Jacuzzi J-VSP Operating instructions

Jacuzzi J-VSP Programming Guide
IMPORTANT: The following programming can only be completed in the OFF position.
IMPORTANT: Programming speeds must be performed in the ON position.
Changing Programmed Speeds:
Programming Priming Mode:
The Jacuzzi VS Pump is factory programmed at the following
speeds:
• LOW: 1200 RPM
• MED: 2300 RPM
• HIGH: 3075 (1.5 HP) or 3450 (2.5 HP)
To increase or decrease speeds:
1. Select desired speed (LOW, MED, or HIGH)
2. Use the UP or DOWN arrows to change speed in 25 RPM increments.
Features of the J-VSP Priming Mode include:
• Completely programmable run time and RPM
• May be utilized as a specialty timer period for additional circulation and filtration
• Priming mode can be programmed from 2 to 120 minutes, and from 600 RPM to 3075 (1.5 HP) or
3450 (2.5 HP)
To Program:
1. Press MENU until PRIM appears on display.
2. Press ENTER to edit.
3. Press the UP or DOWN arrow to change RPM. When finished, press ENTER.
4. Press UP or DOWN arrow to change minutes. When finished, press ENTER. This will return you
to the Main Menu.

IMPORTANT: To ensure TIMER periods turn on after programming, press the AUTO button
until the display screen changes from MANUAL to AUTO.
Setting Your Clock:
To set your clock:
1. Press MENU twice until CLK appears on the screen. Press ENTER to set time.
IMPORTANT: Moving any timer to MIDNIGHT will turn that timer period OFF. To run a timer
perioid through the night, set two timer periods to avoid timer periods stopping prematurely.
(i.e. Timer 1 -9:00 pm - 12:00 am; Timer 2: 12:15 am to 4:00 am).
Configuration Menu:
2. Use UP or DOWN arrow to set hour. Press ENTER.
3. Use UP or DOWN arrow to set minutes. Press ENTER again and select AM or PM.
4. Press ENTER to accept. The LCD screen will then flash 3 times to indicate the new
setting has been saved. Press MENU to exit to Main Menu.
Setting Timer Periods:
To set timer periods:
1. Press MENU twice until TMRS appears on the screen. Press ENTER to set timers.
2. Timer 1 is preset to begin at 8 am. Use the UP or DOWN arrow to change to desired time.
Press HIGH, MED, or LOW to select desired speed during Timer 1. On the screen, HIGH is
represented by “3”, MED by “2”, and LOW by “1”.
3. Press ENTER to move to the end time of Timer 1. Use the UP or DOWN arrow to change to
desired end time.
4. Timer 2 will now appear on the LCD screen. Repeat steps 1-3.
5. Timer 3 and Timer 4 are preset to OFF. Use the UP or DOWN arrow to activate the time and
repeat steps 2-3 to set timer periods.
TMRS: This menu enables and disables all J-VSP timers and comes preset in
the ON position.
SYS: This menu enables and disables the J-VSP pumps ability to communicate
with any Jacuzzi equipment, such as HS interface adapter. This comes preset in
the OFF position.
DIM: This menu controls the brightness of LCD display and can be adjusted
using the UP and DOWN arrows to desired brightness.
Questions? Contact the Jacuzzi Support Hotline at 1-844-615-8994
