Jacobsen Bob-cat 933011 User manual

WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
SETUP, PARTS & MAINTENANCE
MANUAL MIDSIZE CLASSIC
Operation & Safety Manual: 4130479
4130478 REV C
Models:
933011 15 HP KOHLER GEAR DRIVE-36” DECK
933012 15 HP BRIGGS & STRATTON GEAR DRIVE-36” DECK
934011 15 HP KOHLER GEAR DRIVE-48” DECK
934012 15 HP BRIGGS & STRATTON GEAR DRIVE-48” DECK

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
its constituents are known to the State
of California to cause cancer, birth
defects and other reproductive harm.
Californie Proposition 65
Avertissement
Les échappements des moteurs diesel
et certains de leurs composés sont
reconnus par l’Etat de Californie pour
être cancérigènes, provoquer des
défauts congénitaux et d’autres dangers
en matière de reproduction.
ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
California Advertencia
de la Proposicion 65
El estado de California hace saber que
los gases de escape de los motores
diesel y algunos de sus componentes
producen cáncer, defectos de
nacimiento y otros daños en el
proceso de reproducción humana.
L’ é mission du moteur de ce mat é riel
contient des produits chimiques que
l’Etat de Californie consid è re ê tre
canc é rig è nes, provoquer des d é fauts
cong é nitaux et d’autres dangers en
mati è re de reproduction.
El estado de California hace saber
que los gases de escape de este
producto contienen productos
quÍmicos que producen cáncer,
defectos de nacimiento y otros daños
en el proceso de reproducción
humana.
© 2003, TEXTRON INC

1
Midsize
Classic
8-2004
IMPORTANT MESSAGE
Thank you for purchasing this Bob-Cat product. You have purchased a world class mowing product, one of the
best designed and built anywhere.
ThismachinecomeswithanOperationandSafetyManualandaseparateSetup,PartsandMaintenanceManual.
The useful life and good service you receive from this machine depends to a large extent on how well you read
andunderstandthesemanuals.Treatyourmachineproperly,lubricateandadjustitasinstructed,anditwillgive
you many years of reliable service.
YoursafeuseofthisBob-Catproductisoneofourprimedesignobjectives. Manysafetyfeaturesarebuiltin,but
we also rely on your good sense and care to achieve accident-free operation. For best protection, study the
manuals thoroughly. Learn the proper operation of all controls. Observe all safety precautions. Follow all
instructionsandwarningscompletely. Donotremoveordefeatanysafetyfeatures. Makesurethosewhooperate
this machine are as well informed and careful in its use as you are.
Seea Bob-Catdealerforany serviceorparts needed. Bob-Catserviceensuresthat youcontinuetoreceive the
best results possible from Bob-Cat’s products. You can trust Bob-Cat replacement parts because they are
manufactured with the same high precision and quality as the original parts.
Bob-Catdesignsandbuildsitsequipmenttoservemanyyearsinasafeandproductivemanner. Forlongestlife,
usethismachineonlyasdirectedinthemanuals,keepitingoodrepairandfollowsafetywarningsandinstructions.
You'll always be glad you did. Jacobsen, a Textron Company
One Bob Cat Lane
Johnson Creek, WI 53038-0469
TABLE OF CONTENTS FIGURES PAGE
SAFETY ......................................................................................................................................................... 2
ASSEMBLY/SET-UP INSTRUCTIONS ....................................................................................................... 3-6
LUBRICATION ............................................................................................................................................... 7
MAINTENANCE ........................................................................................................................................ 8-11
SERVICE CHART ........................................................................................................................................ 12
SERVICE RECORD..................................................................................................................................... 13
ADJUSTMENTS...................................................................................................................................... 14-16
BELT REPLACEMENT .......................................................................................................................... 17, 18
PARTS SECTION ........................................................................................................................................ 19
ENGINE DECK ASSEMBLY............................... FIGURE 1 ................................................................. 20, 21
TRANSMISSION DRIVE.................................... FIGURE 2 ................................................................. 22, 23
UPPER HANDLE ASSEMBLY ........................... FIGURE 3 ................................................................. 24, 25
PEERLESS TRANSMISSION ............................ FIGURE 4 ................................................................. 26, 27
36" DECK........................................................... FIGURE 5 ................................................................. 28, 29
48" DECK........................................................... FIGURE 6 ................................................................. 30, 31
CASTER ASSEMBLY......................................... FIGURE 7 ................................................................. 32, 33
BRIGGS & STRATTON ELECTRICAL DIA........ FIGURE 8 ................................................................. 34, 35
KOHLER ELECTRICAL DIAGRAM.................... FIGURE 9 ................................................................. 36, 37
DECALS............................................................. FIGURE 10 ............................................................... 38, 39
OPTIONAL GRASSCATCHER (970319)........... FIGURE 11................................................................ 40, 41

2
Midsize
Classic
MODEL NUMBER: This number appears on
sales literature, technical manuals and price lists.
SERIAL NUMBER: This number appears only
on your mower. It contains the model number
followed consecutively by the serial number. Use
this number when ordering parts or seeking
warrantyinformation.
SAFETY
NOTICE !!!
Unauthorized modifications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Jacobsen, a Textron Company strongly warns
against, rejects and disclaims any modifications,
add-on accessories or product alterations that are
not designed, developed, tested and approved by
Jacobsen'sEngineeringDepartment. AnyJacobsen
product that is altered, modified or changed in any
manner not specifically authorized after original
manufacture–includingtheadditionof“after-market”
accessories or component parts not specifically
approved by Jacobsen–will result in the Jacobsen
Warranty being voided.
Anyandallliabilityforpersonalinjuryand/orproperty
damagecausedbyanyunauthorizedmodifications,
add-on accessories or products not approved by
Jacobsen will be considered the responsibility of
the individual(s) or company designing and/or
making such changes. Jacobsen will vigorously
pursuefullindemnificationandcostsfromanyparty
responsibleforsuchunauthorizedpost-manufacture
modifications and/or accessories should personal
injury and/or property damage result.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word definitions:
The signal words below are used to identify levels
of hazard seriousness. These words appear in this
manual and on the safety labels attached to
Jacobsenmachines. Foryoursafetyand thesafety
ofothers,readandfollowtheinformationgivenwith
thesesignalwordsand/orthesymbolshownabove.
DANGER indicates an imminently hazardous
situationwhich,if not avoided, WILL result in death
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, COULD result in
death or serious injury.
CAUTION indicates a potentially hazardous
situation which, if not avoided, MAY result in minor
or moderate injury. It may also be used to alert
against unsafe practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage.

3
Midsize
Classic
GENERAL NOTE: FRONT, REAR, RIGHT HAND AND LEFT HAND REFERENCES BELOW
ARE WITH RESPECT TO AN OPERATOR AT THE CONTROLS.
ASSEMBLY/SET-UP INSTRUCTIONS
3. Bolt the upper handle Eto the lower handle F
using (4) 3/8-16X1 bolts and (4) 3/8-16 whizlock
nuts at location G on both sides as shown.
1. UNCRATE - Discard the sides and top of the crate. Remove the loose parts from the crate. Discard the
rest of the packing material.
2. Remove all tie wraps and banding. Remove
traction control rods D, gear shift lever Aand
parts bag B. Set aside for later use. Remove
fuel tank Cfrom the cutterdeck.

4
Midsize
Classic
ASSEMBLY/SET-UP INSTRUCTIONS
5. Route the throttle cable Kacross the top left side
of the lower handle under the fuel tank C.
NOTE: Route the wiring harness on the left side,
under the tank for units with Kohler engines.
Route the wiring harness on the right side, under
the tank for units with Briggs & Stratton engines.
6. Bolt fuel tank to lower handle using
(4) 3/8-16X3/4" bolts, (4) lockwashers and (4)
flatwashers at locations L.
NOTE: Tighten all fuel tank bolts firmly but do
not overtighten or damage to the fuel tank
threads may result.
4. Attach gear shift lever A removed in Step 2 to
the lower shift arm H using (1) 5/16-18x1 bolt
and (1) 5/16-18 whizlock nut. Shift the lever to
the neutral position and verify that the lever is
centered in the slot. If not, loosen the bolt and
reposition lever. Retighten bolt.
GEARBOX ADJUSTMENT NOTE: The detents
between gears and at neutral may be made more
positive by turning set screw J clockwise. Do
not turn set screw more than two turns below
flush with the housing.

5
Midsize
Classic ASSEMBLY/SET-UP INSTRUCTIONS
7. Remove the plug from the end of the fuel line N
and connect fuel line to the fuel tank valve M
and secure with the supplied hose clamp as
shown.
8. Attach traction control rods Dby inserting the
swivel Pthrough the upper hole in the bellcranks
Qand the other end of the traction control rods
through the traction control lever Son the
handlebar. Secure with washers and hairpins.
9. To adjust traction control rods, remove the
traction control rod swivel Pand the brake rod R
from the bellcrank Qand adjust swivel up or
down the control rod so that once reinstalled
there is a 1/4" (6.35mm) gap between the
bottom of the rod and the bottom of the traction
lock with the traction lock pushed down.

6
Midsize
Classic
ASSEMBLY/SET-UP INSTRUCTIONS
10. To adjust the brakes, remove the brake rod R
from the bottom of bellcrank Qand set the
traction control lever in the neutral position.
Adjust the brake rod by turning it in or out of the
swivel Tin the brake arm until it just goes into
the hole on the bellcrank. Secure with hairpin.
NOTE: The machine should not move with the
traction control levers in the parking brake
position. If machine moves in the parking brake
position, readjust brake rod length. Verify that
machine can be moved easily when the traction
control levers are placed in the neutral position.
11. Fill engine with oil. (See engine manual for specifications.)
12. Fill fuel tank with with clean, fresh unleaded fuel.
GASOLINE IS HIGHLY FLAMMABLE!
•Fill fuel tank with good quality, clean, regular unleaded gasoline.
•Do not use hi-test fuel.
•Do not smoke.
•Do not spill fuel.
•Fill outdoors.
•Do not overfill. Fill to 1" below bottom of filler neck to allow room for expansion.
•USE A FUNNEL TO FILL GAS TANK.
13. Adjust tire pressure in drive wheels and casters to 14 psi (96 kPa).
14. Before attempting to start the mower, read and understand all sections of the Operation & Safety
manual.
NOTICE: Special setup instructions.
•Before engaging the cutterdeck, run the engine for five minutes at full RPM. This is recommended for new
engine installation to permit complete engine lubrication prior to load.
•Do not engage the cutterdeck at full throttle. Set the throttle half way between the highest and lowest
engine speed, engage the PTO switch and increase the engine speed to full before cutting.
•Do not use this machine without an approved grasscatcher, grass discharge chute or mulching plate(s)
correctly fitted.

7
Midsize
Classic LUBRICATION
MACHINE LUBRICATION
Every 50 Working Hours - Lubricate the following points with grease:
1) Caster wheel pivots (2 points)
2) Shaft Couplers (2 points)
3) Drive Wheel Bellcranks (2 points)
4) Idler pivot bearing

8
Midsize
Classic
Oil (daily)
Remove the dipstick N and check that the oil level
reaches the full mark. If necessary, top off with fresh oil.
To obtain the correct oil level, the machine must be
level. See engine manufacturer’s manual for proper oil
viscosity and grade. DO NOT OVER FILL!
AFTER THE FIRST 5 WORKING HOURS
While the engine is warm, remove the drain plug and
drain the crankcase. Replace oil filter U. Clean and
replace the plug. Fill the crankcase through the filler
hole with fresh oil to the full mark. See engine
manufacturers manuals for oil and filter change
intervals.
Cooling Fins and Air Intake screen (daily)
Ensure that the cooling fins and air intake screen W
are cleaned daily. Continued operation with a
clogged cooling system will cause severe
overheating and result in engine damage.
Air Cleaner
Dual element air cleaners have an air cleaner
element with a precleaner element. Both should be
inspected regularly and maintained.
Clean precleaner element every 25 hours (more
often under dusty conditions).
1. Pull up on air cleaner cover handle A, and rotate
toward engine.
2. Remove air cleaner cover B.
3. Carefully lift air cleaner cartridge Cand pre-
cleaner Dfrom blower housing E.
4. Wash pre-cleaner in soapy water. Squeeze dry
in a clean cloth. DO NOT OIL. Every 100 hours
(more often under very dusty or dirty conditions)
wash air filter cartridge with warm soapy water.
Rinse with screen side up allowing dirt and
debris to filter out. Leave filter to dry overnight
before reinstalling.
5. Clean base of air cleaner cartridge area carefully
to prevent debris from entering engine.
6. Place pre-cleaner and cartridge into blower
housing. Cartridge must fit securely in base.
7. Align tabs Fon cover with slots Gon blower
housing and replace cover.
8. Hook handle Aand close cover B.
MAINTENANCE
ENGINE - BRIGGS & STRATTON
The maintenance schedule detailed is for average operating conditions. Under extreme conditions (dusty,
dirty or more than 8 hrs continuous use) maintain more frequently.

9
Midsize
Classic MAINTENANCE
Oil (daily)
Remove the dipstick Nand check that the oil level
reaches the full mark. If necessary, top off with fresh oil.
To obtain the correct oil level, the machine must be
level. See engine manufacturer’s manual for proper oil
viscosity and grade. DO NOT OVER FILL!
AFTER THE FIRST 5 WORKING HOURS
While the engine is warm, remove the drain plug Tand
drain the crankcase. Replace oil filter U. Clean and
replace the plug. Fill the crankcase through the filler
hole with fresh oil to the full mark. See engine
manufacturers manuals for oil and filter change
intervals.
Cooling Fins and Air Intake screen (daily)
Ensure that the cooling fins and air intake screen W
are cleaned daily. Continued operation with a
clogged cooling system will cause severe
overheating and result in engine damage.
Air Cleaner
Dual element air cleaners have a paper air cleaner
element with an oiled, foam precleaner element on
the dirty side of the paper element. Both should be
inspected regularly and maintained.
Clean and re-oil precleaner element every 25 hours
(more often under dusty conditions).
1. Disassemble air cleaner cover.
2. Remove precleaner by sliding it off the paper
cartridge.
3. Wash precleaner in kerosene or liquid detergent
and water.
4. Wrap precleaner in cloth and squeeze to remove
cleaner.
5. Saturate precleaner in engine oil. Squeeze to
remove excess oil.
6. Re-install precleaner over paper cartridge.
Reassemble air cleaner components and screw
assembly down tight.
Every 100 hours (more often under very dusty or
dirty conditions), check the paper cartridge.
– Clean by tapping gently.
– Do not wash the cartridge or use compressed air
– Replace when cartridge is dirty, bent or
damaged.
ENGINE - KOHLER
The maintenance schedule detailed is for average operating conditions. Under extreme conditions (dusty,
dirty or more than 8 hrs continuous use) maintain more frequently.

10
Midsize
Classic
MAINTENANCE
GEARBOX
Check every 500 hours to ensure proper lubrication.
12 oz. is capacity of gearbox.
To check level:
Remove top cover V, 12 oz. of grease will fill 1/3-1/2
of the bottom 1/2 of gearbox. Only add Bentonite
grease-available from your Peerless dealer.
INLINE FUEL FILTER
When required, the fuel filter Xmay be replaced.
See the Parts Section for service part numbers.
SPARK PLUG
•Remove plug and check condition.
•Good operating conditions are indicated if the plug has a light grey or tan deposit. A white blistered
coating may indicate overheating. A black coating usually means an “over rich” fuel mixture caused by
a clogged air cleaner or improper carburetor adjustment. Do not sandblast, wire brush or otherwise try
to clean a dirty plug. Best results are obtained with a new plug.
•See engine manufacturers manual for proper spark plug gap.

11
Midsize
Classic MAINTENANCE
BLADE SHARPENING
Blades may be sharpened by filing or grinding, but with either method the balance of the blades must be
maintained at 5/8 oz/in or less. Failure to maintain balance causes excess vibration, wear and shortened life
of not only the blades, but most all components of the machine. To balance a blade after sharpening: attach
1/8 oz of weight 5" from center on the light end. This should make the light end the heavy end. If it does not:
file or grind the heavy end until the addition of weight makes the light end the heavy end.
Cutterdeck Pulley Assembly
NOTE:
•Do not overheat or weaken the blades.
•Do not straighten bent blades. Replace with new
Bob-Cat blades.
If lift portion of blade is worn thin replace with a
new Bob-Cat blade.
•ALWAYS replace with Bob-Cat blades—do not
use another manufacturer’s blades as this could
be dangerous.
•Replace cracked or bent blades.
BLADE REMOVAL
1. Use a box wrench or socket with a long breaker
bar to remove spindle bolt under cutterdeck.
2. Slip tube over breaker bar or wrench if
necessary to gain leverage.
3. Keep hands clear as blades may rotate when
bolt releases.
4. When changing blades, wear thickly padded
gloves.
5. Block blades from turning by using a piece of
wood.
6. Follow these instructions to prevent injury when
bolt releases.
NOTE: To prevent blade from turning, place block
of wood at location A, with grain perpendicular to
blade.
BLADE RE-INSTALLATION
1. Place the desired number of spacers (no more
than 2) on the spindle bolt below the cutterdeck
between the blade and spindle shaft.
2. Insert the cutter spindle bolt (from bottom)
complete with washer, blade and spacers.
3. Place remaining spacer(s) on the spindle bolt
above the cutterdeck between the conical
washer and nut (as shown). Replace nut and
tighten to 70 ft-lbs.

12
Midsize
Classic
SERVICE CHART
NOTE: CHANGE ENGINE OIL AND FILTER AFTER FIRST 5 HOURS OF
OPERATION.
Consult the manufacturer’s manual for your engine
for further information and instructions.
ECIVRES
NOITAREPO
5TSRIF
SRUOH YLIAD
YREVE
52
SRUOH
YREVE
05
SRUOH
YREVE
001
SRUOH
YREVE
005
SRUOH
ENIGNE
leveLliOkcehCX
riA&liOrofkcehC
skaeL X
ekatnIriAnaelCX
renaelCriAnaelCX
*retliF&liOegnahCX *LAUNAMS'RERUTCAFUNAMENIGNEEES
retliFleuFkcehCX
tsujdA/ecalpeR
gulPkrapS LAUNAMS'RERUTCAFUNAMENIGNEEES
XOBRAEG
leveLliOkcehC X
ENIHCAM
eriTkcehC
serusserP X
snoisneTtleBkcehC RH2/1TSRIFRETFAKCEHC
SRH4TSRIFRETFADNA X
stnioPllAetacirbuLX

13
Midsize
Classic SERVICE RECORD
NOTES
_______________________________________________________________
____________________________________________________
________________________________________________________________________
_______________________________________________________________
____________________________________________________________
____________________________________________________
________________________________________________________________________
_______________________________________________________________
____________________________________________________________
_______________________________________________________________
____________________________________________________________
_______________________________________________________________
_______________________________________________________________
LARENEG ETAD SRH ETAD SRH ETAD SRH ETAD SRH ETAD SRH ETAD SRH
serusserperitkcehC
stniopllaetacirbuL
stlob&stunkcehC
ENIGNE
levelliokcehC
lioegnahC
naelC tnemelerenaelcria
snifgniloocnaelC
ecalpeR tnemelerenaelcria
pag&naelC sgulpkraps
.sretlifdnalioenigneecalpernoitarepofosruoh5tsrifretfA:ETON

14
Midsize
Classic
ADJUSTMENTS
Make all adjustments with the engine shut off, spark
plug wire disconnected and mower drive disen-
gaged.
OPERATOR PRESENT CONTROL LEVERS
The operator present (OP) control levers should be
adjusted to control the operation of the plunger of
the operator present switch B(located under the
right side of the control panel). Depressing OP
control levers Ashould depress the plunger;
releasing the levers should extend it.
TO ADJUST:
1. Loosen clamp bolts Con both ends so clamps
can rotate on shaft.
2. Rotate actuator lever to depress switch plunger.
Keep OP control levers against handles and
tighten bolts C.
3. When released, the OP control levers Ashould
rise and the actuator lever should rotate away
from the switch, allowing the switch plunger to
extend completely.
TRACTION RODS AND WHEEL BELT TENSION
There should be a 1/4" minimum gap between the
traction control rod and the bottom of the neutral
latch slot when the drive is engaged and the traction
lock is pushed down. If there is no gap the rod will
hold the wheel belt idler up and the belt may slip.
Too much gap makes it difficult to get adequate
braking and free-wheeling neutral when traction
locks are in the neutral position. The gap may be
increased from 1/4" as long as the machine will free
wheel in neutral. Increasing the gap reduces the
reach to the traction lever.
TO ADJUST:
1. Disconnect the brake rod R.
2. Remove hairpin cotter from the swivel Pon the
traction control rod D.
3. Lift out the rod and turn the swivel in or out to
move it in the required direction.
4. Refit the swivel to the idler bellcrank Qand
replace the hairpin cotter.
5. Check the gap. If it is still not 1/4", repeat the
procedure until an approximate 1/4" gap is
obtained.
6. Reconnect the brake rod.

15
Midsize
Classic ADJUSTMENTS
TRACTION BRAKES/PARKING BRAKES
With the traction control rods properly adjusted,
apply both parking brakes and try to push the
machine forward. If one or both wheels rotate,
adjust the corresponding brake(s).
TO ADJUST:
1. Remove the hairpin cotter Wfrom the brake rod
Ron idler bellcrank Q.
2. Slide the brake rod out of the bellcrank and turn
the rod in or out of brake end swivel Sas
needed.
3. Reassemble the brake rod to the bellcrank.
4. Check the adjustment. DO NOT OVER ADJUST.
If necessary, repeat the procedure until the
correct adjustment is achieved.
5. If adequate adjustment can not be achieved with
the brake rod, the links Ubetween the brake arm
Tand brake band may be moved to a different
hole in the brake arm.
6. Adjust belt guide Vto remove any sag in the
drive belt between the drive pulley and the wheel
pulley.
When the brakes are properly adjusted the machine
can be freely manuevered with the traction control
levers in the neutral position. If not, the brakes have
been over-adjusted and have to be backed off.
NOTE: Clean inner groove of wheel drive pulley
daily for better drive and neutral. Accumulation of
grass, mud or other debris in pulley groove can
affect declutching. Set mud scraper Zat each wheel
drive pulley to angle down to catch debris.
UPPER HANDLE HEIGHT ADJUSTMENT
To adjust upper handle height: Remove the traction
control rods. Remove bolts Gand loosen bolts Eon
each side of the lower handle. Raise or lower as
required. Reposition upper handle and reinsert bolts
Ginto appropriate hole in lower handle and tighten.
Readjust traction control rods, brakes and parking
brakes.

16
Midsize
Classic
ADJUSTMENTS
DRIVE BELT TENSION ADJUSTMENT
Drive belt tension can be adjusted to one of three
settings to account for various mowing conditions.
1. Adjust by moving the spring anchor bolt to
position 1, 2 or 3.
•Position 1 will provide the least amount of
hand effort and wheel traction.
•Position 3 will provide the highest amount of
hand effort and wheel traction.
TIRE PRESSURE ADJUSTMENT
Tire pressures should be maintained at 14 psi (96 kPa).
NOTE:Adjusting tire pressure between 10 psi (69 kPa) and 28 psi (193 kPa) can improve tracking.
Increase pressure on the side the machine tracks toward and decrease it on the other side.

17
Midsize
Classic BELT REPLACEMENT
36" CUTTERDECK PTO BELT
1. Rotate idler arm Acounterclockwise using a 3/8"
ratchet or breaker bar and remove belt.
2. Install belt as shown.
48" CUTTERDECK PTO BELT
1. Rotate idler arm Bcounterclockwise using a 3/8"
ratchet or breaker bar and remove belt.
2. Install belt as shown.

18
Midsize
Classic
BELT REPLACEMENT
GEARBOX-DRIVE BELT
1. Loosen nut on carriage bolt A.
2. Slide idler pulley Baway from belt.
3. Unbolt clutch stop pin C.
4. Remove PTO belt.
5. Remove gearbox drive belt.
6. Replace by following steps in reverse order.
NOTE: Push idler pulley B toward gearbox drive
belt until gearbox drive belt is snug.
WHEEL-DRIVE BELT
Remove brake rod Rand tracton control rod Dfrom
bellcrank Q. Remove bottom bolt Cand spacer from
fender Yand loosen the bolt Ethat holds bellcrank.
Rotate bellcrank and idler up and out of the way.
The wheel drive belt will be slack enough to be
removed from its pulleys and passed over the drive
wheel. Replace in the reverse order, readjust
traction control rod and brake rod. (Also see Traction
Rods and Wheel Belt Tension in ADJUSTMENTS
section.)
