
29
AOHPM
6
DR0
1RFS0
2SCLK0
3DT0
4
AOHPL
7
MICBIAS
10 MICN1
8MICP1
9
AIR
11 AIL
12
P04
18
SYS_PWR
27 BAT_IN 25
AMB_DET
26
P30 46
P20 44
CODEC_VO
22
AOHPR
5
P12
13
P27 45
ANT1
49 ANT2
50 ANT3
51
HCI_RXD
20
HCI_TXD
21
P13
14 RST_N
15 P35 34
P37 33
GND 32
LED1 31
LED2 30
P01
16 P24
17
PWR(MFB)
28
GND 48
P15
19

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 4 - 10/15/2014
Pin Definition for Flash module
Pin No.
Pin type
Name
Description
1
I
DR0
I2S interface: Digital Left/Right Data from ADC
2
O
RFS0
I2S interface: DAC Left/Right Clock
3
O
SCLK0
I2S interface: Bit Clock
4
O
DT0
I2S interface: Digital Left/Right Data to DAC
5
O
AOHPR
R-channel analog headphone output
6
O
AOHPM
Headphone common mode output/sense input.
7
O
AOHPL
L-channel analog headphone output
8
I
MICN1
MIC 1 mono differential analog negative input
9
I
MICP1
MIC 1 mono differential analog positive input
10
P
MICBIAS
Electric microphone biasing voltage
11
I
AIR
R-channel single-ended analog input
12
I
AIL
L-channel single-ended analog input
13
I/O
P12
GPIO, default pull-high input
1. KEY PIN for FT Test
2. EEPROM clock SCL
14
I/O
P13
GPIO, default pull-high input
1. KEY PIN for FT Test
2. EEPROM data SDA
15
I
RST_N
KEY PIN for FT Test
System Reset Pin (Low active)
16
I/O
P01
GPIO, default pull-high input
BAT_CHK_EN
17
I/O
P24
GPIO, default pull-high input
1. KEY PIN for FT Test
2. System Configuration:
H: Boot Mode
L: Boot Mode with P2_0 low combination
18
I/O
P04
GPIO, default pull-high input.
19
I/O
P15
GPIO, default pull-high input
20
I
HCI_RXD
KEY PIN for FT Test
1-bit serial data received from MCU through UART
21
O
HCI_TXD
KEY PIN for FT Test
1-bit serial data transmitted to MCU through UART
22
P
CODEC_VO
3.1V LDO output for CODEC power
23
P
VDD_IO
I/O power supply input

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 5 - 10/15/2014
Pin No.
Pin type
Name
Description
24
P
ADAP_IN
Power adaptor input
25
P
BAT_IN
Battery input
26
P
AMB_DET
ADC analog input 1
27
P
SYS_PWR
System Power Output
28
I
PWR(MFB)
Multi-Function Push Button key
29
I
LED3
LED Driver 3
30
I
LED2
LED Driver 2
31
I
LED1
LED Driver 1
32
P
GND
Ground Pin
33
I/O
P37
GPIO, default pull-high input
34
I/O
P35
GPIO, default pull-high input (LF/ES samples)
Default pull-low input (CS/MP samples)
Charger Enable
35
I/O
P00
GPIO, default pull-high input
UART TX_IND signal to wake up MCU
36
I/O
P03
GPIO, default pull-high input
UART RX_IND signal to wake up BT
(Note: HCI_RXD can also be used to wake up BT)
37
I
EAN
Embedded ROM/External Flash enable
H: Embedded; L: External Flash
38
I/O
DM
USB Differential data bus
Data -
39
I/O
DP
USB Differential data bus
Data +
40
I/O
P36
GPIO, default pull-high input
41
I/O
P33
GPIO, default pull-high input
ICHG1
42
I/O
P31
GPIO, default pull-high input
ICHG0
43
I/O
P02
GPIO, default pull-high input
44
I/O
P20
GPIO, default pull-high input
1. KEY PIN for FT Test
2. System Configuration,
H: Application
L: Baseband(IBDK Mode)
45
I/O
P27
GPIO, default pull-high input
46
I/O
P30
GPIO, default pull-high input

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 6 - 10/15/2014
Pin No.
Pin type
Name
Description
Line-in Detector
47
I/O
P05
GPIO, default pull-high input
Charger Status
48
P
GND
Ground Pin
49
P
ANT1
Antenna modification point
50
P
ANT2
Antenna modification point
51
P
ANT3
Antenna modification point
Block Diagram
Common RAM
BT 3.0 Digital Core
ROM
Interrupts
BUS
HCI/UART
GPIOs (Buttons)
I2C (GPIOs or H/W)
RAM
MCU Core
DSP Core
Memory Controller
DMA Controller
Modem + MAC
DSP ROM/RAM
PMU
Battery Charger
LDO
SAR_ADC
LED Driver * 2
BUCK
Power Switch
BT 3.0
Transceiver
Synthesizer
RF Transmitter
RF Receiver
XTAL + POR
Misc. PMU logic
EEPROM
Buttons
ULPC 32KHz
SPI
Flash
Audio Codec
Stereo DAC
Stereo ADC
Anti-Pop
Audio Digital Core
I2S/PCM
Module
External
MCU

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 7 - 10/15/2014
Digital Audio Interface
Support I2S and PCM interface
Sampling Rate : 8K, 16K, 44.1K, 48K, 88.2K, 96K
Word Length: 16 bits, 24 bits
4 application modes

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 8 - 10/15/2014
Mode 1: I2S Master
BCLK
ADCLRC
DACLRC
ADCDAT
DACDAT
Slave
SCLK0
RFS0
TFS0
DR0
DT0
Master
External CODEC/DSP BM63
DAC
ADC ADC
A2DP/SCO
SCO
LineIn
Bn-1
RFS0
SCLK0
DR0/DT0 Bn-2 B1B0Bn-1 Bn-2 B1B0
Left Channel Right Channel
1/fs
Word Length
or
Solutions with mic and line-in analog input with I2S audio output
Mic for Bluetooth SCO link
Line-in for external audio playback(for high SNR requirement)
BCLK
ADCLRC
DACLRC
ADCDAT
DACDAT
Slave
SCLK0
RFS0
TFS0
DR0
DT0
Master
External CODEC/DSP BM63
A2DP/SCO
DAC
LineIn
SCO

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 9 - 10/15/2014
Mode 2: I2S Slave
BCLK
ADCLRC
DACLRC
ADCDAT
DACDAT
Master
SCLK0
RFS0
TFS0
DR0
DT0
Slave
External CODEC/DSP BM63
DAC
ADC ADC
A2DP/SCO
SCO
LineIn
Bn-1
RFS0
SCLK0
DR0/DT0 Bn-2 B1B0Bn-1 Bn-2 B1B0
Left Channel Right Channel
1/fs
Word Length
or
Solutions with mic and line-in analog input with I2S audio output
Mic for Bluetooth SCO link
Line-in for external audio playback(for high SNR requirement)
BCLK
ADCLRC
DACLRC
ADCDAT
DACDAT
Master
SCLK0
RFS0
TFS0
DR0
DT0
Slave
External CODEC/DSP BM63
A2DP/SCO
DAC
LineIn
SCO

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 10 - 10/15/2014
Mode 3: PCM master
BCLK
ADCLRC
DACLRC
ADCDAT
DACDAT
Slave
SCLK0
RFS0
TFS0
DR0
DT0
Master
External CODEC/DSP BM63
DAC
ADC ADC
A2DP/SCO
SCO
LineIn
Bn-1
RFS0
SCLK0
DR0/DT0 Bn-2 B1B0Bn-1 Bn-2 B1B0
Left Channel
1/fs
Word Length
Right Channel

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 11 - 10/15/2014
Mode 4: PCM slave
BCLK
ADCLRC
DACLRC
ADCDAT
DACDAT
Master
SCLK0
RFS0
TFS0
DR0
DT0
Slave
External CODEC/DSP BM63
DAC
ADC ADC
A2DP/SCO
SCO
LineIn
Bn-1
RFS0
SCLK0
DR0/DT0 Bn-2 B1B0Bn-1 Bn-2 B1B0
Left Channel
1/fs
Word Length
Right Channel

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 12 - 10/15/2014
Outline Dimension (Module Foot print)

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 13 - 10/15/2014

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 14 - 10/15/2014
Electrical Characteristics
Table 1: Absolute Maximum Voltages
Min
Max
Storage Temperature
-40ºC
+85ºC
ESD: Human Body Mode
±2KV
ESD: Machine Mode
±200V
ESD: Charge Device Mode
±200V
Core supply voltage
VDD_CORE, AVDD_PLL
1.14V
1.26V
RF supply voltage
VCC_RF
1.22V
1.34V
SAR supply voltage
AVDD_SAR
1.62V
1.98V
Codec supply voltage
VDD_AUDIO
2.7V
3.0V
I/O voltage
VDD_IO
3.6V
Supply voltage
BK_VDD
4.5V
3V1_VIN
4.5V
BAT_IN
3.0
4.5V
ADAP_IN
4.5
7.0V
LED
5.1V
Power switch
7.0V
Table 2: Recommended Operating Conditions
Min
Typ
Max
Storage Temperature
-10ºC
+25ºC
+60ºC
Core supply voltage
VDD_CORE, AVDD_PLL
1.14V
1.2V
1.26V
RF supply voltage
VCC_RF
1.22V
1.28V
1.34V
SAR supply voltage
AVDD_SAR
1.62V
1.8V
1.98V
Codec supply voltage
VDD_AUDIO
2.7V
3.0V
I/O voltage
VDD_IO
2.7V
3.0V
3.3V
Supply voltage
BK_VDD
3V
4.3V
3V1_VIN
3V
4.3V
BAT_IN
3V
4.3V
ADAP_IN
4.5V
6.0V
LED
4.3V
5.0V
Power switch
1.8V
6.0V

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 15 - 10/15/2014
Table 3: BUCK switching regulator
Normal Operation
Min
Typ
Max
Unit
Operation Temperature
-40
85
℃
Input Voltage (VIN)
3.0
3.8
4.5
V
Output Voltage (VOUT)
(ILOAD=70mA, VIN=4V)
1.7
1.80
2.05
V
Output Voltage Accuracy
±5
%
Output VoltageAdjustable Step
50
mV/Step
Output Adjustment Range
-0.1
+0.25
V
Output Ripple
10
15
mVRMS
Average Load Current (ILOAD)
120
mA
Settling Time
(start-up time)
EN or VIN to VOUT
1.2
2
ms
Conversion
efficiency
@BAT=3.8V
ILOAD = 50mA
88
%
ILOAD ≥10mA (PWM)
70
ILOAD ≥10mA (PFM)
80
ILOAD ≥250μA (PFM)
65
70
Switching Frequency
800
KHz
PWM/PFM Switching Point
by F/W
mA
Start-up Current Limit
0
50
210
mA
Start-up Inrush
Current
ILOAD = 10mA
400
mA
Quiescent Current
PWM
1000
μA
PFM
30
40
Output Current (Peak)
200
mA
Load Regulation (ILOAD = 10 ~ 100mA)
1
mV/mA
Line Regulation (3.2V < VIN < 4.2V)
0.03
(30)
%/V
(mV/V)
EN threshold
Logic Low Voltage (VIL)
0.4
V
Logic High Voltage (VIH)
1.62
V
EN current
10
nA
Shutdown Current
<1
μA

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 16 - 10/15/2014
Table 4: Low Drop Regulation
Min
Typ
Max
Unit
Operation Temperature
-40
85
℃
Input Voltage (VIN)
3.0
4.5
V
Output Voltage (VOUT)
(1) VOUT_CODEC
(2) VOUT_IO
VOUT = 2.9V
(2.4~3.4V)
2.9
V
VOUT = 1.8V
(1.3~2.3V)
1.8
Accuracy (VIN=3.7V, ILOAD=100mA, 27’C)
±5
%
Output VoltageAdjustable Step
67
100
mV/Step
Output Adjustment Range
±0.5
V
Start-up Inrush Current
ILOAD=10mA
200
400
mA
Settling Time (start-up time)
EN or VIN to VOUT
250
500
μs
Output Current (Average)
VOUT
100
mA
Output Current (Peak)
VOUT
150
mA
Drop-Out Voltage
(ILOAD = maximum output current)
300
mV
Quiescent Current
(excluding load, ILOAD < 1mA)
45
μA
Quiescent Current
(excluding load, ILOAD < 100μA)
N/A
μA
Load Regulation (Iload = 0mAto 100mA), ΔVOUT
Note: 0.4(mV/mA) * (100mA-0mA)=40mV
40
(0.4)
mV
(mV/mA)
Line Regulation (VOUT+0.3V<VIN<4.5V
7
10
mV/V
EN threshold
Logic Low Voltage (VIL)
0.4
V
Logic High Voltage (VIH)
1.62
V
EN current
10
nA
Shutdown Current (*1)
<1
μA

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 17 - 10/15/2014
Table 5: Battery Charger
Charging Mode (BAT_IN rising to 4.2V)
Min
Typ
Max
Unit
Operation Temperature
-40
85
℃
Input Voltage (VIN)
Note: It needs more time to get battery fully charged when
VIN=4.5V
4.5
5.0
7.0
V
Supply current to charger only
3
4.5
mA
Battery trickle charge current
(BAT_IN < trickle charge voltage threshold)
0.1C
mA
Maximum Battery
Fast Charge Current
Note: ENX2=0
Headroom > 0.7V
(ADAP_IN=5V)
170
200
240
mA
Headroom = 0.3V
(ADAP_IN=4.5V)
160
180
240
mA
Maximum Battery
Fast Charge Current
Note: ENX2=1
Headroom > 0.7V
(ADAP_IN=5V)
330
370
420
mA
Headroom = 0.3V
(ADAP_IN=4.5V)
180
220
270
mA
Minimum Step
1
mA
Trickle Charge Voltage Threshold
3
V
Float Voltage
4.158
4.2
4.242
V
Battery Charge Termination Current,
% of Fast Charge Current
10
%
Standby Mode (BAT_IN falling from 4.2V)
Supply current to charger only
2
4
mA
Battery Current
-1
μA
Battery Recharge Current
Note: C Battery Capacity (*1)
0.25C
mA

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 18 - 10/15/2014
Table 6: Audio codec ADC
Conditions
Min
Typ
Max
Unit
Temperature
-40
25
85
℃
Resolution
16
Bits
Input sample rate, Fsample
8KHz for MIC
44.1/48KHz for Line-in
8
48
KHz
Signal to Noise Ratio
(SNR @MIC or Line-in mode)
fin=1KHz
B/W=20~20KHz
(A-weighted)
THD+N < 1%
2.26Vpp input
8KHz
90
92
dB
44.1/
48KHz
90
92
Digital Gain
-54
4.85
dB
Digital Gain Resolution
2~6
dB
MIC Boost Gain
20
PGAAnalog Gain
-6
26
dB
Analog Gain step
1
dB
Input full-scale at maximum
gain (differential)
4
(AVDD=2.8V)
mVRMS
Input full-scale at minimum
gain (differential)
Note:
Input VPP=0.8*AVDD
800
(AVDD=2.8V)
mVRMS
3dB bandwidth
20
KHz
Microphone mode
input impedance
Input impedance
6
10
KΩ
Input capacitance
20
pF
THD+N (microphone input)
@30mVRMS input
0.02
%
THD+N (line input)
0.04
%
ADC channels
2
Analog supply voltage
2.6
2.8
3.0
V
Digital supply voltage
1.08
1.2
1.32
V
Crosstalk @line-in mode
42
45
48
dB

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 19 - 10/15/2014
MIC AMP
+
-
LINE AMP
+
-
MICP1
MICN1
AIL
1-bit
SD ADC
Digital
Codec
DSP
Core
MIC Boost Gain
0dB or 20dB
PGA Analog Gain
-6 ~ 26dB in 1dB step
ADC Digital Gain
-54 ~ 4.85dB
Fixed in 0dB now
DSP Digital Gain
-96 ~ 0dB in 6dB step
Fixed in 0dB now
System Gain = MIC Boost Gain + PGA Analog Gain + ADC Digital Gain + DSP Digital Gain
MIC Boost Gain and PGA Gain are controlled by DSP F/W
(1) MIC mode:
(a) There are 16 gain levels: 46/43/40/37/34/31/28/25/22/19/16/13/10/7/4/0 dB
(b) 46/43/40/37 dB gain levels are normally used for MIC mode
(2) Line-in mode:
(a) MIC boost gain = 0 dB
(b) PGA analog gain = 0 dB
(c) ADC digital gain = 0 dB
(d) DSP digital gain = 0 dB
(e) Gain control for line-in mode is recommended to be done by DAC side
Note: For I2S digital audio output, no gain control in BM63 so far and it is controlled by external DAC
MIC AMP
+
-
LINE AMP
+
-
MICP1
MICN1
AIL
1-bit
SD ADC
Digital
Codec
DSP
Core
MIC Boost Gain
0dB or 20dB
PGA Analog Gain
-6 ~ 26dB in 1dB step
ADC Digital Gain
-54 ~ 4.85dB
Fixed in 0dB now
DSP Digital Gain
-96 ~ 0dB in 6dB step
Fixed in 0dB now
BT
RF/MAC
External
MCU
External
DSP/DAC
(YDA174)
I2S
I2C
Digital/Analog
Gain Control
UART
A2DP down link
&
SCO down link
SCO up link
Line-in mode

BM63SPKA1MGA
ISSC Confidential(Version: 1.2) - 20 - 10/15/2014
Table 7: Transmitter section for BDR (25℃)
Min
Typ
Max
Bluetooth
specification
Unit
Maximum RF transmit power
2.0*
5.0
-6 to 4
dBm
RF power variation over temperature
range with compensation disabled
±2.0
dB
RF power control range
18
≥16
dB
RF power range control resolution
±0.5
dB
20dB bandwidth for modulated
carrier
925
≤1000
KHz
ACP
Note:
F0=2441MHz
F = F0±2MHz
-42
-40
≤-20
dBm
F = F0±3MHz
-49
-48
≤-40
dBm
F = F0±>3MHz
-57
-53
≤-40
dBm
∆f1avg maximum modulation
145
175
140<∆f1avg<175
KHz
∆f2max maximum modulation
120
135
140
≥115
KHz
∆f2avg/∆f1avg
0.9
0.95
≥0.80
ICFT
4.5
8
10.5
±75
KHz
Drift rate
3.3
5
7.0
≤20
KHz/50
us
Drift (single slot packet)
12
≤40
KHz
2nd harmonic content
-42
≤-30
dBm
3rd harmonic content
-45
≤-30
dBm
* The transmit power is calibrated in MP.
