Ivation IVAPWS8WT User manual

Portable Washer/Spinner
8 lb. capacity
User Guide
IVAPWS8WT
Thank you for purchasing the Ivation portable washer/spinner. This User Guide
is intended to provide you with guidelines to ensure that operation of this product
is safe and does not pose risk to the user. Any use that does not conform to the
guidelines described in this User Guide may void the limited warranty.
Read and make sure you understand and follow all instructions in this guide before
operating this unit. Thoroughly familiarize yourself with the controls and the proper
use of the equipment.
Parts
1. Wash tub water inlet
2. Wash timer
3. Wash selector
4. Spin timer
5. Spin tub water inlet
6. Wash tub cover
7. Wash t u b
8. Pulsator
9. Housing
10. Water inlet hose
11. Safety cover
12. Power cord
13. Spin tub cover
14. Spin tub inner cover
15. Drain hose
Safety Precautions
As with all electrical appliances, safety measures must be observed, including the following:
• Caution: Risk of Electric Shock
• To reduce the risk of electric shock do not attempt to disassemble or alter this device. There are no user-serviceable parts.
• This product is intended for private domestic use only. It is not intended for any commercial trade use.
• Use this product only for its intended purpose.
• Never allow children to have access to this equipment.
• This product is intended for small loads of laundry. Do not overfill the machine.
• Do not plug into an outlet being used by another appliance.
• Never put your hand into the tub while the machine is running.
• Do not put heavy or heated objects on top of the machine.
• Keep machine away from heat-generating equipment.
• Do not use or store machine in direct sunlight.
• Do not use or store machine in wet or damp areas, or in areas prone to high humidity such as bathrooms.
• Do not wash waterproof clothes.
• Do not wash clothes that are heavily soiled with petroleum-based compounds or solvents.
• Always make sure the machine is placed on a solid level surface.
• Never use the appliance near flammable or combustible objects, liquids, or gases.
• Turn off and unplug the appliance before moving or servicing it.
• Do not use the appliance if the electrical cord or any parts are damaged.
1
1
6
7
8
9
10 11
15
14
13
12
234 5

Preparation
• This unit is equipped with a built-in pump for fast and easy draining. Position the drain hose so that discharged water will easily flow away
from the machine.
• Plug the power supply cord into an AC outlet with voltage corresponding to the rating label of the appliance. To reduce risk of electric shock,
plug into a ground fault circuit interrupter (GFCI) outlet.
• Insert the water inlet hose into water inlet connector.
• Refer to the water level mark and select the water level according to the volume of laundry to be washed or rinsed.
Operation
Wash
• Connect the drain hose and water inlet hose.
• Add water and detergent. Turn the WASH knob to dissolve and stir laundry detergent in water.
• Put laundry into machine.
• Use the timer to select washing duration.
• Select the appropriate wash mode (normal or strong) by turning the NORMAL/STRONG/DRAIN knob. Washing will begin.
Drain
When washing or rinsing is complete, turn the knob to the DRAIN position. Turn the knob back to NORMAL when draining is complete.
Intermediate Spin
• Move laundry from the wash tub to the spin tub. Arrange laundry uniformly so that the weight is evenly distributed. An unbalanced tug may
cause vibration and noise.
• Press the laundry down firmly and place the safety over on top.
• Close the outer cover of the spin tub and spin laundry for 1 minute.
Soak/Rinse
Place laundry into wash tub. Set the timer for 1 – 5 minutes. Select water level and wash mode. Let rinse. Drain water.
Spin Dry
Move laundry to the spin tub. Arrange laundry uniformly so that the weight is evenly distributed. An unbalanced tug may cause vibration and noise.
Press the laundry down firmly and place the safety cover on top.
Close the outer cover of the spin tub and spin laundry for 1 – 5 minutes. (Spin duration: 1 minute, 3 minutes, 5 minutes.)
If abnormal noise or vibration occurs, open the spin tub cover and rearrange the laundry. Resume operation.
2

Soak/Rinse
Place laundry into wash tub. Set the timer for 1 – 5 minutes. Select water level and wash mode. Let rinse. Drain water.
Spin Dry
• Move laundry to the spin tub. Arrange laundry uniformly so that the weight is evenly distributed. An unbalanced tug may cause vibration
and noise.
• Press the laundry down firmly and place the safety over on top.
• Close the outer cover of the spin tub and spin laundry for 1 – 5 minutes. (Spin duration: 1 minute, 3 minutes, 5 minutes.)
• If abnormal noise or vibration occurs, open the spin tub cover and rearrange the laundry. Resume operation.
Cleaning and Maintenance
• Unplug the washer from the power supply.
• Clean the machine with a soft damp cloth.
• Do not spray water directly onto the machine. If the machine becomes too soiled, add a mild detergent to clean. Do not use petroleum-based
detergent to clean the machine.
• There will be lint left behind in the overflow filter and the lint filter after each use. These filters need to be cleaned frequently in order to
maintain optimal performance of the machine.
Cleaning the Lint Filter
• IMPORTANT! – The lint filter must always be in place during washing, and must be cleaned immediately after each use.
• Gently press down on the filter frame and pull it off. Remove filter.
• Wash the filter while it is still wet. Wash only with plain water. Let filter air dry. Do not dry under direct sunlight.
• Reinstall the dry filter, ensuring it is firmly in place.
Cleaning the Overflow Filter
• Clean the overflow filter at least once every 2 months.
• Dismantle the overflow filter. Pinch the flexible-fastening claw; pull it gently away from
machine as shown.
• Dismantle the bellows. Dismantle the top of the pipe in the overflow filter. Clean the filter
under running water.
• Reinstall the bellows:
Insert the tie plate of the bottom of valve cover.
Put up the hook at the left top.
Press the top of the slot.
Do not pull on the pipe
Water level
adjuster Bellows
PROBLEM CHECK FOR POSSIBLE CAUSE
The machine does not work Is the power supply on?
Is the power supply cord connected to an outlet?
Has laundry inside the machine become tangled in the pulsator?
Is the timer set?
Are the tub lids closed?
Unable to drain Is the control in the "Drain" position?
Has the drain hose been lowered?
Is the drain hose frozen?
Is the drain hose blocked?
Anormal sound or vibration Are there any loose articles in the wash tub?
Is something touching the pulsator in the wash tub?
Is the machine placed on a level surface?
Is the load unbalanced?
Is an article lodged between the spin bowl and tub?
Is the safety cover placed correctly on top of laundry in the spin tub?
Are the tub lids correctly secured?
Is the load too big?
Are the tub lids correctly secured?
Is the load too big?
3

Specifications
Wash Tub Capacity: 8 lbs. (4kg)
Spin Tub Capacity: 4.4 lbs. (2kg)
Rated Voltage/Frequency: AC 110 –120V, 60Hz
Wash Motor Rated Power: 240W
Spin Motor Rated Power: 140W
Waterproof Rating: IPX4
