Jacuzzi MAJORA 6 User manual

majora® 6 whirlpool bath and soaking bath
this is majora®—“large” to the spanish-speaking. also a whirlpool bath of immense quality—a truly grand experience.
The Majora®offers a deep, oval well with
six jets for larger than life restoration,
muscle therapy and invigoration.
features:
• 4 fully adjustable TheraPro™ jets
• 2 directionally adjustable AccuPro™ jets
• Sculpted armrest and backrest
• Integral handrails
• Built-in tile flange and integral skirt with access
panels on skirted models
• Electronic on/off controls
• Drain included on whirlpool baths
majora®6
whirlpool bath
model number: H544 – RH, H543 – LH
exterior dimensions:
72" long x 42" wide x 19¾" high
interior dimensions (at bottom):
45" long x 27" wide
# of Jets/type of Jets:
4 TheraPro™ Jets,
2 AccuPro™ Lumbar Jets
operating gallons:
70 gallons
majora®6
soaking bath
model number: H545
exterior dimensions:
72" long x 42" wide x 19¾" high
interior dimensions (at bottom):
45" long x 27" wide

Majora® 6 Whirlpool Bath
Model: H543, H544
Majora® 6 Bath
Model: H545
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Electrical Components and Electrical Specifications do not apply to non-jetted baths.
Ordering Information
Product Code:
H544 Majora® 6 Whirlpool Bath
Right Hand
H543 Majora® 6 Whirlpool Bath
Left Hand
H545 Majora® 6 Bath
• Right and Left Hand Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
HTC Jet Trim Kit: #D095
BMH Jet Trim Kit: #J869
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Technical Specifications
Dimensions
72” L x 42” W x 19-3/4” H
(1829 mm) L x (1067 mm) W x (502 mm) H
Drain/Overflow
A: 15-5/8” (397 mm) B: 10-1/2” (267 mm)
Cutout
70” x 40”
Total Weight
H543, H544: 937 lb (425 kg) / 45 lb/sq. ft. (218 kg/m2)
H545: 913 lb (414 kg) / 44 lb/sq. ft. (212 kg/m2)
Operating Gallonage
70 U.S. Gal. (265 Liters)
Product Weight
H543, H544: 104 lb (47 kg)
H545: 80 lb (36 kg)
Skirt Mounting
Not Available
Electrical Specifications Models H543, H544 only
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
Heater (Optional) Models H543, H544 only
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
42"
72"
12" x 4"*
21"
2"
10-1/2"
Motor
12" H x 18" L Service Access
Opt. Service Access
4-3/8"
© Jacuzzi Whirlpool Bath • 14801 Quorum Drive • Dallas • Texas • 75254 • www.jacuzzi.com
END VIEW
H
W
SIDE VIEW
L
2"
#FR66 12/06
DRAIN/OVERFLOW
A
B
Product Shown: Majora® 6 Whirlpool Bath Left Hand Model: H543
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
