Jacuzzi Tara Whirlpool Bath and Soaking Bath B950 User manual

tara™ whirlpool bath and soaking bath
like the fabled Irish tower of kings that shares its name, the tara™ whirlpool bath is itself a singularly regal experience in an everyday world.
Cozy up to the Tara™ whirlpool bath’s
corner configuration and linger as you
massage away the cares of the day.
whirlpool bath features:
• 4 Fully adjustable TheraPro™ jets
• 2 Directionally adjustable AccuPro™ lumbar jets.
• 1 Directionally adjustable AccuPro™ foot jet.
• Exclusive Tru-Level™ base system.
• Slip-resistant bottom.
• Patented Silent Air™ Induction system.
• Available with built-in tile flange and integral
skirt with access panels
• Drain included on whirlpool baths
tara™ whirlpool bath
model number: 8450 RH Pump,
B950 LH Pump
exterior dimensions:
60" long x 60" wide x 20¾" high
interior dimensions (at bottom):
45" long x 40" wide
# of Jets/type of Jets:
4 TheraPro™ Jets,
2 AccuPro™ Lumbar Jets,
1 AccuPro™ Foot Jet
operating gallons:
74 gallons
Detail: The Tara™ whirlpool bath places Jacuzzi‘s
patented jets right in reach. Perfectly positioned
AccuPro™ jets massage away cares as you
recline against Tara‘s backrest.
tara™ soaking bath
model number: 9191
exterior dimensions:
60" long x 60" wide x 20¾" high
interior dimensions:
45" long x 40" wide

Tara™ Whirlpool Bath
Model: B950, 8450
Tara™ Bath
Model: 9191
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Electrical Components and Electrical Specifications do not apply to non-jetted baths.
Ordering Information
Product Code:
9191 Tara™ Bath
8450 Tara™ Whirlpool Bath
Right Hand
B950 Tara™ Whirlpool Bath Left Hand
• Center Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Trip Kit, 26” Cable: #8730
TheraPro™ Jet Rings Kit: #D095
AccuPro™ Jet Rings Kit (2 required): #P556
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Technical Specifications
Dimensions
60” L x 60” L x 20-3/4” H
(1524 mm) L x (1524 mm) L x (527 mm) H
Drain/Overflow
A: 16” (406 mm) B: 12-3/8” (314 mm)
Cutout
See Illustration Below
Total Weight
B950, 8450: 984 lb (446 kg) / 39 lb/sq. ft. (192 kg/m2)
9191: 942 lb (427 kg) / 38 lb/sq. ft. (184 kg/m2)
Operating Gallonage
74 U.S. Gal. (280 Liters)
Max. 87 U.S. Gal. (329 Liters)
Product Weight
B950, 8450: 118 lb (54 kg)
9191: 76 lb (34kg)
Skirt Mounting
Optional
Electrical Specifications Models B950, 8450 only
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
Heater (Optional) Models B950, 8450 only
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
- 2" x 4" Stud
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
Motor
Service
Access
Opt.
Service
Access
© Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino • CA • 91710 • www.jacuzzi.com
H
L
2"
SIDE VIEW END VIEW
#FS26 06/07
Product Shown: Tara™ Corner Whirlpool Bath Model: 8450
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
DRAIN/OVERFLOW
A
B
25-1/2"
(648 mm)
58"
(1473 mm)
45-9/16"
(1157 mm)
58"
(1473 mm)
25-1/2"
(648 mm)
TARA CORNER CUTOUT
Right & Left Hand
Drain
59"
Ref.
