GridBee GS-12
120V Single Phase
Operation & Maintenance Manual

Table of Contents
About Ixom
Ixom combines knowledge and experience from across the water quality spectrum to help solve
real-world problems. Whether in Lakes, Stormwater Retention Ponds, Raw Drinking-Source Reservoirs, Water
Treatment Plants, Potable Storage Tanks, or Wastewater Treatment Processes, Ixom equipment continues to
be at the forefront as the #1 world leader for in-situ water body treatment.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Table of Contents
10014_20200528
GridBee GS-12
120V Single Phase
Operation & Maintenance Manual
Saftey Instructions 1
Package Contents 4
Machine Requirements 5
Top of Tank Junction Box 6
Placement 9
Final Checklist 12
Troubleshooting 13
Technical Specifications 15
Warranty 16
Customer Service 17
O&M_GS12_120V_1PH_10025_20200811

Carefully read safety information when you see
any safety symbols.
Be sure you have read all installation, operation, maintenance and safety instructions before
you install, service or begin to operate this unit.
Accidents occur every year because of careless use of industrial equipment. You can avoid hazards
by following these safety instructions, and applying some ordinary common sense when operating or
servicing this unit.
Keep in mind that full operator attention and alertness are required when operating or servicing
this unit.
USE COMMON SENSE!! Most accidents can be avoided by using common sense and
concentration on the job being done.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Safety
Safety
1949_10036_20200528 O&M_GS12_120V_1PH_10025_20200811 - 1

IMPORTANT!!!
Follow all federal and state laws in regards to
safety regulations of working at heights, conned
spaces, rescue, etc. as required by the U.S.
Department of Labor, Occupational Safety and
Health Administration. Use necessary PPE when
placing and servicing this unit.
Identify all possible hazards. Determine what
safeguards are needed and implement them.
Only you, the user, understand your product
and system characteristics fully. The ultimate
responsibility for safety is with you. Your
safety ultimately rests in your hands. Do
your part and you will enjoy safe, trouble free
operation for years to come. This instruction
manual is not intended to include a
comprehensive listing of all details for all
procedures required for placement, operation
and maintenance. If you have a question about
a procedure or are uncertain about any detail,
Do Not Proceed. Please contact Ixom
Customer Service at 866-437-8076 to speak
to a representative.
ELECTRICAL HAZARD
WARNING: THIS EQUIPMENT CONTAINS
HIGH VOLTAGE! ELECTRICAL SHOCK CAN
CAUSE SERIOUS OR FATAL INJURY. ONLY
QUALIFIED PERSONNEL SHOULD ATTEMPT
PLACEMENT, OPERATION AND MAINTENANCE
OF ELECTRICAL EQUIPMENT. REMOVE ALL
SOURCES OF ELECTRICAL POWER BEFORE
PERFORMING ANY SERVICE WORK TO THE
MACHINE. USE PROPER LOCKOUT TAGOUT
(LOTO) PROCEDURES TO ENSURE A SAFE
WORK ENVIRONMENT.
Rotating Hazard
CAUTION: KEEP BODY APPENANDAGES OR
LOOSE CLOTHING AWAY FROM EQUIPMENT
WHILE OPERATING. ENSURE EQUIPMENT IS
OFF BEFORE ATTEMPTING SERVICE.
Crush Hazard
WARNING: DO NOT REMOVE ANY FLOAT
ASSEMBLY BOLTS OR PINS WHILE EQUIPMENT
IS FLOATING IN WATER. EQUIPMENT MUST BE
SECURELY SUPPORTED BEFORE PERFORMING
SERVICE.
Laceration Hazard
CAUTION: EDGES MAY BE SHARP AND CAUSE
LACERATION IF PROPER CARE IS NOT USED.
Entanglement Hazard
WARNING: ENSURE THAT PERSONNEL ARE
CLEAR OF THE ELECTRIC CORD AND CHAIN TO
AVOID ENTANGLEMENT.
Thin Ice Hazard
WARNING: ICE SURROUNDING MACHINE MAY
NOT SUPPORT WEIGHT, KEEP CLEAR OF THIN
ICE.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Safety
Safety
1949_10036_20200528 O&M_GS12_120V_1PH_10025_20200811 - 2

Permit-Required
Conned Spaces
A conned space has limited openings for
entry or exit, is large enough for entering and
working, and is not designed for continuous
worker occupancy. Conned spaces include
underground reservoirs, ground storage tanks,
elevated tanks, silos, manholes, and pipelines.
Conned Space Tips
• Do not enter permit-required conned spaces
without being trained and without having a
permit to enter.
• Review, understand and follow employer’s
procedures before entering permit-required
conned spaces and know how and when
to exit.
• Before entry, identify any physical hazards.
• Before and during entry, test and monitor for
oxygen content, ammability, toxicity or
explosive hazards as necessary.
• Use fall protection, rescue, air monitoring,
ventilation, lighting and communication
equipment according to entry procedures.
• Maintain contact at all times with a trained
attendant either visually, via phone, or by
two-way radio. This monitoring system
enables the attendant and entry supervisor
to order you to evacuate and to alert
appropriately trained rescue personnel to
rescue entrants when needed.
Refer to 29 CFR 1910.146 for complete
regulations set by OSHA. Refer to your state's
regulations if your state established and operates
their own safety and health programs approved
by OSHA.
Protect Yourself
It is important that you comply with all relative
OSHA and local regulations while installing
and performing any maintenance to the mixer
circulation equipment.
Key OSHA Compliance Standards that must
be followed (and not limited to) are:
• 1910.146 Permit-required conned spaces
• 1910.147 Lockout/Tagout
• 1926.500 Fall Protection
Fall Protection Tips
• Identify all potential tripping and fall hazards
before work starts.
• Look for fall hazards such as unprotected
oor openings/edges, shafts, open hatches,
stairwells, and roof openings/edges.
• Inspect fall protection and rescue equipment
for defects before use.
• Select, wear, and use fall protection and
rescue equipment appropriate for the task.
• Secure and stabilize all ladders before
climbing.
• Never stand on the top rung/step of a ladder.
• Use handrails when you go up or down stairs.
• Practice good housekeeping. Keep cords,
welding leads and air hoses out of walkways
or adjacent work areas.
Refer to 29 CFR 1926.500 for complete
regulations set by OSHA. Refer to your state's
regulations if your state established and operates
their own safety and health programs approved by
OSHA.
Lockout Tagout
When the On/Off switch is in the "ON" position,
the mixer may start up at any time if not already
operating. The mixer's On/Off switch can be
locked out by placing a pad lock thru the door latch
of the controller after the switch has been turned
to the "OFF" position. The On/Off switch is to be
used as the emergency stop.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Safety
Safety
1949_10036_20200528 O&M_GS12_120V_1PH_10025_20200811 - 3

1 5/16” Hole Saw
Chain Grab Tools Lexel
Sealant Tube
Kellem Grip
Cord Strain Relief
Cord Fixture
GS Core Unit
75’ or 150’ Electric Cord
(Not Pictured)
75’ or 150’
Stainless Steel
Chain
Top of Tank
Junction Box Cord Seal
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Package Contents
GS Series
1926_10005_20200225 O&M_GS12_120V_1PH_10025_20200811 - 4

Hatch Requirement
A 12 inch (305 mm) diameter hatch opening is required
to t the GS Mixer through.
Power Requirement
120 VAC, 20 amp GFCI protected service and means
of quick power disconnect recommended.
Figure 1: Typical GS Placement
Optional
Mixer Control Panel
Optional Customer
SCADA
120 VAC, 20Amp
GFCI Circuit Breaker
RATING FULL
LOAD
MAXIMUM
LOAD
WINDING (1)
RES. IN OHMS
EFFICIENCY
%
POWER
FACTOR % LOCKED
ROTOR
AMPS
KVA
CODE
HP KW VOLTS HZ S.F. (2)
AMPS WATTS (2) AMPS WATTS M=MAIN RES. S=START RES. F.L. S.F. F.L. S.F.
1/2 0.37 115 60 1.6 7.9 910 9.8 1120 1.4-2.0 42 54 99 99 28 H
Service Entrance to Motor - Maximum Length In Feet
Based on Service Factor Amps, and 5% Voltage Drop
Motor Rating 60° C and 75° C Insulation - AWG Copper Wire Size
Volts HP kW 14 12 10 8 6 4 3 2 1 0 00 000 0000
115 1/2 0.37 100 160 250 390 620 960 1190 1460 1780 2160 2630 3140 3770
{
Remove Power
Cord for Conduit
Connection
Junction Box & Cord Fixture
supplied with GS Mixer.
Located within arms reach
of the hatch.
Exterior Conduit and
3-Conductor Power Cable
(2-Power + 1-Ground)
Terminate conduit using ex
conduit with male thread end
for panel mount.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Requirements
Requirements
GS Series
1912_10008_20200225 O&M_GS12_120V_1PH_10025_20200811 - 5

Steel Roof
GS Series
General Notes:
1. Top of tank junction box.
2. Cord seal tting.
3. Brass nut.
4. Plastic seal washer with Lexel.
5. Tank penetration tting.
6. A 1-5/16” dia. hole to be drilled
into tank roof. Sealed with
Lexel to protect from corrosion.
7. Strain Relief Washer.
8. Quick link for connecting retrieval
chain and kellem grip to strain
relief washer.
9. Kellem grip to support cable
weight and to provide strain
relief.
NOT DESIGNED AS A SUBMERSIBLE
PENETRATION.
Alternative Method:
Penetration through hatch neck
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Top of Tank Junction Box
1914_10007_20200618 O&M_GS12_120V_1PH_10025_20200811 - 6

Concrete Roof
GS Series
General Notes:
1. Top of tank junction box.
2. Eye-bolt, epoxied into hatch neck,
for retrieval chain and kellem grip.*
3. Kellem grip.
4. Bolts, epoxied into hatch neck to
secure concrete penetration tting.
5. Concrete penetration tting.*
6. Small bores drilled into hatch neck
the length of the bolts, 1/2” dia.
typical, lled with concrete
epoxy. Follow concrete epoxy
manufacture’s preparation and
installation guidelines.
7. A 3/4” dia. minimum to 1-1/4” dia
maximum hole drilled through hatch
neck for electrical cord.
8. Junction box mounted to existing or
new structure. Structure not
included.
9. 3/4” NPT electrical conduit
connection: conduit to juction box
not included.
*Not included in standard contents
Contact Ixom for
exchange.
NOT DESIGNED AS A SUBMERSIBLE
PENETRATION.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Top of Tank Junction Box
1914_10007_20200618 O&M_GS12_120V_1PH_10025_20200811 - 7

Aluminum Geodesic Dome Roof
GS Series
General Notes:
1. Cord seal tting.
2. Brass nut.
3. Plastic seal washer with Lexel.
4. Top of tank junction box.
5. Penetration xture.
6. Aluminum geodesic dome
panel.
7. Aluminum geodesic dome
batten bar.
8. Support I-beam.
9. Quick link.
10. Kellem grip.
11. A 1-5/16” dia. hole drilled
through panel and sealed with
Lexel. Locate penetration within
arms reach of an access point.
12. Eyebolt drilled through support
I-beam to support kellem grip
and retrieval chain. Eyebolt not
included.
NOT DESIGNED AS A SUBMERSIBLE
PENETRATION.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Top of Tank Junction Box
1914_10007_20200618 O&M_GS12_120V_1PH_10025_20200811 - 8

Floor Conguration
GS Series
Optional Mixer
Control Panel
Junction Box &
Tank Penetration
GFCI Protected
Source Power GS Mixer
Exterior Conduit and 3-Conductor Power
Cable (2-Power + 1-Ground)
GS mixer resting on tank oor under hatch.
Retrieval chain attached to mixer. Slots
aligned parallel with line extending from cen-
ter of tank to tank wall.
Junction box & roof
mount cable xture
supplied with GS mixer
and located within
arms reach of the
hatch.
Terminate conduit
using ex conduit with
male thread end for
panel mount
Chain and cable
attached to quick link
Cord ran through cord
seal.
Locate power source receptacle and ex con-
duit termination at customer preferred location
of mixer control panel
Terminate conduit using ex conduit with male
thread end for panel mount
IMPORTANT
It is important to disinfect all components in contact
with potable water. There may be additional decon-
tamination procedures required, so it is important to
understand what procedures are acceptable. Decon-
tamination should be performed right before the unit
is lowered through the hatch. The mixer should be
immersed in water shortly after having been decon-
taminated to prevent corrosion caused by contact
with chlorine or alternate disinfectant.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Placement
1916_10006_20200514 O&M_GS12_120V_1PH_10025_20200811 - 9

Suspended Conguration
GS Series
Cord ran through
penetration tting
and cord seal.
Chain and Kellum
Grip attached to
quick link on
penetration tting
Mixer suspended
near tank oor
Chain Connected
to Mixer
Suspended Conguration
The suspended conguration is primarily used
on tanks without a at bottom. This method of
installation is different with aluminum roofs or
geodesic domed roofs.
Installation Procedures
Step 1:
Attach the retrieval chain to the GS mixer at the
pre-located quick link. Tighten the quick link with
a wrench/pliers. Plan out a safe procedure and
hoist the GS Mixer to the top of the tank near the
hatch opening. Use the chain and submersible
cable attached to the GS Mixer for lifting and
supporting the weight. Keep clear of chain and
electric cord to avoid entanglement.
Step 2:
Tie off the tail end of the retrieval chain and
electric cord strain relief to the quick link at the
bottom of the tank penetration tting.
Step 4:
Pull the retrieval chain up until it is taught, then
mark off the desired distance the GS Mixer is to
be suspended above the oor, placing the quick
link that desired distance down the retrieval
chain below the tank penetration tting.
Step 5:
Slowly pull up the GS Mixer and connect the
quick link to the tank penetration tting.
IMPORTANT
It is important to disinfect all components in
contact with potable water. A common practice is to
use a minimum 200ppm chlorine or alternate dis-
infectant solution in water to spray all components
that will contact the drinking water. There may be
additional decontamination procedures required,
so it is important to understand what procedures
are acceptable. Decontamination should be per-
formed right before the unit is lowered through the
hatch. The mixer should be immersed in water
shortly after having been decontaminated to pre-
vent corrosion caused by contact with chlorine or
alternate disinfectant.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Placement
1916_10006_20200514 O&M_GS12_120V_1PH_10025_20200811 - 10

In many cases, mixer deployment just below the main access hatch is sufficient. However, consider the
below recommendations, where practical, for guidelines of mixer placement.
Short circuit path:
Ideally, the mixer should be placed in the short circuit path between the
inlet and outlet of the tank. This provides the mixer the best opportunity
to blend all incoming water with the tank volume prior to water exiting
the outlet.
Common Inlet / Outlet:
The mixer should be favored toward a common inlet / outlet pipe to
prevent short circuiting. This provides the mixer the best opportunity to
blend all incoming water with the tank volume prior to water exiting the
tank. However, the mixer should stay clear at least 10-15ft away from a
common inlet/outlet pipe.
Radial Orientation:
It is best to orientate the mixer so the discharge slots are radial with the
tank. This is most critical if the mixer is placed near a sidewall of the tank.
Center Tank Placement:
A mixer is often positioned at the tank center when a separate inlet and
outlet are positioned at or approximately 180° apart. It is most critical for
the mixer to be along a short circuit path.
Mixer Elevation:
The mixer should be located in the lowest
elevation of the tank, and resting or
supported in a horizontal position with
discharge slots pointed vertical. Water
below the mixer will not be circulated.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
PLACEMENT
MIXER PLACEMENT GUIDELINES
For GS Series Mixers
10496_20200522 O&M_GS12_120V_1PH_10025_20200811 - 11

Installation Checks
Before starting the GS Series mixer a few checklist
items are recommended to conrm the installation is
correct.
Installation Checks Check
Is the mixer placed correctly with slots facing up? (Placement)
Is the mixer retrieval chain connected securely? (Placement)
Is the kellum grip supporting the weight of the cord/hose? (Placement)
Is the cord/hose ran through the cord seal in the top of tank junction box? (Placement)
Is the Tank Penetration tting sealed with Lexel? (Top of Tank Junction Box)
Are the top of tank junction box splices correct and each splice individually sealed to protect from
corrosion? (Top of tank Junction Box) (Not applicable for GS-12-Air)
Is the eld wiring correct? (Requirements)
Is the mixer submerged with at least 2’ (0.75m) of water above the discharge slots?
Pre Operation Checks Reading
Continuity Check Line to Neutral:
Line to Ground:
Neutral to Ground:
Source Voltage Reading
Operation Check (While Mixer is Running) Reading / Observation
Source Voltage Reading
Amperage Reading
Normal Operating Range: (7.5 amps to 10.0 amps)
Flow Check Auditory
Flow Check Visual
Operation Checks
The following checklist items are recommended to
conrm proper operation.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Final Checklist
Final Checklist
1931_10003_20200323 O&M_GS12_120V_1PH_10025_20200811 - 12

Voltage (ṽ)
To measure the voltage follow these steps.
1. Set the voltmeter on Volts AC.
2. Place the positive probe on the black wire and the negative
probe on the white wire on the top of the contactor (source side).
3. Record the reading.
Amperage (Ã)
To Measure the Amperage follow these steps.
1. Use a clamp type ammeter, set to Amps AC.
2. Clamp around the black wire on the bottom of the contactor
(load side). Marked Load 1 (L1).
3. Record the reading with mixer turned on.
Ohms (Ω)
To Measure the Ohms follow these steps.
1. Turn off the circuit breaker feeding the control panel and follow
lock out tag out procedures.
2. Measure the Voltage to conrm that the power is removed.
3. Disconnect the black and white wires from the bottom of the
contactor (load side). Marked Load 1 (L1) and Neutral (N).
4. Set the Voltmeter to Ohms.
5. Place the positive probe on the black wire and the negative
probe on the white wire that were disconnected.
6. Record the reading.
Depending on the length and gauge of wires to the mixer the ohms
should be approximately:
1-4 Ohms, 120V and 6-10 Ohms, 230V.
Figure 1: SCADA Control Panel
Problem Possible Cause
Mixer Intermittently Tripping
Circuit Breaker
Multiple GFCI on Circuit
Source Power Fluctuation
Mixer Quickly Tripping Circuit
Breaker
Short to Ground
Locked Rotor on Motor
Mixer Not Operating but Circuit
Breaker not tripped
Loose or Loss of Connection
Mixer Making Loud Noise Motor Bearing Failure
Impeller Misalignment
Figure 2: Disconnect Control Panel
Contactor
Contactor
Incoming
Power
Incoming
Power
Troubleshooting Information
Serial Number
Location Name
Tank Name
Distributor Name
(if applicable)
Voltage Reading
Amperage Reading
Ohm Reading
(For Optional Mixer Control Panel)
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Troubleshooting
Troubleshooting
GS Series
1930_10004_20200811 O&M_GS12_120V_1PH_10025_20200811 - 13

Step 1
Isolate power to the GS mixer to prevent it from turning on
during inspection. The mixer must be off to perform this
inspection safely.
Step 2
Remove white end plate on the end of GS Mixer. The side
that should be removed is the side without the screen on it.
You will nd four (4) screws that will need to be removed in
order for the end plate to become free from the mixer.
(See Figure 1)
Step 3
Visually inspect the impeller for debris or build up. You
should be able to move the impeller freely with no resistance.
(See Figure 2)
Step 4
Remove any debris if necessary.
Step 5
Place the white end plate back on the GS Mixer, ensuring
to line up the notch on the top side of the mixer. The four
screws that were removed in Step 2 should be put back in
place at this point as well.
Tools Needed
1. Electric Drill
2. #3 Phillips drill bit
GS Mixer End Plate Removal and Impeller Visual
Figure 2: Impeller View
Figure 1: End Plate Removal
Impeller
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Troubleshooting
Troubleshooting
GS Series
1930_10004_20200811 O&M_GS12_120V_1PH_10025_20200811 - 14

Intake - Intake draws water in a horizontal layer within 2 inches (5.08 cm) of the tank or reservoir oor. Chlorine boost
connection point on machine via 3/8” NPT female thread for adapting to 1/2” (13mm) hose for fast chlorine dispersion
during in-reservoir boosting.
Electrical Requirements - 120VAC motor requires 120VAC/1PH power source outlet (minimum 20 Amp service). The
GS-12 draws approximately 9.0 Amps @ 120VAC / 60Hz. Nominal power consumption of 800 Watts.
Sealed Penetration Fitting - T316 stainless steel tank tting and cord grip included for sealed cord entry through
tank roof. Not designed as a submersible penetration.
Wiring - Includes either 75 ft (22 m) of 12AWG or 150 ft (44m) of 10AWG submersible power cable to terminate
within junction box at top of tank. Junction box included.
Motor - 1/2 HP stainless steel submersible, designed for continuous operation, low power requirement,
direct drive, no gearbox and no lubrication schedule required. Automatic reset, on-winding thermal overload
protection and surge arresters built in. Mounted in ow sleeve for superior cooling and long motor life in
submerged temperatures up to 122 F. See certications section below. 120VAC/1PH standard, other voltages
available as special order.
Figure 1: GS-12
Technology Description- GridBee® electric submersible water circulation equipment, designed for continuous operation.
Constructed with T316 stainless steel shell and safe materials for contact with potable drinking water. Designed to be
placed into service through roof hatch without tank entry.
Certications - Ixom’s potable water products are certied to ANSI/NSF Standard 61, and 372 for lead-free content.
Learn more at: www.medoraco.com/std61
Maintenance / Warranty - Limited maintenance. Limited 5-year parts and labor warranty. See Warranty Statement for
details.
Optional Accessories - (1) Portable Chlorine Boost Hose and Boost Pump System, (2) Dual Injection Kit,
(3) Control and SCADA Panel
Minimum Water Depth - The mixer requires at least 2 feet
(0.6meters) of water above the discharge slots to prevent
pump cavitation and motor damage. Shut the mixer off if
water surface is less than 2ft from the mixer slots.
Materials of Construction - T316 stainless steel shell and
hardware construction. UHMW-PE end plates for worry-free
safe contact with all tank surfaces. See certications
section below.
75 ft (22 m) or 150 ft (44 m) of T316 stainless steel retrieval
chain included for machine installation and retrieval without
requiring tank entry.
Minimum Access Opening - Machine can be placed
through 12 inch (30 cm) diameter opening.
Patent Pending Subject to change without notice.
Shipping Size / Weight
75 ft unit - Box 1 of 2: 44x16x12 in. / 88 lbs, Box 2: of 2: 17x13x8 in. / 25 lbs: Total shipment weight: 113 lbs
150 ft unit - Box 1 of 2: 44x16x12 in. / 127 lbs, Box 2: of 2: 17x13x8 in. / 41 lbs: Total shipment weight: 168 lbs
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Technical Data Sheet
GS-12
1572_10024_20200731 O&M_GS12_120V_1PH_10025_20200811 - 15

GridBee GS Mixers. The GridBee Series GS mixers are warranted to be free of defective parts,
materials, and workmanship for a period of ve years from the date of purchase. This warranty is valid
only for use of the equipment in accordance with the owner’s manual and any initial and ongoing
factory recommendations. This warranty is limited to the repair or replacement of defective components
only and does not apply to normal wear and tear. If the factory’s service crews performed the original
on-site placement and startup, then this warranty also includes labor. Where labor is included, in lieu of
sending a factory service crew to the site for minor repairs, Ixom may choose to send the replacement
parts to the owner postage-paid and may pay the owner a reasonable labor allowance, as determined
solely by Ixom, to install the parts. There is no liability for consequential damages of any type. The
warranty that is submitted and provided with the purchased equipment is the valid warranty.
GridBee control panels, cold weather hose kits, air compressors and any optional accessories.
These items are considered “buyout” items for Ixom, and as such include a warranty against defects in
material and workmanship for one year from the date of purchase. This warranty covers parts only, not
labor. Parts that are determined by Ixom to be defective in material or workmanship under normal use
during the one year warranty period will be repaired or replaced. Shipping charges are the
responsibility of the customer.
Terms applicable to all equipment. This Limited Replacement Warranty is subject to the terms of
Ixom’s General Terms and Conditions of Sale. In the event of any inconsistency between the terms of
this Limited Replacement Warranty and Ixom’s General Terms and Conditions of Sale, the terms of this
Limited Replacement Warranty shall prevail to the extent of that inconsistency.
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Warranty
GridBee GS Submersible Mixer Limited Replacement Warranty
1684_10018_20200420 O&M_GS12_120V_1PH_10025_20200811 - 16

Ixom employs qualied highly trained Service and Placement Technicians certied to perform the
necessary tasks required to install or remove SolarBee and GridBee circulation equipment
Ixom's specialized Service and Placement Technicians are trained in Conned Space, Fall Protection,
and other related subjects as required by OSHA to perform the necessary work to install or remove
SolarBee and GridBee equipment, and are knowlegeable in the regulations and standards of OSHA.
If you feel the need to service your SolarBee or GridBee circulation equipment, please contact Ixom's
Customer Service Department at:
[phone]
Ixom Service & Support
© 2020 Ixom | www.medoraco.com | 866 - 437 - 8076 | [email protected]
Service & Support
1928_10001_20200420 O&M_GS12_120V_1PH_10025_20200811 - 17
