IVEX-PL-3111R User Manual
Explosion proof Security Camera
Be sure to read this manual before installing or using the product.

02
Contents
1. Safety Instruction
2. Key Features
3. Components
4. Part Names
5. Configuration
5-1. Information for Name Plate
5-2. Explosion proof Cable grand
5-3. Multi Cable Configuration
5-4. Ground Connection
6. How to install
7. Specification
8. Appearance
3
5
6
6
7
7
7
8
8
9
10
11

03
1. Safety Instruction
1. Be sure to read this User's Manual before using / installing this product.
2. When installing the product, all structures and bolts / screws used to fix or tighten the
product should be made of stainless steel and use only the manufacturer's recommended
replacement parts.
3. Please use the product within the range of -25 ℃ ~ 65 ℃ for maximum and ambient
temperature range.
4. During installation and use, the user shall be protected from mechanical shocks greater
than 2 Joules
5. Do not change or repair the pressure joint of the enclosure and do not disassemble the
tempered
6. Cable glands and cables with a minimum operating temperature of 90°C should be used
and Cable glands or Stopping Plugs certified to Ex d IIC, Ex t b IIIC must be used for
all cable entries.
7. To reduce the risk of fire in a hazardous environment, disconnect equipment from the circuit
before opening the equipment and take care to minimize the risk of brush discharge.
8. Do not loosen or twist the protective ground wire, and use appropriate clamping tools during
installation.
9. To prevent electrostatic discharge, install the product properly as shown below.
1) Make sure that the product is properly grounded.
2) Make sure that the housing and adjacent objects do not touch each other.
3) If dust accumulates on the equipment, clean it with a damp cloth.
4) Do not install in the following places where static electricity may increase
• Near ventilation systems
• Where there is a risk of static build up by compressed air and dust
• Near machines that use friction
• Near systems that spray electrons (eg near electrostatic paint systems)
• Those that can cause large static electricity Near other machines and systems

04
1. Safety Instruction
Warning!
Failure to Observe the Following May Result in Death or Serious Injury to the User.
1. Never Open it in an Explosion Hazard area.
2. Disconnect the Equipment from the Circuit Before Opening the Equipment in a
Hazardous Situation.
3. To Reduce the Risk of Fire or Electric Shock in Hazardous Areas, be Sure to Turn
Off the Power Before Opening the Product.
4. To Reduce the Risk of Fire or Electric Shock in Hazardous Areas, Always Tighten the
Cable at the Product Inlet with a Sealing Fitting or Cable gland.
5. To Reduce the Risk of Fire or Explosion Resulting From Ignition, Never Open
the Product in Hazardous Areas Where Explosive Gases are Expected.
Caution!
Failure to Observe the Following May Result in Personal Injury or Property Damage.
1. To Reduce the Risk of Electric Shock, Never Remove the Cover.
2. It Shall be Established by Means Proven Explosion-proof Product Installation
Specialist When Installing the Product, Do not run to Open or Disassemble the Product.

05
2. Key Features
▪1/2.8" Sony STARVIS CMOS
▪Multi Format Video Output : AHD / TVI / CVI / CVBS 1 Video Output Selectable
▪UTC Support
▪2.7 ~ 12 mm Lens
▪True D/N(Auto/Day/Night)
▪Explosion proof Cable glands All-in-one
• EMC Certification : IECEx / ATEX / KCs / NEPSI / CE / FCC
• Ex Grade : Ex db IIC T6 Gb, Ex tb IIIC T85℃ Db
• Material of Body : AISI 316L Stainless Steel / Electrolytic Polishing
• Operation Temperature : -25°C ~ +65°C
• Cable Outlet : 1 EA(NPT 1/2”)
• Protection Degree : IP66 (IEC 60079-0 and IEC 60529)
• Certificate issuer : DEKRA Certification B.V.
• Explosion-proof specification
IEC 60079-0 : 2011 (Ed. 6) + IS01 : 2013 EN 60079-0 : 2012 + A11 : 2013
IEC 60079-1 : 2014 (Ed. 7) EN 60079-1 : 2014
IEC 60079-31 : 2013 (Ed. 2) EN60079-31 : 2014
Explosion Proof Bullet Camera System
IVEX-PL-3111R
Explosion Proof Bullet Camera System

06
3. Components
1. Camera 2. Accessory 3. User’s Manual
4. Wall type
Brackets(Option)
4. Part Names
WARNING
If you Disassemble
Camera, IP Rating do
not Guaranteed
1. Camera front cover
2. Main Body
3. Camera Back Cover
4. Sunshield
5. Angle Brackets
6. Ring Brackets
7. Explosion-proof
Cable gland (NPT 1/2”)
(7)
(6)
(4)
(5)
< Side >
< Front > < Rear >
(3)
(2)
(1)
M5 L type
hex wrench x1
M5 bolts
for camera x3
ONE HOLE
LUG x1

07
5. Configuration
5-1. Information for Name Plate
5-2. Explosion proof Cable grand
1/2”- NPT Explosion-proof
Cable gland
1/2” to 3/4”
Expansion Adapter (Option)
• Model No. OSCG KR OSNJ-A2F 16a
• Entry threads : NPT 1/2”
• Protection type : Ex d IIC, Exe II, Ex tD A21
• BS, IEC & CENELEC According to Zone1,
Zone2, Zone21, Zone22, gas group IIA, IIB,
IIC Suitable for use in
• IP Rating : IP66, IP67
• Operating temperature : 120℃
• Inner diameter : 3.0~7.5mm

08
5. Configuration
5-3. Multi Cable Configuration
5-4. Ground Connection
1. MWID(External) : Maximum wire insulation diameter is 4.5mm, maximum wire size is 25㎟.
Minimum wire insulation diameter is 3.5mm, minimum wire size is 15㎟.
2. For ISO 4762, use hexagon socket head cap screws M4 x P0.7 or M5 x P0.8 for grounding.
3. The bolts are made of stainless steel and the One Hole Lug is made of electro-tin plated copper.
4. CAUTION : Do not loosen or twist the protective earth conductor
Hexagon socket head
sem`s cap screw M5*P0.8
ONE HOLE
LUG
2. Multi Cable Length : 500mm
1. Video Output : AHD / TVI / CVI / CVBS 1 Video Output Selectable
Power (DC12V)
0.5M 5M
AHD
(Basic Video Output)

09
6. How to install
◆Loosely loosen two M5 x 8 bolts of angle bracket using L-shaped hexagonal wrench,
adjust it to the desired angle, and tighten the bolts tightly again.
< Wall Type >< Stand Type > < Ceiling Type >
◆Wall Mounting Use the 2 ~ 4 bolts and nuts provided on the dedicated bracket to
mount the explosion proof camera on the top of the wall bracket with the stand type
and tighten it firmly from the bottom of the bracket.
< Wall Bracket(Option)- Before Tightening > < Wall Bracket(Option)-After Fastening >

10
7. Specifications
MECHANICAL PART
CAMERA PART
Image Sensor 1/2.8" Sony STARVIS CMOS
Total Pixels 1945(H) x 1109(V) = 2.16 Megapixel
Scanning System 16 : 9 Progressive Scan
Resolution Digital : 1920 x 1080p, More than 1000 TVL(1080p)
Angle of View 33 ~ 100°(H)
Lens 2.7 ~ 12 mm
Min. illumination More than 0.03 lux(DSS off) / Max Gain 63dB
S/N Ratio More than 52dB(AGC off)
Shutter Auto / Flicker / Manual(1/30(25) ~ 1/30,000
Sens-Up Off / x2 / x4 / x8 / x16 / x32
AGC 0 ~ 10
Day & Night Auto / Day / Night
AWB Auto / Preset / Manual
DNR Off / Low / Middle / High
Video Output AHD / TVI / CVI / CVBS : 1 Video Output Selectable
Frame Rate 1080p –25fps/30fps
Model IVEX-PL-3111R
Material AISI 316L Stainless Steel / Electrolytic Polishing
Window Material Fully tempered plate glass
Ex Certification IECEx / ATEX / JPEx / NEPSI / KCs / CE / FCC / KC
Ex Grade Ex d IIC T6 Gb, Zone 1 & 2
Ex tb IIIC T85˚C Db, Zone 21 & 22
Protection Degree IP66
Operation
Temperature/Humidity -25°C ~ +65°C / Less than 90% RH
Size 107.2(W) x 148(H) x 187(L) mm
Weight Approx. 3 kg
Input Voltage DC12V
Cable Outlet 1 EA(NPT 1/2”)

11
8. Appearance
DIMENSION
Unit : mm
