Jacuzzi Riva 6 User manual

Riva®6
SOAKING BATH
MODEL NUMBER:
B685
EXTERIOR DIMENSIONS:
72" long x 42" wide x
20½" high
INTERIOR DIMENSIONS:
50" long x 28" wide
Riva®6
WHIRLPOOL BATH
MODEL NUMBER:
N274 – Right-hand
B690 – Left-hand
EXTERIOR DIMENSIONS:
72" long x 42" wide x
20½" high
INTERIOR DIMENSIONS:
50" long x 28" wide
# OF JETS/TYPE OF JETS:
4 TheraPro™ Jets
3 AccuPro™ Lumbar Jets
OPERATING GALLONS:
62 gallons
Evoking the breathtaking beauty and ancient maritime
tradition of the northern Italian town for which it is
named, the Riva®is true to form—an elegant classic. And
truly versatile—at home in both traditional and more
contemporary interior design.
WHIRLPOOL BATH FEATURES:
• Sculpted armrest.
• Contoured backrest.
• 4 Fully adjustable TheraPro™ jets
• 3 Directionally adjustable AccuPro™ lumbar jets.
• Exclusive Tru-Level™ base system.
• Slip-resistant bottom.
• Patented Silent Air™ Induction system.
• Drain included on whirlpool baths
Riva®6 |WHIRLPOOL BATH and SOAKING BATH
Detail: The Jacuzzi Magic Touch®control system makes customizing your
bath in the Riva®whirlpool bath easy. 4 massaging TheraPro™ jets
soothe sore, tired muscles.

Riva®6
WHIRLPOOL BATH
Technical Specifications
DIMENSIONS
72” L x 42” W x 20-1/2” H
(1829 mm) L x (1067 mm) W x (521 mm) H
DRAIN/OVERFLOW
A: 16” (406 mm) B: 11-1/2” (292 mm)
CUTOUT
Template Provided Part Number: P186000
TOTAL WEIGHT
B690, N274: 871 lb (395 kg) / 42 lb/sq. ft. (203 kg/m2)
B685: 840 lb (381 kg) / 40 lb/sq. ft. (195 kg/m2)
OPERATING GALLONAGE
62 U.S. Gal. (235 Liters)
Max. 77 U.S. Gal. (291 Liters)
PRODUCT WEIGHT
B690, N274: 105 lb (48 kg)
B685: 74 lb (34 kg)
SKIRT MOUNTING
Not Available
ELECTRICAL SPECIFICATIONS MODELS B690, N274 ONLY
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
HEATER (OPTIONAL) MODELS B690, N274 ONLY
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
© 2008 Jacuzzi Whirlpool Bath • 14525 Monte Vista Avenue • Chino, CA 91710 • www.jacuzzi.com
INSTALLATION NOTES
Refer to installation instructions included with xture before
beginning installation. Please conrm product availability and
specications before commencing with any installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
#FS07-000 05/08
N274
Riva™ 6 Whirlpool Bath, Right Hand
B690
Riva™ 6 Whirlpool Bath, Left Hand
B685 Riva™ 6 Bath
• Right and Left Hand Drain Location
• Accessories / Hardware:
4 XHTC Jet Trim Kit: #D095
2 X BMH Jet Trim Kit: #J869
Trip-Lever Drain Kit: #X559
Rotary Drain Kit, 26” Cable: #8730
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Riva®6
SOAKER BATH
Electrical Components and Electrical Specifications do not apply
to non-jetted baths.
72"
21"
42"
2"
14" x 4"
11-1/2"
Motor
12" H x 18" L
Service Access
6-7/8"
SIDE VIEW
W
H2''
L
END VIEW
DRAIN/OVERFLOW
A
B
Product Shown: Riva™ 6 Whirlpool Bath
Left Hand Shown Model: B690
* Measurements inside unit represent
cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
