CHINESE RANGE
TITAN CHINESE RANGE
MODEL NO. DESCRIPTION
o
jcr-1 one hole chinese range
o jcr-2 two hole chinese range
o jcr-3 three hole chinese range
o jcr-4 four hole chinese range
o jcr-5 five hole chinese range
o jcr-6 six hole chinese range
STANDARD FEATURES
• Heavy gauge stainless steel front, sides, interior angle
structuring, plate shelf, top, sides & pipe legs
• Range top 12 gauge stainless steel angle iron and reinforced
with 10 gauge steel burner chamber
• Heavy gauge steel body structure
• Each burner individually controlled—each hole has individual
main “shut-off” valve
• Heavy-duty stainless steel pipe legs with adjustable feet for
leveling
• Stainless steel tubular rack provided for holding wok covers
• Top-cooling water flow is controlled by independent valve—
water flows through perforated stainless steel tube running
the length of the appliance, beneath 14 gauge stainless steel
front plate shelf
• Gas inlet and water drain location are available (by
specification) at either end on rear of appliance
• Appropriate size wok, cover and drip pan for each hole
• Stainless steel drip pan for each hole
• One faucet kit for every two holes
• Spice tray
• 1-1/4" gas regulator
form #jt0550 ©2008 jade range, llc
JCR-4 (four 20"holes)
TM
TITAN™
DRAIN PIPE 2"
(SPECIFY LEFT OR RIGHT)
1 1/4" GAS
DRIP PANS
1/2" WATER
CONN.
40" [1016]
10 1/2" [267]
20" [508]
30 1/2" [775]
62 3/4" [1594]
1 1/2" [38]
10" [254]
2" [51]
2 1/2" [64]
16" [406]
14 3/4" [375]
4 1/2" [114]
30" [762]
3" [76]
24" [610]
LENGTH
CONNECTION
(SPECIFY LEFT OR RIGHT)
CUSTOM CHINESE RANGE FORMULA
To calculate width of range, add 1" to each hole plus width of hole; add
4" for each side; add 6" between each hole.
Example: For JCR-2 (one 14" hole and one 16" hole), calculate
4 + (14 + 1) + 6 + (16 + 1) + 4 = 46" overall width
PLEASE SPECIFY WHEN ORDERING
• Hole Size(s)
• 3-ring oor Jet Burners o
• Gas Inlet: Right oLeft o
• Water Drain: Right oLeft o
• Manual o or Swing on Faucet o
Ring burners or jet burners to 100,000 BTU/hr. each
H
HStandard hole diameters are: 12", 14", 16", 18", 20", 22" & 24".
Depth is 42" when 24" hole is specified.
JADE RANGE, LLC., A MIDDLEBY COMPANY • 2650 Orbiter Street • Brea, CA 92821 • PHONE: [phone] FAX: [phone]
Note: In line with their policy to continually improve products, Jade reserves the right to change materials and specifications without notice. printed in usa
