ITC T-1S60 User manual

OPERATION MANUAL
POWER AMPLIFIER
T-1S240
T-1S120
T-1S60
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
PUBLIC ADDRESS SYSTEM
ON
OFF
POWER
CLIP TEMP PROT SIGNAL
VOLUME
5
0
1
2
3
4 6
7
8
9
10
POWER AMPLIFIER
T-1S60
ON
OFF
POWER
CLIP TEMP PROT SIGNAL
VOLUME
5
0
1
2
3
4 6
7
8
9
10
POWER AMPLIFIER
T-1S120
ON
OFF
POWER
CLIP TEMP PROT SIGNAL
VOLUME
5
0
1
2
3
4 6
7
8
9
10
POWER AMPLIFIER
T-1S240

2
1. SAFETY PRECAUTIONS ........................................................................................ 3
2. GENERAL DESCRIPTION ..................................................................................... 5
3. FEATURES ............................................................................................................... 5
4. NOMENCLATURE AND FUNCTIONS
4. 1 Front Panel ..................................................................................................................6
4. 2 Rear Panel...................................................................................................................7
5. CONNECTIONS .........................................................................................................8
6. OPERATION GUIDANCE
6. 1 .......................................................................9
6. 2 ...........................................................9
6. 3 .................................................................................................... 10
6. 4 POWER SUPPLY INPUT .............................................................................................10
6. 5 SPEAKER OUTPUTS 4~16 & 70V& 100V.................................................................... 11
7. .........................................................................................12
8. APPLICATIONS ......................................................................................................13
9. BLOCK DIAGRAM...................................................................................................14
10. SPECIFICATIONS .......................................................................... .....................15
11.DIMENSIONAL DIAGRAM ..................................................................................16
POWER SWITCH & POWER INDICATOR
PHONE JACK LINE INPUT AND XLR LINE INPUT
XLR LINE OUTPUT
MACHINE OPERATION
TABLE OF CONTENTS

3
1. SAFETY PRECAUTIONS
Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer. Make no further
attempt to operate the unit in this condition as this
may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
ITC
ITC
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.

SAFETY PRECAUTIONS
4
An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your ITC dealer as to the cleaning. If dust
is allowed to accumulate in the unit over a long
period of time, a fire or damage to the unit may
result.
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
Switch off the power, and unplug the power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
Due to product upgrades, while some of the features and specification in the user manual does not
match the actual functions, sorry for any inconvenience and thanks for your kind understanding!

3. FEATURES
This range of power amplifiers are designed for general commercial and industrial public address ap-
plications. Rack mount design in 2U type, rated power ranges from 60W to 240W which provides a
wide selection to meet different size sound system needs. Both balanced and unbalanced line inputs
make it selectable for installer, balanced line output feeds to another power amplifier as well as secu-
res the signal transmission is less noise and longer distance. 70V, 100V and 4-16ohmspeaker outputs
are convenient for installation when selection different speaker matching. A master volume control is
included. Complete protection includes clip, short circuit, high temp and overload. Indications for
power,signal, clip, protection and temp.
2. GENERAL DESCRIPTION
1. Rack mount amplifier in 2U type
2. Rated power from60W to 240W
3. 70V, 100V and 4~16ohm speaker outputs
4. solated transformer for human safety operation
5. Balanced XLR type line input and unbalanced 1/4 inch TRS phone jack line input
6. Balanced XLR type line output feeds to another power amplifier
7. Reliable protection of over heat, over load, clip & short circuit.
8. Indications for power, signal, clip, protection and temp
9. Excellent device of radiator cooling fanner that ensures working effectively.
10. GND/lift switch to have two options: earth line grounded or lifted
5

1. POWER SWITCH
On top of the opening Power Press the end, power shut down
2. VOLUME
Channel volume control
3. TEMP
The protection indicator will be light on when the inside temperature is over 90C, the output
will be
cut to protect the amplifier from damage. It will resume to work after cooling down
4. PROT
The protection indicator will be light on when the constant output is 160% higher than the rated
output, the output will be cut to protection the amplifier from damage. This indicator will be
extinguished when amplifier is under normal working conditions.
5. CLIP
Clip lit when max wattage output & output signal distortion.
6. SIGNAL
Signal indicator LED When lit input signal is detected.
7. POWER
Power indicator LED
12
4. NOMENCLATURE AND FUNCTIONS
4.1 FRONT PANEL
3
4
56
7
6

GND
LIFT
INPUTS LINK
COM
4-16 70V 100V
OUTPUTS
COMCOM
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
NOMENCLATURE AND FUNCTIONS
8. ~220-240V 50/60Hz POWER INPUT
9. COMMON SPEAKER OUTPUT
Connectors for 4 ohms or 70V and 100V
speaker
10. LINE INPUT (XLR)
Music signal input balance
11. LINE INPUT (6.35TRS)
Balanced or unbalanced input music signal (unbalanced input, use of non-equilibrium
6.35TRS jack)
12. LINK OUTPUT (6.35TRS)
Balanced or unbalanced output music signal (unbalanced output, use of non-equilibrium
6.35TRS jack)
13. LINE CASCADE OUTPUT (CORLEONE SOCKET)
XLR, output signal of power amplifier
14. FAN
Equipment, exhaust vents, equipment work properly, you must wrap the hole can not have any
object covered, to avoid overheating protection
15. GROUND LIFTER
Earth line ground or lift switch. Enable the switch to "GND" position when one unit is used,
disable the switch "LIFT" when several units are used to avoid noise caused by several earth
line grounded.
4.2 REAR PANEL
8910 11 13 14
15
7
12

5. CONNECTIONS
SPEAKER CONNECTIONS
70V/
4~16
100V
4~16 LINE
70V COM
70V LINE
41
20
100V LINE
(T-1S120)
(T-1S240)
83
42
(T-1S120)
(T-1S240)
100V 70V 4~16
COM
4~16 100V 70V COM 4~16
8
81 (T-1S60) 166 (T-1S60)

INPUTS LINK
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
GND
LIFT
INPUTS LINK
COM
4-16 70V 100V
OUTPUTS
COMCOM
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
Picture 1.1
Electricity power on when power switch is at ON position and power indicator light in blue.
Electricity power off when power switch is at OFF position and power indicator extinguished.
T-1S60
POWER AMPLIFIER
Notice:
Please make sureamplifier operation isunder well powersupplied status. Pleasecontact
professional technician fromdistributor for anyrepairment.
6.2 PHONE JACK LINE INPUT AND XLR LINE INPUT
70V,Speaker Output
+
-
6.3mm phono jack 180 3-pole XLR
1 foot for the ground
2 feet Signal Hot-side (positive)
3 feet signal cold side (negative)
12
3
1 CH Pre-Amplifier
100V 70V 50V 4 COM
LINK
XLR BAL
1-GND
2-HOT+
3-COLD
1
2
3
12
3
~220V 50Hz
T2AL 250V
OUTPUTS
INPUTS OUTPUTS
INPUTS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRICUS
-NE PAS QUVRIR
AVIS:
PUBLIC ADDRESS SYSTEM
SERIAL NO:
Both phone jack and XLR inputs are balanced. Both are one of your options for line signal inputs from pre
amplifier or mixer. The line output volume level is controlled by front panel knobs
6. OPERATION GUIDANCE
6.1 POWER SWITCH & POWER INDICATOR
Picture 1.2
Notice:
please minimum thevolume knob to"MIN" position whenline input isoperated to avoidelectricity
shock to theamplifier.
9

INPUTS LINK
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
GND
LIFT
INPUTS LINK
COM
4-16 70V 100V
OUTPUTS
COMCOM
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
GND
LIFT
INPUTS LINK
COM
4-16 70V 100V
OUTPUTS
COMCOM
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
+
-
6.3mm phono jack 1803-pole XLS
12
3
USEONLYWITHA 250VFUSEUSE ONLYWITHA 250VFUSE
~220V 50Hz
T2AL250V
~220V 50Hz
T2AL250V
OUTPUTS
COM 4-16 70V 100VCOM COM
GND
LIFT
C
Power Amplifier
OUTPUTS
COM 4-16 70V 100VCOM COM
GND
LIFT
6.3 XLR LINE OUTPUT
Picture 1.3
The XLR input is balanced. The line output could link another amplifier for more loudspeaker connection. The
line output volume level is controlled by front panel knobs.
Notice:
please minimum thevolume knob to"MIN" position whenline output isoperated to avoidelectricity
shock to theamplifier.
6.4 POWER SUPPLY INPUT
OUTPUTS
COM 4-16 70V 100VCOM COM
GND
LIFT
C
Picture 1.4
70V,Speaker Output
1 foot for the ground
2 feet Signal Hot-side (positive)
3 feet signal cold side (negative)
Power electricity to supply power to this amplifier. Please make sure suitable AC voltage inputs by guidance
of this equipments silk printing and specifications. Take off the power cord when non-use
Notice: Please inputonly suitableAC voltage toavoid any burnand damage tothe amplifier.
10
OPERATION GUIDANCE

GND
LIFT
INPUTS LINK
COM
4-16 70V 100V
OUTPUTS
COMCOM
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
6.5 SPEAKER OUTPUTS 4~16 & 70V& 100V
4-16 ,SPEAK 70V,SPEAK 100V,SPEAK
+
-
+
-
+
-
USEONLY WITHA 250VFUSE
OUTPUTS
COM 4-16 70V 100VCOM COM
GND
LIFT
C
USEONLY WITHA 250VFUSE
OUTPUTS
COM 4-16 70V 100VCOM COM
GND
LIFT
C
USEONLY WITHA 250VFUSE
OUTPUTS
COM 4-16 70V 100VCOM COM
GND
LIFT
C
High impedance and low impedance both speaker output for different application use. Only choose one of the
positive end from 4~16 & 70V& 100V, then connect the negative end"COM" and one the positive end to the
speaker's according ends. High impedance speaker output only for high impedance speaker connection and
low impedance speaker output only for low impedance speaker connection. Speaker total power output shall
be no higher than 80% percent of the amplifier rated power output.
Notice:
No mixing connectedthe positive andnegative ends betweenthe amplifier andloudspeaker.
Never allowed touse more thanone output among4~16 /70V/100V.
Speaker continuous poweroutput never higherthan 80% ofthe amplifier ratedpower output.
Never connect highimpedance output tolow impedance speakernor connect lowimpedance output to
high impedance speaker.
Please cover thespeaker output endsafter wiring toavoid any touch.The speaker output are high
voltage, never touchby human bodyto avoid electricityshock.
11
Picture 1.5
OPERATION GUIDANCE

OPERATIONATTENTION
7. MACHINE OPERATION
MIC INPUT CHANNEL 1~3
This is a special connector which will accept 3-conductor XLR.
These inputs are suitable to receive signal from microphones level devices.
LINE JACK (TRS PHONE JACK)
Sleeve:GROUND
Tip:HOT(+)
Ring:COLD(-)
MIC JACK (XLR JACK)
Pin 1:GROUND
Pin 2:HOT(+)
Pin 3:COLD(-)
HOT
COLD
GROUND
1.GROUND
3.COLD
2.HOT
CH1/CH2 LINKS
2
3
1
CH1/CH2 INPUTS
1
3
2
1.GROUND
3.COLD
2.HOT
CH1/CH2 LINKS CH1/CH2 INPUTS
3
21
3
2
1
It indicate signal distortion when the panel's CLIP
LED is lighting red and it may caused by:
1. If there is excess signal input, the power LED
will light, in this case, please turn signal to the
minimum.
2. There is overload output if the LED is not ligh-
ting, please check the input circuit.
When you start the machine, it will run into auto-
checking condition, its protection LED (yellow)
will shine 3 seconds. If the protection time is too
long, please check the machine or contact with
our distribution of your local place.
=
=
=
=
=
=
=
=
Do not open and close the machine frequently.
Restart should be after 10 seconds
Power supply should match up to the machine.
The machine outfit with ground line, so please
plug on the connected-ground wire-net
As formidable shock or impact on machine s-
uch as (thunder shock, halfway signal pause,
excess rated signal input or other interference),
the machine will auto-check and restart auto-
matically.
Please switch off the switch till there is no noise
if there is a badly power abnormality or interfe-
rence.
Contact with our local distributions if machine
is failure to work.
12

8. APPLICATIONS
REAR PANEL CONNECTIONS
GND
LIFT
INPUTS LINK
COM
4-16 70V 100V
OUTPUTS
COMCOM
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-
Speaker
AUX2 OUT
AUX1
MIC2 MIC3
MUTE EMC INPUT
MIC2 MIC3
LINE INPUT
OUTPUT
COM 4-16 70V 100V
REC LINE 10 LINE 9 LINE 8 LINE 7
LEFT
RIGHT
MIC INPUTS MIC/LINE INPUTS
220V/50Hz
MAX 9.9W P.T.T 12
3
4
5
6
789
10
INSIDEAC/DC
FUSE 220VAC DC POWER
24V MAX 0.6A
PUBLICADDRESS SYSTEM SERIAL NO:
2 1
3
7
4
5
2
4
2
GND
PRIORITY
CHIME
LEDPWR
MICINPUT
1
3
5
6
7
1
3
6
CHIME
REMOTE
MODEL NO: T-2S01
PREAMPLIFIER
2--OUTPUTS--1
13

9. BLOCK DIAGRAM
EB
PA 100V
70V
CH1 LINK CH1 INPUTS TO
4~16
COM
POWER
Z ~220-240V 50/60Hz
PT
14

10. SPECIFICATIONS
MODEL
RATED POWER OUTPUT
SPEAKER OUTPUTS
PROTECTION
INPUT SENSITIVITY
FREQUENCY RESPONSE
S/N RATIO
T.H.D
CONTROLS
INDICATORS
4~16 ,70V/100V
775mV/0dB
50Hz~18KHz
Better than 105dB
Less than 1% at 1KHz, 1/3 rated power
Power switch, volume control
Power, clipping , Signal , protect and high
AC fuse, short-circuit , clipping and high temperature
DIMENSION(mm)
NET WEIGHT
GROSS WEIGHT
484X353X88
POWER CONSUMPTION
POWER REQUIREMENTS
T-1S120
120W
~220-240V 50/60Hz
(Specific voltage andfrequency values to the machine to prevail in kind.)
10.7Kg
9.3Kg
220W
POWER AMLIFIER
T-1S240
240W
14.6Kg
13.2Kg
440W
15
T-1S60
60W
9.1Kg
6.9Kg
120W

100
Over
Over
100
94
11. DIMENSIONAL DIAGRAM
84
84
323
317
88
436
100
Over
6
25
484
UNIT :mm
UNIT :mm
16
GND
LIFT
INPUTS LINK
COM
4-16 70V 100V
OUTPUTS
COMCOM
INPUTS LINK
1122
33
XLR BAL
1-GND
2-HOT+
3-COLD-

PUBLIC ADDRESS SYSTEM
PUBLIC ADDRESS SYSTEM
VersionV0.4
