Jacuzzi Sabella EH90 User manual

sabella® whirlpool bath
sabella®. dissect the name and you discover beauty—“bella,” the Italian word for beautiful.
Consider the look, and you know that
this clean lined splendor makes a classic
companion to your contemporary interior.
In any décor, the Sabella®is a deep-welled
refuge of profound relaxation.
features:
• 4 fully adjustable PowerPro® jets
• 4 spinning neck jets
• 2 directionally adjustable AccuPro™ foot jets
• Handrails (purchased separately)
• RapidHeat™ inline heater
• Wave Pulse™ system
• Water level sensor
• Multi-speed motor
• 256 color Chromatherapy lighting system
• All-in-one electronic control panel
• Sculpted armrest
• PrO
3
™
Ozone Sanitation System standard
sabella®whirlpool bath
model number: EH90
exterior dimensions:
72" long x 47" wide x 23¾" high
interior dimensions:
44" long x 26" wide
# of Jets/type of Jets:
4 PowerPro®Jets,
4 AccuPro™ Rotating Neck Jets,
2 AccuPro™ Foot Jets
operating gallons:
98 gallons
Detail: The Sabella® whirlpool’s gentle curves embrace a
relaxing body. Handrails make for safe entry and exit.
(Handrails are a must-buy accessory and are not included.)

Sabella™ Whirlpool Bath
Model: EH90
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Ordering Information
Product Code:
EH90Sabella™ Whirlpool Bath
Right Hand
• Center Drain Location
• Accessories / Hardware:
Trim Kit: 4 HTA Jet Rings #M952
Rotary Drain Kit, 30” Cable #K606
Trim Kit: 2 BMH Jet Rings #J869
Oval Trim Kit #N557
2 X Trim Kit: 2 Neck Jet Rings #P556
Panel Overlays #P205
Hand Rails (Must Buy) #D461
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Technical Specifications
Dimensions
72” L x 47” W x 23-3/4” H
(1829 mm) L x (1194 mm) W x (603 mm) H
Drain/Overflow
A: 20 “ (508 mm) B: 14 “ (356 mm)
Cutout
Template Provided Part Number #P187000
Total Weight
1199 lb (544 kg) / 51 lb/sq. ft. (249 kg/m2)
Operating Gallonage
98 U.S. Gal. (371 Liters)
Product Weight
133 lb (60 kg)
Skirt Mounting
Not Available
Electrical Specifications
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 20 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
Heater (Standard)
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
† Add 1/4” to this dimension when roughing-in for 3-wall niche.
72"
10-1/4" 36"
3"
1"
3"
3"
1"
7"
47"
13-3/4"
18" x 4"
Heater
Motor
Opt. Service
Access
12" H x 18" L Service Access
© Jacuzzi Whirlpool Bath • 14801 Quorum Drive • Dallas • Texas • 75254 • www.jacuzzi.com
SABELLA
L
H
(51 mm)2"
(25 mm)
1"
W
SIDE VIEW END VIEW
(Heater)
(Motor)
MAX. 1/2"**
#FS12 12/06
DRAIN/OVERFLOW
A
B
Product Shown: Sabella™ Whirlpool Bath Right Hand Shown Model: EH90
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
