ITC T-30C User manual

Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
MIXER AMPLIFIER
T-60C
T-30C
PUBLIC ADDRESS SYSTEM
OPERATION MANUAL
ON
OFF
POWER
TREBLE MIC 1 MIC 2 LINE 1 LINE 2BASS
MIC 1
MUTE
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
PEAK
PROTECT
2 4 6810
OUTPUT LEVEL
MIXER AMPLIFIER
T-60C

TABLE OF CONTENTS
1. SAFETY PRECAUTIONS .......................................................................................3
2. GENERAL DESCRIPTION ....................................................................................5
3. FEATURES .............................................................................................................. 5
4. NOMENCLATURE AND FUNCTIONS
4.1 Front Panel....... ...................................................................................................... 6
4.2 Rear Panel..............................................................................................................7
5. CONNECTIONS
5.1. Speaker Connections ........................................................................................... 8
5.2. XLR Connections ................................................................................................. 8
6. ........................................................................................ 9
7. APPLICATIONS .....................................................................................................10
8.SPECIFICATIONS ................................................................................................. 11
9.DIMENSIONAL DIAGRAM ...................................................................................12
MACHINE OPERATION
2

Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Use the unit only with the voltage specified on the
unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or
electric shock.
Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
Be sure to ground to the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your nearest dealer. Make no further
attempt to operate the unit in this condition as this
may cause fire or electric shock.
If you detect smoke or a strange smell coming
from the unit.
If water or any metallic object gets into the unit
If the unit falls, or the unit case breaks
If the power supply cord is damaged (exposure of
the core, disconnection, etc.)
If it is malfunctioning (no tone sounds.)
To prevent a fire or electric shock, never open nor
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your nearest dealer.
ITC
ITC
Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
Do not insert nor drop metallic objects or
flammable materials in the ventilation slots of the
unit's cover, as this may result in fire or electric
shock.
1. SAFETY PRECAUTIONS
3

An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
When Installing the Unit
Never plug in nor remove the power supply plug
with wet hands, as doing so may cause electric
shock.
When unplugging the power supply cord, be sure
to grasp the power supply plug; never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
When moving the unit, be sure to remove its power
supply cord from the wall outlet. Moving the unit
with the power cord connected to the outlet may
cause damage to the power cord, resulting in fire or
electric shock. When removing the power cord, be
sure to hold its plug to pull.
Do not block the ventilation slots in the unit's cover.
Doing so may cause heat to build up inside the unit
and result in fire.
Avoid installing the unit in humid or dusty locations,
in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or
steam as doing otherwise may result in fire or
electric shock.
When the Unit is in Use
Do not place heavy objects on the unit as this may
cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
Make sure that the volume control is set to
minimum position before power is switched on.
Loud noise produced at high volume when power is
switched on can impair hearing.
Do not operate the unit for an extended period of
time with the sound distorting. This is an indication
of a malfunction, which in turn can cause heat to
generate and result in a fire.
Contact your dealer as to the cleaning. If dust
is allowed to accumulate in the unit over a long
period of time, a fire or damage to the unit may
result.
ITC
If dust accumulates on the power supply plug or in
the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
Switch off the power, and unplug the power supply
plug from the AC outlet for safety purposes when
cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric
shock.
SAFETY PRECAUTIONS
4

3. FEATURES
2. GENERAL DESCRIPTION
=100V/70V line transformer-isolated speaker outputs, low impedance 4-16 ohms speaker outputs.
=Two line input.
=AUX, MIC, Bass, Treble volume control.
=MIC 1 mute level control.
=Power and protection indicators and 6 output level meters.
The Mixer Amplifier series is equiped with priority function. They are designed to suit all PA system
application in schools home offices and stores.
5

1. POWER
Power indicator
2. POWER SWITCH
On top of the opening Power
Press the end, power shut down
3. COOLING FANS
4. BASS
Adjust bass response. Rotate clockwise to increase
bass output and anticlockwise to reduce it.
5. TREBLE
Adjust treble response. Rotate clockwise to increase
treble output and anticlockwise to reduce it.
4. NOMENCLATURE AND FUNCTIONS
234
6. MIC1 \ MIC2
MIC volume control (MIC1/MIC2)
7. LINE1 \ LINE2
Line volume control(LINE 1/LINE 2)
8. MUTE
Mute Microphone 1 mute level control
9. MIC
MIC1 input 6.3 Microphone jack input
10.PROTECT
Protection indicator LED
11.LEVEL INDICATORS
Level meters 6 output level indicators
61
11
4.1 FRONT PANEL(2U)
5789
10
ON
OFF
POWER
TREBLE MIC 1 MIC 2 LINE 1 LINE 2 BASS
MIC1
MUTE
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
PEAK
PROTECT
246810
LEVEL
6

12 14
NOMENCLATURE AND FUNCTIONS
12.SPEAKER TERMINALS
Connectors for 4-16 ohms or 70V and 100V
speaker
13.FAN
14.MIC
MIC 2 input 6.3 Microphone jack input
15. \
Line Balanced inputs
16.~220-240V 50/60Hz POWER INPUT
17.INSURANCE TUBE
LINE1 LINE2
15
4.2 REAR PANEL(2U)
13 16
17
LINE2 LINE1 MIC2
++
--
OUTPUT
COM 4-16 70V 100V
7

70V 100V
COM 4-16 70V 100V COM 4-16
100V LINE
70V 100V
COM 4-16
(T-30C)
(T-60C)
163
82
70V LINE
5.1 SPEAKER CONNECTIONS
5.2 XLR CONNECTIONS
4-16
5. CONNECTIONS
(T-30C)
(T-60C)
333
167
8

OPERATIONATTENTION
6. MACHINE OPERATION
1. When the peak indicator in panel (red) power on, it
means that the signal output is in distortion. The rea-
sons are that: if all the electronic tube power on, it
means input signal is too big, please turn it down: if
not all the ones power on, it means output overload,
please check the wire input.
2. The machine will start automatically in 3 seconds,
meanwhile the protective tube power on, if test in good
condition, the indicator will power off .If all the time in
protective condition, it means something wrong with
machine, please contact with distributor.
3. Do not power on frequently, restart machine in 10
seconds.
4. Connect amplifier power in correctly with certain figure
sheet.
5. Cover has been connected with ground wire and the jack
should be injected correctly with electronic network.
6. When the signal input is strongly impacted,(etc lightning),
amplifier will analyze it cutting off signal automatically ,
check itself and restart.
7. With mic 1complusively broadcast, amplifier will auto-
matically put other signal input into mute control and the
signal will recover in 3seconds when there is no mic
signal.
8. Once the machine in trouble, please send it to distributor.
9

7. APPLICATIONS
REAR PANEL CONNECTIONS
MIC 2
SPEAKERS
AUDIO
OUT
R L
AUDIO SOURCES
COM
ADRESS TAG
AUDIO
OUT
R L
AUDIO SOURCES
COM
ADRESS TAG
LINE2 LINE1
MIC2
++ --
OUTPUT
COM 4-16 70V 100V
10

8. SPECIFICATIONS
MODEL
RATED POWER OUTPUT
SPEAKER OUTPUTS
TONE
FREQUENCY RESPONSE
MIXER AMPLIFIERMIXER AMPLIFIER
T-60C
60W
4~16 ,70V/100V
Bass: 10dB at 100Hz
Treble: 10dB at 10KHz
40Hz~18KHz(half power output)
DIMENSION(mm)
NET WEIGHT
GROSS WEIGHT
484X333X66
POWER CONSUMPTION
POWER REQUIREMENTS
T-30C
30W
~220-240V 50/60Hz
-
+
-
+
7.6Kg
6.4Kg
51W
9.6Kg
8.4Kg
96W
11

100
Over
100
Over
Over
100
9. DIMENSIONAL DIAGRAM
UNIT:mm
6
66
61
333
327
66
72
436
484
UNIT:mm
ON
OFF
POWER
TREBLE MIC 1 MIC 2 LINE 1 LINE 2 BASS
MIC1
MUTE
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
PEAK
PROTECT
246810
LEVEL
ON
OFF
POWER
TREBLE MIC 1 MIC 2 LINE1 LINE 2 BASS
MIC1
MUTE
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
5
0
1
2
3
4 6
7
8
9
10
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
0
-5
-4
-3
-2
-1 +1
+2
+3
+4
+5
PEAK
PROTECT
246810
LEVEL
LINE2 LINE1 MIC2
++
--
OUTPUT
COM 4-16 70V 100V
12

PUBLIC ADDRESS SYSTEM
VersionV0.2
