Jade WATERFALL Series User manual

COMPONENTS
A. hook
B. anchors
C. hole
D. screw
BACK SIDE :
FRONT SIDE :
Tools for assembling:
Installation Manual
Cold Water
Hot Water
Mounting bracket
Mounting bracket
AQUAFALL III - Shower Panel
8092
WATERFALL SERIES
Customer Service: 866-333-0555
2. micro jets
7. shower holder with connecter
8. 1.5 m flexible hose
measuring tape level
6. hand shower
1.shower head
64-7/8"
5-7/8"
4. temperature control
5. On/Off
3. diverter valve
(Rain shower/Hand Shower/Middle Jet/Bottom Jet)
(limit button at 38º)
NOTE: PUSH ON THE BUTTON TO GO HIGHER THAN 38º
ATTENTION:
BEFORE INSTALLATION, PLEASE MEASURE
THE EXACT DISTANCE BETWEEN THE 2
BRACKETS ON THE BACKSIDE OF THE PANEL
OR SEE DIMENSIONS ON STEP 1
LISTED/
HOMOLOGUÉ
50628
CSA B 125.1
ASME A 112.18
SHOWER COLUMN/ COLONNE DE DOUCHE
Attention: We recommend using Teflon tape to all pipe connections

WALL
FIXING THE HOOKS ON THE
STEP 1.
Once the right place where to
install the unit has been chosen,
proceed to measure the
distances in between as shown
in the images.
STEP 2.
WATER CONNECTION
Once the hooks have been
installed on the wall, proceed to
make the water connections of
cold-water hose and hot-water
hose in the back of the unit as
shown in the image.
Cold Water
Hot Water
Once, the measurements are
marked on the wall, drill the
correspondents holes on the wall
and install the hooks with the screws
and the anchors supplied in the box.
1-1/4"
HOOK DETAIL
MEASUREMENTS:
A = 35-3/4”
B = 23-1/2”
*C = 84-1/4”
2
AQUAFALL III - Shower Panel
8092
WATERFALL SERIES
Customer Service: 866-333-0555
Attention: Verify all connections for leakage before putting in place
ATT: min 42”
ATT: make sure outlet is min 42” height
(based on suggested heights step 1)
A
B
C
SHOWER HEAD
FLOOR
D
D = 16”
NOTE:
DISTANCE “A” NEVER CHANGES
DISTANCE “C” CAN VARY,ACCORDING TO “B”
DISTANCE “D” IS BASED ON ILLUSTRATION BELOW
3”-3-½” apart.
* illustration only

CONGRATULATIONS! Now your shower column should be ready for use. Enjoy your shower !
If you have any questions, feel free to contact us at the Customer Service: 866-333-0555.
Thank you for choosing Jade.
3
STEP 4.
INSTALLING HAND SHOWER
Once the unit is connected to the
water outlets on the wall, install
the hand shower, as illustration
shows. Make sure to use
washers supplied.
1 YEAR WARRANTY •WARNING: DO NOT USE CORROSIVE CLEANING PRODUCTS
STEP 3.
MOUNTING THE UNIT
Finally, after all previous steps
have been done, the shower
column can be mounted onto the
hooks fixed on the wall by
snapping back brackets (see
page 1) onto wall hooks as
illustration shows.
AQUAFALL III - Shower Panel
8092
WATERFALL SERIES
Customer Service: 866-333-0555
WARNING
PLEASE NOTE JADE IS NOT RESPONSIBLE
FOR ANY DAMAGE DUE TO LEAK.
PLUMBER MUST CHECK FOR LEAK
AT THE TIME OF INSTALLATION.
For better results, use the level
to avoid undesired distortions

DO NOT RETURN THIS PRODUCT TO THE STORE
Jade Customer Service.
STOP
ARRÊT
Please contact Jade before returning any product. If you are missing parts
or experiencing problems with your installation, our Customer Service
Department will be happy to assist you.
NE PAS RETOURNER CE PRODUIT AU MAGASIN
S'il vous plaît contactez Jade avant de retourner tout produit. Si vous manquez
des pièces ou avez des problèmes avec votre installation, notre Service à la
Clientèle sera heureux de vous aider.
Service à la Clientèle.
1-866-333-0555
