JAI CV-M300C User manual

• 2/3”monochromeCCDcamera
• CCIR: 752 (h) x 582 (v) pixels. EIA: 768 (h) x 494 (v) pixels
• Increasedsensitivityandimproveddynamicrange
• Reducedsmearlevel
• High S/N ratio >58 dB
• Interlacedornon-interlacedscanning
• Fieldorframeaccumulationmode
• Internal,externalHD/VDorrandomsynchronization
• Random trigger with edge pre-select, start/stop and pulse width control shutter
• Long time exposure with external VD pulses
• HD/VD input or output TTL or 75 Ohm
• Exposure enable (EEN) and write enable (WEN) output
• Pixelclock outputfor framegrabber friendlyinterface
• Ruggedandcompactconstruction
IndustrialMonocromeCCDCamera
CV-M300
The leading manufacturer of high performance camera solutions

Specifications for CV-M300
SwitchSetting
SHUTTER
TRIGGER
ACCUMM
INTERLACE
GAMMA
GAIN
OFF ON
1
2
3
4
5
6
7
8
Normal < > External
Field < > Frame
Interlace < > Non-interlace
1.0 < > 0.45
Manual < > Auto
1/60 1/100 1/250 1/500 1/1000 1/2000 1/4500 1/10,000
Seconds
< < < < > > > >
< < > > < < > >
< > < > < > < >
ConnectionDescription
HiroseHR10A-10R-12P.Male.
Pin 1 Ground
2 +12V DC
3 Ground
4 Videooutput
5 Ground
6 HDin/(HDoutput)
7 VD input/
(VD/WENoutput)
8 Ground
9 Pixel clock output
(sine)optional**
10 Ground
11 +12V DC
12 Ground
HiroseHR10A-7R-6P.Male.
Pin 1 N.C.
2 EENoutput
3 Ground
4 N.C.
5 Trig.input
6 WENpulseoutput
**Pixel clock output by internal
jumpersetting.
DC-IN/SYNC.
TRIGGER
Spectral Sensitivity
Dimensions
Scanningsystem 625lines 525lines
25frames/sec. 30 frames/sec.
CCDsensor Monochrome2/3"ITCCD
Sensingarea 8.8 mm(h)x 6.6mm(v)
Effectivepixels 752(h)x582(v) 768 (h)x 494(v)
Pixelsinvideooutput 737(h)x575(v) 758(h)x486(v)
Cellsize 11.6 (h) x 11.2 (v) µm 11.6 (h) x 13.5(v) µm
Resolution(horizontal) 560TVlines 570TVlines
Sensitivityonsensor 0.05Lux, Maxgain,50%video
S/Nratio >59 dB (AGCoff,Gamma 1)
Videooutput CompositeVSsignal1.0Vpp,75Ohm
Gamma 0.45–1.0
Gain Manual–Automatic
Potentiometer–AGC
Gain range 0to +18dB
Scanning 2:1interlace–non-interlace
Accumulation Field–frame
Synchronization Int. X-tal. or Ext. HD/VD or random trigger
HDsync. input/output 4Vpp,75 Ohm*
VDsync.input/output 4Vpp,75Ohm*
Triggerinput 4Vpp,75Ohm*
WENoutput(writeenable) 4Vpp,75Ohm*
EEN output (exposure enable) 4Vpp ,75 Ohm*
Pixelclockout(optional) 4Vpp,75Ohm
Triggermodes Normal, Edge pre-select,
PulsewidthcontrolandStart/stop
Triggerinputduration >H to <1000H. (CCIR: 64 µsec. to 1 msec.,
EIA: 63.5 µsec. to 1 msec.)
Internaland edgepre-select 1/50, 1/100,1/250,1/500, 1/1000,
1/2000,1/4500,1/10,000sec.
Pulsewidthcontrol 1H to 251H
Start/stop 1/77to1/10,000sec.
Longtime exposure 1 field to ∞∞
∞∞
∞
Durationbetweenext. VD pulses
Operatingtemperature -5°Cto+45°C
Humidity 20 –80%non-condensing
Power 12V DC ±10%.3.6 W
Lensmount C-mount
Dimensions 40 x50x80 mm (HxWxD)
Weight 230g
* HD sync., VD sync./(Trigger) input or output by internal jumpers.
Factory setting: HD/VD input. Inputs TTL or 75 Ohm terminated by
internaljumpers. Factory setting:75Ohm terminated.
Specifications CV-M300C CV-M300E
Company and product names mentioned in this datasheet are trademarks or registered trademarks of theirrespective owners. JAI A.S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
31010442.05.01.2000
CV-M300C2/3”IndustrialMonochromeCamera.CCIR
CV-M300E2/3”IndustrialMonochromeCamera.EIA
OrderingInformation
Topview
26
550 4-M3
Frontview 50
(1.97)
40
(1.57)
C-mount
Sideview
80 12.7
26
13
Bottomview
4-M3
34 4-M3
30
14
30 U1/4-20
ø6
Rearview
