TECHNICAL MANUAL
INSTALLATION MANUAL FOR EXPORT UNITS
SERVICE MANUAL FOR DOMESTIC UNITS
FOR JACKSON MODELS:
JP-24
JP-24F
JP-24B
JP-24BF
An
Company
HOT WATER SANITIZING UNDERCOUNTER DISHMACHINES
March 6, 2006
P/N 7610-002-49-79 (Revision D)
Jackson MSC, Inc.
P.O. BOX 1060
HWY. 25E
BARBOURVILLE, KY. 40906
FAX [phone]
PHONE [phone]
www.jacksonmsc.com

i
REVISION REVISION
DATE MADE BY APPLICABLE ECN DETAILS
A07-15-2002 MAW 6527 Release manual for service use.
B06-04-2003 MAW 6673, 6681
6637 Updated per ecns.
C02-11-2004 MAW 6836 Updated per ecns.
D03-06-2006 MAW 7421, 7231
6964, 7095
Change thermostat from 05930-121-71-29 to 05930-510-03-79.
Change thermostat from 05930-121-71-36 to 05930-011-49-43.
Change Diverter Valve Assembly number from 05700-002-23-21
to 06410-012-23-21 & Diverter Valve Assembly 05700-002-23-22
to 06401-022-23-21. Replace 04820-300-07-00 vacuum breaker
with 04820-003-06-13.

ii
NOMENCLATURE FOR THE MODELS COVERED IN THIS MANUAL
JP-24B
JP-24 = Undercounter, high temperature, hot water sanitizing, no booster tank.
JP-24F = Undercounter, high temperature, hot water sanitizing, no booster tank, with top and side panels.
JP-24B = Undercounter, high temperature, hot water sanitizing, with a booster tank.
JP-24BF = Undercounter, high temperature, hot water sanitizing, with a booster tank, with top and side panels.
Model:
Serial No.:
Installation Date:
Service Rep. Name:
Phone No.:
Jackson MSC Inc. provides technical support for all
of the dishmachines detailed in this manual. We
strongly recommend that you refer to this manual
before making a call to our technical support staff.
Please have this manual with you when you call so
that our staff can refer you, if necessary, to the prop-
er page. Technical support is available from 8:00
a.m. to 5:00 p.m. (EST), Monday through Friday.
Technical support is not available on holidays.
Contact technical support toll free at 1-888-800-
5672. Please remember that technical support is
available for service personnel only.

SECTION DESCRIPTION PAGE
I. SPECIFICATION INFORMATION
Specifications JP-24/JP-24F 2
Specifications JP-24B/JP-24BF 3
Dimensions 4
II. INSTALLATION/OPERATION INSTRUCTIONS
Installation Instructions 6
Electrical Installation Instructions 7
Operation Instructions 8
Detergent Control 9
Cycle Counter Retrofit Kit Instructions 10
III.PREVENTATIVE MAINTENANCE
Preventative Maintenance 12
IV. TROUBLESHOOTING 14
V.SERVICE PROCEDURES
Rinse Solenoid Valve Repair Parts Kit 17
Vacuum Breaker Repair Parts Kit 21
Replacing the Pump Motor/Booster Tank Heater 23
Replacing the Drain Valve 24
Rinse Regulating Thermostat Replacement 25
VI. PARTS SECTION
Gauge Panel Assembly 30
Electrical Panel Assembly (JP-24/F 208-240 Volt, 50/60Hz) 31
Electrical Panel Assembly (JP-24B/BF 208-240 Volt, 50/60Hz) 32
Electrical Panel Assembly (JP-24B/BF 460 Volt, 60Hz) 32
Gauge Panel Assembly (Used with the external mounted control panel assemblies) 34
Electrical Panel Assembly (External & AMTRAK Option) 34
Kick Plate Assembly 37
Incoming Plumbing Assembly (JP-24/JP-24F) 38
Incoming Plumbing Assemblies(JP-24B/JP-24BF) 39
Rinse Stiffener/Rinse Hub Weldment 40
Solenoid Valve Repair Kit/Vacuum Breaker Repair Kit/Water Pressure Regulator Kit (WPRK Option) 41
Drain Valve Assembly 42
Drain Plumbing Assembly 43
Wash Motor to Wash Tub Assembly 44
Rinse Tank & Components/Wash Heater Kit 45
Door Assembly 46
Miscellaneous Door Sub-Assemblies 47
Rinse Arm & Wash Arm Assemblies 48
Frame, Shroud, & Panel Components/Miscellaneous Parts 49
Cycle Counter Retrofit Kit 50
VII. SCHEMATICS
JP-24/JP-24F 208/230 V, 50/60 HZ, single phase 52
JP-24B/JP-24BF 208/230 V, 50/60 HZ, single phase 53
JP-24B/JP-24BF 460 V, 60 HZ, three phase 54
JP-24 Technical Manual 7610-002-49-79 Rev. D
Issued: 03-06-2006 Revised: N/A
TABLE OF CONTENTS
iii

1
SECTION 1:
SPECIFICATION INFORMATION

JP-24 Technical Manual 7610-002-49-79 Rev. D
Issued: 03-06-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
SPECIFICATIONS of the JP-24/JP-24F
2
PERFORMANCE/CAPABILITIES
OPERATING CAPACITY (RACKS/HOUR)
RACKS PER HOUR 30
DISHES PER HOUR 600
GLASSES PER HOUR 600
OPERATING CYCLE (SECONDS)
WASH TIME 82
DRAIN TIME 28
RINSE TIME 10
TOTAL CYCLE TIME (MINUTES) 2
5 MINUTE TIMER OPERATING CYCLE (SECONDS)
WASH TIME 262
DRAIN TIME 28
RINSE TIME 10
TOTAL CYCLE TIME (MINUTES) 5
TANK CAPACITY (LITERS) (GALLONS)
WASH TANK (21.5) 5.65
TEMPERATURES
WASH --- (MINIMUM) (65.6°C) 150°F
RINSE --- (MINIMUM) (82.2°C) 180°F
WATER REQUIREMENTS
INLET TEMPERATURE (82.2°C) 180 °F
GALLONS PER HOUR (198.7L) 52.3
WATER LINE SIZE I.P.S. (Minimum) (1.27 cm) 1/2”
DRAIN LINE SIZE I.P.S. (Minimum) (3.81 cm) 1 1/2”
FLOW PRESSURE P.S.I. 20A5
FLOW, GALLONS PER MINUTE (27L) 7.1
ELECTRICAL REQUIREMENTS
WASH MOTOR HP 3/4
NOTE: Typical Electrical Circuit is based upon (1) 125% of the
full amperage load of the machine and (2) typical fixed-trip cir-
cuit breaker sizes as listed in the NEC 2002 Edition. Local
codes may require more stringent protection than what is dis-
played here. Always verify with your electrical service con-
tractor that your circuit protection is adequate and meets all
applicable national and local codes. These numbers are pro-
vided in this manual simply for reference and may change
without notice at any given time.
JP-24/JP-24F:
RINSE TYPICAL
HEATER TOTAL ELECTRICAL
VOLTS PH HZ RATINGS AMPS CIRCUIT
208 1 50 900KW 12 15 AMP
230 1 50 1100KW 12 15 AMP
208 1 60 900KW 10 15 AMP
230 1 60 1100KW 10 15 AMP
NOTE: Always refer to the machine data plate for specific
electrical and water requirements. The material provided on
this page is for reference only and may be subject to change
without notice.

JP-24 Technical Manual 7610-002-49-79 Rev. D
Issued: 03-06-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
SPECIFICATIONS of the JP-24B/JP-24BF
3
PERFORMANCE/CAPABILITIES
OPERATING CAPACITY (RACKS/HOUR)
RACKS PER HOUR 30
DISHES PER HOUR 600
GLASSES PER HOUR 600
OPERATING CYCLE (SECONDS)
WASH TIME 82
DRAIN TIME 28
RINSE TIME 10
TOTAL CYCLE TIME (MINUTES) 2
5 MINUTE TIMER OPERATING CYCLE (SECONDS)
WASH TIME 262
DRAIN TIME 28
RINSE TIME 10
TOTAL CYCLE TIME (MINUTES) 5
TANK CAPACITY (LITERS) (GALLONS)
WASH TANK (21.5) 5.65
RINSE TANK (11.4) 3
TEMPERATURES
WASH --- (MINIMUM) (65.6°C) 150°F
RINSE --- (MINIMUM) (82.2°C) 180°F
WATER REQUIREMENTS
INLET TEMPERATURE (40° Booster Heater) (82.2°C) 140°F
INLET TEMPERATURE (70° Booster Heater) (43.3°C) 110°F
GALLONS PER HOUR (198.7L) 52.3
WATER LINE SIZE I.P.S. (Minimum) (1.27 cm) 1/2”
DRAIN LINE SIZE I.P.S. (Minimum) (3.81 cm) 1 1/2”
FLOW PRESSURE P.S.I. 20A5
FLOW, GALLONS PER MINUTE (27L) 7.1
ELECTRICAL REQUIREMENTS
WASH MOTOR HP 3/4
NOTE: Typical Electrical Circuit is based upon (1) 125% of the
full amperage load of the machine and (2) typical fixed-trip cir-
cuit breaker sizes as listed in the NEC 2002 Edition. Local
codes may require more stringent protection than what is dis-
played here. Always verify with your electrical service con-
tractor that your circuit protection is adequate and meets all
applicable national and local codes. These numbers are pro-
vided in this manual simply for reference and may change
without notice at any given time.
RINSE TYPICAL
HEATER TOTAL ELECTRICAL
VOLTS PH HZ RATINGS AMPS CIRCUIT
208 1 50 6.7KW 40 50 AMP
230 1 50 8.2KW 43 60 AMP
208 1 50 8.2KW 47 60 AMP
230 1 50 10KW 51 70 AMP
220 1 50 9.15KW 48 60 AMP
208 1 60 6.7KW 39 50 AMP
230 1 60 8.2KW 46 60 AMP
208 1 60 8.2KW 42 60 AMP
230 1 60 10KW 50 70 AMP
460 1 60 480/8.2KW 11 15 AMP
460 1 60 480/9.6KW 14 20 AMP
NOTE: Always refer to the machine data plate for specific
electrical and water requirements. The material provided on
this page is for reference only and may be subject to change
without notice.

JP-24 Technical Manual 7610-002-49-79 Rev. D
Issued: 03-06-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
JP-24 DIMENSIONS
4
LEGEND
A - Water Inlet 1/2” ID Female Pipe Thread, 2 1/2”
AFF
B - Detergent Feeder Connection
C - Electrical Connection
D - Drain Connection Flexible Hose 6’ Free
Length,
1” ID x 1 3/8” OD
E - Rinse Additive Connection
DIMENSIONS
Height (minimum): 33 1/4” (84.5 cm) Inside Clearance Height: 14 1/2” (36.8 cm)
Height (maximum): 34 1/4” (87 cm) Inside Clearance Width: 20 1/4” (51.4 cm)
Width: 24” (60.9 cm) Inside Clearance Depth: 21 1/4” (54 cm)
Depth: 22 5/8” (57.5 cm) Door Open Depth: 39 1/2” (100.3 cm)
Wall Clearance (minimum): 2 1/2” (6.4 cm)
*All dimensions are for reference only and are subject to change without notice.
A
A
C
E
C
DE
B
24 1/4”
(61.6 cm)
22 5/8”
(57.5 cm)
16 3/4”
(42.5 cm)
DOOR OPEN
19”
(48.3 cm)
4 1/4”
(10.8 cm)
33 1/4”
(84.5 cm)
6 1/2”
(16.5 cm)
4 1/2”
(11.4 cm)
8 1/2”
(21.6 cm)
3 3/4” (9.5 cm)
2 3/4” (7 cm)
2 1/2”
(6.47 cm)
12”
(30.5 cm)
2 1/2” (6.4 cm) Min. Wall Clearance
13 1/4”
(33.7 cm)

SECTION 2:
INSTALLATION/OPERATION
INSTRUCTIONS
5
