Ivation IVADRMK10 User manual

PORTABLE ELECTRONIC
DRUM PAD
USER GUIDE
IVADRMK10
Thank you for purchasing the Ivation® Portable Electronic Drum Pad. This User Guide is intended to
provide you with guidelines to ensure that operation of this product is safe and does not pose risk to
the user. Any use that does not conform to the guidelines described in this User Guide may void the
limited warranty.
Please read all directions before using the product and retain this guide for reference.
This product is intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions.
See warranty for details.
Safety Precautions
• If you have batteries installed in your drum pad, but won’t be using it for an extended period of
time, make sure to remove the batteries to avoid leakage.
• Do not install rechargeable batteries in this device, as it is not compatible with them. Only
regular alkaline batteries will function properly. Please note that when the USB power cable
is connected, the battery power will be cut o automatically.
• When this product is connected to a speaker, please make sure to remove the power cable
after using it, and then turn o the drum set via the switch in the back.
• While using this product, please make sure not to shift the drum pad or place it on an
uneven surface, or else the pad may not function correctly.
• Make sure that the drum pad is never scratched with sharp or hard objects. Any kind of
cracking incurred on the pads can cause either a device malfunction or permanent damage
to the product.

• After use, when storing the drum pad, you may roll it up if necessary, but make sure not to bend
or twist the pads too much or else the device could start to function improperly or stop
working altogether.
• Please do not pull or twist the control box or the drum pad with excessive force.
• In order to prevent malfunctions or permanent damage to the drum set, please make sure not to
use it or store it in places where it might be exposed to strong electromagnetic waves.
• Please do not disassemble, attempt to disassemble, or modify this product.
• Do not throw the electronic drum pad.
• Please make sure not to use or store this product in environments where it will be exposed
to excessive moisture, humidity, or dust/dirt accumulation. These environments could
permanently damage the drum set or cause it to malfunction.
Package Contents
• Portable electronic drum pad
• Two wooden drumsticks
• Two pedals for the bass drum and hi-hat functions
• USB power cable
Product Overview
PAD4: HI-HAT
PAD5: SNARE
PAD6: TOM2
PAD1: CRASH
PAD2: TOM1
PAD7: TOM3
PAD3: RIDE
17 16 15 14 13
12 11 10 9 8 7 6
2 3 4 5
1

Number Label Functions
1ON/OFF Power switch.
2 USB/DC 5V USB power supply connection.
3MP3 MP3 player input connection.
4HEADPHONE JACK Audio output connection port for use with personal
headphones or speaker systems.
Connection port for the dual-pedal interface of HI-HAT
control and KICK control. When the HI-HAT pedal is pressed,
5PEDAL it produces a closed HI-HAT tone; when the HI-HAT pedal is
not pressed, it produces an open HI-HAT tone. When the KICK
pedal is pressed, it produces the BASS DRUM tone. This
creates a realistic drum set eect with dual-pedal interaction.
6KIT Press this button to cycle through and select the dierent
tones available for this drum kit.
7 CLICK Press this button to cycle through three dierent
metronome patterns: 4/4, 3/4, and 6/8 time.
8PLAY/STOP Play or stop playing demo songs.
9 DEMO Press this button to cycle through, select,
and play the available demo songs.

Number Label Functions
10 SPECIAL Swap the positions of the SNARE and HI-HAT pads.
11 VOLUME + Volume up.
12 VOLUME – Volume down.
The first four LED lights on the strip to the left of the function keys will be illuminated any time the user
is playing the drum set, and the fifth LED light will be illuminated whenever the drum pad is powered
on, to indicate that the device is currently working and receiving power.
The above listed options represent the order in which the KIT button will cycle through the dierent
drum tones that are available to use. After the 5th option, pressing the KIT button again will cycle back
to the 1st option.
Drum Tone Directory (KIT Button)
1st Pop
2nd Rock
3rd Latin
4th Electro/EDM
5th Percussion

Demo Song Directory (DEMO Button + PLAY/STOP Button)
1st Heavy Rock
2nd Funk
3rd Latin
4th Dance
5th Samba
6th Cha-Cha
7th Swing Hi-Hat
8th Upbeat Rock
The above listed options represent the order in which the DEMO button will cycle through the dierent
demo songs that are available. After the 8th option, pressing the DEMO button again will cycle
back to the 1st option.
Using the Portable Electronic Drum Pad
1. Either install 2x AAA alkaline batteries (not included) in the battery compartment underneath
the control panel, or plug the USB cable into your computer’s USB port or a USB wall adapter to
provide power to your drum pad.
NOTE: You will need a Philips-head screwdriver to remove the two screws holding the battery
compartment door in place. Once the batteries are installed, replace the screws.
2. Use the ON/OFF switch on the back to turn the drum pad on, and then connect headphones or
a portable speaker to the required audio output jack.
3. If you want to use the metronome while you play, press the CLICK button to start the metronome in
4/4 time, or press it again to cycle through the other available time signatures (3/4 and 6/8).
4. If you’d like to play along to a demo song, press the PLAY/STOP button first to start playback,
then press DEMO to cycle through the dierent song options as listed in the Demo Song Directory.

5. To change the tone of the drum kit, press the KIT button to cycle through the options as listed in
the Drum Tone Directory.
6. If needed, press the SPECIAL key to switch the positions of the snare and hi-hat pads, so that the
snare pad will produce the hi-hat tone and respond to the hi-hat pedal, and the hi-hat pad will
produce the snare tone.
7. Connect an audio device via the MP3 input jack to either play along with your own pre-recorded
tracks, or record yourself drumming.
8. Use the included USB cable to connect your drum pad to your personal computer or laptop
and play along with your favorite games or transform your performances using your preferred
music editing software.
Troubleshooting
• Removing the batteries from the battery compartment will always cause the drum pad to stop
working as long as it is not plugged in.
• When the batteries start to reach the end of their lifespan, you may notice a decrease in sound
quality or erratic functionality. If you notice this occurring, please make sure to change the battery
as soon as possible.
• If the drum pad experiences a malfunction, turn the power switch to the OFF position, remove
the batteries or disconnect it from the power supply, and wait approximately 5-10 seconds
before reconnecting it to the power supply/reinstalling the batteries and flipping the switch back to
the ON position. This should restore the default settings.
• If the drum pad makes a buzzing sound, make sure there are no other electronic devices nearby
that might be causing interference and that the drum pad is sitting on a smooth, even surface.
• If the room in which you are using the drum pad experiences a dramatic change in temperature
or fluctuation in humidity levels, you may experience some sound issues or irregular functions in
the drum pad. If this occurs, try to smooth the drum pad and roll it out so that it lays flat on the
playing surface to confirm that the drum sections are working normally. If you continue to
experience issues, you may need to move the drum pad to another room with more stable conditions.
Care & Maintenance
• To clean the drum pad, wipe it with soft and dry fabric. Do not submerge the drum pad in water or
use detergents to clean it.
• After use, you should store the drum pad in a cool, dry place. If you won’t be using it again for a
while, make sure to take out the batteries as well.
• Don’t use this product in any location where it will be exposed to high temperatures, moisture,
or high levels of humidity, or else it will not function properly.

• If using batteries, please follow these guidelines to ensure your batteries are properly maintained:
o Do not use rechargeable batteries in this device; they are incompatible with its design.
o Please dispose of batteries in the proper locations and receptacles. Do not dispose of
batteries in any type of fire, as this could result in the battery exploding and leaking acid.
o Do not mix types of batteries (e.g., regular and rechargeable) in this device.
o Always make sure the batteries you install are consistent with one another. Do not mix
old and new batteries as this could result in inconsistent device performance or malfunctions.
o Always make sure to install the batteries in accordance with the polarity markings in the
battery compartment, or else the device will not function and could become damaged.
o When the batteries are used up, remove them promptly from the device. Do not leave
dead batteries in the compartment.
Specifications
• Power: DC 5V
• Input: 2.5W
• Output: 2W
• Battery: 2 AAA, not included
• Volume Control: 10 Levels
• Dimensions: 17.9” x 11.2” x 1.1” (430 x 285 x 30mm)
• Interface: USB MIDI Jack, MP3 Jack
• Drum Pads:
- 1 SNARE
- 3 TOMS
- 1 CRASH
- 1 RIDE
- 1 HI-HAT
• Foot Pedals:
- 1 Bass Drum
- 1 Closed High-Hat
• Drum Tones: 5 options
• Demo Songs: 8
• Selectable Rhythms: 3

Distributed by
C&A Marketing, Inc.
114 Tived Lane East
Edison, NJ 08837 USA
Europe: C&A Europe
167 Hermitage Road
Crusader Industrial Estate
London N4 1LZ
United Kingdom
Made in China
Ivation is a trademark of
C&A IP Holdings, LLC in the U.S.
©2018. All rights reserved.
All other products, brand names, company names, and logos are trademarks of their respective owners,
used merely to identify their respective products, and are not meant to connote any sponsorship,
endorsement or approval.
Questions or problems? Contact us!
[e-mail]
1-866-849-3049
