JAM Pedals Delay Llama User manual

v
Delay Llama
The Delay Llama is a tone machine
that will become an indispensable
part of your sound adding warmth
and depth through organic repeats
which seamlessly integrate into
your playing, courtesy of its BBD
chips, faithful reproductions of the
Panasonic MN3205.
Its straight-forward layout is
addressed to delay users who are
looking to elegantly enhance their
hard-earned tone, similarly to how
a tape-echo machine would with no
frills.
The mk.3 version expands on the
utility value of this modern classic,
while retaining the form factor and
ease of use, by introducing Tap
Tempo with subdivisions and Hold
(self oscillation) functions.
The Delay Llama comes with 600ms
max. delay time, and can also be
used with bass guitars!
CONTROLS
yT: Delay Time
yR: Amount of Repeats
yL: Delay Level on top of dry signal
yTOGGLE-SWITCH: Tap Tempo
Subdivisions (top to bottom: 8th,
quarters, dotted 8th)
yInternal trimmer (blue rectangle)
to set the max. number of repeats
yInternal trimmer to set the trails'
fade out time (only applicable
when the pedal is set in buffered
bypass mode, read below)
FOOTSWITCHES
yLEFT: Turns the pedal ON / OFF
yTAP:
• MOMENTARY minimum 2
consecutive stomps: Tap Tempo
• LATCHING engages HOLD
(oscillation) for as long as it is
pressed
If you slap this
Llama, it will slap
back!

BYPASS MODE SELECTION
Your pedal comes pre-set in true
bypass mode.
If you wish to change it to buffered
bypass mode so your trails will
fade out naturally after you have
disengaged the pedal:
yremove the power cable from
your pedal
ypress and hold the TAP
footswitch
yinsert the power cable
yrelease after you see the left LED
blink 3 times
To set your pedal back to true
bypass mode, repeat above steps.
The LED will now blink 2 times to
indicate successful true bypass
mode operation.
INTERNAL TRIMMERS LOCATION
1. Internal trimmer to set the trails'
fade out time
2. Internal trimmer to set the max.
number of repeats (multi-turn)
SPECIFICATIONS
yTrue or Buffered (Trails) Bypass
yWorks with 9V DC adaptor
(tip-negative)
yPower consumption: 120 mA
yDimensions (jacks, pots etc
included): 7.5 x 12 x 5.6 cm /
2.9 x 4.7 x 2.2 inches
yWeight: 280g / 0.6 lbs.
