ITC TI-120S User manual

OPERATION MANUAL
Please follow the instructions in this manual to obtain the optimum resultsfrom this unit.
We also recommend that you keep this manual handyfor future reference.
TI-350S
MIXER ZONE AMPLIFIER
TI-240S
TI-120S
PUBLIC ADDRESS SYSTEM
MIN MAX
MASTER
MIC4 LINE2
LINE1
MIC LEVEL
TREBLE TREBLEBASS BASSTREBLE TREBLE TREBLEBASS BASS
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5
ALL CALL
2 4 80 CLIPPROT
ON
OFF
TREBLEBASS BA SS
MIC1 MIC2 MIC3
MIN MAX
LINE LEVEL
MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
ACDC PWR
MIN MAX MIN MAX
10 10 10 10 10 1010 1010 1010 1010 1010 1010 1010 1010 1010 10
CHIMESIREN
VOLUMEVOLUME
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6
1
2
3 4
5
6
MIXER ZONE AMPLIFIER
TI-120S

TABLE OFCONTENTS
1. SAFETYPRECAUTIONS .......................................................................................2
2. GENERALDESCRIPTION ....................................................................................4
3. FEATURES ...............................................................................................................4
4. NOMENCLATUREAND FUNCTIONS
4.1 FrontPanel ............................................................................................................ 5
4.2 RearPanel..............................................................................................................6
5. OPERATING.............................................................................................................8
6. APPLICATIONS ......................................................................................................9
7.SPECIFICATIONS .................................................................................................10
8. BLOCKDIAGRAM ................................................................................................11
9. DIMENSIONALDIAGRAM ..................................................................................12

2
1. SAFETY PRECAUTIONS
Be sure to read the instructions in this sectioncarefully before use.
Make sure to observe the instructions in this manualas the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
Do not place cups,bowls, or other containers of
liquid or metallic objects ontop of the unit. If they
accidentally spill into the unit, this maycause a
fire or electric shock.
Do not insert nor drop metallic objects orflammable
materials in the ventilation slots of the unit'scover,
as this may result in fire or electric shock.
When Installing the Unit When Installing the Unit
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from theAC outlet and contact
your nearest dealer. Make no furtherattempt
to operate the unit in this condition as thismay cause
fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure
of the core, disconnection,etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock,never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing
to your nearest dealer.
ITC
ITC
Do not expose the unit to rain oran environment
where it may be splashed by water orother liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on
the unit.Using a voltage higher than that which
is specified may result in fire or electric shock.
Do not cut,kink otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, andnever
place heavy objects - including the unit itself- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Becausehigh voltage
is applied to the speaker terminals,never touch
these terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground
to a gas pipe as a catastrophic disaster mayresult.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in theunit falling
down,causing personal injury and / or property
damage.

3
An all-pole mainsswitch with acontact separation ofat least 3mm in eachpole shall beincorporated in
the electrical installationof the building.
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in personal
injury and/or property damage. In addition, the object
itself may fall off and cause injury and/or damage.
Make sure that the volume ontrol is set to minimum
position before power is switched on. Loud noise
produced at high volume when power is switched
on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. Thisis an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning.
If dust is allowed to accumulate in the unit over a
long period of time, a fire or damage to the unit
mayresult.
ITC
Ifdustaccumulates onthe power supplyplug orin
the wall AC outlet, afiremay result.Clean it peri-
odically. Inaddition, insertthe plugin thewalloutlet
securely.
Switchoff thepower, andunplugthe powersupply
plugfrom theAC outletfor safetypurposes when
cleaningorleaving theunitunused for10 days or
more.Doingotherwise maycausea fire orelectric
shock.
Due to product upgrades, while some of the
features and specification in the user manual
does not match the actual functions, sorryfor
any inconvenience and thanks for your kind
understanding!
When Installing the Unit When Installing the Unit

3. FEATURES
2. GENERAL DESCRIPTION
1. .
2.
3. .
4. .
5. .
6. .
7.
5 zone output and 5 zone separate volume control
Built-in
Built-in 24V interface
Each channel with separate treble and bass control
Built-in 24V phantom power and separate power switch
Capacity of controlling by remote paging MIC
Selectable priority muting.
Swhable audio signal priority for MIC channels 1.
a. EMC input signal over other input soures, all 100V-open the area.
b. Remote MIC and Telephone input over SIREN, CHIME, MIC 1~4, LINE 1~2, input sources.
c. MIC 1,SIREN,CHIME over MIC 2~3, LINE 1~2 input sources.
siren.
The MixerZoneAmplifier seriesis equipedwith priorityfunction. Theyare designedto suitall PA
system applicationin schools,home ,officesand stores.
4

4.1 FRONT PANEL
1. TONE CONTROL
Individual Bass and Treble controls are used
to cut(decrease) or boost(increase) the lower
and Higher frequencies +12dB.
2. CHANNEL VOLUME
Controls the individual volume levels of Cha-
nnels.
3. ALARM INDICATOR
4. ALARM BUTTON
Press the bell button bell light, a bell indicating
the input signal output; bell signal conditioning
potentiometer can adjust its output volume.
5. ALARM POTENTIOMETER
6. BELL SIGNAL POTENTIOMETER
7. BELL SIGNAL BUTTON
Press the alarm button, alarm light, alarm
indication signal input with the output; alarm
signal conditioning potentiometer can adjust
the output volume.
8. BELL SIGNAL INDICATOR
9. MASTER VOLUME
This rotary switch controls the overall output
volume of the amplifiers output signal.
10.DC INDICATOR
24V DC supply power the indicator on
11.POWER SWITCH
Pressing this switch turns the unit on, as ind-
icated by the Power LED above the switch.
Pressing it again turns the unit off.
4. NOMENCLATUREAND FUNCTIONS
12. AC INDICATOR
~220-240V AC supply power the indicator on
13. POWER SWITCH INDICATOR
14. SPEAKER SELECTOR
These switches are used to select output to
any combination of up to five individual
speakers.
MIN 2
12.5V6V
OUTPUT
VOLTAGE 120W
240W
350W 6V
6V 12.5V 12.5V
3 4 5
70V50V
22V
32V
38V 50V
50V 70V 70V
MAX
100V
100V
100V
15. (ZONE1~ZONE5)ZONE SELECTION BUTTON
16. (ZONE1~ZONE5)ZONE SELECTION INDICATOR
17. ALL CALL INDICATOR
18. ALL CALL CONTROL
19. CLUP INDICATOR LED
20. OUTPUT LEVEL INDICATOR LED
21. PROTECT INDICATOR LED
5
2
14
6
13478910 1211
151617182021
135
19
MIN MAX
MASTER
MIC4 LINE2
LINE1
MIC LEVEL
TREBLE TREBLEBASS BASSTREBLE TREBLE TREBLEBASS BASS
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5
ALL CALL
2 4 80 CLIPPROT
ON
OFF
TREBLEBA SS BASS
MIC1 MIC2 MIC3
MIN MAX
LINE LEVEL
MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
ACDC PWR
MIN MAX MIN MAX
10 10 10 10 10 1010 1010 1010 1010 1010 1010 1010 1010 1010 10
CHIMESIREN
VOLUMEVOLUME
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6
1
2
3 4
5
6

XLR BAL
1-GND
2-HOT+
3-COLD-
CHIME ACTIVE
+48V PHANTOM
ON OFF ON OFF ON OFF ON OFFPRIORITY
MIC 1
GAIN
CHIME
2 TONE 4 TONE
REMOTE
~ 230V 50Hz
T3.15AL 250V
MIC 2
GAIN
+48V PHANTOM
MIC 3
GAIN
+48V PHANTOM
MIC 4
GAIN
+48V PHANTOM
TEL
VOLUME
INPUT
LINE 1
OUT
LINE 2 LINE
TEL
EMC
INPUT
OUTPUT
ZONE 5ZONE 4
ZONE 3
ZONE 2ZONE 1
COM 100V COM 100V COM 100V COM 100V COM 100V 100V
48 70V
COM
BATT SUPPLY
24V 8A
NOMENCLATURE ANDFUCTIONS
4.2 REAR PANEL
22.DC INPUT TERMINALS
These terminals are provided for the conne-
ction of backup battery.Connect a 24VDC 50A
battery source to these terminals.Make certain
the red terminal is connected to the battery's
positive (+) side,and the black terminal to the
battery's negative (-) side.
23.INPUT GAIN CONTROLS(TRIM VR)
These knobs provide continuous control of the
input levels for each of the six input channels.
When adjusting the input gain, make certain
that the levels are not set too high, or distortion
will result.
NOTE: It is safe to connect most modern dynamic
microphones or line level devices to the
channel Inputs when phantom power is
activated. However, some older ribbon
microphones may be damaged by phan-
tom power, and certain unbalanced line
level devices maymalfunction or produce
an Audible hum when phantom power is
active.
24.MIC INPUT CHANNEL 1~4
This is a special connector which will accept
either a 3-conductor XLR or a 3-conductor 1/3
jack.These inputs are suitable to receive signal
from microphones level devices.
+24V
+24V
(3)COLD
(2)HOT
(1)GNO
0V
25.LINE INPUT CHANNEL 1~2
This line-level input is an extra stereo input for a
stereo source such as a tape deck or CD player.
26.LINE OUTPUT
(Connection for power amplifier or recording equi-
pment)
27.EMC INPUT
When EM switch is connected and pressed in fire
or other emergencies, EM broadcasting stored in
voice ic is outputted. When selected, these sw-
hes will give priority to over all other signals inputs.
28.TEL AUDIO INPUT
Remote telephone paging and announcement
29.TEL AUDIO VOLUME
30.CHIME
2 Tone/4 Tone chime switch
31.FANNER
32.REMOTE CONTROL INPUT
By connecting a 15-pin D-SUB connector, it is po-
ssible to control speaker zone selection and activ-
ate the chime via wired remote. connection term-
inals for the remote are shown below.
MIC JACK (XLRJACK)
Pin 1:GROUND
Pin 2:HOT(+)
Pin 3:COLD(-)
LINE JACK (TRSPHONE JACK)
Sleeve:GROUND
Tip:HOT(+)
Ring:COLD(-)
GROUND
2.HOT
3.COLD
1.
1
3
2
HOT
COLD
GROUND
32
3122 23 24 25 26 27 28 29 30
3437 36 35 33
6

NOMENCLATURE ANDFUCTIONS
33.MIC 1 PRIORITY SWITCH
When selected, these switches will give prio-
rity to channels 1 over all other channels in-
puts.
34.4 hms\8 hms 70V\100V SPEAKER OUT-
PUT TERMINAL
This terminal is for speaker wire connection.
connect speakers whose combined impeda-
nce is equal to or higher than the rated output
impedance, as shown below.
35.(CH1~CH5)ZONE SPEAKER OUTPUT
36.POWER SWITCH
This switch turns the phantom power supply
on or off for all channels. When the switch is
turned on,+24V DC power is supplied to pins
2 and 3 of each channel's input connector.
Use phantom power when connecting cond-
enser microphones, which require an external
power supply.
37.~220-240V 50/60HZ POWER INPUT
Pin 1:Remote amplifierinput signalhot(+)
Pin 2:Remote amplifierinput signalcold(-)
Pin 3:Signal ground
Pin 4:Remote control1(Speaker 1)
Pin 5:Remote control2(Speaker 2)
Pin 6:Remote control3(Speaker 3)
Pin 7:Remote control4(Speaker 4)
Pin 8:Remote control5(Speaker 5)
Pin 9:Remote controlground
Pin 10:DC +24V
Pin 11: InputChime
Pin 12:NC
Pin 13:NC
Pin 14,15: NC
7

CONNECTING SPEAKERS
5. OPERATING
Before connecting speakers, disconnect the AC
power cable.Note theproper connectingterminals
as shownBelow.Make certainthat thetotal impe-
dance isnot lessthan therated impedanceindicated.
CONNECTING HIGH-VOLTAGEDISTRIBUTED
SPEAKER SYSTEMS
When connecting speaker system in parallel,
you can connect speakerswith atotal ratedinput
of upto 100W.
NOTE: Be surethat totalimpedance isnot lessthan
rated impedance.(See upperchart.)
WARNING: Extreme care must be exercised when
connecting high-impedance systems, as
Potentially Hazardousvoltages maybe
present atthese terminals.
Do notinstall thisequipment ina confinedspace with
less-than-adequate ventilation.
=
COM 100V
CH 1 CH 2 CH3 CH 4 CH 5
COM 100V COM 100VCOM 100V COM 100V
COM100W100W100W100W100W
8

MICROPHONE WITH ZONE CONTROL
11
22
33
010
010
010
CHIME VOL. MASTER VOL.
MIC VOL.
ON
OFF
POWER
24VDC
1
2
3
1 GND 2 GND 3 +24DC
CHIME
2 TONE 4 TONE
TEL
OUTPUT
MIC
ACTIVE OUT
BATTERY 24DC
MIC 2MIC 1 MIC 4MIC 3
+ ALARM IN -
ALARM OUT
EMERGENCY PANEL
AUDIO
OUT
R L
AUDIO SOURCES
MIC LINE
COM
ADRESSTAG
TELEPHONE INTERFACE
SPEAKERS SPEAKERS
6. APPLICATIONS
OTHER AMPLIFIER
9
XLR BAL
1-GND
2-HOT+
3-COLD-
CHIME ACTIVE
+48V PHANTOM
ON OFF ON OFF ON OFF ON OFFPRIORITY
MIC 1
GAIN
CHIME
2 TONE 4 TONE
REMOTE
~ 230V 50Hz
T3.15AL 250V
MIC 2
GAIN
+48V PHANTOM
MIC 3
GAIN
+48V PHANTOM
MIC 4
GAIN
+48V PHANTOM
TEL
VOLUME
INPUT
LINE 1
OUT
LINE 2 LINE
TEL
EMC
INPUT
OUTPUT
ZONE 5ZONE 4
ZONE 3
ZONE 2ZONE 1
COM 100V COM 100V COM 100V COM 100V COM 100V 100V
48 70V
COM
BATT SUPPLY
24V 8A

7. SPECIFICATIONS
10
AMPLIFIER SECTION
(4OHMS LOAD OUTPUT) RATED OUTPUT POWER (THD 1%)
SPEAKER ZONE 1~5 OUTPUT 25W
INPUTSENSITIVITY/IMPEDANCE
S/N
MIC INPUT SECTION
(MIC 1~4 IN@1KHZ)
LINE INPUT SECTION
(LINE1~2 IN@1KHZ)
INPUTSENSITIVITY/IMPEDANCE
INPUTSENSITIVITY/IMPEDANCE
S/N RATIO
S/N
FREQUENCYRESPONSE ( 3DB)
FREQUENCYRESPONSE ( 3DB)
PHANTOMPOWER
TONE CONTROL(BASS:100HZ,
TREBLE:10KHZ)
TONE CONTROL(BASS:100HZ,
TREBLE:10KHZ)
FREQUENCYRESPONSE ( 3DB)
PRE AMP OUT(MIC 1~4, LINE 1~2, TELIN, REMOTE IN)
T.H.D
REMOTE MIC SENSITIVITY/IMPEDANCS
POWER SOURCE
POWER CONSUMPTION
WEIGHT
DIMENSIONS(mm)
TELAUDIO INPUT
350W(RMS) 240W(RMS) 120W(RMS)
70W MAX 50W MAX 25W MAX
TI 350S TI-240S TI-120S
5MV 600 -245MV 5K BAL
350mV/47K
Better than 55dB
Better than 65dB
50Hz~16KHz
50Hz~16KHz
+10dB
10dB
+48V
0.775V/10K
Better than 65dB
50Hz~16KHz
1V/600
Less than 0.1% at 1KHz,1/3 rated power
775mV/10K
~220-240V;
50/60Hz, 24VDC
500W 320W 180W
484x399x132
22.4Kg 20.15Kg 16.9Kg

8. BLOCKDIAGRAM
8ohm
8ohm
11

Over
100
Over
UNIT:mm
Over
100
128
25
450
425
128
436
132
138
9.DIMENSIONAL DIAGRAM
484
UNIT:mm
100
6
12
MIN MAX
MASTER
MIC4 LINE2
LINE1
MIC LEVEL
TREBLE TREBLE
BASS BASS
TREBLE TREBLE TREBLE
BASS BASS
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5
ALL CALL
2 480 CLIPPROT
ON
OFF
TREBLE
BASS BASS
MIC1 MIC2 MIC3
MIN MAX
LINE LEVEL
MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
ACDC PWR
MIN MAX MIN MAX
10 10 10 10 10 1010 1010 1010 1010 1010 1010 1010 1010 1010 10
CHIMESIREN
VOLUMEVOLUME
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6
1
2
3 4
5
6
XLR BAL
1-GND
2-HOT+
3-COLD-
CHIME ACTIVE
+48V PHANTOM
ON OFF ON OFF ON OFF ON OFFPRIORITY
MIC 1
GAIN
CHIME
2 TONE 4 TONE
REMOTE
~ 230V 50Hz
T3.15AL 250V
MIC 2
GAIN
+48V PHANTOM
MIC 3
GAIN
+48V PHANTOM
MIC 4
GAIN
+48V PHANTOM
TEL
VOLUME
INPUT
LINE 1
OUT
LINE 2 LINE
TEL
EMC
INPUT
OUTPUT
ZONE 5ZONE 4
ZONE 3
ZONE 2ZONE1
COM 100V COM 100V COM 100V COM 100V COM 100V 100V
48 70V
COM
BATT SUPPLY
24V 8A
MIN MAX
MASTER
MIC4 LINE2
LINE1
MIC LEVEL
TREBLE TREBLE
BASS BASS
TREBLE TREBLE TREBLE
BASS BASS
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5
ALL CALL
2 4 80 CLIPPROT
ON
OFF
TREBLE
BASS BASS
MIC1 MIC2 MIC3
MIN MAX
LINE LEVEL
MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
ACDC PWR
MIN MAX MIN MAX
10 10 10 10 10 1010 1010 1010 1010 1010 1010 1010 1010 1010 10
CHIMESIREN
VOLUMEVOLUME
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6
1
2
3 4
5
6

PUBLIC ADDRESS SYSTEM
PUBLIC ADDRESS SYSTEM
VersionV0.5
