ITC T-770 User manual

T-770/770AT-770/770A
T-770/770A
OWNER'S MANUAL
PROJECTION SPEAKERPROJECTION SPEAKER
Safety Tips
Readers
Warning Such as the inappropriate use of staff will cause
injury, death and property damage.
Please be sure to use the former reading detailed notes.
Really pay attention to this manual and a safety with the important warning.
Recommend that you keep this manual for future reference.
When installed loudspeakers
Definitely will not be allowed to speakers and any exposure in the rain-wet
or water, may be inconsistent with ,or fire.
Restricted by the provisions of the speakers on the voltage, such as the
use of high voltage may cause electric shock or fire disaster. Is no pruning,
distorted, or replacement of damaged wires.
Avoid instability in the installation or set up speakers, such as shaking the
table or flat surface , the speaker can avoid falling caused personal injury
or property damage.
Speakers will be installed in support of the speaker or the weight of a solid
shelf. Speaker swap can be avoided caused personal injury or property
damage.
Wet hands must not be admitted into or plugs, may lead to electric shocks.
The allocation of plugs, make sure that pull plugs, rather than pull wires.
The use of a damaged power line of machinery may cause fire or electric
shock.
Mobile speaker, you plug the prior allocated. If the speaker and plugs may
be moving together will cause fire or electric shock.For plugs,identified as
plugs for grip.
Will not be allowed to speakers on the vent cover. May cause internal
heating caused by the fire.
Avoid speakers installed in the humidity or dust, direct contact with the sun,
from the near-electric, or smoke or steam, may cause fire or electric shock.
Common warning signs and security
The manual shown warning signs and security is to prevent the improper
operation due to personal injury arising from the loss of property, please
read before using this product must understand that this manual security
symbols and Warning to indicate fully aware of potential risks.
Dear customers,your use of the broadcasting company speaker series. We
would like to extend my heartfelt thanks to all of the Company manufactured
products have been tested before, the commitment to keep its quality. Loud -
speakers broadcast Pan-for hotels, commercial buildings, supermarkets,
schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please
read this note.

WALL
1. Speaker weight of 2.7/2.2Kg,
must be chosenby our body
strong and avoidunstable
speakers falling or injuries.
WALL WALL
WALL WALL
123
45
2. Use ofmeasuring tools, measure
parts of thethree round holesthe
size of speakersand the distance
between pore spaces,and selected
in line withthe screw holewill be
fixed Fortunately,speaker wall
accessories.
3. The horngently into theaccessories
have been installedon the walls,the
speakers on bothsides of porespaces
with walls on two other partsof the
alignment holes. selectedin line with
the horn screwhole bit, fixed.
4. Figure, a 90-degree vertical install-
ation in thewall fixed. Such as the
need to changethe point of view
can be movedto install speakers.
5. Figure used to change the install-
ation point ofview, theinstallation
of speakers.
Specifications
Label stickersInstallation
Dimension
T-770/770A
770:172 mm
770A:138 mm
6mm
54mm
770A:210 mm
770:315 mm
T-770 T-770A
7.5W,15W 3W,6W,10W
3.75W,7.5W 1.5W,3W,5W
100dB 91dB
250-14KHz 130-15KHz
172X172X315mm 138X138X210mm
2.7Kg 2.2Kg
Impedance Black:COM,White:1.3K
Green:670
Blue:COM,Green:3.3K
Yellow:1.7K ,Red:1K
Model
Power Taps@100V
SPL(1W/1M)
Freq Response
Weight
Dimensions
Power Taps@70V
T-770T-770 T-770A
39 mm
29 mm
Power@100V: 7.5W,15W
Power@70V: 3.75W,7.5W
Impedance: Black:COM
White:1.3K
Green:670
Power@100V: 3W,6W,10W
Power@70V: 1.5W,3W,5W
Impedance: Blue:COM
Green:3.3K
Yellow:1.7K
Red:1K
Public Address Systems Public Address Systems
PROJECTION SPEAKER PROJECTION SPEAKER
