7244F
1-1/2” Offset Bottom Pivot
Improper pivot set installation can lead to personal injury or property damage. Follow
all instructions carefully. For questions contactTechnical Support at 1-888-371-7331.
CAUTION
!
1. Prepare and mortise bottom of door and floor to receive pivot set. Determine pivot location
using dimensions on reverse side. Be sure to properly locate and mark pivot center point
of the base plate. The bottom pivot set is non-handed.The pivot shaft will thread into either
side of door leaf.To determine hand of door, see diagrams above.
2. Prepare bottom of door: Locate, drill, and tap 1/4-20 mounting holes for metal door. Locate
and drill pilot holes for #14 wood screws for wood door. Mount door leaf in bottom of door with
1/4-20 x 3/4” FHMS or #14 FHWS screws provided. Drill 7/16” dia. x 3/4” deep holes for base
platemounting.Insert and secure anchorpins,thenmount base plate tofloorwith screws provided.
3. At this point, hang door. Refer to instruction sheet packed with top pivot for details.
4. If height adjustment is necessary for proper door clearance, adjust bottom pivot as follows:
A. Loosen set screw using 3/32” Allen wrench provided (see diagram above).
B. Use 5/16” Allen wrench to adjust pivot shaft height as needed (Figure 1).
C. Tighten set screw firmly.
5. Fasten pivot cap as shown. Secure with cap screw.
Figure 1
Lefthand
installation
Right hand
installation shown;
left hand opposite
Right hand
installation
Base plate
Pivot shaft
3/32”set
screw
Door leaf
Pivot cap
Cap screw
Installation Instructions
26488 Rev. 3 © 2006 Ingersoll-Rand Company Limited

26488 Rev. 3
26488-00
Right hand installation shown;
left hand opposite
It is very important for installer to verify that center line of top pivot point lines up
with center line of bottom pivot point before final installation. Heel edge of door
must be beveled 1/8” in 2” as shown below.
NOTE
!
1-1/16
27 mm
Edge of base
plate is flush
with edge of
door
1-1/8”
29 mm
3/4”
19 mm
2-3/8”
60 mm
Depth of mortise will
varydependingupon
installationand/or
thresholdheight.
*
*
1-1/16”
27 mm
to
5/8”
16 mm
*
