Itek I58011 User manual

INSTRUCTION MANUAL
HOME ENTERTAINMENT
Q U A LITY REFLECTED
®
BLUETOOTH SOUND BOX I58011
TO: CUSTOMER SERVICES DEPARTMENT ITEK SUTTON HOUSE BERRYHILL ROAD, FENTON STOKE ON TRENT ST4 2NL
Please place post-
age stamp here
HOME ENTERTAINMENT
Q U A LITY REFLECTED
®

This product is guaranteed for 12 months from the date of the original purchase.
If any defect arises due to faulty materials or workmanship the faulty products must be returned
to the place of purchase. Refunds or replacement is at the discretion of the Retailer .
The following conditions apply:
The product must be returned to the retailer with the original proof of purchase.
The product must be installed and used in accordance with the instructions contained in this
instruction guide.
For domestic purposes. ONLY.
It does not cover wear and tear, damage, misuse or consumable parts.
PFD has no responsibility for incidental or consequential loss or damage.
Valid in the UK and Eire only.
TECHNICAL SPECIFICATION.
Rated Power:3W x 2
Size: 7.5” x 2.0” x 2.6”
Signal- to- Noise: 40dB
Charge Voltage : 5V(USB)
Bluetooth Range: 33 Feet
Sutton House,
Berryhill Road,
Fenton
Stoke on Trent
Staffordshire,
ST4 2NL.
GETTING STARTED
Remove product from the packaging.
Retain packaging for storage purposes or future reference or dispose of safely.
PACKAGE CONTENTS
Rechargeable Bluetooth XL Sound Box
USB cable (For Charging Purpose)
3.5mm audio connection cable (Auxiliary Cable)
Instruction manual
FEATURES
Compatible with Bluetooth® devices & connects via 3.5mm audio jack
Perfect for use with a variety of electronic devices, indoors or outdoors
Use as Hands-Free speaker phone device, with a built-in microphone
Deep rich sound in a compact portable size that goes anywhere
USB rechargeable built-in battery
IMPORTANT SAFETY INFORMATION
Read all instructions before using this product.
Do not leave this product unattended while connected to the power supply.
Do not immerse in water or any other liquids.
Do not use if unit has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by qualied personnel. Improper re-
pairs may place user at serious risk.
Place unit on sound, even surface, free from vibrations and away from sources of heat.
Do not use with wet hands.
Do not put objects into openings.
Keep free of dust, lint, hair etc.
Do not use this unit for anything other than its intended use.
Keep this product out of reach of children.
This product is not a toy.
Do not play music at excessive levels especially near children, as damage to hearing may occur.
3
2
1
46
5
7
DESCRIPTION OF PARTS
1. ON/OFF Switch
2. 3.5mm Audio Input
3. Micro USB Charging Port
4. Play / Pause / Answer / Hang Up Button
5. Skip Backward (Single Press);Volume
Decrease (Long Press)
6. Skip Forward (Single Press);Volume In-
crease (Long Press)
7.LED Indicator

INSTRUCTIONS FOR USE
CHARGING BATTERY
For best results, fully charge the unit before rst use.
Connect the USB cable (included) to the charging port of the speaker and insert the other end
into a USB port on your computer or other suitable USB outlet.
The LED indicator will turn on, indicating that the battery is charging. It will take 3-4 hours for
the battery to fully charge.
LED INDICATOR
There is an LED light located in the middle of the front speaker.
LED Off - Power OFF
Flashing BLUE - Power ON
Flashing BLUE/RED - Pairing mode (searching Bluetooth devices)
RED (While in use) - Low Battery Level
BLUE - Battery almost drained
RED (While Charging) - Battery is recharging
Turn the speaker to Bluetooth pairing mode -
1.Turn the main power switch on the back of Bluetooth XL Sound Box to “ON” position.
2.Wait 2~3 seconds until the LED indicator starts blinking red and blue.
This indicates that it is in pairing mode.
3. If the unit doesn’t get into “Pairing” mode by itself, press the “Play / Pause / Answer / Hang
Up” button, for 2-3 seconds.This will put the unit in “Pairing” mode.
Note: Bluetooth XL Sound Box will stay in “Pairing” mode for 1 minute. If the source device (like cell phones,
tablets, MP3 players etc.) are not synced to the unit within 1 minute, simply turn the unit “OFF” and then turn
it back “ON”, and repeat step 2 or 3.
PAIRINGYOUR DEVICE with Bluetooth XL Sound Box –
Your Bluetooth XL Sound Box can wirelessly stream audio from any Bluetooth enabled device
within 33 Feet. Simply follow the below steps.
1.Turn on the Bluetooth on your Mobile Phone or Tablet or Computer etc.
2.It will search for various devices
3.Bluetooth XL SOUND BOX will show up as “SPEAKER”
4.Select “SPEAKER”
5.Once paired, the LED light will turn to BLUE Color.
ANSWERING CALLS While Connected Through Bluetooth Technology
When you receive an incoming call, Bluetooth XL Sound Box will make an alerting sound.
If you are listening to music from your phone, the music will automatically pause.
There’re 2 ways to answer a call:
(a)as you usually do, using your phone
(b)press the “Play / Pause / Answer / Hang Up” button located at the top of the unit.
•Speak normally, in to the unit (as unit has a microphone built-in).
Note: Answering calls will only function while the unit is connected through Bluetooth technology.
OTHER CONTROLS (When Connected Through Bluetooth Technology)
• Volume Increase: Press and hold the “Increase Volume / Skip-Forward” button to increase
the volume.
• Volume Decrease: Press and hold the “Decrease Volume / Skip-Backward” button
to decrease volume.
• Skip Forward Track: Press the “Volume Increase/Skip-Forward” button once to skip a track
forward.
• Skip Backward Track: Press the “Volume Decrease/Skip-Backward” button once to skip a
track backward.
• Pause – Press the “Play / Pause / Answer / Hang Up” button once to pause the music. Press
again once to resume the music.
• Answer Call – Press “Play / Pause / Answer / Hang Up” button once to answer the call when
you get the incoming call.
•End Call – Press “Play / Pause / Answer / Hang Up” button once to end the call. If you were
listening to music prior to receiving the call, then the music would resume once you
end the call.
Note: Answering calls will only function while the unit is connected through Bluetooth technology.
Auxiliary Mode
•You can play music using the 3.5mm Audio Connection Cable (Auxiliary Cable). Plug one end of
the cable to the source device (Laptop,Tablet, Mobile phone, MP3 Player etc.) and the other end
to the Bluetooth XL Sound Box.
Note: While using unit in this mode, all the media controls (Skip Backward / Skip Forward etc.)
will remain with the source device.
Microphone function doesn’t work in Auxiliary mode.
DO’S AND DON’TS
Do not play music at excessive levels as damage to hearing and/or equipment may result.
Do not use outdoors in wet or in damp surroundings.
Solution
Charge speaker battery.
Turn Source device's Bluetooth
function ON.
Adjust source volume.
Adjust speaker volume.
Charge Battery.
Charge Battery.
Turn the source on.
Turn the speaker on.
Adjust volume on speaker /source.
Play media from source.
Possible Cause
Speaker Battery too low.
Source device's Bluetooth function
not turned ON.
Source (Tablet, Phone,.) volume too low.
Speaker volume too low.
Battery dead
Battery nearly dead
Source (Tablet, Phone, Laptop.) turned off.
Speaker turned off.
Volume turned down on speaker / source.
Media paused on source.
Problem
Unable to detect the
source through
Bluetooth
Low sound level
Sound distorted
No sound at all.

Model no: Serial no: Batch no: Name: Address: Date Purchased: E-mail Address: IMPORTANT This warranty is invalid if alterations have been made to this certicate
Dealer Stamp/Details: If you would NOT like to receive special offers and promotions from PFD and it’s associated companies please tick this box
HOME ENTERTAINMENT
Q U A LITY REFLECTED
®
Disposal of Unit
Disposal instructions for Itek items in accordance with the WEEE directive.
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish.You are required to dispose of old electrical and electronic appliances like this separately. Please
visit www.recyclemore.co.uk, or www.recylcenow.co.uk for access to information about the recycling of
electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled, rather
than taken to landll. Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
Declaration of Conformity
We PFD Ltd Declare that this product conforms to all the following
product legislation
In accordance with the following directive(s):
2004/108/EEC.The Electromagnetic compatibility Directive
2006/95EC.The LVD directive (LowVoltage Directive)
2002/95/EC.The RoHS. Directive. (Restriction of Hazardous substances Directive)
Peter Bowden
Quality Assurance Manager
Sutton House, Berryhill Road, Fenton, Stoke-On-Trent, Staffordshire, ST4 2NL.
CARE AND MAINTENANCE
Clean the unit with a soft, damp cloth. Never use chemicals or hard abrasives.
Keep this unit away from wet or damp surroundings.
Note: iPad, iPod and iPhone are trademarks of Apple Inc, registered in the US, and other countries.
