OWNER'S MANUAL
PROJECTION SPEAKER
PROJECTION SPEAKER
T-770T/770ATT-770T/770AT
T-770T/770AT
Safety Tips
Readers
Warning Such as the inappropriate use of staff will cause
injury, death and property damage.
Please be sure to use the former reading detailed notes.
Really pay attention to this manual and a safety with the important warning.
Recommend that you keep this manual for future reference.
When installed loudspeakers
Definitely will not be allowed to speakers and any exposure in the rain-wet
or water, may be inconsistent with ,or fire.
Restricted by the provisions of the speakers on the voltage, such as the us
of high voltage may cause electric shock or fire disaster. Is no pruning,
distorted, or replacement of damaged wires.
Avoid instability in the installation or set up speakers, such as shaking the
table or flat surface , the speaker can avoid falling caused personal injury
or property damage.
Speakers will be installed in support of the speaker or the weight of a solid
shelf. Speaker swap can be avoided caused personal injury or property
damage.
Wet hands must not be admitted into or plugs, may lead to electric shocks.
The allocation of plugs, make sure that pull plugs, rather than pull wires.
The use of a damaged power line of machinery may cause fire or electric
shock.
Mobile speaker, you plug the prior allocated. If the speaker and plugs may
be moving together will cause fire or electric shock.For plugs,identified as
plugs for grip.
Will not be allowed to speakers on the vent cover. May cause internal
heating caused by the fire.
Avoid speakers installed in the humidity or dust, direct contact with the sun
from the near-electric, or smoke or steam, may cause fire or electric shock.
Common warning signs and security
The manual shown warning signs and security is to prevent the improper
operation due to personal injury arising from the loss of property, please
read before using this product must understand that this manual security
symbols and Warning to indicate fully aware of potential risks.
Dear customers,your use of the broadcasting company speaker series. We
would like to extend my heartfelt thanks to all of the Company manufactured
products have been tested before, the commitment to keep its quality. Loud -
speakers broadcast Pan-for hotels, commercial buildings, supermarkets,
schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please
read this note.

T-770T/770AT
770AT 138 mm
770T 172 mm
6mm
30mm
770AT 205mm
770T 252mm
Dimension
Installation
Specifications
Label stickers
Model
Power Taps@100V
Power Taps@70V
SPL(1W/1M)
Freq Response
Weight
Dimensions
Impedance
Wall Wall Wall
12
45
2. Use ofmeasuring tools, measure
parts speakers three hole size and
spacing of holes from, and selection
in line with the screw hole, fortunately,
speaker accessories fixed to thewall.
3. The horn gently into the accessories have
been installed on the walls,the speakers on
both sides of pore spaces and the walls of
two other parts of thealignment holes.
selected in line with thehorn screw hole bit,
fixed.
4. Figure, a90-degree vertical installation
fixed in the wall. Such as the needto
change the security point of view can
be moved loaded speakers.
3
5. Figure used to change the installation
point of view, Installation of speakers.
Wall Wall
T-770T T-770AT
39 mm
29 mm
T-770ATT-770T
2.5W,5W,10W5W,10W,20W
1.25W,2.5W,5W2.5W,5W,10W
92dB92dB
130-15KHz
110-15KHz
138X138X205mm
172X172X252mm
2.9Kg3.3Kg
Power@100V: 5W,10W,20W
Power@70V: 2.5W,5W,10W
Impedance: Blue:COM
Green:2K
Yellow:1K
Red:500
Power@100V: 2.5W,5W,10W
Power@70V: 1.25W,2.5W,5W
Impedance: Blue:COM
Green:4K
Yellow:2K
Red:1K
Public Address Systems Public Address Systems
PROJECTION SPEAKER PROJECTION SPEAKER
Blue:COM,Green:2K
Yellow:1K ,Red:500
Blue:COM,Green:4K
Yellow:2K ,Red:1K
1. During installation, the speaker
shall be fixed to a affordable wall
to avoid any drop or damage,
since the speaker weight is
about 3.3/2.9kgs.
