ITC T-108L User manual

T-108L
T-108L
OWNER'S MANUAL
Ceiling Speaker
Ceiling Speaker
Safety Tips
Readers
Warning Such as the inappropriate use of staff will cause
injury, death and property damage.
Please be sure to use the former reading detailed notes.
Really pay attention to this manual and a safety with the important warning.
Recommend that you keep this manual for future reference.
When installed loudspeakers
Definitely will not be allowed to speakers and any exposure in the rain-wet
or water, may be inconsistent with ,or fire.
Restricted by the provisions of the speakers on the voltage, such as the us
of high voltage may cause electric shock or fire disaster. Is no pruning,
distorted, or replacement of damaged wires.
Avoid instability in the installation or set up speakers, such as shaking the
table or flat surface , the speaker can avoid falling caused personal injury
or property damage.
Speakers will be installed in support of the speaker or the weight of a solid
shelf. Speaker swap can be avoided caused personal injury or property
damage.
Wet hands must not be admitted into or plugs, may lead to electric shocks.
The allocation of plugs, make sure that pull plugs, rather than pull wires.
The use of a damaged power line of machinery may cause fire or electric
shock.
Mobile speaker, you plug the prior allocated. If the speaker and plugs may
be moving together will cause fire or electric shock.For plugs,identified as
plugs for grip.
Will not be allowed to speakers on the vent cover. May cause interna
heating caused by the fire.
Avoid speakers installed in the humidity or dust, direct contact with the sun
from the near-electric, or smoke or steam, may cause fire or electric shock.
Common warning signs and security
The manual shown warning signs and security is to prevent the improper
operation due to personal injury arising from the loss of property, please
read before using this product must understand that this manual security
symbols and Warning to indicate fully aware of potential risks.
Dear customers,your use of the broadcasting company speaker series. We
would like to extend my heartfelt thanks to all of the Company manufactured
products have been tested before, the commitment to keep its quality. Loud -
speakers broadcast Pan-for hotels, commercial buildings, supermarkets,
schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please
read this note.

Max Power
T-108L
1.87W,3.75W,7.5W,15W
30W
90dB
90-20KHz
230mm
265X75mm
1.2Kg
Black:COM Blue:5.3K Red:2.7K White:1.3K Green:670
T-108L
T-108L
CEILING SPEAKER
1.87W
3.75W
7.5W
COM
Frequency Response(-10dB): 90-20KHz
SPL(1W/1M) 90dB
100Volt
Cutout Size: 230mm
15W
Black-----COM
670 ------15W
1.3K ----7.5W
2.6K --3.75W
5.3K --1.87W
64.00 mm
T-108L
265 mm
230 mm
265 mm
75 mm
Model
Power Taps@100V
Impedance
SPL(1W/1M)
Frqe Response
Weight
Cutout size
Dimensions
Step 1 With a measurement tool measuring holes on the ceiling speakers
the size of the wiring through the hole to open a good connection
on the speaker.
Step 2 Separate speakers on both sides of the iron, so that the edge close
to the ceiling speakers, the merger places in the ceiling hole.
Step 3 So that speakers and fixed on the ceiling, and the completion of the
installation of speakers.
Installation
Dimension Specifications
Label stickers
