PureWhite™ LED
Light Fixture
Installation and
Operation Guide

PUREWHITE POOL AND SPA LED LIGHT FIXTURE
Available in 120VAC and 12VAC models
PureWhite Pool and Spa LED light xtures offer superior, bright white illumination for your
pool. This owner’s manual contains important information on installing and using your
new PureWhite Pool and Spa LED light xture. Read and follow all instructions contained
in this manual. Please keep it in a safe place for future reference.
Most states and local codes regulate the construction, installation, and operation of public
pools and spas, and the construction of residential pools and spas. It is important to
comply with these codes, many of which directly regulate the installation and use of this
product. Consult your local building and health codes for more information.
Read and follow all warning notices and instructions contained in this guide before
installing or using the product. Severe injury, death or property damage may result if the
warnings and instructions contained in this manual are not followed.
INSTALLER NOTICE: This Installation and Operation Guide contains important information
about this LED light. Be sure to give this guide to the owner and/or operator of the LED
light for reference regarding the proper installation, operation and use of this product.
DANGER! FAILURE TO PROPERLY INSTALL AND USE THIS PRODUCT CAN
RESULT IN SERIOUS BODILY INJURY OR DEATH.
WARNING! Comply with all related codes for the installation and
use of this product.
WARNING! Before installing or using this light, read all warnings and
instructions contained in this manual.
pg 1
PUREWHITE POOL AND SPA LED LIGHT FIXTURE NICHE COMPATIBILITY
For LPL-F1W, LPL-F3W and LPL-F5W Series ONLY
Pentair®: 78210400, 78210500, 78210600,
78210700, 79206700
Hayward®: SP0604C, SP0600U
Jandy®: PLNICLRG, SSNICLRG1R, SSNICLRG1S
Jacuzzi®: 94131234
For LPL-S1W ONLY
Pentair®: 78244200, 78244300,
78243200, 78243300, 79206600
Hayward®: SP0606C, SP0610C
Jandy®: PLNICSM, SSNICSM1R,
SSNICSM1S

Always disconnect power to the pool light at the circuit breaker panel before attempting
to service the light. Failure to do so could result in serious injury or
WARNING! Risk of electrical shock or electrocution
Do not, under any circumstances, splice wire underwater or behind the light niche during
the installation of this light.
death due to electrical shock. Installation must be performed in accordance with all
applicable federal, state & local installation codes and ordinances by a licensed or
certied electrician or a qualied pool professional. Improper installation may result in
death or serious injury to pool users, installers or others due to electrical shock. In addition,
improper installation may cause property damage. This device is not intended for use in
anything other than in-ground pools.
PureWhite pool and spa LED lights are operated through the light’s switch. No special
controller or interface is required. Use a junction box to connect and operate multiple
lights with a single switch.
The following steps detail installation of the PureWhite LED light xture into a new pool
or spa construction. Read this section in its entirety prior to beginning any installation.
WARNING! Important Safety Information for Light Installation
INSTALLER NOTICE: This light’s external cord cannot be replaced and should be handled
with care. Any damage to this external cord necessitates replacing the light.
INSTALLER NOTICE: A licensed electrician must complete the following steps prior to
installation of this light in a new pool or spa construction.
WARNING! Conrm that the pool or spa meets all current National Electrical Code
(N.E.C.) Article 680-22 requirements and any applicable local codes or ordinances. The
pg 2
OPERATION FOR 120VAC AND 12VAC
PUREWHITE POOL AND SPA LED LIGHT FIXTURES
PUREWHITE POOL AND SPA LED LIGHT FIXTURE INSTALLATION
(NEW POOL OR SPA CONSTRUCTION)

4" Min.
48" Min.
18" Min. Top of Lens
to Water Level
8" Min. Junction Box
or Low Voltage
Transformer to the
Max. Water Level of Pool
To: GFCI, Circuit Breaker,
and Power Source
Rigid Conduit
#8 AWG Ground
Connector Bonding
Lug is Located at
Rear of Niche
Coil 4 ft. of Power
Cord Around Fixture
Concrete Must Be Cut
Back Around Niche to
Allow for a Compacted
Plaster Seal
1. Feed the xture cord through the conduit to the junction box. Be sure to leave at
least four (4) feet of cord at base of the xture to coil around the light to ensure ease of
servicing once the pool is lled; reference Figure 1.
2. At the junction box, cut the cord. Be sure to leave at least six (6) inches of cord for
making connections.
3. Carefully strip the outer cord jacket to expose six (6) inches of the underlying three
insulated wires.
4. Connect these three (3) wires to their corresponding junction box circuit wires and
secure the junction box cover in place.
Figure 1.
NEW CONSTRUCTION INSTALLATION STEPS
(ONCE ALL ELECTRICAL REQUIREMENTS ARE MET)
pg 3
electrical system must be installed by a licensed or certied electrician to meet or exceed those
requirements prior to installation of the light. This includes, but is not limited to, the following
National Electrical Code requirements:
• Installation of a ground fault circuit interrupter (GFCI) for line voltage models on the lighting
circuit with an appropriately rated circuit breaker.
• A junction box or low voltage transformer is located at least 8 inches above the maximum
pool water level and at least 48 inches from the pool edge; reference Figure 1.
• Proper electrical bonding of the light xture and all metal items within 5 feet of the pool
• Proper wet niche installation with the top edge of the underwater light’s lens at least 18
inches below the surface of the water in the pool and not more than 20” in Canada; reference
Figure 1.
• Proper electrical wet niche bonding and grounding using the #8 AWG ground connector at the
rear of the niche; reference Figure 1.

This special pilot screw secures and electrically grounds the xture to the mounting ring
and wet niche. Failure to install the stainless steel pilot screw provided could create an
electrical shock hazard, resulting in death or serious injury to pool users, installers or others.
5. Using the stainless steel pilot screw provided, install the PureWhite LED light xture
assembly into the niche, carefully tightening the pilot screw. (reference Figure 1)
6. Fill the pool to completely submerge the light prior to operating the light. Do not
operate light out of water, this may cause damage to the light.
7. Make a nal check to conrm proper light operation by switching “on” the main switch or
circuit breaker and the light switch. The light should illuminate when power is switched
“on”. If the light is not operating, go back to Step 1 to recheck each installation step for
proper completion.
damage to the light. If the light is operating without being fully submerged in water, the
light’s circuitry will automatically shut down for a cooling period before powering back on
within 10 mintues to prevent damage to the light.
WARNING! Do not operate this light for more than two minutes without
completely submerging it in water. Failure to do so can result in permanent
WARNING! Use only the stainless steel pilot screw provided with this
underwater light.
PUREWHITE POOL AND SPA LED LIGHT FIXTURE INSTALLATION
(EXISTING POOL OR SPA)
Installation of this light must be completed by a licensed or certied electrician or a qualied
pool professional in accordance with the National Electrical Code and any applicable local
codes and ordinances. Improper installation may result in death or serious injury to pool users,
installers or others due to electrical shock. In addition, improper installation may cause property
damage.
Always disconnect power to the pool light at the circuit breaker panel before attempting to
service the light. Failure to do so could result in serious injury or death due to electrical shock.
Conrm that the pool or spa meets the current National Electrical Code requirements and any
applicable local codes or ordinances. The electrical system must be installed by a licensed or
certied electrician to meet or exceed those requirements prior to installation of the light. This
includes, but is not limited to, the following National Electrical Code requirements:
Danger - Risk of electrical shock or electrocution!
pg 4

• Installation of a ground fault circuit interrupter (GFCI) for line voltage models on the lighting
circuit with an appropriately rated circuit breaker.
• A junction box or low voltage transformer is located at least 8 inches above the maximum
pool water level and at least 48 inches from the pool edge; reference Figure 1.
• Proper electrical bonding of the light xture and all metal items within 5 feet
of the pool.
• Proper wet niche installation with the top edge of the underwater light’s lens at least 18
inches below the surface of the water in the pool and not more than 20” in Canada; reference
Figure 1.
• Proper electrical wet niche bonding and grounding using the #8 AWG ground connector at the
rear of the niche; reference Figure 1.
• The wet niche is properly electrically bonded and grounded via the No. 8 AWG ground
connector located at the rear of the niche; see Figure 1.
The following steps detail installation of the PureWhite LED light xture into an existing
pool or spa. Read this section in its entirety prior to beginning any installation.
Failure to bring the pool or spa electrical system up to current code requirements prior to
light installation may create an electrical shock hazard resulting in death or serious injury
to users, installers, or others due to electrical shock, and may also cause property damage.
WARNING! Pool or spa electrical system must meeting current
code requirements.
4" Min.
48" Min.
18" Min. Top of Lens
to Water Level
8" Min. Junction Box
or Low Voltage
Transformer to the
Max. Water Level of Pool
To: GFCI, Circuit Breaker,
and Power Source
Rigid Conduit
#8 AWG Ground
Connector Bonding
Lug is Located at
Rear of Niche
Coil 4 ft. of Power
Cord Around Fixture
Concrete Must Be Cut
Back Around Niche to
Allow for a Compacted
Plaster Seal
Figure 1.
pg 5
EXISTING CONSTRUCTION INSTALLATION STEPS
(ONCE ALL ELECTRICAL REQUIREMENTS ARE MET)

1. Disconnect the main electrical switch or circuit breaker and the switch which operates
the installed light.
2. Remove the existing light per the original manufacturer’s instructions. Place the light
xture on the deck. 3. Leaving the light xture on the deck, cut the light cord. Be sure to
leave at least six (6) inches of cord in order to connect it to the replacement light cord.
Discard the light xture.
4. Remove the existing cord by pulling it up out of the niche and onto the deck. Carefully
strip the outer cord jacket to expose six (6) inches of the underlying three insulated wires.
5. Tape the three existing light wires to the replacement light cord with electrical insulating
tape. Avoid wrapping too much tape around the cords. Otherwise, the thickness will be too
great for the cord to be able to be pulled through the conduit to the junction box.
6. After removing the junction box cover, disconnect the light xture wires. Then, pull the
cord through the conduit until it is visible in the junction box conduit. Remove the tape
from the cords and separate the wires.
7. Carefully strip the outer cord jacket from the new light cord to expose six (6) inches of
the underlying three insulated wires.
8. Connect these three (3) wires to their corresponding junction box circuit wires and
secure the junction box cover in place.
9. Be sure to leave at least four (4) feet of cord at base of the xture to coil around the light
to ensure ease of servicing; reference Figure 1.
10. Install the PureWhite light xture into the niche.
11. Using the stainless steel pilot screw provided, install the PureWhite LED light xture
assembly into the niche, carefully tightening the pilot screw. (reference Figure 1)
12. Make a nal check to conrm proper light operation by switching “on” the main switch
or circuit breaker and the light switch. The light should illuminate when power is switched
“on”. If the light is not operating, go back to Step 1 to recheck each installation step for
proper completion.
This special pilot screw secures and electrically grounds the xture to the mounting ring
and wet niche. Failure to install the stainless steel pilot screw provided could create an
electrical shock hazard, resulting in death or serious injury to pool users, installers or others.
WARNING! Use only the stainless steel screw provided with this underwater light.
INSTALLER NOTICE: This light’s external cord cannot be replaced and should be handled
with care. Any damage to this external cord necessitates replacing the light.
pg 6

© 2012 J&J Electronics, Inc. All rights reserved. PureWhite™ is a trademark of and manufactured by J&J Electronics, Inc. All registered and trademarked brands and names are
the property of their respective companies. REF. 120712
J&J Electronics | Irvine, California
www.jandjpoolspa.com
3-YEAR LIMITED WARRANTY
(For LPL-F1W, LPL-F3W, LPL-F5W and LPL-S1C Series ONLY)
J&J Electronics, Inc. (“J&J”) warrants the above-referenced model numbers of PureWhite In-ground Pool or Spa LED Light Fixture (the
“Product”) to be free from defects in material and workmanship, under normal use, conditions and service, for a period of three (3) years
from the original date of purchase, subject to the terms specied herein. If during the rst twenty-four (24) months of the warranty period,
the Product fails to operate due to a defect in material or workmanship, J&J will, at its option, repair or replace the Product at no charge. If
during months twenty-ve (25) through thirty-six (36), the Product fails to operate due to a defect in material or workmanship, J&J will grant
the purchaser a pro-rated credit1 for purchase of a J&J PureWhite LED In-ground Pool or Spa Light Fixture, as the purchaser’s sole remedy.
Pro-rated credit is calculated as follows:
Product Price ($)2 x Unexpired warranty period (months)
Total Warranty Period (months)
1 Credit is only redeemable by the purchaser through J&J and will be applied against the current MSRP of the product purchased.
2 Product Price is the price at which the product was purchased as stated on the purchaser’s invoice and may not exceed the MSRP for the product at the time
of the purchase.
TERMS AND CONDITIONS
This warranty is available to the original purchaser of the Product only. This warranty applies only when Products are properly installed in an
in-ground pool; any other use voids the warranty. Products must be used in lighting equipment designed and approved for the application
and in environmental conditions within the normal specied operating range. This warranty does not apply to any abnormal use of Product,
use in violation of any applicable standard, code or instructions for use in installations including those contained in the latest National
Electrical Code (NEC), the Standards for Safety of Underwriters Laboratory, Inc. (UL), Standards for the American National Standards Institute
(ANSI). This warranty will not apply in the event of conditions demonstrating abnormal use or stress, under/over voltage/current conditions,
excessive switching cycles or operating hours or outside the recommended operating conditions. This warranty does not apply to color shifts
or dimming caused by emissions. (LED color shifts and dimming occur normally over time.) This warranty does not cover damage occurring
during shipment, damage or failure resulting from alteration, accident, acts of God, theft, abuse, negligent installation, improper service,
unauthorized repairs or where adequate care has not been taken to prevent damage to the Product. Tampering with any internal component
of this Product will void the warranty.
This warranty gives you specic rights. You may have other rights that vary according to the laws of your state.
LIMITATION OF LIABILITY
THE FOREGOING SHALL CONSTITUTE THE EXCLUSIVE REMEDY OF THE PURCHASER AND IS IN LIEU OF ALL OTHER WARRANTIES,
WHETHER EXPRESS OR IMPLIED, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND
ALL WARRANTIES ARISING FROM COURSE OF DEALING OR USAGE OR TRADE. THE LIABILITY OF J&J UNDER THIS WARRANTY SHALL BE
LIMITED TO THE REPLACEMENT, REPAIR OR PRO-RATED CREDIT OF THE PRODUCT AS STATED HEREIN. J&J IS NOT RESPONSIBLE FOR
SHIPPING OR TRANSPORTATION COSTS RELATED TO OBTAINING WARRANTY SERVICE. IN NO EVENT SHALL J&J BE LIABLE FOR ANY OTHER
COSTS OR DAMAGES, INCLUDING LOST PROFITS OR REVENUES, LABOR CHARGES OR FOR ANY INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES.
To obtain warranty service, retain the failed Product, retain the installation invoice showing product purchase price and contact
J&J Electronics, Inc. at 800.735.4553 ext. 242 or [e-mail]. As of 4/12/2012
