jablotron TM-201A User manual

JABLOTRON ALARMS a.s. Pod Skalkou 4567/33 46601 Jablonec n. Nisou
Czech Republic www.jablotron.com
||
|
TM-201A multi-functional electronic thermometer, - 1 - MNU51203
TM-201A multi-functional electronic thermometer
The TM-201A multi-functional electronic thermometer can be used in all
installations where one or two temperature values need to be measured with
a subsequent relay closing or opening action. The thermometer is equipped
with warning (optical and acoustic) indication. It can be typically used
as a protective thermometer, bistable thermostat or difference thermostat.
Figure 1: Front view
1. Thermometer installation
Install the thermometer in such a way as to make it well visible to the user. Do not install it in places where it may
be exposed to intensive radiant heat. The thermometer is designed for wall-mounted indoor installation. It can be mounted
directly into a common device installation box or on plaster. The bottom part of the housing is always used for this purpose.
1. Remove the top part of the thermometer from the frame (by pushing a screwdriver into the gap between
the display and frame at the T2 indicator).
2. Release the bottom housing by pressing the four latches in the corners (figure 2).
3. First, mount the bottom housing and then snap the display frame into it.
4. Connect the supply cables of the sensors to the T1 and T2 terminals. Always tighten the terminals with
the terminal boards removed. Remove the terminal boards by pulling them towards yourself.
Both the temperature sensors are the same and they can be connected with either polarity. If just one sensor
is sufficient for the selected function of the thermometer, it should always be connected to the T1 terminals.
5. The contacts of the controlled device should be connected to the OUT terminals. The load capacity of the output
is 1 A/250 V and it has safety isolation characteristics. For higher loads use an auxiliary relay or contactor.
6. Connect the 12 V / 50 mA power supply to the + - terminals (observe the correct polarity). As the power supply
unit you can use:
a) LT-089.06 Jablotron.
b) DE06-12 Jablotron.
7. Switch on the power supply.
8. Use the UPŸand DOWNźcontrol keys to set the operational mode of the thermostat and the required
parameters
(see par. 4, Mode selection, Parameter setting).
9. You can reduce the illumination intensity of the display by connecting the LOW INTENSITY jumper
on the thermometer board.
10. Reinsert the top part of the thermometer into the frame.
Figure 2: Bottom housing Figure 3: Description of the terminals and boards
2. Installation of the sensors
Install the CP-201T temperature sensors (not included in the delivery) in the place to be measured (e.g. accumulation tank,
hot water reservoir etc.). Always ensure sufficient thermal contact (we recommend you to use a commonly available heat-
conductive paste). If no pockets are available, attach the sensors to the pipeline using tying tapes with sufficient strength
and insulate the sensors to prevent the ambient temperature from biasing the measurement (you are not recommended

TM-201A multi-functional electronic thermometer, - 2 - MNU51203
to use thin cable ties – they get loose with increasing temperatures and the sensor loses contact with the pipe; using metallic
tapes or collars is preferred).
Caution - the insulation of the supply cables of the sensors is resistant to a max. of 105 °C. The supply cables of the
sensors can be extended with the use of a common cable with copper conductors with a cross-section of at least 0.35 mm2
(the total length of the supply cable of a sensor should not exceed 30m).
3. Front panel indicators
Figure 4: display description: 1 - LED 1 (indicates status of the T1 sensor); 2 - LED 2 (indicates status of the T2 sensor);
3 - LED 3 (warning / closing / opening in the negative logic setting / relay); 4 – Display
4. Mode selection, Parameter setting
The TM-201A thermometer can be used in one of the preset modes (F1 – F5). The selected mode appears on the display
for 3 seconds after connection of the power supply. The F1 operation mode and the values highlighted with bold type
are set as default (in the mode tables see the Default columns).
In the standby condition the TM-201A thermometer shows the temperature measured by the connected sensors
(or “--.-“ if no sensors are connected). If not, briefly disconnect and reconnect the power supply.
At the terminal-board side the thermometer is equipped with two keys that are used to set the operational modes
and parameters. The keys are identified with the Ÿ(UP)and ź(DOWN) symbols. By pressing a key you make a selection
and browse the settings; simultaneous pressing of both the keys is used to enter the setting mode and to confirm
a selection. There is a functional delay during the parameter setting mode; if no key is pressed for a minute, the setting
mode will be terminated, incl. saving all the parameters.
Selecting and setting an operational mode (F1 – F5)
To set an operation mode, follow the points below:
1) Press and hold both the keys ŸDQGź for 6 seconds.
2) A short beep will sound and the current operational mode will start flashing on the display (F1 in the default
setting).
3) Press the
Ÿor źkeys briefly to select the required operational mode (F1 – F5).
4) Confirm the mode by simultaneously pressing the ŸDQGź keys for a short time (for less than 2 seconds).
5) Saving the selected operational mode is indicated by its flashing (for approx. 3 seconds) and a continuous
acoustic signal (for approx. 2 seconds).
6) Now, the first parameter of the selected operational mode is displayed (the P2.1 parameter in the F2 mode,
the P3.1 parameter in the F3 mode etc.) To set the parameters, follow the procedure below.
Figure 5. Example of setting the F3 mode after activation of the thermometer
F1 F2 F3 F4 F5 rES End
Thermometer
with warning
indication
(1 or 2
sensors)
Heating
thermostat
(1 sensor)
Cooling
thermostat
(1 sensor)
Bistable
thermostat
(2 sensors)
Differential
thermostat
(2 sensors)
Restoration
of the
default
settings
End
without
changing the
mode

JABLOTRON ALARMS a.s. Pod Skalkou 4567/33 46601 Jablonec n. Nisou
Czech Republic www.jablotron.com
||
|
TM-201A multi-functional electronic thermometer, - 3 - MNU51203
Restoring the default settings and exiting without saving the changes
1) If you want to restore the default settings of the thermometer, browse to the rES item and simultaneously press
the ŸDQGź keys to confirm it.
2) You can exit the setting mode without changing the mode any time by selecting and confirming the End item,
or by pressing the ŸDQGź keys simultaneously for a long time (6 seconds).
Selecting and setting individual parameters.
To set the parameters of an operational mode, follow the points below:
1) Briefly press the Ÿor źkey.
2) A short beep will sound and the first parameter of the operational mode will appear on the display
(the P2.1 parameter in the F2 mode etc.).
3) Use the Ÿor źkeys to select the parameter you want to set.
4) Press the Ÿand źkeys simultaneously to enter the parameter setting mode. A short beep will sound
and the currently set value will start flashing. Briefly press (or hold) the Ÿor źkey to set the required
parameter value.
5) Briefly press the Ÿand źkeys simultaneously to confirm the parameter setting. Saving is confirmed
by a short beep and displaying the number of the set parameter.
6) Repeat points 3 - 5 to set the other parameters of the particular mode.
7) Exit the setting mode by selecting and confirming the End item. You can also exit the setting mode any time
by allowing a time-out or by simultaneously pressing the Ÿand źkeys for a long time. After the termination
of the setting mode the TM-201A thermometer will return to the standby condition.
Figure 6. Example of setting the P2.3 parameter after activation of the thermometer and with the F2 operation mode selected
4.1. F1 mode – Thermometer with warning indication
A protective thermometer with a warning indication and relay switching, and protection from overheating or freezing.
Parameter Description Range Default
P1.1 Lower limit - a temperature drop below this limit switches the relay and
warning indication. The hysteresis for relay opening is 3 °C.
-20 °C to +105 °C 5 °C
P1.2 Upper limit - a temperature increase above this limit switches the relay
and warning indication. The hysteresis for relay opening is 3 °C.
-20 °C to +105 °C 90 °C
P1.3 Siren - activation/deactivation of acoustic indication. ON / OFF ON
P1.4 T2 sensor - temperature sensor connected to the T2 terminals. ON / OFF ON
P1.5 LED 3 indication – indicates closing (opening in the negative logic) of
the relay.
ON / OFF ON
P1.6 Negative relay logic - reversed logic of the relay function (permanently
closed in the standby condition).
ON / OFF OFF
P1.7 Minimum relay closing time - used to limit too frequent switching on
and off of the connected device. If this parameter is active, the relay will
be closed for at least this time period, regardless of the measured
temperature.
OFF, 1 to 15 min OFF
P1.8 Minimum pause time - used to limit too frequent switching on and off of
the connected device. If this parameter is active, the relay will only be
closed after expiration of this minimum pause period. It is considered
from the last closing of the relay, it is not applied at the first activation of
the thermometer.
OFF, 1 to 15 min OFF
End Exiting the setting mode

TM-201A multi-functional electronic thermometer, - 4 - MNU51203
Example of using the F1 mode
The thermometer only contains one relay; therefore,
only use the relay switching in the F1 mode for monitoring
of the minimum (P1.1) or maximum temperature (P1.2).
The relay will be closed if the temperature drops below
the minimum value or if it exceeds the maximum value.
The closing of the relay can activate remote notification
of the user via an external device. It may also
be accompanied by an acoustic indication (P1.3).
Only one T1 sensor or both the T1 and T2 sensors
can be used (P1.4). If both the sensors are used, the set limit
is monitored by both the sensors (T1 and T2).
4.2. F2 mode – Thermostat (heating)
Parameter Description Range Default
P2.1 Heating temperature - the required temperature of the heating (T1 sensor) -20 °C to +105 °C 25 °C
P2.2 Hysteresis – the temperature drop for heating reactivation. 0.1 °C to 10 °C 1 °C
P2.3 LED 3 indication – indicates closing (opening in the negative logic) of the
relay.
ON / OFF ON
P2.4 Negative relay logic - reversed logic of the relay function (permanently
closed in the standby condition).
ON / OFF OFF
P2.5 Minimum relay closing time - used to limit too frequent switching on and off
of the connected device. Parameter description, see P1.7.
OFF, 1 to 15 min OFF
P2.6 Minimum pause time - used to limit too frequent switching on and off of the
connected device. Parameter description, see P1.8.
OFF, 1 to 15 min OFF
End Exiting the setting mode
4.3. F3 mode – Thermostat (cooling)
Parameter Description Range Default
P3.1 Cooling temperature - the required temperature of the cooling (T1 sensor) -20 °C to +105 °C 20 °C
P3.2 Hysteresis – the temperature increase for cooling reactivation. 0.1 °C to 10 °C 1 °C
P3.3 LED 3 indication – indicates closing (opening in the negative logic) of the
relay.
ON / OFF ON
P3.4 Negative relay logic - reversed logic of the relay function (permanently
closed in the standby condition).
ON / OFF OFF
P3.5 Minimum relay closing time - used to limit too frequent switching on and off
of the connected device. Parameter description, see P1.7.
OFF, 1 to 15 min OFF
P3.6 Minimum pause time - used to limit too frequent switching on and off of the
connected device. Parameter description, see P1.8.
OFF, 1 to 15 min OFF
End Exiting the setting mode
4.4. F4 mode – Bistable thermostat
In this mode the thermostat can be typically used to control preferential heating from an accumulation tank.
Parameter Description Range Default
P4.1 Relay closing temperature by T1 - The T1 sensor is always used to close
the relay that is closed when the set temperature is exceeded.
-20 °C to +105 °C 65 °C
P4.2 Relay opening temperature by T2 - The T2 sensor is always used to open
the relay that is opened when the temperature drops below the set value.
-20 °C to +105 °C 35 °C

JABLOTRON ALARMS a.s. Pod Skalkou 4567/33 46601 Jablonec n. Nisou
Czech Republic www.jablotron.com
||
|
TM-201A multi-functional electronic thermometer, - 5 - MNU51203
P4.3 LED 3 indication – indicates closing (opening in the negative logic) of the
relay.
ON / OFF ON
P4.4 Negative relay logic - reversed logic of the relay function (permanently
closed in the standby condition).
ON / OFF OFF
P4.5 Minimum relay closing time - used to limit too frequent switching on and off
of the connected device. Parameter description, see P1.7.
OFF, 1 to 15 min OFF
P4.6 Minimum pause time - used to limit too frequent switching on and off of the
connected device. Parameter description, see P1.8.
OFF, 1 to 15 min OFF
End Exiting the setting mode
If an installation requires it, the value of the P4.2 parameter can be higher than that of P4.1.
If both the values (T1 and T2) are achieved, the relay will remain closed (T1 takes priority).
Example of using the F4 mode
The thermometer monitors the priority of the accumulation
tank
- T1 for closing (P4.1) – the tank takes priority
- T2 for opening (P4.2) – the boiler takes priority
The relay is closed when the set temperature is achieved
at the T1 sensor and it is opened on cooling at the T2
sensor.
Auxiliary relay(s) can be used not only to switch a valve
(hydraulic switch), but also to block or switch a gas (electric)
boiler.
The relay logic can be reversed (P4.4) depending of the
type of the valve used (normally closed/open).
4.5. Mode F5 – Differential thermostat
Parameter Description Range Default
P5.1 Closing difference - determines the temperature difference of the T1 –
T2 sensors to close the relay.
1 °C to 30 °C 10 °C
P5.2 Opening difference - determines the temperature difference of the T1 –
T2 sensors to open the relay.
1 °C to 30 °C 3 °C
P5.3 Minimum T1 sensor temperature – determines the temperature at the
T1 sensor at which the relay will be closed if the switching difference
condition of P5.1 is met at the same time.
-20 °C to +105 °C 30 °C
P5.4 Maximum T1 sensor operation temperature – if this temperature is
exceeded, the relay will be opened (protective function).
OFF/
-20 °C to +105 °C
OFF
P5.5 Maximum T2 sensor operation temperature – if this temperature is
exceeded, the relay will be opened (protective function).
OFF/
-20 °C to +105 °C
OFF
P5.6 LED 3 indication – indicates closing (opening in the negative logic) of
the relay.
ON / OFF ON
P5.7 Negative relay logic - reversed logic of the relay function (permanently
closed in the standby condition).
ON / OFF OFF
P5.8 Minimum relay closing time - used to limit too frequent switching on
and off of the connected device. Parameter description, see P1.7.
OFF, 1 to 15 min OFF
P5.9 Minimum pause time - used to limit too frequent switching on and off of
the connected device. Parameter description, see P1.8.
OFF, 1 to 15 min OFF
End Exiting the setting mode
The actual possible range of the differences depends on the settings of the limits. Example: If the closing difference is set
to 15°C, the setting range of the opening difference will be 1 °C – 14 °C.

TM-201A multi-functional electronic thermometer, - 6 - MNU51203
Example of using the F5 mode
The thermometer monitors charging of the hot water
reservoir (e.g. in a circuit with a solid fuel boiler)
The relay will be closed if the T1 temperature
of the heating water is higher than the T2 temperature
in the reservoir by the required number of degrees
(P5.1, switching difference).
The relay will be opened if the difference of the T1 – T2
temperatures decreases to the set value (P5.2, opening
difference), or if the maximum set hot water temperature
in the reservoir (P5.5) is achieved.
Thus, the settings of the closing and opening difference
can be used to control exceeding the heating water
temperature. You can also set the minimum T1 operation
temperature to avoid cooling the boiler during the power
increase stage (P5.3).
5. Warning indication
A missing temperature sensor that is required by the selected function is indicated by flashing of LED 3 and the respective
LED 1 or LED 2. If only one sensor can be connected in a particular mode, it must always be connected to the T1 terminal.
In the F1 mode the warning indication is active on exceeding the limit values. The acoustic indication can be deactivated
with the P1.3 parameter. If in the F1 mode no sensor is connected to the T2 terminals, the P1.4 parameter must be
set to OFF. In the F2 – F5 modes lighting of LED 3 may indicate closing/opening of the relay (if indication of the relay status
is activated by the respective parameter).
6. Technical parameters
TM-201A thermometer
Supply voltage 11 V to 17 V DC
Standby consumption/maximum consumption 20 mA/50 mA
Measuring range -40 °C to 125 °C
Temperature sensor type NTC 10 k:, B25/100 = 3455 K
Operating temperature range -10 °C to +40 °C
Seasonal space heating energy efficiency ڦS= 1 % (acc. Regulation (EU) No. 813/2013)
Temperature control class I. (acc. Regulation (EU) No. 813/2013)
OUT output switching contact, max. 1 A/250 V, resistance load 6 A, protection class II
Acoustic/optical indication Siren/LED
Ingress protection class IP 41 (in accordance with EN 60529)
In conformity with EN 60730-1, EN 61000-6-1, EN 61000-6-3, EN 50581
Recommended temperature sensor
Type CP-201T Jablotron (NTC 10 k:, B25/100 = 3455 K)
Measuring range -25 °C to 105 °C
Sensor accuracy ± 1% at 25 °C, ± 2 °C in the range of -25 °C to 105 °C
Specifications CP-201T Manual (NW) MNC52900
JABLOTRON ALARMS a.s. hereby declares that the TM-201A is in a compliance with the relevant Union
harmonisation legislation: Directives No: 2014/35/EU, 2014/30/EU, 2009/125/ES, 2011/65/EU. The original of the
conformity assessment can be found at www.jablotron.com - Section Downloads.
Note: Although this product does not contain any harmful materials we suggest you return the product
to the dealer or directly to the producer after use.
