ITC TI-1206S User manual

MIXER ZONE AMPLIFIER
OPERATION MANUAL
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
PUBLIC ADDRESS SYSTEM
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5
ALL CALL
MIXER ZONE AMPLIFIER
TI-2406S
ZONE6
PROT
AC
DC
PWR
CLIP
SIG
MASTER
MIC1 MIC2 MIC3 MIC4 LINE1 LINE2
TREBLE TREBLE TREBLE TREBLE TREBLE TREBLE
ON
OFF
BASS BASS BASS BASS BASS BASS
USB
SD
SD /M ED IA
MODE
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6
TI-5006S
TI-3506S
TI-2406S
TI-1206S

TABLE OF CONTENTS
2
1. SAFETY PRECAUTIONS .......................................................................................3
2. GENERAL DESCRIPTION ....................................................................................5
3. FEATURES ...............................................................................................................5
4. NOMENCLATURE AND FUNCTIONS
4.1 Front Panel ..............................................................................................................6
4.2 emote control......................................................................................................... 6
4.3 Rear Panel............................................................................................................... 7
5. OPERATION ILLUSTRATION ................................................................................8
6. ............................................................................................11
7. APPLICATIONS ..................................................................................................... 12
8.BLOCK DIAGRAM .................................................................................................13
9.SPECIFICATIONS ................................................................................................. 14
10.DIMENSIONAL DIAGRAM ................................................................................. 15
R
TROUBLESHOOTING

Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer. Make no further
attempt to operate the unit in this condition as this
may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
ITC
ITC
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.
1. SAFETY PRECAUTIONS
3

An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning. If dust
is allowed to accumulate in the unit over a long
period of time, a fire or damage to the unit may
result.
ITC
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
Switch off the power, and unplug the power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
SAFETY PRECAUTIONS
4
Due to product upgrades, while some of the features and specification in the user manual does not
match the actual functions, sorry for any inconvenience and thanks for your kind understanding!

This product is a six zones mixer amplifier, combining of high-performance switching power supply+H
-class amplifier chip Built in Bluetooth and Tuner, with 2U chassis design, high efficiency, light weight,
beautiful appearance.
2. GENERAL DESCRIPTION
1. 4 channel Mic inputs, 2 channel line inputs, separated treble and bass control.
2. 6 zone outputs with independent volume control.
3. Built-in chime, chime tone optional: 4 tones and 2 tones (built-in), alarm generator.
4. MP3 decoder module supports USB / SD / Bluetooth / FM Tuner playback. Configure MP3 remote
control, support power-off memory, MIC recording function.
5. When start the built-in generator, the background music will be off and 6-channel zone output will be
on automatically, switch output volume to be maximum.
6. Built-in 24V DC power input.
7. MIC1-4 built-in 48V phantom power, with independent control switch.
8. T-216 remote control microphone can remote control zones outputs, up to 6 units cascaded .
9. The audio input with separate control, tone control and master volume control.
10. A variety of LED display (signal, clip, protection LED indicator).
11. With fan forced cooling structure, to ensure long time working.
12. There are 5 level priority functions:
The first level of EMC priority: When the EMC alarm signal input,it will force to close all
audio sources, 6-way partition output will automatically open.
The second level of alarm generator,except EMC input,It is higher priority than any other
signal input, will force to close all other audio sources,6-way partition output will
automatically open.
The third level of built-in TEL/REM MIC,it is higher priority than MIC1-4,LINE1-2,bell tone.
The fourth level of built-in bell tone,it is higher priority than MIC1-4,LINE1-2.
The fifth level of built-in MIC1,it is higher priority than MIC2-4,LINE1-2.
13. The constant voltage output: 70V, 100V, constant impedance output: 4-16Ω.
5
3. FEATURES

4. NOMENCLATURE AND FUNCTIONS
6
4.1 FRONT PANEL
1. MIC1 / MIC2 / MIC3 / MIC4 volume control adjustment
2. MIC1 / MIC2 / MIC3 / MIC4 treble and bass adjustment
3. LINE1 / LINE2 volume control adjustment
4. LINE1 / LINE2 treble and bass adjustment
5. MASTER-master volume control
6. Power switch
7. PROT / CLIP / SIG / PWR / AC / DC status indicator
8. Six zones voltage switch knob
9. Six zones switch button and indicator
10. All zones switch button and indicator
11. Built-in MP3 player module
Remote control usage attention:
1. When install battery, please mind electrode.
2. Please let remote control aim right with window of host machine.
3. When found remote distance get short and insensitive, please change battery.
4. Please take out battery when don't use it for a long time.
5. Take it easy in case of falling.
Normal usage distance of remote control:
Remote control distance: 8 meter, angle: level ±35, vertical 15.±
1. Power switch
2. Mode
3. Previous/next
4. Volume increase/decrease
5. 0~9 number button
6. Play/pause
7. Sound effect control
8. Mute
9. Cycle play button
10. Pause
4.2 Remote control
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5
ALL CALL ZONE6
PROT
AC
DC
PWR
CLIP
SIG
MASTER
MIC1 MIC2 MIC3 MIC4 LINE1 LINE2
TREBLE TREBLE TREBLE TREBLE TREBLE TREBLE
ON
OFF
BASS BASS BASS BASS BASS BASS
USB
SD
SD /M ED IA
MODE
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6
12 3 456
7
89
1011
MODE E Q
STOP
1
2
3
4
5
6
7
8
910

7
4. NOMENCLATURE AND FUNCTIONS
4.3 REAR PANEL
1. The AC power input socket
2. The cooling fan
3. Spare (battery) power connector
4. 4~16Ω / 70V / 100V Speaker output port,
Connecting the speaker terminal. COM is for public terminal which could be connected
with negative terminal and the ground wire. 4~16Ω terminal is used to connect the speaker
with impedance 4~16Ω; 70V terminal is used to connect the speaker with 70V; 100V
terminal is used to connect the speaker with 100V.
5. Alarm /Chime trigger control interface
6. Chime volume control
7. Alarm volume control
8. MIC1 / MIC2 / MIC3 / MIC4 line / microphone / phantom power switch
9. MIC1 / MIC2 / MIC3 / MIC4 balanced input port
10. Two-way line input interface, used to connect the line output interface
11. Line output interface, used to connect the line input interface
12. Telephone volume control
13. Telephone signal input port
14. EMC input port
15. Mute input port
16. Remote Microphone Control Port
17. Six-zone 100V speaker output port
REMOTE MIC
MIC 1MIC 2
MIC 3
MIC 4
SIREN
MIC LINE
PHANTOM
MIC LINE
PHANTOM
MIC
LINE
PHANTOM
MIC
LINE
PHANTOM
CHIME
TEL
EMC
MUTE
G +G +
TEL FM ANT
G +
SIREN
CHIME
XLR BAL
1-GND
2-HOT+
3-COLD-
COM
BATT SUPPLY
24V 8A
OUTPUT
100V
70V
COM 4-16Ω
OUT IN
LINE LINE2 IN LINE1
ZONE
1
COM 100V
ZONE
2
ZONE
3
ZONE
4
ZONE
5
ZONE
6
COM COM COM COM COM
100V 100V 100V 100V 100V
12 3 45678 9
101112141617
1315

8
5. OPERATION ILLUSTRATION
1. Connect the speakers:
1. Before connecting the speakers, please make sure that the equipment is powered off. In the
case of power on, may have the risk of electric shock.
2. It is not possible to use 4~16Ω70V / 100V terminals at the same time
3. Please make sure there are no applied load to the speaker cables.
4. During the installation of speakers, please make sure that the sum of the rated input power
of the speakers to be connected is less than rated power of equipment.
/ .
2.Connect external devices
①Please ensure that the equipment and all equipment will be connected are powered off.
②Using the corresponding cable to connect this equipment and other external equipment.
:
3.Connect the power line and turn it on:
①Please make sure that the power switch of equipment and its connected equipment are
turned off (in the OFF position).
②Turn the volume knob to the left
③Connect the supplied power line to the AC IN interface
④Plug the power line into the applicable socket
⑤Turn on the connected equipment (CD player, etc.), and then turn on the equipment.
Note:
1.Before powering on, please check and make sure there is no problem with the cable and connection.
2.When you turn off the system, turn off the equipment, and then turn off the connected equipment.
WARNING:
Be sure to attach the supplide terminal cover after conncection completion. Because high voltage is
applied to speaker terminals, never touch terminals to avoid eletric shock.
OUTPUT
100V
70V
COM 4-16Ω
4~16Ω 70V LINE
OUTPUT
100V
70V
COM 4-16Ω
100V LINE
OUTPUT
100V
70V
COM 4-16Ω
40 (TI-1206S)
Total impedance
20 (TI-2406S)
14 (TI-3506S)
9.8 (TI-5006S)
83 (TI-1206S)
Total impedance
41 (TI-2406S)
28 (TI-3506S)
20 (TI-5006S)

9
5. OPERATION ILLUSTRATION
Note:
1.Turn off the power switch,Please wait about 5 seconds before turning on again.Continuous rapid
turning on and off the power switch,it will lead to equipment failure.
2.Even the switch is in the off status, there will be a little current in equipment. If it won’t use the
equipment in a long time, please unplug the power cord from the wall AC socket.
6.
①USB and SD card interface with functions of priority to automatically play audio
②MODE button: press the MODE : choose radio, bluetooth or audio playback.
③If press quickly,it is last song;Long press is the volume decrease.
④When playing music,press one time quickly is pause,press again is play.
⑤If press quickly,it is next song;Long press is the volume increase.
Built-in MP3 player operation method:
." ”
" " " "
" " button:
" " button:
" " button:
Note:
1. When using the built-in MP3 player buttons, please pay attention the strength when
control, avoid excessive force to cause damage of MP3 player button.
2. When insert SD card or USB interface,Please insert in a right way,avoid the wrong
way or too hard to cause the damage of the SD card or USB interface.
4.
1.Turning the volume knob to the left,Connect the microphone and microphone input interface.
2.Turning the volume knob in the right position.
3.Facing the microphone and Speak loudly, turn the volume knob to the right, until the output signal
no longer distortion.If input is high but output is low voice, and then increase the volume by using
the volume knob.If the speaker volume is very high, then reduce the volume by using the volume
knob.
Microphone using:
5.Shutdown the system:
1.Turning the volume knob to the left until the minimum position.
2.Turning off the panel power switch of the professional power amplifier, at 0ff.In turn shutoff
processor equipment and audio source equipment.
USB
SD
SD / M E DIA
MODE

10
5. OPERATION ILLUSTRATION
7.Mobile phone bluetooth operation method:
①Press the MODE button on the MP3 player and set to bluetooth MODE.
②Enter the mobile phone Settings, find the bluetooth related Settings.
③Click on the bluetooth switch, turn on the bluetooth, if already turned on, then ignore.
Because mobile phone system is different, setting interface may be a little different.
④Pay attention, after turn on bluetooth , you must be set to let all the devices are
detected when search the bluetooth paired phone , or may not be able to complete the
search match.
⑤When search the target device, click it,it will connect automatically, once connect
successfully, it can normally play mobile phone music.
8.Operation instruction for MIC/MIC2/MIC3/MIC4 input switch:
As shown in the right picture, the input switch included:
line input, Mic input, Phantom power supply.
①When switch to Line input, you can input the source from
such as CD, VCD, DVD and some other external audio
equipment.
②When switch to the MIC input, you can use the electret
condenser microphone.
③When switch to PHANTOM, the input interface with 48V
phantom power supply, you can use the condenser microphone.
" "
MIC 1
MIC LINE
PHANTOM
9.How to operate a remote microphone:
REMOTE MIC remote microphone interface:external connect T-216 remote call
microphone for any call and the whole area calls, chime ring control.
" " "
"

11
6. TROUBLESHOOTING
Failure phenomena Failure cause
1. Power switch is not opened
1Power line is cut off
2. The protection function of the equipment is
not activated
.
2. All lines are connected, but there is
no sound.
1. The power switch is not opened or the power
plug is bad contacted.
2. The fuse is burnt
3. The volume knob is not opened or turned down
to a extra low level
4. There is no audio signal input
5. There is short-circuit in the speaker line.
3. The sound suddenly disappears in
normal status.
1. The equipment is in very high temperature to
make it into protection status.
2. The connection wire is bad contact.
4. Low sound
The equipment is set to be low impedance
connection, but the speakers connected is
with high impedance.
5. Sound is distorted The input level of Mic or external equipment
is too high

7. APPLICATIONS
REAR PANEL CONNECTIONS
12
REMOTE MIC
MIC 1MIC 2
MIC 3
MIC 4
SIREN
MIC
LINE
PHANTOM
MIC
LINE
PHANTOM
MIC
LINE
PHANTOM
MIC
LINE
PHANTOM
CHIME
TEL
EMC
MUTE
G +G +
TEL
FM ANT
G +
SIREN
CHIME
XLR BAL
1-GND 2-HOT+ 3-COLD-
COM
BATT SUPPLY
24V 8A
OUTPUT
100V
70V
COM 4-16Ω
OUT IN
LINE LINE2 IN
LINE1
ZONE 1
COM 100V
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
COM COM COM COM COM
100V 100V 100V 100V 100V
MIC 1MIC 2MIC 3MIC 4
T-6221 CD PLAYER T-6221 CD PLAYER
Tel Input
Zone1
Zone2 ......
Zone6
4-16Ω
T-1S240
ON
OFF
CHIME
VOL.
MASTER
VOL.
MIC
VOL.
CHIME
2 TONE 4 TONE
LINK
24V 500mA
POWER
T-216
70V
100V
AC power input

13
8. BLOCK DIAGRAM
EMC Highest priority TEL/REMOTE Second priority SIREN third priority
CHIME Fourth priority
EMC Highest priority
X1 X2 X3
MIC1A
5 6 4 3 1 2
T R S
MIC1B
X1 X2 X3
MIC2A
5 6 4 3 1 2
T R S
MIC2B
X1 X2 X3
MIC3A
5 6 4 3 1 2
T R S
MIC3B
BAL/UNBAL
X1 X2 X3
MIC4A
5 6 4 3 1 2
T R S
MIC4B
BAL/UNBAL BAL/UNBAL BAL/UNBAL LINE
PHANTOM
MIC LINE
PHANTOM
MIC LINE
PHANTOM
MIC LINE
PHANTOM
MIC
LINE1 LINE2
MP3/BT 模块
1 2 3
GND
SIREN CHIME
LEVEL
CHIME
Q1
GND
MUTE_MIC1
SIREN
TEL/REMOTE MIC
EMC
GND
TEL/REMOTE MIC
EMC
2-STAGE EQ
BASS TREBLE
2-STAGE EQ
BASS TREBLE
2-STAGE EQ
BASS TREBLE
2-STAGE EQ
BASS TREBLE
2-STAGE EQ
BASS TREBLE
2-STAGE EQ
BASS TREBLE
LEVEL
MUTE_MIC1
LEVEL LEVEL LEVEL LEVEL LEVEL
GND
EMC
LEVEL
MASTER
LI NE OUT
120W/240W
switching
power supply
Power amplifier
module
DC 24V inverter
power supply
1 2 3 4 5 6
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6
9
10
1 2 3 4 5 6 7 8
11 12
COM COM COM COM COM COM 100 V 100 V 100 V 100 V 100 V 100 V
BATT SUPPLY COM4-16Ω 70V-100V
=
= = = = = =
Output transformer
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6
GND
SIREN
TEL/REMOTE MIC
EMC
MUTE
Single-chip
ALL ZONE
4
61
5
3
2
4
61
5
3
2
4
61
5
3
2
4
61
5
3
2
4
61
5
3
2
4
61
5
3
2
1 2 3 4 5 6
0
5
3
4
1 2
1 2 3 4 5 6
0
5
3
4
1 2
LEVEL
SIREN
GND
TEL/REMOTE MIC
EMC
1 2 3 4 5 6
1 2 3 4 5 6 7 8
0
9
10 11 12
J5A
MUTE
EMC
TEL
REMOTE MIC
GND
LEVEL
MUTE
RS485
LEVEL
MIC1 Fifth priority
TEL/REMOTE MIC
EMC
单片机
SIREN
CHIME
CHIME
EMC

14
9. SPECIFICATIONS
Model
Rated Power
TI-1206S TI-2406S
120W 240W
Speaker Output 4~16Ω/ 70V/100V
TI-3506S
350W
Input Sensitivity
MIC:5mV
LINE: 350mV±20mV
AUX: 350mV±20mV
EMC/TEL: 775mV
±1mV
Pre-output AUDIO OUT:1V±50mV/100Ω
Mic Tones Low frequency
High frequency
:±10dB at 100Hz；
:±10dB at 10KHz
SNR
THD
Indicator
Short-circuit Mode
Cooling Mode
Protection Mode
Effector Parameter
Frequency Response MIC：80H 16KHz（±3dB）
LINE：20Hz 20KHz（±3dB）
z~
~
MIC ≥65dB; ≥70dB：Music:
THD+N≤0.1%
Short-circuit, no voltage
Air cooling
Overheat/Short-circuit
Operation Temperature
Storage Temperature
Relative Humidity
+5℃ +40℃~
-20℃ +70℃~
<95%(No condensation)
Power Consumption
Dimension
Weight
484×353 88mm×
210W 530W
6.7Kg 8.2Kg
380W
7.2Kg
Music Tones Low frequency
High frequency
:±10dB at 100Hz；
:±10dB at 10KHz
Power indicator
Voltage
~110V 50Hz
~120V 50Hz
~220V 50Hz
~230V 50Hz
~240V 50Hz
~110V 60Hz
~120V 60Hz
~220V 60Hz
~230V 60Hz
~240V 60Hz
TI-5006S
500W
800W
8.4Kg

10. DIMENSIONAL DIAGRAM
15
6
84 84
25 328
88
94
436
484
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5ALL CALL ZONE6
PROT
AC
DC
PWR
CLIP
SIG
MASTER
MIC1 MIC2 MIC3 MIC4 LINE1 LINE2
TREBLE TREBLE TREBLE TREBLE TREBLE TREBLE
ON
OFF
BASS BASS BASS BASS BASS BASS
USB
SD
SD/ ME DIA
MODE
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6
REMOTE MIC
MIC 1MIC 2
MIC 3
MIC 4
SIREN
MIC
LINE
PHANTOM
MIC
LINE
PHANTOM
MIC
LINE
PHANTOM
MIC
LINE
PHANTOM
CHIME
TEL
EMC
MUTE
G +G +
TEL FM ANT
G +
SIREN CHIME
XLR BAL
1-GND
2-HOT+
3-COLD-
COM
BATT SUPPLY
24V 8A
OUTPUT
100V
70V
COM 4-16Ω
OUT IN
LINE LINE2 IN LINE1
ZONE
1
COM 100V
ZONE
2
ZONE
3
ZONE
4
ZONE
5
ZONE
6
COM COM COM COM COM
100V 100V 100V 100V 100V
UNIT:mm
UNIT:mm
100
Over
100
Over
Over
100
ZONE1 ZONE2 ZONE3 ZONE4 ZONE5ALL CALL ZONE6
PROT
AC
DC
PWR
CLIP
SIG
MASTER
MIC1 MIC2 MIC3 MIC4 LINE1 LINE2
TREBLE TREBLE TREBLE TREBLE TREBLE TREBLE
ON
OFF
BASS BASS BASS BASS BASS BASS
USB
SD
SD/ MEDI A
MODE
1
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
61
2
3 4
5
6

PUBLIC ADDRESS SYSTEM
VersionV0.5
