ITRON WaterMind v2 User manual

WaterMind v2
Advanced Logger
Installation Instructions
1 - Pre-installation Precaution
WaterMind v2 Advanced Logger is an accurate measuring device to be connected to a pipe for pressure monitoring and/or to a
water meter via wired pulse input and/or to an external power supply. It has built-in cellular equipment for data transfer.
To protect your safety, to ensure the proper measuring performance and to comply with warranty terms, please respect the
installation procedure described in this document.
1.1 Safety Advice for Pressure Monitoring Only
Only qualified and trained personnel, familiar with hazards linked to water networks at high pressures, should install the
WaterMind v2 Advanced Logger.
1.2 Battery Handling
Batteries pose a fire, explosion and severe burn hazard. Do not short circuit, disassemble, dispose of in fire, heat,
expose to water, puncture or crush. Do not connect in reverse polarity.
Manufacturers Material Safety Data Sheets are available upon request.
1.3 Cellular Network and Battery Lifetime
WaterMind v2 Advanced Logger uses GSM/GPRS/3G communication networks for data transfer: 850/900/1800/1900MHz
(GSM) and 800/850/900/1900/2100MHz (UMTS). The performance of these networks depends on many parameters under the
responsibility of cellular operators and in no case is Itron’s responsibility. .
However, the battery lifetime is impacted by the performance of the cellular network that it is connected to. The estimated
battery lifetime is based on a standard and correct performance of the cellular network and the respect of the recommended
configuration by the user.
1.4 Declaration and Environmental Protection
WaterMind v2 Advanced Logger is conform with both relevant Union Harmonization Legislation Directives: 2014/53/EU (RED)
and 2011/65/EU (RoHS 2).
These approvals only apply to the WaterMind v2 Advanced Logger. Any accessories that may be delivered with the device are
not covered by these approvals.
WaterMind v2 Advanced Logger is protected against dust ingression, water jets and permanent immersion (IP68 acc. to
EN60529)
Full declaration of conformity is available at www.itron.com/watermind
1.5 Proximity to Users (RF Exposure)
This device in intended to be installed in un-manned locations. We recommend to maintain a distance of 0.25m (25cm)
between the device and users.
INSTALLATION

2 - WaterMind Advanced Logger Overview
3 – Inventory
WaterMind v2 Advanced Logger is provided with a flow cable for pulse input connection and a coiled tube per pressure
transducer for pressure input, at no additional cost.
However, the USB cable is not included. It can be ordered as a spare part.
1
5
2
6
1
2
3
4
5
7
8
9
10
11
3
4
1
1
2
2
3
3
4
4
5
5
6
7
8
9
11
10
One-quarter Turn screw
Bidirectional Flow Input (Pulse)
Pressure Transducer
USB Connection for PC
Label
Itron Logo
Product Name
Product Code
Serial Number
Manufacturing Date
Itron Web Address
Itron Address
Country of Origin marks
Crossed out wheeled
dust bin
QR Code
Product Code
Serial Number
Manufacturing Date
CE Marking
It is strongly recommended to install Watermind in conditions that prevent freezing, especially for models with pressure
sensors, where water goes through the coiled tube to the product.
Ambient Operating Temperature -10°C to +50°C
Battery Lifetime 5 years minimum (with one daily dial-up, under normal working
conditions, depending on configuration, temperature and location)
Dimensions
Diameter Amm 115
Height Bmm 140
Total Height Cmm 155
Fast Couples Height Dmm 15
A
D
B
C
www.itron.com
9 rue Ampère
71031 Mâcon, France
Country of Origin: UK
WM_LOG_1P_1Pr_3G
S/N: 150156
2018/04/01
WaterMind Advanced Logger
WM_LOG_USB_CABLE
WaterMind USB Cable
(Spare part)
WM_LOG_SP_FLOW_C
WaterMind Spare Flow Cable
WM_LOG_SP_COILTUBE
WaterMind
Spare Coiled Tube for pressure
transducer conncetion (2.8m)

4 – Installation
WaterMind installation is very quick and easy. Below the pre-requirements and main steps are outlined.
4.1 – Pre-Installation Requirements
There are some elements that are required before going on field to install WaterMind:
• WaterMind Configurator software installed on a laptop with Windows OS.
• Tenant settings file containing name, ID and cryptographic access key.
• Tenant-Specific URL and port.
These elements are all provided upon the opening of a service requested, that can be managed by your local Itron
representative.
4.2 – Installation Steps
A - Open the cover using a small screwdriver. A quarter-turn is required to loosen for each of the 4 fasteners.
B - Connect Battery.WaterMind is delivered with
the internal battery disconnected to save energy
during transport and storage periods.
D - Press and click to Close the cover. Pay attention
to ensure the cover fits the body.
C - Insert the SIM Card in the slot with
the SIM symbol.
E - Commission the WaterMind v2
Advanced logger in the system. This can
be done at the office, before going on field.
- Device name
- Meter serial number
- Tenant settings
- Pulse weight
- Connetion type (2/ 3 /5 wires)
- Cellular network params: APN, user
and password
Connect the WaterMind v2 Advanced Logger to a laptop using the USB cable and configure to set the folowing parameters:
You can set up and change most of the parameters remotely, at a later time.
You may wish to configure multiple dialups to monitor logger operation on the day of deployment. Remember to
revert to a more permanent setting (eg. daily) after the correct logger operation is verified.
i
Configurator.exe
C -
Insert the SIM Card
x4
Press/
Click
x4 Screws
Screwdriver
5mm
Pay attention
to a laptop using the USB cable and configure to set the folowing parameters:
Press/
Bracket
Label

While Itron strives to make the content of its marketing materials as timely and accurate as possible, Itron
makes no claims, promises, or guarantees about the accuracy, completeness, or adequacy of, and expressly
disclaims liability for errors and omissions in, such materials. No warranty of any kind, implied, expressed,
or statutory, including but not limited to the warranties of non-infringement of third party rights, title, merchantability,
and fitness for a particular purpose, is given with respect to the content of these marketing materials.
© Copyright 2018 Itron. All rights reserved. SYS-0066.0-ig-EN-04.18
Join us in creating a more resourceful world.
To learn more visit itron.com
ITRON WATER METERING
9, rue Ampère
71031 Mâcon cedex
France
Phone: [phone]
Fax: [phone]
F - Select the right wire mapping according to the meter you are connecting to the Watermind v2 Advanced Logger.
WaterMind Adv. Logger Cyble Sensor /
SharpFlow (5 wires)
Cyble Sensor
(2 wires)
Other Meter
(3 wires)
--- White - Low Frequency --- ---
Green - Forward Pulse Grey - High Frequency White - Low Frenquency Yellow - Forward Pulse
Brown - Ground Brown - Ground Brown - Ground Brown - Ground
Yellow - Flow Direction /
Reverse Pulse Yellow - Dir --- White - Reverse Pulse
Orange - Tamper Green - Tamper --- ---
Red +ve DC (6V to 30V) --- --- ---
Black -ve DC (6V to 30V) --- --- ---
G - Splice the Pulse Input Cable following these steps.
H - Connect Pulse and Pressure Inputs.
I - Meter Serial Number & Register Setup
Check that the pre-configured meter serial number is the right one.
Set up the value of the water meter register.
Force the dial-up to update the server.
1.
3.
2.
4.
External Power Cable
Flow Meter Cable
Logger Cable
Cable Tie
Splicing Crimps
Power:
Red & Black
Splicing Boot
Silicone
Rubber
Flow:
Green & Brown
